Toshiba Satellite M45-S355 Specifications

Satellite®
Model Name Description
Satellite M45-S355 Intel ® Pentium® M processor 750, 1024MB DDR SDRAM, 100GB HDD (5400 RPM),
15.4" WXGA, DVD SuperMulti Double Layer, 802.11b/g, Microsoft® Windows® XP Home
(SP2), TOSHIBA® Express Media Player, i.LINK® 1394, Bridge Media Adapter
Satellite M45-S3551 Intel ® Pentium® M processor 750, 1024MB DDR SDRAM, 100GB HDD (5400 RPM),
15.4" WXGA, DVD SuperMulti Double Layer, 802.11b/g, Microsoft® Windows® XP Pro
(SP2), TOSHIBA® Express Media Player, i.LINK® 1394, Bridge Media Adapter
System Characteristics
Operating System
•
Microsoft® Windows® XP Home (SP2) (S355)
•
Microsoft Windows XP Professional (SP2) (S3551)
•
TOSHIBA® Express Media Player for quick access to CD, DVD
playback
2
CPU
Intel® Centrino™ Mobile Technology featuring
•
Intel Pentium® M processor 750 [1.86GHz, 2MB L2 cache,
533MHz FSB]
•
Mobile Intel 915GM Express Chipset
•
Intel PRO/Wireless 2200BG (802.11b/g)
4
Memory
•
1024MB (Min)/2048MB (Max with two slots occupied) PC2700
DDR333 SDRAM 2.5V SODIMM Memory modules
•
2 memory slots (both memory slots may be occupied at the time
of purchase); 2 user upgradeable SODIMM slots.
Mass Storage
•
5
Hard Disk Drives
100GB (5400RPM), Enhanced IDE (ATA-6) hard
o
disk drive; 9.5mm height; user removable)
•
Optical Disk Drive
Fixed Bay DVD SuperMulti Double Layer drive
o
Maximum Speed
o
CD-ROM(24x:read), CD-R(24x:write), CD-
RW(10x:write), DVD-ROM(8x:read), DVD-
R(8x:write), DVD-RW(4x:write),
DVD+R(8x:write), DVD+R [Double Layer]
(2.4x:read/write),DVD+RW(4x:write), DVD-
RAM(3x:write)
ODD Interface – Enhanced IDE
o
6
Display
•
15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280 x 800 native resolution (WXGA)
•
Contrast 400:1
•
Brightness Control – FN+F6/ F7
•
Maximum brightness: 200 cd/m
Graphics
•
Intel® Graphics Media Accelerator 900, 10-128MB Internal
(UMA) shared video memory
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm
o
keyboard height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's
o
Guide for more information
Windows Key Function
o
Application Key Function
o
•
TouchPad™ (scroll with help of driver)
•
Internet Button
•
CD Control Button
Express Media Player button, Skip Previous, Skip
o
Next, Play/Pause, Stop
Expandability
•
2 available expansion memory slots (both slots may be
occupied at time of purchase)
•
1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
•
Bridge Media Adapter (Secure Digital®, Memory Stick™,
Memory Stick PRO™, Multi Media Card, SmartMedia, xD
Picture Card [shared slots])
© Copyright 2005 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
3
2
Satellite M45 Series Revision v1.04 3-May-05 DMD Source: CB V1.30
Communications
•
Integrated V.92 modem
•
Marvell® 10BASE-T/100BASE-TX Ethernet
•
Integrated Intel® Pro/Wireless LAN 2200BG (802.11BG)
Ports and Slots
•
RGB (monitor out port)
•
3 Universal Serial Bus (USB) ports
•
TV-Out (S-Video)
•
RJ11 modem port
•
RJ45 LAN port
•
7
i.LINK™ IEEE 1394
Physical Description
•
Dimensions (WxDxH[front/back]): 14.17" (360mm)x10.57"
(269mm)x1.14" (29mm)/1.43" (36.2mm) without feet
•
8
Weight : starting at 6.0 lbs. (2.72kg) – 6.7 lbs (3.0kg)
•
Switch: Power, Wireless Communication
•
LED Indicators: Power (common with Power/System Sleep
Status), DC-IN, Primary HDD access, Power Save mode (with
ACPI-OS, common to Power), Caps Lock, Arrow mode,
Numeric mode, Main Battery Charging Status, System
Sleep/Suspend Status (common with Power/System Sleep
Status), Wireless Communication (for Wireless LAN), SD Card,
System sleep status (shared with Power)
Sound
•
Analog Devices, Inc. AD1981B Software Sound, AC'97 Rev2.2
Compatible
•
16-bit stereo; Built-in stereo speakers
•
Direct 3D Sound; DirectSound, Direct Music, MIDI (playback)
Support
•
Audio Ports: External Microphone (monoaural), Headphone
(stereo), Sound Volume (by dial)
Power Supply
•
75W (15V x 5A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•
Dimensions (WxHxD): 5.35" (136mm) x 2.09" (53mm) x 1.18"
(30mm)
•
9
Weight : starting at .88 lbs (400g)
10
Battery
•
6-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)
•
Dimensions (WxHxD): 8.13" (206.6mm) x 0.87" (22.02mm) x
2.1" (53.8mm)
•
11
Weight : 0.75 lbs (340g)
•
Recharge Time: Main Battery Off/On – approximately 4.0 hours
hrs/approximately 12 hours
•
Battery Life: Up to 2 hour, 42 minutes (when using in Windows®
mode) (measured by Mobilemark™ 2002)
Security
•
Slot for cable lock, Memory (by one screw), Main HDD (by six
screws)
•
Passwords: User Power on Password, CPU Serial Number,
Setup, Supervisor Password
•
Hotkey locks: Keyboard (FN+F1), Screen Blank
•
Software: Screen Saver
BIOS
•
APM Support (V1.2), ACPI Support (V1.0b), PnP Support
(V1.0), VESA Support, DPMS Support, DDC Support, SM BIOS
Support (V2.3), PCI BIOS Support (V2.1)
13
Software
TOSHIBA Software and Utilities
•
TOSHIBA Express Media Player
•
TOSHIBA ConfigFree™
Part Number UPC Code
PSM40U-073001 032017347168
PSM40U-073002 032017347175
12
