Summary of Contents for Zanussi ZWD86SB4PW
- Page 1 User Manual GETTING STARTED? EASY. ZWD86SB4PW EN User Manual Washer Dryer...
-
Page 2: Safety Information
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. -
Page 3: General Safety
GENERAL SAFETY Do not change the specification of this appliance. • This appliance is intended to be used in household and similar • applications such as: staff kitchen areas in shops, offices and other working – environments; by clients in hotels, motels, bed & breakfast and other –... - Page 4 The appliance must be connected to the water mains using the • new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. Old hose sets must not be reused. • If the mains power supply cable is damaged, it must be •...
-
Page 5: Safety Instructions
Before any maintenance operation, deactivate the appliance • and disconnect the mains plug from the socket. SAFETY INSTRUCTIONS INSTALLATION • This appliance is fitted with a 13 A mains plug. If it is necessary to change the mains plug fuse, The installation must comply with use only a 13 A ASTA (BS 1362) fuse (UK and relevant national regulations. -
Page 6: Product Description
• Do not dry dripping wet clothes in the software, door, door hinge and seals, other appliance. seals, door locking assembly, plastic peripherals • Do not let hot items to touch the plastic parts of such as detergent dispensers. Please note that the appliance. -
Page 7: Technical Data
TECHNICAL DATA Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /55.7 cm Electrical connection Voltage 230-240 V Overall power 2200 W Fuse 13 A Frequency 50 Hz Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against moisture Cold water... -
Page 8: Information For Installation
3. Remove the internal film. 7. Remove the power supply cable and the drain hose from the hose holders. 4. Open the door. Remove the polystyrene piece from the door seal and all the items from the 8. Remove the three bolts. Use the key supplied drum. - Page 9 2. Loosen or tighten the feet to adjust the level. All 1. Make a U shape with the drain hose and put it feet must rest firmly on the floor. around the plastic hose guide. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
-
Page 10: Installation On Suspended Flooring
INSTALLATION ON SUSPENDED FLOORING Suspended wooden floors are particularly susceptible to vibration. To limit vibration we recommend placing a The end of the drain hose must always waterproof wooden panel, at least 15 mm thick, be ventilated , i.e. the inner diameter of under the appliance. -
Page 11: Control Panel Description
CONTROL PANEL CONTROL PANEL DESCRIPTION Programme knob Additional rinse (Extra Rinse) Spin speed reduction (Spin) Automatic drying level (Auto Dry) Temperature selection (Temp.) Start/Pause Display Delay start setting (Delay Start) Drying time selection (Time Dry) Time saving (Flex Time) Prewash phase (Prewash) DISPLAY... -
Page 12: Programme Chart
Time area : Programme duration : Selected drying time : Delay start : Alarm codes : Message of error : The programme is completed. Time programme indicators : Normal duration indicator : Quick indicator : Super quick indicator Delay start indicator Child safety lock indicator Door locked indicator Indicators of dryness level... - Page 13 Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed Eco 40-60 + Cupboard White cotton and fast-coloured cotton. 4 kg dry level (Dry only mode) Cottons White cotton and coloured cotton. 8 kg 40 °C Normally, heavily and lightly soiled items.
- Page 14 Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed Steam programme can be used for reducing wrinkles and odours of garments that just Steam need to be refreshed, avoiding washing. The fabric fibres are relaxed and afterwards ironing becomes effortless.
- Page 15 Programme ■ ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ Wool ■ ■ ■ ■ ■ ■ Delicates ■ ■ ■ 20min Wash ■ ■ ■ ■ ■ Rinse ■ Drain ■ ■ ■ Spin ■ Wool ■...
-
Page 16: Automatic Drying
Universal Liquid Liquid for Delicates Programme Special Universal coloureds woollens powder 60min ▲ ▲ Wash&Dry 1) At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended -- = Not recommended AUTOMATIC DRYING Initial cycle times for programmes with Auto Dry option are only estimates, the actual drying time may slightly differ from the time displayed. -
Page 17: Extra Rinse
Spin Suggested Dryness Level Type of fabric Load (kg) speed duration (rpm) (mins) Cupboard Dry Synthetics and mixed fab- 1200 90 - 105 For items to be stored rics 1200 40 - 50 (jumpers, blouses, underwear, household and bed linen) Wool 1200 80 - 100... -
Page 18: Before First Use
Use this option for persons allergic to detergents You can select: and in areas where the water is soft. • QUICK: to wash items with daily soil. The related indicator comes on. • SUPER QUICK: to wash quickly items with almost no soil. -
Page 19: Using Detergent And Additives
3. Put the laundry in the drum, one item at a time. CHECK THE POSITION OF THE DETERGENT FLAP Do not put too much laundry in the drum. 4. Close the door firmly. 1. Pull out the detergent dispenser until it stops. 2. -
Page 20: Interrupting A Programme And Changing The Options
SETTING A PROGRAMME • The door locks, the display shows the 1. Turn the programme knob to switch the indicator appliance on and set the required programme: If the indicator flashes, the door is locking. If the display shows an alarm •... -
Page 21: Daily Use - Drying Only
The washing programme is completed, but Before starting the new programme there is water in the drum: the appliance could drain the water. In • The drum turns regularly to prevent the creases this case, make sure that the detergent in the laundry. -
Page 22: Drying At Automatic Levels
3. Turn the programme dial to the programme • The display shows the set time value: for applicable for the items to dry. The display example – • After some seconds the display shows a shows the drying indicator new time value: . -
Page 23: Fluff In The Fabrics
NON-STOP PROGRAMME The display shows regularly a new time value. 1. Turn the programme knob to the desired The last minutes of the drying cycle programme to activate the appliance. the appliance performs the anti-crease 2. Load the laundry one item at a time. and the cooling phases. -
Page 24: Hints And Tips
HOW TO REMOVE THE FLUFF IN THE 3. Set the rinse programme. GARMENTS 4. Press at the same time to activate To remove the fluff inside the drum, set a special the cleaning function until the display shows programme: CLE. 1. - Page 25 – liquid detergents, preferably for low softener for washing machines. In areas where the temperature wash programmes (60 °C max) water hardness is soft it is not necessary to use a for all types of fabric, or special ones for water softener.
-
Page 26: Care And Cleaning
To avoid the static charge at the end of the drying WARNING! To avoid creasing and cycle: shrinkage do not overdry the 1. Use fabric conditioner in the washing cycle. laundry. 2. Use special fabric conditioner for tumble dryers. GENERAL TIPS When the drying programme is completed remove Refer to the «Drying programmes»... -
Page 27: Maintenance Wash
MAINTENANCE WASH Clean it when needed, using ammonia cream cleanser agent without scratching the seal surface. With the low temperature programmes it is possible that some detergent stays in the drum. Perform a Always obey the instructions that you maintenance wash regularly. To do this: find on the packaging of the product. -
Page 28: Cleaning The Drain Filter
CLEANING THE DRAIN FILTER Do not clean the drain filter if the water in the appliance is hot. • Repeat the steps 2 and 3 until the water stops flowing out. • Always keep a rag nearby to dry up any water spillage. 180°... -
Page 29: Cleaning The Inlet Hose And The Valve Filter
Regularly check the drain pump filter and make sure that it is clean. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Author- ised Service Centre. Make sure also that you tighten the filter correctly to prevent leakages. CLEANING THE INLET HOSE AND THE VALVE FILTER 45°... -
Page 30: Frost Precautions
3. Put the two ends of the inlet hose in a When you drain the water with the emergency drain container and let the water flow out of the procedure, you must activate the drain system hose. again: 4. Empty the drain pump. Refer to the emergency 1. - Page 31 • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this The appliance does not information, contact your local water authority. fill with water properly. • Make sure that the water tap is not clogged.
- Page 32 Problem Possible solution • Set the spin programme. The spin phase does • Make sure that the drain filter is not clogged. Clean the filter, if neces- not operate or the sary. Refer to "Care and cleaning". washing cycle lasts lon- •...
-
Page 33: Emergency Door Opening
Problem Possible solution The fabrics washed in the previous cycle released fluff of a different col- our: The laundry is full of dif- • The drying phase helps to eliminate some fluff. ferent colours fluff. • Clean the clothes with a fluff remover. In case of an excessive amount of fluff in the drum run the special pro- gramme to clean it (refer to “Fluff in the fabrics"... - Page 34 The QR code on the energy label supplied with the appliance pro- vides a web link to the product information sheet. Keep the energy label for reference together with the user manual and all other documents provided with this appliance. LEGEND Laundry load.
- Page 35 Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.50 0.50 4.00 Time to Off/Standby mode is 15 minutes maximum. COMMON PROGRAMMES - WASHING ONLY These values are indicative only. Programme Litres h:mm °C Cottons 2.15 3:25 1600 90°C Cottons...
-
Page 36: Environmental Concerns
Programme Litres h:mm °C Synthetics 2.00 4:00 1200 40°C 1) Reference indicator of the spin speed. ENVIRONMENTAL CONCERNS with the symbol with the household waste. Recycle materials with the symbol . Put the Return the product to your local recycling facility or packaging in relevant containers to recycle it. - Page 40 WWW.ZANUSSI.COM/SHOP...
