INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
EXPEDITION I WOOD INSERT
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBER:
EXPEDITION-I
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
R
If the information in these instructions
is not followed exactly, a fire may result
causing property damage, personal injury,
or death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over fire - If heater or chimney connector glows,
you are over firing. Over firing will void your warranty.
• Comply with all minimum clearances to combustibles
as specified.
Failure to comply may cause house fire.
Hot glass and appliance will cause burns.
• Do not touch glass until it is cooled
• Use leather gloves when reloading fuel
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as appliance.
• Alert
children
high temperatures
• High temperatures may ignite clothing or other
flammable materials.
• Keep
clothing,
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this manual,
please contact your dealer or visit www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre revendeur ou
visitez www.quadrafire.com
7094-802E
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
and
adults
to
furniture,
draperies
WARNING
hazards
of
and
other
11/23
Advertisement
Table of Contents
Related Manuals for Quadra-Fire EXPEDITION-I
Summary of Contents for Quadra-Fire EXPEDITION-I
- Page 1 • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. • Do not over fire - If heater or chimney connector glows, MODEL NUMBER: you are over firing. Over firing will void your warranty. • Comply with all minimum clearances to combustibles EXPEDITION-I as specified. Failure to comply may cause house fire. WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down.
-
Page 2: Table Of Contents
D. Venting Systems ..............14 E. Inspections ................14 F. Chimney Height / Rise and Run ..........14 G. Securing Chimney Components ..........14 H. Larger Chimneys..............15 I. Masonry Chimney..............15 J. Metal Heat Circulating Masonry..........16 K. Prefabricated Metal Chimney ..........16 L. Ovalizing Round Stainless Steel Liners........17 M. Altering the Fireplace .............17 Quadra-Fire is a registered trademark of Hearth & Home Technologies. 7094-802E 11/23... -
Page 3: Important Safety Information
Important Safety Information A. Insert Safety Certification C. BTU & Efficiency Specifications Mode Number: EXPEDITION-I EPA Certification #: 292-21 Laboratory: PFS TECO EPA Certified Emissions: 1.9 grams per hour Report Number: 21-670 *LHV Tested Efficiency: 70% Solid Fuel Type, Listed **HHV Tested Efficiency: 65%... -
Page 4: Mobile Home Approved (Usa Only)
D. Mobile Home Approved (USA only) K. California - Prop65 • This appliance is approved for mobile home installations WARNING when not installed in a sleeping room and when an outside combustion air inlet is provided. This product and the fuels used to operate this product (wood), and the products of combustion of such fuels, can expose you to chemicals • The structural integrity of the mobile home floor, ceiling, including carbon black, which is known to the State of California to... -
Page 5: Getting Started
Getting Started A. Design and Installation Considerations B. Draft Draft is the pressure difference needed to vent appliances CAUTION successfully. When a appliance is drafting successfully, all combustion byproducts are exiting the home through Check building codes prior to installation. the chimney. • Installation MUST comply with local, regional, state Considerations for successful draft include: and national codes and regulations. -
Page 6: Negative Pressure
C. Negative Pressure D. Tools And Supplies Needed Before beginning the installation be sure the following tools WARNING and building supplies are available: - Reciprocating saw Asphyxiation Risk. - Framing material • Negative pressure can cause spillage - Pliers combustion fumes, soot - High temp caulking material carbon monoxide. -
Page 7: Install Checklist
F. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjuction with, not instead of, the instructions contained in this installation manual. _________________________________________________________________________________ Customer: ______________________________________________________________________________ Date Installed: ______________________________________________________________________________ Lot / Address: ________________________________________________________________________ Location of Appliance:... -
Page 8: Dimensions And Clearances
Dimensions and Clearances A. Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 42-3/4” (1086 mm) 26-1/2” 32-1/2” (826 mm) (672 mm) 24” (610 mm) 31” 15-1/4” (787 mm) (388 mm) 9-3/8” 25” (237 mm) (635 mm) 3-1/8” 17-7/8” (455 mm) (79 mm) Figure 8.1 - Front View with Medium Flat Surround (SP1-4331) Figure 8.4 - Top View with Cast Surround 26-1/2”... - Page 9 12-1/8” 11-3/8” (309 mm) (290 mm) 19-3/4” 19-3/4” (502 mm) (502 mm) 19” 19” (483 mm) (483 mm) Figure 9.1 - Side View with Flat Surround Figure 9.4 - Side View with Cast Surround 11-1/2” 12-1/4” (292 mm) (311 mm) 21-3/8” 21-3/8” (544 mm) (544 mm) Figure 9.2 - Side View with Flat Surround and Optional 15 Degree Figure 9.5 - Side View with Cast Surround and Optional 15 Degree Adapter (DV-6DLR-E15ADSS) Adapter (DV-6DLR-E15ADSS) 13-1/4”...
-
Page 10: Clearances To Combustibles
B. Clearances to Combustibles United States and Canada (UL and ULC) In Canada a full length 6 inch (152mm) S635 flue liner required as per ULC S628. In USA a minimum 5 ft length (1.82m), 6 inch (152mm) diameter flue liner is required as per UL 1482. TOP TRIM (3/4”... - Page 11 How to Determine if Alternate Floor Protection Materials CAUTION are Acceptable All floor protection must be noncombustible (i.e. metals, brick, Hearth and Home Technologies does not recommend adhesive based vinyl flooring due to thermal expansion. Floating-style stone, mineral fiber boards, etc.). Any organic materials (i.e. flooring (LVP - luxury vinyl plank or LVT – luxury vinyl tile) can be plastics, wood paper products, etc.) are combustible and used, but it will reach temperatures up to 110 °F in a room with must not be used. The floor protection specified includes ambient temperature of 70 °F. Consult flooring specifications to some form of thermal designation such as R-value (thermal...
-
Page 12: Chimney Systems
Chimney Systems A. Locating Your Stove & Chimney Location of the appliance and chimney will affect performance. As shown in Figure 12.1 the chimney should: • Install through the warm space enclosed by the building envelope. This helps to produce more draft, especially during lighting and die down of the fire. • Penetrate the highest part of the roof. This minimizes the affects of wind turbulence and down drafts. • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. • Locate termination cap away from trees, adjacent structures, uneven roof lines and other obstructions. Your local dealer is the expert in your geographic area and can usually make suggestions or discover solutions that will easily correct your flue problem. Recommended Recommended Location Location Marginal Location Location Recommended Location NOT Recommended Windward Outside Air Kit Termination Cap Leeward Multi-level Roofs Figure 12.1... -
Page 13: Chimney Termination Requirements
B. Chimney Termination Requirements NOTICE: Locating the appliance in a basement or in Follow manufacturer’s instructions for clearance, securing a location of considerable air movement can cause flashing and terminating the chimney (Figure 13.1 and intermittent smoke spillage from appliance. Do not locate appliance near Figure 13.2). •... -
Page 14: Venting Systems
D. Venting Systems WARNING Chimney Connector - It is also known as flue pipe or stove pipe. It must be 6 inches (152mm) minimum diameter Asphyxiation Risk. stainless steel connector pipe. • DO NOT CONNECT THIS Appliance Chimney - The chimney can be new or existing, masonry TO A CHIMNEY FLUE SERVICING or prefabricated and must meet the following minimum ANOTHER APPLIANCE. -
Page 15: Larger Chimneys
H. Larger Chimneys • Cross-sectional area shall conform to NFPA 211-2006 Section 12.4.5.1. It is recommended that chimneys with larger diameters than • Should be lined with a 6 inch (152mm) stainless steel flue 6 inches (152mm) be relined. An oversized flue can affect liner to improve performance and reduce creosote build- draft and impair performance and will allow increased build- up of creosote. • An equivalent liner must be a listed chimney liner system or other approved material. NOTICE: Check with your local building authorities and/ or consult the National Fire Protection Association •... -
Page 16: Metal Heat Circulating Masonry
J. Metal Heat Circulating Masonry NOTE: Refer to chimney liner manufacturer for recommendations on supporting the liner. Installation into This insert conforms with the safety standard UL-1482 and fireplaces without a permit will void the listing. ULC S628 (Canada) in all respects and is approved to UL & ULC safety standards for installation and use within a fireplace with masonry chimney, in accordance with NFPA Minimum Opening Dimensions Inches Millimeters 211, with a direct flue collar connection. -
Page 17: Ovalizing Round Stainless Steel Liners
L. Ovalizing Round Stainless Steel Liners WARNING Ovalizing round stainless steel liners to accommodate the liner passing through the damper region of a fireplace is an Asphyxiation Risk. allowable and acceptable practice. DO NOT connect this appliance to a chimney flue servicing another appliance or to any air Ensure that the ovalization is minimized to the extent distribution duct or system. required to fit through the damper. This may allow flue gases to enter M. Altering the Fireplace the house. -
Page 18: Appliance Set-Up
Appliance Set-Up A. Outside Air Kit A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is consumed by the fire must be replaced. Air is replaced via air leakage around OUTSIDE AIR PLATE windows and under doors. In homes that have tightly sealed doors and windows, an outside air source is needed. Installation Instructions 1. Ensure existing access hole in fireplace will not be COVER PLATE covered by the outer can. Existing outside air intake hole may be under, at the rear, or side of outer can. Outside... -
Page 19: Stove Pipe Or Liner To Flue Collar
C. Optional Offset Adapter Optional use of a Simpson Duravent 15° Universal Elbow Part Number 4615 may be purchased directly through your local Simpson Duravent Pipe Distributor or from your local Quadra-Fire dealer, Part Number DV-6DLR-E15ADSS. 5/16 Bolts Figure 19.2 shows a vertical installation and also how to create an optional 30° elbow installation. The 15° elbow may be secured directly to the flue collar. -
Page 20: Power Cord
E. Power Cord The power cord is shipped assembled to the appliance. You may route the power cord either to the left or right side depending on your configuration for power source (Figure 20.1). NOTE: Power cord is 96 inches in length. Figure 20.2 Figure 20.1 F. -
Page 21: Flat Surround With Trim Kit
G. Flat Surround with Trim Kit 5. Install two steel springs at the top on each side and between the flat surround and the assembled trim kit as Overall Part shown in Figure 21.3 Trim Kit Dimensions Number Small Size 38” x 28” SP1-3828 TRIMKIT-3828-NL Standard Size 43” x 31” SP1-4331 TRIMKIT-4331-NL 1. -
Page 22: Standard Surround & Cast Trim Kit
H. Standard Surround & Cast Trim Kit 6. Place the cast footers under the metal sides aligning the top and bottom holes in the cast footers and metal sides. Overall Dimensions Part Number 7. The 9 mounting clips are shipped in one long strip. Hand Standard Size 43” x 31” CT1-4331 break apart or use pliers. -
Page 23: Mobile Home Installation
Mobile Home Installation, Approved for USA Installation ONLY! You must use a Quadra-Fire Outside Air Kit Part #: Spark Arrestor Cap OAK-ACC 1. An outside air inlet must be provided for combustion and must remain clear of leaves, debris, ice and/or snow. It Storm Collar must be unrestricted while unit is in use to prevent room... -
Page 24: Reference Materials
Reference Materials A. Wiring Harness Service Part: SRV7000-891 Five Setting Switch Switch Snap Disc Power Cord Blower Figure 24.1 B. Brick Diagram Service Part: SRV7094-022 Figure 24.2 Placement Dimensions Qty Required 9” x 4.5” x 1.25” 7” x 4.5” x 1.25” 9” x 2” x 1.25” 7094-802E 11/23... -
Page 25: Service And Maintenance Log
C. Service and Maintenance Log Date of Service Performed By Description of Service 7094-802E 11/23... - Page 26 Date of Service Performed By Description of Service 7094-802E 11/23...
- Page 27 7094-802E 11/23...
- Page 28 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
