2.5.2 Connecting Low DC Power
14
2
1 3
Positive Terminal
1
Negative Terminal
2
Surge Ground Terminal
3
Braided Ground Cable
4
Figure 2.5 Terminal Block Wiring - Single DC Power Supply Inputs
2 2
1 3 1
Positive Terminal
1
Negative Terminal
2
Surge Ground Terminal
3
4
4
