TOSHIBA
1
Satellite A75 Series
Model Name
Description
Satellite A75-
Intel® Pentium® 4 Processor 538, 15.4" WXGA, 512MB, 40GB (5400 RPM), 8x DVD
S125
SuperMulti (Double Layer), TV-Out, CD play/Instant play button, Parallel port, 802.11b/g,
Microsoft® Windows® XP Home,1-year Limited Warranty
Satellite A75-
Intel® Pentium® 4 Processor 538, 15.4" WXGA, 512MB, 40GB (5400 RPM), 8x DVD
S1251
SuperMulti (Double Layer), TV-Out, CD play/Instant play button, Parallel port, 802.11b/g,
Microsoft® Windows® XP Pro, 1-year Limited Warranty
System Characteristics
3
Operating System
•
Microsoft® Windows® XP Home
•
Microsoft® Windows® XP Professional
4
Processor
•
Mobile Intel® Pentium® 4 Processor 538 supporting HT
Technology [3.20GHz, 1MB L2 cache, 533MHz Front Side Bus]
Chipset
•
ATI MOBILITY™ RADEON® 9000 IGP
5
Memory
•
Configured with 512MB SDRAM
•
512MB (Min)/1536MB (Max), 512MB on-board memory with 1
available memory slot for 256MB, 512MB, or 1024MB PC2700
DDR 333MHz SDRAM 2.5V SODIMM memory modules. Both
slots may be occupied.
Mass Storage
6
Hard Drive
•
40GB (5400 RPM); Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drive
•
Fixed Bay DVD SuperMulti Double Layer Drive
Maximum Speed:
o CD-ROM(24x:read), CD-R(24x:write), CD-RW(10x:write),
DVD-ROM(8x:read), DVD-R(8x:write), DVD-RW(4x:write),
DVD+R(8x:write), DVD+R [Double Layer]
(2.4x:write),DVD+RW(4x:write), DVD-RAM(3x:write)
7
Display
•
15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
•
Brightness Control
8
Graphics
•
ATI MOBILITY™ RADEON® 9000 IGP with 64MB of shared
memory, user adjustable to 128MB
Sound
•
Realtek ALC250 Software Sound
•
16-bit stereo; Built-in stereo speakers
•
3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•
Sound Volume Control Dial
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Device:
TouchPad™
o
•
CD Buttons (Skip to previous Track, Play, Stop, Skip to Next
Track)
Expandability
•
1 main memory slot. May be occupied.
•
1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Communications
•
Integrated V.92 modem
•
10/100 Base-TX Ethernet
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
2
9
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Satellite A75-S125/1251 Series Rev. 1.50 05-19-2005 CBB CB V1.3
•
Atheros® 802.11b/g wireless-LAN supporting Atheros SuperG™
10
technology
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
3 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack
•
Headphone jack
•
RJ-45 LAN port
•
RJ-11 modem port
•
Parallel port
Physical Description
•
Dimensions (WxDxH Front/H Rear): 14.4" (365mm) x 10.8"
(275mm) x 1.54" (39mm)/1.81" (46mm)
•
11
Weight
: Starting at 7.98lbs (3.62kg) depending upon
configuration
•
Indicators: DC-In, Power, Primary Battery, Hard Drive, CD-DVD
ROM Access, Caps Lock, Arrow Lock, Numeric Lock, Main
Battery Charging Status, Sleep Suspend Mode
Power Supply
•
120W (19V 6.3A) Auto-sensing external AC Adapter, 100-240V /
50-60Hz ifrequency (Universal) input.
•
Weight: 1.43lbs (0.65kg)
•
Dimensions (WxDxH): 5.91'' (150mm) x 2.56'' (65mm) x 1.42''
(36mm)
12
Battery
•
12-cell (6450mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•
Weight: starting at 1.49 lbs (0.68kg)
•
Dimensions (WxDxH): 10.7'' (271.5mm) x 2.82'' (71.7mm) x
1.04'' (26.5mm)
•
Battery Life: Up to 2 hours (12-cell battery)
•
Recharge Time
Main Battery Off/On – up to 4.0 hrs/ up to 12.0 hrs
o
Security
•
Physical Security
Slot for cable lock;
o
Memory (protected by a screw)
o
Hard disk drive (protected by a screw)
o
Battery pack (protected by sliding latch)
o
•
Software Security
User Power-on password
o
Supervisor Password
o
Software: Screen Blank (by Hotkey), Screen Saver (by
o
software).
BIOS
•
ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS
v2.31, PCI BIOS v2.2 support
14
Software
Toshiba Software and Utilities
•
Toshiba Notebook Maximizer
•
Toshiba Speech System
•
Toshiba ConfigFree™
•
Toshiba Custom Utilities
•
Toshiba Touch and Launch
Third-party Software
•
Microsoft® Works™
•
Microsoft® Office® OneNote™ 2003
•
Intuit® Quicken® New User Edition 2005
Part Number
UPC Code
PSA70U-1Y300G
032017362062
PSA70U-1Y300P
032017362079
13
