Model 4030
Two-Channel Listening Station

User Manual

93507489000 Rev F
N O
I N T
N -
E R
R U
P T
I N T
E R
R U
P T
August / 2007

Advertisement

Table of Contents
loading

Summary of Contents for Telex 4030

  • Page 1: User Manual

    Model 4030 Two-Channel Listening Station User Manual I N T 93507489000 Rev F I N T August / 2007...
  • Page 2 OTICE The product information and design disclosed herein were originated by and are the property of Telex Communications, Inc. Telex reserves all patent, proprietary design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed therein, except to the extent rights are expressly granted to others.
  • Page 3: Table Of Contents

    Specifications ... 4 Chapter 2 Operation ... 5 External Connections & Controls ... 5 Model 4030 Connections and Controls ... 5 Chapter 3 Parts Documentation and Schematic ... 7 Final Assembly, Model 4030 ... 8 Connector Plate Assembly, Model 4030 ... 9 PC Board Assembly, Model 4030 ...
  • Page 5: Description And Specifications

    General The Model 4030 is a portable user station for use with RTS/Telex two-wire or 4010 IFB intercom systems. The Model 4030 is a listen-only IFB belt pack that can be used to listen to one or two intercom or program channels.
  • Page 6: Specifications

    Specifications Power Requirements 32 VDC nominal (standard RTS line), 150mA maximum Environmental Requirements Storage: -20°C to 80°C, 0% - 95% humidity, non-condensing Operating: 0°C to 50°C, 0% - 95% humidity, non-condensing Dimensions: Physical: 3.65” (92.77mm) L x 3.75” (95.3mm) W x 1.5” (38mm) D Weight: 10.8 oz.
  • Page 7: Operation

    Intercom Channel Connectors - The Model 4030 intercom channel is connected via a 3-pin female connector. The Model 4030 is powered from the intercom system power supply and will turn ON with the intercom system. Model 4030 Connections and Controls...
  • Page 9: Parts Documentation And Schematic

    CHAPTER 3 Parts Documentation and Schematic Parts may be obtained directly from Telex Communications, Inc., at: Telex Communications, Inc. 12000 Portland Ave South Burnsville, MN 55337 USA Telephone: (800) 392-3497 Fax: (800) 323-0498...
  • Page 10: Final Assembly, Model 4030

    Final Assembly, Model 4030 FIGURE 2. Item Description Case, 4030 Top Plate, 4030 Connector Plate Assembly PC Board, 4030 Knob, Nylon Body Knob Boot Screw, 4-40X .25LG, Flat Head Gray Beltclip Screw, 4-40X .25LG, Pan Head Screw, 6-32X .1875LG, Pan...
  • Page 11: Connector Plate Assembly, Model 4030

    Connector Plate Assembly, Model 4030 FIGURE 3. Item Description Connector Plate, Gray Connector Assembly, IFB 3-Pin Female Line Connector Assembly, IFB Phono/Stereo Nut and Washer Part of 1/4” Jack Screw, Part of 40055 Connector Screw Locking Agent Part No. 90807374008...
  • Page 12: Pc Board Assembly, Model 4030

    PC Board Assembly, Model 4030 FIGURE 4. Ref Des Part Number 51821625 51821626 54131005 54680412 Q1,Q2 54749000 D1,D2,D3,D4 58711100 PEM1,PEM2 59832002 J1,J2 59958104 R7,R8,R9 102404300 R1,R2 102404333 102404384 R23,R24 102513000 R13,R16,R18,R2 6,R27,R28, 102513100 102513102 102513154 102513472 R14,R15 102513473 Description 47UF, Cap Al Elect...
  • Page 13: Connector Assemblies

    Connector Assemblies FIGURE 5.
