TRENDnet TU2-ETG User Manual

Usb 2.0 gigabit ethernet adapter
Hide thumbs Also See for TU2-ETG:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for TRENDnet TU2-ETG

Summary of Contents for TRENDnet TU2-ETG

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction ...1 Features ... 1 Package Contents ... 1 System Requirements... 1 LED Status ... 2 2. Installation ...3 Driver Installation ... 3 Verifying the Driver Installation in Windows ... 7 Connecting to a Network ... 7 Configuring Network Settings ...

  • Page 3: Introduction

    1. Introduction The USB 2.0 Gigabit Ethernet Adapter instantly adds advanced network adapter to your desktop or laptop PC. The adapter supports Windows-based desktop computers or notebook PCs with a USB 1.0, 1.1 or 2.0 ports. It auto-senses between 10, 100 and 100Mbps network speeds. The adapter’s Auto-MDIX feature allows you to use a straight-through or crossover Ethernet cable.

  • Page 4: Led Status

    LED Status Color Link Green 1000Mbps Green Status Description Link is not established. Link is established. Link is not established Link to 10/100Mbps network. Link to 1000Mbps network. Blinking There is 1000Mbps traffic flow over the network.

  • Page 5: Installation

    2. Installation Driver Installation Note: DO NOT connect the Ethernet adapter to your computer before completing the driver installation. 1. Insert the provided CD into your CD-ROM drive. The setup program will start automatically. If not, locate and double-click the Setup.exe file in the Driver folder to launch the setup program.
  • Page 6 3. Click Install to start the installation. 4. Click Finish when the installation is complete. 5. Select Yes, I want to restart my computer now and click Finish to reboot your computer. 6. After reboot, connect the Ethernet adapter’s USB end to a free USB port of your computer.
  • Page 7 Windows XP 1. When the Found New Hardware Wizard screen appears, select Install the software automatically (Recommended) and click Next. 2. If compatibility message appears, just click Continue Anyway. 3. Click Finish to complete the installation.
  • Page 8 Windows 2000 If Digital Signature Not Found window appears, just click Yes. Windows ME Just wait the system to complete the installation. Windows 98SE Upon your USB device connection, if the system prompts you for the Windows 98SE CD-ROM, click OK. Remove the provided CD and insert the Windows 98SE CD-ROM.

  • Page 9: Verifying The Driver Installation In Windows

    Verifying the Driver Installation in Windows To verify your Ethernet adapter installation, select Control Panel > System > (Hardware) > Device Manager. In the Network adapters group, a string similar to USB2.0 to Gigabit Ethernet Adapter should be displayed. If there is a question or exclamation mark next to that item, then the driver is not properly installed.

  • Page 10: Configuring Network Settings

    Configuring Network Settings You should configure your Ethernet adapter as required according to your network environment. If you are unsure about the settings, consult your network administrator for assistance. The following describes how to launch the network settings window for your Ethernet adapter. Windows XP/2000 After the installation, a local area connection icon is automatically created for your Ethernet adapter in the Network Connections folder.

  • Page 11: Windows Me/98Se

    Windows ME/98SE Right-click the Network Neighborhood icon on the desktop and select Properties. Then the Network window appears.

  • Page 12: Specifications

    3. Specifications Hardware Standards Data Transfer Rate Embedded Buffers Supported OS LEDs Power Power Consumption 950mW Power Management Temperature Humidity Certification * Specification is subject to change without further notice. USB 2.0, 1.1 IEEE 802.3: 10Base-T IEEE 802.3u: 100Base-TX IEEE 802.3ab: 1000Base-T Ethernet: 10Mbps/20Mbps (Half/Full Duplex) Fast Ethernet: 100Mbps/200Mbps (Half/Full Duplex) Gigabit: 2000Mbps (Full Duplex)

  • Page 13: Limited Warranty

    TU2-ETG – 5 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
  • Page 14 REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD. LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR...
