Windows AC TTW
SERVICE MANUAL
Models:
TE08CEM9115S
TE10CEM9230S
TE08CM10115S
TE10CM10115S
TE10CM10230S
Dimension Mode
TTW
TTW sleeve
TE12CEM9230S
TE12CM10115S
TE12CM10230S
W (mm, inch)
H (mm, inch)
615
24.2
369
649
25.6
388
TE14CM9230S
TE14CEM9230S
TTW sleeve
D (mm, inch)
14.5
515
20.3
15.3
445
17.5
Advertisement
Table of Contents
Related Manuals for Master elios TE08CEM9115S
Summary of Contents for Master elios TE08CEM9115S
- Page 1 Windows AC TTW SERVICE MANUAL Models: TE08CEM9115S TE10CEM9230S TE12CEM9230S TE14CM9230S TE08CM10115S TE10CM10115S TE12CM10115S TE14CEM9230S TE10CM10230S TE12CM10230S TTW sleeve Dimension Mode W (mm, inch) H (mm, inch) D (mm, inch) 24.2 14.5 20.3 TTW sleeve 25.6 15.3 17.5...
-
Page 2: Table Of Contents
CONTENTS 1. Operation Modes and Instructions 1.1 Display control 1.2 Remote control 2. Electronic function 2.1 Terms and definitions 2.2 Protection function 2.3 Auto mode 2.4 Fan-only mode 2.5 Cooling mode 2.6 Auto-defrosting function protection as below 2.7 Heating mode 2.8 Dry mode 2.9 Sleep mode 3. -
Page 3: Operation Modes And Instructions
1. Operation Modes and Instructions 1.1 Display control ELECTRONIC HEATING MODELS COOLING-ONLY MODELS... - Page 4 On-Off Button Press to turn on or off the unit. NOTE: The unit will initiate automatically the Energy Saver function under cool, Dry, Auto (only Auto-Cooling and Auto-Fan) modes. Up and Down Button Press or hold either Up( ) or Down( ) the setting temp 2℉/1℃ each times from 62℉ (17℃) to 86℉ (30℃). Also can be used for time adjust in Timer function.
-
Page 5: Remote Control
Follow Me Feature (on some models) This feature can be activated from the remote control only. The remote control serves as a remote thermostat allowing for the precise temperature control at its location. To activate the Follow Me feature, point the remote control towards the unit and press the Follow Me button. The remote display is actual temperature at its location. -
Page 6: Electronic Function
2 Electronic function 2.1 Terms and definitions TA: Temperature of indoor ambient (T1) TE: Temperature of evaporator (T2). TS: The set temperature. DAHT: Sensor of heater 2.2 Protection function The compressor restart protection functions with a delay of 3 minutes. 5 minutes operation for compressor(this function is for cooling and heat pump mode) ... -
Page 7: Auto-Defrosting Function Protection As Below
Operation conditon (TA-Ts) ℉ compressor on compressor off with a delay of 1 minute When TA≤TS (lasting 1 minute), compressor off When T1>TS+2℉, compressor on The Ion/ Timer/ Sleep/ Energy Saver/ Follow Me functions are valid at the cooling mode. 2.6 Auto-defrosting function protection as below: ... -
Page 8: Dry Mode
2.8 Dry mode The temp can be setting as same as Cooling mode. The fan speed is low and can’t be controlled at the mode. 2.9 Sleep mode This function is 7 hours. It is valid in cooling, heating and auto mode. ... -
Page 9: Internal Structures
3 Internal Structures... -
Page 10: Installation And Use Notice
4 Installation and use notice 4.1 For different Wall Sleeve, the cut of Tapered Space Blocks are different as shown below: 1) Fedders of Friedrich 16 3/4″Deep Tapered Spaceer Blocks is cut into three pieces as shown below: 2) General Electra/Hotpoint 16 7/8″Deep Tapered Spaceer Blocks is cut into two pieces as shown below: 3) Whirlpool 17 1/8″Deep... - Page 11 4.2 Cleaning filter Notice: The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils.
-
Page 12: Troubleshooting
5 Troubleshooting In general, possible trouble is classified in three kinds. One is called Starting Failure which is caused from an electrical defect, another is ineffective Air Conditioning caused by a defect in the refrigeration circuit and improper application, and the other is called the Structure Damage. 5.1 Troubleshooting Problem Solution... -
Page 13: Sensor Malfunction
5.2 Sensor malfunction LED display Stand for Room temperature sensor error Room temperature sensor protection at open circuit sensor error in fan only mode Room temperature sensor protection at short circuit sensor error in fan only mode Electronic heating sensor error Evaporator temperature sensor at open or short circuit ●...
