Toshiba Satellite M45-S2653 Specifications

Satellite® M45 Detailed Product Specification
Model Name Description
M45-S2653 Microsoft® Windows® XP Home Edition, Intel Pentium® M Processor 730, 512MB DDR
SDRAM, 80GB (5400RPM PATA), DVD SuperMulti (+/-R double layer), 15.4" TruBrite™
widescreen WXGA, Intel Graphics Media Accelerator 900, Intel® PRO/Wireless
2200BG, CD control buttons, IEEE® 1394, 6-in-1 Bridge Media Adapter, Express Media
Player, 1 year limited warranty
2
Operating System
• Microsoft® Windows® XP Home
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
3
Processor and Chipset
Intel® Centrino™ Mobile Technology featuring:
• Intel Pentium® M Processor 730
o 1.60GHz, 2MB L2, 533MHz FSB
• Mobile Intel 915GM Express Chipset
• Intel PRO/Wireless 2200BG (802.11b/g),
4
Memory
• Configured with 512MB DDR SDRAM (both slots may be filled)
• 512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
or 1024MB PC2700 DDR 333MHz SDRAM,
5
Hard Disk Drive
• 80GB (5400 RPM) Parallel-ATA (PATA) hard disk drive; 9.5mm
height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats:
6
Display
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
7
Graphics
• Intel Graphics Media Accelerator 900 with 10MB-128MB
dynamically allocated shared graphics memory
Sound
• Analog Devices, Inc. AD1981B 16-bit stereo software sound
o Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
• Sound Volume Control Dial
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Express Media Player CD/DVD launch button
• CD/DVD control buttons (Skip to Previous/Next Track, Play, Stop)
8
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite M45_S2653 BTS Rev. 1.00 2005-10-21 MCL T20050726 CB1.40
1
Communications
• V.92 software modem
• Marvell 10BASE-T/100 BASE Ethernet
• Integrated Intel Pro/Wireless Network Connection 2200BG
(802.11b/g):
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• 6-in-1 Bridge Media Adapter, SD (Secure Digital), Memory Stick™,
Memory Stick PRO™, SmartMedia™, MMC, xD Picture Card
[shared slots]
o Secure Digital slot supports SDIO
Ports
• RGB (monitor) port
• TV-out (S-Video)
• i.LINK™ IEEE-1394
• 3 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.6"
(268.5mm) x 1.14" (29.0mm)[F]/1.43" (36.2mm)[R] without feet
• Weight: Starting at 6.00 lbs (2.72 kg) - 6.61 lbs (3.00 kg) depending
upon configuration
• Indicators (LED): Power, DC-IN, Primary HDD Access, ODD
Access, CapsLock, Arrow Mode, Numeric Mode, Main Battery
Charging Status, System Sleep/Suspend Status, Wireless
Communication, SD Card
• Chassis Description
o Case material: ABS Plastic
o LCD Cover Color: Aluminum Silver
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Main HDD (6
• Software Security
o Passwords: User power-on password, supervisor
o Hotkey locks: Screen Blank
Power Supply
• 75W (15V x 5A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 5.35" (136.0mm) x 1.18" (30mm) x 2.09"
(53.0mm)
• Weight: starting at .88 lbs (400g)
12
Battery
• 6-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
Part Number
PSM40U-11ZO4H
9
10
11
screws), Modem (3 screws)
password
UPC
032017463370
