Summary of Contents for Firstech BLADE Series
- Page 2 FTI-CDPS - Notas de preparación y cobertura del vehículo Make Model Year Install Lights Hood I/O Changes DL-CH7 Park / Auto Green White/Blue 1500 PTS Diesel 2013-17 Type 1 OBD-II Type B Firmware: Los vehículos cubiertos usan BLADE-AL (DL) -CH7, confirman la aplicación, modulan el flash y actualizan el controlador firmware antes de instalar.
-
Page 3: Headlight Switch
FTI-CDP1 - DL-CH7 - Type 1 2013-17 RAM 1500 PTS Diesel Diesel WTS BLADE Techfeedtree Set feature option 4-10-4 *Not required OBD-II connector PTS button ENGINE START STOP Headlight switch Type A *Not required C5 - Ignition 26 25 26 25 pink/white C1 - Hood pin ( - ) violet/blue... -
Page 4: Install Guide
ALL IN ONE INSTALL GUIDE CHRYSLER/DODGE/JEEP/RAM Patent No. US 8,856,780 CA 2759622 COM-BLADE-AL(DL)-CH7-EN 20201117 Doc. No.: ##72396## CARTRIDGE INSTALLATION Slide cartridge into unit. Notice Ready for Module Programming button under LED. Procedure. MODULE PROGRAMMING PROCEDURE - WITH KLON - 1 OF 2 Close driver door. - Page 5 ALL IN ONE INSTALL GUIDE CHRYSLER/DODGE/JEEP/RAM Patent No. US 8,856,780 CA 2759622 MODULE PROGRAMMING PROCEDURE - WITH KLON - 2 OF 2 Close driver door. Remove remote starter from vehicle. Re-open driver door to wake up data bus. Connect remote starter to computer.
