Toshiba Satellite A70-S2362 Product Information

Satellite® A70 Series Notebook
Feature Model(s):
Satellite A70-S256 Mobile Intel® Pentium ® 4 processor 532 supporting Hyper-Threading Technology 3.06 GHz, 15.4" WXGA, 512MB,
60GB (4200 RPM), DVD-CDRW, Modem/LAN/802.11g Wi-Fi, WinXP Pro
Satellite A70-S2561 Mobile Intel® Pentium® 4 processor 532 supporting Hyper-Threading Technology 3.06 GHz, 15.4" WXGA, 512MB, 60GB
(4200 RPM), DVD-CDRW, Modem/LAN/802.11g Wi-Fi, WinXP Home
Satellite A70-S2362 Intel Celeron D Processor 325 (2.53GHz), 15.4" WXGA, 512MB,40GB (4200RPM), DVD-CDRW, Modem/LAN/802.11g
Wi-Fi, i.LINK
1
System Characteristics
Custom configuration options and optional items listed below are highlighted.
Operating System
•
Microsoft Windows XP-Pro (A70-S256 & A70-S2362)
•
Microsoft Windows XP-Home Edition (A70-S2561)
•
Microsoft Windows 2000 (Components Only)
2
Processor and Chipset
•
Mobile Intel® Pentium® 4 processor 532 supporting Hyper-Threading Technology 3.06 GHz
•
ATI® Mobility RADEON™ 9000 IGP 64MB of shared video memory.
•
1MB Level 2 cache memory integrated on die, (256KB L2 Cache for Celeron D model)
•
533MHz Processor System Bus Clock Speed
Memory
•
512MB (1DIMM) fixed memory module with 1 available upgradeable slot expandable to 1,536MB
•
Optional expansion memory: PC2700 (DDR 256MB/512MB/1024MB) SODIMM: Memory compatible with
PC2700 DDR333
3
Mass Storage
•
80GB ( 4200rpm & 5400rpm), 60GB (4200rpm & 5400rpm)
•
2.5" Enhanced IDE (ATA-6) hard disk drive: 9.5mm height
Optical Drives
•
FIXED DVD-ROM/CDRW Multi-function drive: Enhanced IDE (ATAPI) Interface; Maximum read speed: CD-
ROM, CD-R(24x), CD-RW(12x), CD-ROM(24x), DVD-ROM(8x); DVD-R, DVD-RW (4xMax), DVD-
RAM(2xMax).
Maximum write speed: CD-R (24xMax), CD-RW (4xMax), HS CD-RW (10xMax), US CD-RW (24xMax)
•
FIXED DVD Super Multi-Drive: Enhanced IDE (ATAPI) Interface; Maximum read speed: CD-ROM, CD-R
(24x); CD-RW (12x); DVD-ROM (8x); DVD-R (4x); DVD-RW (2x); DVD+R (2.4Max), DVD+RW (2.4Max),
DVD-RAM (2x Max).
Maximum write speed: CD-R (16 Max), CD-RW (4 Max), HS CD-RW (8x Max), DVD-R (4x Max),
DVD-RW (2xMax), DVD+R (2.4x Max), DVD+RW (2.4), DVD-RAM (2x Max).
4
Display
15.4" widescreen TFT WXGA LCD, display supports up to 16M colors at 1280X800
•
Brightness control
Graphics
•
ATI® Mobility Radeon™ 9000 IGP with 64MB of shared video memory
•
DirectX8 supported by hardware and Direct X9 supported by software
•
Direct 3D support and DirectVideo
•
External Color Support/Refresh rate:
640 x 480
800 x 600
1024 x 768
1280 x 800
1280 x 1024
1600 x 1200
1920 x 1440
2048 x 1536
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key stroke, 6mm height; Dedicated Windows® keys
support; HotKey function; TouchPad pointing device
Expandability
•
1 Memory Card Expansion Slot Available
•
1 PC Card slot support 1 Type II PC Card
5
Communications
•
Integrated V.92/56K modem; Data and fax support
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless LAN (Atheros 802.11b/g)
Ports
•
Parallel printer port
•
RGB (monitor) port
•
3 Universal Serial Bus ports (USB)
•
TV-Out Port
•
RJ-45 LAN Port
•
RJ-11 modem port
•
FIR
•
IEEE1394
•
5-IN-1 Bridge Media (Select Model Only)
6
Physical Description
•
Dimensions (LxWxH): 14.4" x 10.8" x 1.5/1.8 (2.1" w/feet)
•
Weight: 7.98 lbs.
•
LED Indicators: Power, Power Save Mode, HDD, CD/DVD-ROM Access, DC-IN, Caps Lock, Arrow, Numeric,
Main Battery Charging Status, System Sleep / Suspend status, Wireless Communication switch
Sound
•
Realtek ALC250 Codec Chip; Software Sound
•
Built-in stereo speakers; Sound Volume (by dial), Direct 3D Sound, Direct Sound, DirectMusic, MIDI Playback
Support; Full Duplex Support
•
Ports: External Microphone port, headphone port
Power Supply
•
AC Adapter: 120W external AC Adapter, 100-240V / 50-60Hz frequency (Universal) input voltage, 19V x 6.3A
Output. Dimensions (LxWxH): 5.91" x 2.56" x 1.48" Weight: 1.4lbs
•
Battery Pack: 12-cell, rechargeable, removable Lithium Ion (Li-Ion) battery, 14.8V x 6450mAh
•
Dimensions (LxWxH): 10.7" x 2.82" x 1.04" Weight: 1.49 lbx.
•
Battery Saver (in Windows XP): Stand by, HDD Auto Off, Display Auto Off, Throttling, Hibernation
•
Battery life (main batt):Up to 2 Hrs (see battery section)
•
Recharge time (main off/on): Up to 12H(system on)/ Up to 4H(system off)
Battery life may vary depending on applications, power management settings and features utilized. Recharge time varies depending on usage.
Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum
capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack or see information on accessories shipping
with your computer, visit the Toshiba website at www.accessories.toshiba.com
Security
•
Slot for computer lock, HDD (6 screws) and memory (1 screw), User Power-on password, Setup Security, Screen
Blank (by Hotkey), Screen Saver (by software)
Bios
•
ACPI, PnP, VESA, DPMS, DDC, SM BIOS, PC BIOS support, Boot Device
_______________________________________________________________________________________________________
Toshiba Software and Utilities
•
Toshiba Speech System
•
Toshiba Notebook Maximizer
•
Toshiba ConfigFree™ software
•
Toshiba Custom Utilities
Satellite_A70-S256 (Version 1.3) 6/24/04
This information is Subject to Change
®
1394, CD-Keys, 5-in-1 Media Reader, Win-XP-Pro
16bit/32bit colors
16bit/32bit colors
16bit/32bit colors
16bit/32bit colors
16bit/32bit colors
16bit/32bit colors
16bit/32bit colors
16bit/32bit colors
DPD Product Marketing
PSA70U-00D006
PSA70U-00D009
PSA70U-00Y00F
Additional Software
•
Microsoft® Works®
•
Microsoft® Office® OneNote™ 2003
•
Software Decoder: InterVideo® (Win-DVD™ 5) –w/SRS TruSurround XT® Technology (SRS TruSurround XT®
Technology Features: TruSurround, SRS Dialog Clarity, Enhancement & TruBass)
•
Microsoft® Office® 2003 Student/Teacher Edition 60-Day Trial Version
•
Sonic RecordNow Application & DSL Writing Software
•
ArcSoft ShowBiz® DVD Version 1.3
•
Intuit® Quicken® New User Edition 2004
•
Norton® AntiVirus™ 2003 – w/3-Month Subscription
•
AOL® (3 –Month offer)
AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY
MEMBERSHIP FEE, SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry
surcharges and communication surcharges may apply, including AK, even during promotional period. Members may incur telephone charges on
their phone bill, depending on their location and calling plan, even during promotional period. Available to new AOL members in the United
States, age 18 or older; a major credit card or checking account is required.
•
Adobe® Acrobat Reader
•
AT&T® Worldnet® Service – 1 Month FREE
--Telephone access and other charges and other terms and conditions may apply. Offer available to new customers
only.
•
QuickTime™ Player
•
RealOne™ Player 8 Basic
•
Microsoft® Internet Explorer
•
WIN-DVD4
•
Napster Download Trial
Environmental
•
Temperature: Operating: 5° to 30°C (41° to 86°F); Non-operating: -20° to 55°C (-4° to 131°F)
•
Thermal gradient: Operating: 15°C per hour maximum; Non-operating: 20°C per hour maximum
•
Relative Humidity: Operating: 20% to 80%; Non-operating: 10% to 90%
•
Altitude (relative to sea level): Operating: -60 to 3000 meters; Non-operating: -60 to 10,000 meters
•
Shock: Operating: 10G; Non-operating: 60G
•
Vibration: Operating: 0.5G; Non-operating: 1.0G
SelectServ® Warranty Programs
•
Warranty Extensions to 3 Years
•
3 Year SystemGuard
•
3 Year Depot Express
•
3 Year Business On-Site Repair; Next Day Business Day Response
•
3 Year SystemGuard + Depot Express
•
3 Year SystemGuard + Business on Site Repair, Next Bus. Day Response
Selected Accessories
Category................................................. Part Number........................................... Description
AC adapter ............................................. PA3290U-2ACA.................................... Toshiba 120W Global AC Adapter (smaller tip)
Primary Battery ...................................... PA3383U-1BRS .................................... Toshiba Li Ion Battery (12 cell)
FDD ....................................................... PA3109U-1FDD .................................... Toshiba USB FDD Kit
Input ....................................................... PA1336U-1NKB.................................... Toshiba USB Keyboard
Input ....................................................... PA1337U-1NMS ................................... Toshiba USB Optical Mouse
Memory.................................................. KTT3311/256 ........................................ Kingston 256MB Memory
Memory.................................................. KTT3311/512 ........................................ Kingston 512MB Memory
Memory.................................................. KTT3311/1G ......................................... Kingston 1GB Memory
Cases ...................................................... PA1335U-1NCS .................................... Toshiba Ambassador Leather Case
Cases ...................................................... NWCER2............................................... Excursion Roller 16"
Cases ...................................................... PA1362U-1NCS .................................... Toshiba BackPack
Cases ...................................................... PA1360U-1NCS .................................... Toshiba Nylon Case
Cases ...................................................... PA1361U-1NCS .................................... Toshiba Executive Leather Case
Security .................................................. NWDEFCL ............................................ Targus-Noteworthy DEFCON CL Cable Lock
Storage & Back-up................................. HDD1232CZP41002 ............................. Toshiba 5GB Type II PC Card HDD w/Back-up
Storage & Back-up................................. ABSPLUS-60.0 ..................................... CMS ABSplus 60GB PCMCIA Automatic
Storage & Back-up................................. ABSPLUS-80.0 ..................................... CMS ABSplus 80GB PCMCIA Automatic
Storage & Back-up................................. UABS2-60.0 .......................................... CMS ABSplus 60GB USB 2.0 Automatic
Storage & Back-up................................. UABS2-80.0 .......................................... CMS ABSplus 80GB USB 2.0 Automatic
Go to www.accessories.toshiba.com for additional, available accessories
1
SUBJECT TO CHANGE: While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product
specifications, configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product
information about your computer, or to stay current with the various computer software or hardware options, visit Toshiba's Web site at pcsupport.toshiba.com.
2
Central Processing Unit ("CPU") Performance Disclaimer.
CPU performance in your computer product may vary from specifications under the following conditions:
•
use of certain external peripheral products
•
use of battery power instead of AC power
•
use of certain multimedia games or videos with special effects
•
use of standard telephone lines or low speed network connections
•
use of complex modeling software, such as high end computer aided design applications
•
use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
•
use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude
(all temperature references are approximate and may vary depending on the specific computer model – please
refer to your Resource Guide or visit the Toshiba website at
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on
an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions under
"Environmental Conditions" in your product Resource Guide. Contact Toshiba Technical Service and Support for more information.
3
Hard Disk Drive Disclaimer: 1 Gigabyte (GB) means 1000 * 1000 * 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system,
however, reports storage capacity using powers of 2 for the definition of 1 GB = 1024 * 1024 * 1024 = 1,073,741,824 bytes, and therefore may show less storage
capacity. Available storage capacity will also be less if the product includes pre-installed operating system and/or application software. Actual formatted capacity
may vary.
4
TFT Display Disclaimer: Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of
thin-film transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic
characteristic of the TFT manufacturing technology.
****Weight: Weight may vary depending on actual configuration.
5
FCC Modem Speed Disclaimer.
Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
Wireless or Connectivity Claims.
Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone
charges and air time, etc. to achieve the functionality as advertised.
6
Weight Disclaimer
Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
7
Battery: Battery life may vary depending on product model, configuration, applications, power management settings and features utilized.
Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will
lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see
the accessories information that shipped with your computer or visit the Toshiba web site at

Return Policy

TAIS does not accept the return of component parts, or bundled software, which have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system,
contact t he TAIS dealer where you purchased the product, and comply with the dealer's standard return policies and procedures.
Source: CB Version 1.0 6-2-04 (AT)
UPC CODE:
032017251274
UPC CODE:
032017251281
UPC CODE:
032017255418
SWP-PEQQ3V
SWP-PEGQ3V
SWP-PEQX3V
SWP-PEQN3V
SWP-PEGX3V
SWP-PEGN3V
software
Backup System
Backup System
Backup System
Backup System
www.pcsupport.toshiba.com for details).
www.accessories.toshiba.com
