Page 1: Reference Guide
Reference Guide NPD4298-00 EN...
Page 2: Copyright Notice
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by pur-...
Page 3 Software and Documentation as described above. 10. In no event will Epson or its licensor be liable to you for any consequential, incidental INDI- RECT, PUNITIVE or special damages, including any lost profits or lost saving, even if Epson has been advised of the possibility of such damages, or for any claim by any third party.
Page 4: About Adobe Color Profile
11. Notice to Government End Users: The Software is a “commercial item,” as that term is defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consis- tent with 48 C.F.R.
Page 5 4. DISCLAIMER OF WARRANTY Adobe licenses the Software to you on an “AS IS” basis. Adobe makes no representation as to the adequacy of the Software for any particular pur- pose or to produce any particular result. Adobe shall not be liable for loss or damage aris- ing out of this Agreement or from the distribution or use of the Software or any other materials.
Page 6 9. GOVERNING LAW This Agreement will be governed by and construed in accordance with the substantive laws in force in the State of California as such laws are applied to agree- ments entered into and to be performed entirely within California between California resi- dents.
Page 7: Openssl Statement
5. All company names and product names used in this document is the trademarks or regis- tered trademarks of their respective holder. This ICC Profile made by GretagMacbeth ProfileMaker and granted TOYO INK certain license to distribute by GretagMacbeth AG. TOYO Offset Coated 2.1 ©...
Page 8: Original Ssleay License
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PRO- CUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROF- ITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLI- GENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 9: Netsnmp License
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SER- VICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABIL- ITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 10 Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of condi- tions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Page 11 Part 4: Sun Microsystems, Inc. copyright notice (BSD) Copyright (c) 2003 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, California 95054, U.S.A. All rights reserved. Use is subject to license terms below. This distribution may include materials developed by third parties. Sun, Sun Microsystems, the Sun logo and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc.
Page 12 PLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCURE- MENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABIL- ITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 13 THIS SOFTWARE IS NOT ORIGINAL MIT SOFTWARE, MODIFIED BY KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.,...
Page 15: Table Of Contents
Contents 1 Operation on Mac OS X ... 1 System Requirements for the Printer Driver 2 Installing the Printer Driver 3 Installing the Printer Driver Printer Setup Utility Settings 7 When Using a USB Connection When Using a Network Connection Bonjour Setting 9 AppleTalk Setting 12 IP Printing Setting 14...
Page 16 Page Attributes Options Specifying Custom Paper Size Specifying Print Settings (Mac OS X 10.4) 39 Print Dialog Box Common buttons Copies & Pages Layout Scheduler Paper Handling ColorSync Cover Page Error Handling Paper Feed Color Options Advanced Color Options/Image Advanced Color Options/Text Advanced Color Options/Graphics Advanced Color Options/Simulation Printer Features...
Page 17 Manual Scanning Mode Troubleshooting 85 2 Operation on Linux ... 87 System Requirements for the Printer Driver 88 Installing PPD File From the Command Line 89 Adding the Printer 90 Specifying Printer Driver Settings 93 Displaying the Settings Page Printer Driver Settings Extra 94 General 95 Graphics Options 96...
Page 18 HTTP 126 FTP 126 SMB 127 BONJOUR 127 IPP 128 RAW PORT 128 SLP 128 SNMP 129 WSD PRINT 129 IPSEC 129 IP ADDR. FILTER 129 IPv6 130 NETWARE 131 APPLETALK 131 SPEED/DUPLEX 131 IEEE802.1X 131 5 Network Printing ... 133 Network Connection 134 Theory Making the Connection...
Page 19 SNMP 144 TCP/IP 144 WSD print 144 Printing via IPP (Internet Printing Protocol) Adding an IPP Port using the software CD-ROM 145 Adding an IPP Port using Add Printer Wizard – Windows Server 2003/XP/ 2000 147 Adding an IPP Port using Add Printer Wizard – Windows Vista 149 Printing via Web Service Print Function Adding a printer from the Network window 151 Adding a printer using Add Printer Wizard 153...
Page 20 Direct Print 192 Scan Page Favorite 193 Address Setting 193 Group Setting 193 Configuring the Printer 194 System Page Device Information 195 Counter 200 Online Assistance 201 Import/Export 202 Authentication 203 Date/Time 206 Admin Password 209 Save Settings 210 Machine Settings 211 ROM Version 214 Maintenance 214 Status Notification Settings 215...
Page 21 SSL/TLS Information 288 SSL/TLS Setting (When a certificate is not installed) 288 SSL/TLS Setting (When a certificate is installed) 289 Self-signed Certificate Setting 289 Request a certificate 291 Certificate Request 292 Install a Certificate 293 Encryption Strength Setting 293 Remove a Certificate 294 Mode Using SSL/TLS 294 Authentication 295 Contents...
Page 22 viii Contents...
Page 23: Operation On Mac Os X
Operation on Mac OS X...
Page 24: System Requirements For The Printer Driver
Before installing the printer driver, make sure that your system meets the fol- lowing system requirements. Computer Connecting the computer and printer Operating system Available disk space Supported languages Apple Macintosh computer installed with the following processor: – PowerPC G3 or later processor (Pow- erPC G4 or later is recommended) –...
Page 25: Installing The Printer Driver
You must have administrator privileges in order to install the printer driver. Before proceeding with the installation, be sure to exit all running applications. Installing the Printer Driver The procedure for installing the printer driver on Mac OS X 10.4 is described below.
Page 26 Click Continue. Click Continue. Installing the Printer Driver...
Page 27 In the Select a Destination page, select the disk in which you wish to install the software, and then click Continue. Click Install in the Easy Install page. Installing the Printer Driver...
Page 28 Enter the administrator user name and password in the Authenticate dia- log box, and then click OK. Installation starts. After the installation has been completed, click Close. This completes the installation of the printer driver. Installing the Printer Driver...
Page 29: Printer Setup Utility Settings
This function is not supported by Mac OS X 10.5. When Using a USB Connection Use a USB cable to connect the machine to your computer. Open Printer Setup Utility, which can be accessed by clicking Macintosh HD, then Applications, then Utilities. In the Printer List, click Add.
Page 30 If AL-CX28 does not appear, check that the machine is turned on and the USB cable is connected, and then restart the computer. Check that EPSON CX28 PPD is selected in the Print Using list. Click Add. The new printer appears in the Printer List screen.
Page 31: When Using A Network Connection
The network connection settings can be specified in one of three ways: Bonjour Setting, AppleTalk Setting and IP printing Setting (IPP, LPD or Socket). Bonjour Setting Connect the machine to an Ethernet network. Open Printer Setup Utility, which can be accessed by clicking Startup Disk, then Applications, then Utilities.
Page 32 Select AL-CX28-xxxxxx.local in the Printer Browser. “xxxxxx” refers to the last six digits of the MAC address (in hexa- decimal). Check that EPSON CX28 PPD is selected in the Print Using list. Click Add. Printer Setup Utility Settings...
Page 33 Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click Continue. The new printer appears in the Printer List screen. Printer Setup Utility Settings...
Page 34: Appletalk Setting
Click Add in the Printer List. The detected printer appears in the Printer Browser. Do not select EPSON AppleTalk or EPSON TCP/IP using the More Printers button. This blocks communication between your computer and printer via a network and prevents the printer from being found.
Page 35 Select AL-CX28-xxxxxx in the Printer Name list. “xxxxxx” refers to the last six digits of the MAC address (in hexa- decimal). Check that EPSON CX28 PPD is selected in the Print Using list. Click Add. The new printer appears in the Printer List screen.
Page 36: Ip Printing Setting
IP Printing Setting Connect the machine to an Ethernet network. Open Printer Setup Utility, which can be accessed by clicking Startup Disk, then Applications, then Utilities. Click Add in the Printer List. Click IP Printer. Printer Setup Utility Settings...
Page 37 - For an LPD setup, select Line Printer Daemon - LPD. - For a port 9100 setup, select HP Jet Direct - Socket. Do not select EPSON AppleTalk or EPSON TCP/IP using the More Printers button. This blocks communication between your computer and printer via a network and prevents the printer from being found.
Page 38 Enter the IP address for the machine in the Address text box. - For an LPD setup, type “lp” in the Queue text box. - For an IPP setup, type “ipp” in the Queue text box. Select EPSON CX28 PPD in the Print Using list. Click Add. Printer Setup Utility Settings...
Page 39 Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click Continue. The new printer appears in the Printer List screen. Printer Setup Utility Settings...
Page 40: Printer Settings (Mac Os X 10.5)
When Using a USB Connection Use a USB cable to connect the printer to your computer. Select System Preference from the Apple menu. Click Print & Fax. In the Print & Fax, click + button. Printer Settings (Mac OS X 10.5)
Page 41 The detected printer appears in the Printer Browser. Select SEIKO EPSON AL-CX28 in the Printer Name list. Printer Settings (Mac OS X 10.5)
Page 42 If SEIKO EPSON AL-CX28 does not appear, check that the printer is turned on and the USB cable is connected, and then restart the com- puter. Check that EPSON CX28 PPD is selected in the Print Using list. Click Add.
Page 43 Click Continue. The new printer appears in the Print & Fax screen. Printer Settings (Mac OS X 10.5)
Page 44: When Using A Network Connection
The network connection settings can be specified in one of three ways: Bon- jour Setting, AppleTalk Setting and IP printing Setting (IPP, LPD or Socket). Bonjour Setting Connect the machine to an Ethernet network. Select System Preference from the Apple menu. Click Print &...
Page 45 The detected printer appears in the Printer Browser. Select AL-CX28-xxxxxx.local in the Printer Name list. “xxxxxx” refers to the last six digits of the MAC address (in hexadeci- mal). Printer Settings (Mac OS X 10.5)
Page 46 Check that EPSON CX28 PPD is selected in the Print Using list. Click Add. Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click Continue. The new printer appears in the Print & Fax screen.
Page 47: Appletalk Setting
AppleTalk Setting Connect the machine to an Ethernet network. Select System Preference from the Apple menu. Click Print & Fax. In the Print & Fax, click + button. The detected printer appears in the Printer Browser. Printer Settings (Mac OS X 10.5)
Page 48 More Printers button. This blocks communication between your computer and printer via a network and prevents the printer from being found. Check that EPSON CX28 PPD is selected in the Print Using list. Click Add. Printer Settings (Mac OS X 10.5)
Page 49 Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click Continue. The new printer appears in the Printer List screen. Printer Settings (Mac OS X 10.5)
Page 50: Ip Printing Setting
IP Printing Setting Connect the machine to an Ethernet network. Select System Preference from the Apple menu. Click Print & Fax. In the Print & Fax, click + button. Printer Settings (Mac OS X 10.5)
Page 51 Click IP. Select desired print protocol from the Protocol pop-up menu. - For an IPP setup, select Internet Printing Protocol - IPP. - For an LPD setup, select Line Printer Daemon - LPD. - For a port 9100 setup, select HP Jetdirect - Socket. Printer Settings (Mac OS X 10.5)
Page 52 Printers button. This blocks communication between your computer and printer via a network and prevents the printer from being found. Check that EPSON CX28 PPD is selected in the Print Using list. Click Add. Printer Settings (Mac OS X 10.5)
Page 53 Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click Continue. The new printer appears in the Print & Fax screen. Printer Settings (Mac OS X 10.5)
Page 54: Selecting Print Options
For Mac OS X 10.2/10.3/10.4 Open Printer Setup Utility (Print Center), which can be accessed by clicking Startup disk, then Applications, then Utilities. Select this printer in the Printer List, and then select Show Info from the Printers menu. Select Installable Options from the pop-up menu. Selecting Print Options...
Page 55 Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click Apply Changes. Close the Printer Info dialog box. Selecting Print Options...
Page 56 Select System Preference from the Apple menu. Click Print & Fax. Select this printer in the Printers List, and then click Options & Sup- plies. Select Driver. Selecting Print Options...
Page 57 Select the appropriate settings in the Printer Memory, Storage, and Paper Source Unit according to your printer setup. Click OK. Close the Print & Fax screen. Selecting Print Options...
Page 58: Specifying Page Setup Settings
The following dialog box appears when Page Setup... is selected from the File menu in the application being used. Select Page Setup... from the File menu. The Page Setup dialog box appears. Select this printer in the Format for pop-up menu. You can select the following sections from the Settings pop-up menu.
Page 59: Page Attributes Options
The Page Attributes section is used to specify the settings for the paper size, scaling, and print orientation. Paper Size Select the desired paper size from the Paper Size pop-up menu. Orientation Select either a vertical or horizontal page orientation for printouts. Scale If you want to enlarge or reduce the size of the printout, enter the scale ratio here (25-400%).
Page 60: Specifying Custom Paper Size
You can also specify a paper size that is not listed in the Paper Size pop-up menu. Select Manage Custom Sizes from the pop-up menu, in the Page Setup dialog box. The Custom Page Sizes dialog box appears. Click this button to create a new custom page size. Click this button to delete a custom page size.
Page 61: Specifying Print Settings (Mac Os X 10.4)
The following dialog box appears when Print... is selected from the File menu in the application being used. Select Print... from the File menu. The Print dialog box appears. Select this printer in the Printer pop-up menu. The Print dialog box is used to specify the following print options. Print Dialog Box Section Copies &...
Page 62: Common Buttons
Section Color Options Printer Features Supply Levels Summary No warning message will be displayed if options cannot be used together are selected. Common buttons ? (Help button) This displays help information about the Print dialog box. Click this button to select the PDF menu. The print output can be saved as a PDF file.
Page 63: Copies & Pages
The Copies & Pages section is used to specify the number of copies to print and the range of pages to print. Copies This specifies the number of copies to be printed. If the Collated check- box is selected, all pages in the documents are printed as sets of print- outs.
Page 64: Layout
The Layout section is used to specify the page layout when printing and the setting for double-sided printing. Pages per Sheet Specifies the number of pages to be printed on one sheet of paper. For example, if 2 is selected, two pages are printed on one sheet of paper. Layout Direction If you are printing more than one page per sheet, this specifies the direc- tion and order the pages should be arranged on each sheet of paper.
Page 65: Scheduler
The Scheduler section is used to specify the timing and priority for printing jobs. Print Document Now: Select this option to begin printing immediately. Specify the time to begin printing. On Hold: Select this option to hold the print job. Priority Select the priority for printing jobs that are being held.
Page 66: Paper Handling
The Paper Handling section is used to specify the pages that are to be printed and the order in which the pages are printed. Page Order Automatic: Select this option to print in the original page order of the document. Normal: Select this option to print in the normal page order.
Page 67: Colorsync
ColorSync Color Conversion Allows you to select host-based color matching or printer-based color matching. Quartz Filter Allows you to select Quartz Filter. Cover Page Print Cover Page Allows you to set cover page before or after document. Cover Page Type Allows you to select cover page type.
Page 68: Error Handling
Error Handling PostScript Errors Allows you to select whether or not a report is outputted when a Post- Script error occurs. Tray Switching This feature is not available with this printer. Specifying Print Settings (Mac OS X 10.4)
Page 69: Paper Feed
The Paper Feed section is used to specify the paper feed setting. All pages from All pages in the document are printed using the paper in the specified paper tray. First page from The first page of the document is printed on paper from a paper tray differ- ent from the tray used to print the rest of the document.
Page 70: Color Options
Color Options Quick Color Allows you to select a color preset. Brightness Allows you to set Brightness. Color as Grayscale Allows you to set Grayscale color. Color Separation Allows you to set Color Separation. Economy Print Allows you to set Economy Print Mode. Edge Strength Allows you to select Edge Strength.
Page 71: Advanced Color Options/Image
Advanced Color Options/Image RGB Source Allows you to select RGB color profiles for images. RGB Intent Allows you to select color intent for RGB images. RGB Gray Treatment Allows you to select RGB gray treatment for images. Destination Profile Allows you to select Destination Profile for images. Halftone Allows you to select halftone for images.
Page 72: Advanced Color Options/Text
Advanced Color Options/Text RGB Source Allows you to select RGB color profiles for text. RGB Intent Allows you to select color intent for RGB text. RGB Gray Treatment Allows you to select RGB gray treatment for text. Destination Profile Allows you to select Destination Profile for text. Halftone Allows you to select halftone for text.
Page 73: Advanced Color Options/Graphics
Advanced Color Options/Graphics RGB Source Allows you to select RGB color profiles for graphics. RGB Intent Allows you to select color intent for RGB graphics. RGB Gray Treatment Allows you to select RGB gray treatment for graphics. Destination Profile Allows you to select Destination Profile for graphics. Halftone Allows you to select halftone for graphics.
Page 74: Advanced Color Options/Simulation
Advanced Color Options/Simulation Simulation Profiles A llows you to select color profiles for simulation. Match Paper Color Allows you to set Match Paper Color. CMYK Gray Treatment Allows you to select Simulation gray treatment. Hide Advanced Options Click this button to hide the Advanced Color Options pane and display the Color Options pane.
Page 75: Printer Features
Nearest Size and Scale If no paper tray contains paper of the specified size, the page is automati- cally enlarged or reduced and paper of the most appropriate size is selected. Manually Print on 2nd Side This feature must be set when you set paper already printed on the front side.
Page 76: Supply Levels
The Supply Levels section provides information for checking the amount of service life remaining on each consumable. The Supply Levels section appears when a printer is created on Mac OS X v10.4 with a Bonjour, IPP, LPD, Socket connection. The Supply Levels section may not appear depending on the applica- tion you use.
Page 77: Specifying Print Settings (Mac Os X 10.5)
The following dialog box appears when Print... is selected from the File menu in the application being used. Select Print... from the File menu. The Print dialog box appears. Select this printer in the Printer pop-up menu. The Print dialog box is used to specify the following print options. Print Dialog Box Section Layout...
Page 78: Common Buttons
Section Color Options Printer Features Supply Levels Summary No warning message will be displayed if options cannot be used together are selected. Common buttons ? (Help button) This displays help information about the Print dialog box. Click this button to select the PDF menu. The print output can be saved as a PDF file.
Page 79: Layout
Pages All: Prints all pages in the document. From, to: Specifies the range of pages to be printed. Paper Size Select the desired paper size from the Paper Size pop-up menu. Orientation Select either a vertical or horizontal page orientation for printouts. Layout The Layout section is used to specify the page layout when printing and the setting for double-sided printing.
Page 80: Color Matching
Two-Sided Select the desired setting for double-sided printing. Off: Long-edged binding: Short-edged binding: Double-sided printing is performed with the bind- Reverse Page Orientation The printing direction is inverted vertically. Color Matching Color Matching ColorSync: Allows you to select host-based color matching. In Printer: Allows you to select printer-based color matching.
Page 81: Paper Handling
The Paper Handling section is used to specify the pages that are to be printed and the order in which the pages are printed. Pages To Print All pages: Select this option to print all pages. Odd Only: Select this option to print only the pages with odd page num- bers.
Page 82: Paper Feed
The Paper Feed section is used to specify the paper feed setting. All pages from All pages in the document are printed using the paper in the specified paper tray. First page from The first page of the document is printed on paper from a paper tray differ- ent from the tray used to print the rest of the document.
Page 83: Cover Page
Cover Page Print Cover Page Allows you to set cover page before or after document. Cover Page Type Allows you to select cover page type. Billing Info Allows you to set billing information printed on cover page. Specifying Print Settings (Mac OS X 10.5)
Page 84: Scheduler
The Scheduler section is used to specify the timing and priority for printing jobs. Print Document Now: Select this option to begin printing immediately. Specify the time to begin printing. On Hold: Select this option to hold the print job. Priority Select the priority for printing jobs that are being held.
Page 85: Color Options
Color Options Quick Color Allows you to select a color preset. Brightness Allows you to set Brightness. Color as Grayscale Allows you to set Grayscale color. Color Separation Allows you to set Color Separation. Economy Print Allows you to set Economy Print Mode. Edge Strength Allows you to select Edge Strength.
Page 86: Advanced Color Options/Image
Advanced Color Options/Image RGB Source Allows you to select RGB color profiles for images. RGB Intent Allows you to select color intent for RGB images. RGB Gray Treatment Allows you to select RGB gray treatment for images. Destination Profile Allows you to select Destination Profile for images. Halftone Allows you to select halftone for images.
Page 87: Advanced Color Options/Text
Advanced Color Options/Text RGB Source Allows you to select RGB color profiles for text. RGB Intent Allows you to select color intent for RGB text. RGB Gray Treatment Allows you to select RGB gray treatment for text. Destination Profile Allows you to select Destination Profile for text. Halftone Allows you to select halftone for text.
Page 88: Advanced Color Options/Graphics
Advanced Color Options/Graphics RGB Source Allows you to select RGB color profiles for graphics. RGB Intent Allows you to select color intent for RGB graphics. RGB Gray Treatment Allows you to select RGB gray treatment for graphics. Destination Profile Allows you to select Destination Profile for graphics. Halftone Allows you to select halftone for graphics.
Page 89: Advanced Color Options/Simulation
Advanced Color Options/Simulation Simulation Profile Allows you to select color profiles for simulation. Match Paper Color Allows you to set Match Paper Color. CMYK Gray Treatment Allows you to select Simulation gray treatment. Hide Advanced Options Click this button to hide the Advanced Color Options pane and display the Color Options pane.
Page 90: Printer Features
Nearest Size and Scale If no paper tray contains paper of the specified size, the page is automati- cally enlarged or reduced and paper of the most appropriate size is selected. Manually Print on 2nd Side This feature must be set when you set paper already printed on the front side.
Page 91: Supply Levels
The Supply Levels section provides information for checking the amount of service life remaining on each consumable. The Supply Levels section appears when a printer is created on Mac OS X v10.5 with a Bonjour, IPP, LPD, Socket connection. The Supply Levels section may not appear depending on the applica- tion you use.
Page 92: Summary
Summary The Summary is used to check the currently selected print settings. Specifying Print Settings (Mac OS X 10.5)
Page 93: System Requirements For The Scanner Driver
Driver Before installing the scanner driver, make sure that your system meets the following system requirements. Computer Connecting the computer and printer Operating system Available disk space Supported languages System Requirements for the Scanner Driver Apple Macintosh computer installed with the following processor: –...
Page 94: Installing The Scanner Driver
Insert the software CD-ROM in the CD/DVD-ROM drive of your Macin- tosh. Double-click the CD icon on the desktop, Mac folder, Scanner Driver folder, and then double-click the EPSON AL-CX28 Scanner.pkg. The installer for the scanner driver starts up. Installing the Scanner Driver...
Page 95 Click Continue. Click Continue. Check the details of the license agreement, and then click Continue. Installing the Scanner Driver...
Page 96 Click Agree in the confirmation dialog box if you agree to the terms of the license. In the Select a Destination page, select the disk in which you wish to install the software, and then click Continue. Click Install in the Easy Install page. Installing the Scanner Driver...
Page 97 Enter the administrator user name and password in the Authenticate dia- log box, and then click OK. Installation starts. After the installation has been completed, click Close. This completes the installation of the scanner driver. Installing the Scanner Driver...
Page 98: Scanning From A Computer Application
– When connecting via network, select EPSON AL-CX28 Network. – When connecting with a USB cable, select EPSON AL-CX28. Specify the necessary scanner driver settings. For details on scanner driver setting, refer to “Specify the Scan Settings” on page 79.
Page 99: Uninstalling The Scanner Driver
Double-click EPSON AL-CX28 Uninstaller.app, which can be accessed by clicking Library, then Application Support, EPSON, then EPSON AL-CX28. Click Uninstallation. Click OK. Enter the administrator user name and password, and then click OK. Uninstallation begins. Uninstalling the Scanner Driver...
Page 100 Click OK. This completes the uninstallation of the scanner driver. Uninstalling the Scanner Driver...
Page 101: Specify The Scan Settings
Specify the Scan Settings Auto Scanning Mode Load Specify a saved settings file (dat file) for scanning. Save Save the current settings as a settings file (dat file). Default Return all settings to their defaults. Help icon Click to display the Help. About icon Click to display the software version information.
Page 102 Scale Shows the width and height of the area to be scanned. If the resolution is set at 1200 × 1200 dpi or higher, a setting larger than 100% cannot be specified. Scanning Mode Select Auto or Manual. When Manual is selected, settings can be speci- fied for Brightness/Contrast, Filter, Curves, Levels, Color Balance and Hue/Saturation.
Page 103: Manual Scanning Mode
Before/After (RGB) Move the pointer in the preview window to display the color tones at the pointer’s position before and after adjustments. Width/Height Displays the width and height for the selected area in the selected mea- surement units. Manual Scanning Mode When Manual is selected for Scanning Mode, various setting for scanning tone are available.
Page 104 Filter This function is used to sharpen the image or blur it for special effect. Curves This function is used to set the gamma of the image. In the graph, the X-axis represents the input level, and the Y-axis represents the output level.
Page 105 Levels This function is used to set the gamma value, increase shadow and high- light areas, enhance shadow value and reduce highlight value. The X-axis indicates the scaling value and the Y-axis indicates the pixel value. The shadow, gamma and highlight values for the scanned image can be adjusted by dragging the triangular pointer right below the X-axis.
Page 106 Hue/Saturation This function is used to set hue and saturation as well as the lightness of the image. Specify the Scan Settings...
Page 107: Troubleshooting
Symptom The setting in the saved presets are not applied. Media type error appears. The printer stops respond- ing. The printer is not detected using Rendezvous/Bon- jour. Checking the version num- ber of the printer driver and PPD file. The dialog box may appear unusual when selecting other manufacturer printer and back to AL-CX28.
Page 108 Symptom When printing 2 pages on a single sheet of paper, the pages are not centered on the paper. When printing multiple cop- ies of multiple pages on a single sheet of paper with Collated selected, the pages are printed continu- ously.
Page 109 Operation on Linux...
Page 110: System Requirements For The Printer Driver
Before installing the printer driver, make sure that your system meets the fol- lowing system requirements. Operating systems Connecting the computer and printer Network Available hard disk space Supported languages As an example, the descriptions of the operations for Red Hat 9.0 are provided in this chapter.
Page 111: Installing Ppd File From The Command Line
Before proceeding with the installation, be sure to exit all running applications. Root privileges are required in order to install ppd file. Copy the ppd file from the software CD-ROM to the “/usr/share/cups/ model” on the computer. A ppd file for each language is available in the corresponding “LinuxPPD/<language>”...
Page 112: Adding The Printer
After copying the PPD file, be sure to restart CUPS. Start up the Web browser. Enter the URL “http://localhost:631”, and then click Manage Printers. The CUPS Administration Web page appears. Click Add Printer. A pop-up window appears. Enter the user name and password for using root privi- leges, and then click OK.
Page 113 IP or Printer Hostname>[:port] Example: Using Printer IP - socket:/ /192.168.1.2:9100 Using printer Hostname - socket://Hostname:9100 Hostname may be substituted by IP Address, and Port is optional. Click Continue. Select EPSON, then click Continue. Adding the Printer...
Page 114 Select EPSON AL-CX28 PPD (en), then click Con- tinue. The following message appears. Adding the Printer...
Page 115: Specifying Printer Driver Settings
Displaying the Settings Page Start up the Web browser. Enter the URL “http://local- host:631”, and then click Manage Printers. Printer on localhost.local- domain window appears. Click Configure Printer. The printer driver settings page appears. Specifying Printer Driver Settings...
Page 116: Printer Driver Settings
Extra Parameters Brightness Color Separation Economy Print Edge Strength Manually Print on 2nd side Select whether or not to print on the back Nearest Size and Scale Resolution Select Color Settings Specifies the brightness of the image as -15%, -10%, -5%, 0%, 5%, 10%, or 15%. The default setting is 0%.
Page 117: General
General Parameters Collate Duplex Options Paper Sizes Paper Source Paper Type Specifying Printer Driver Settings Settings If On is selected, all pages in the documents are printed as sets of printouts. The default setting is Off. Specifies the duplex print binding position as Simplex, Long Edge, or Short Edge, if the duplex unit for the printer has been installed.
Page 118: Graphics Options
Graphics Options Parameters Graphics Edge Enhance- ment Graphics Halftone Graphics RGB Gray Treat- ment Graphics RGB Intent Graphics RGB Source Image Options Parameters Image Edge Enhancement Select whether image edges are empha- Image Halftone Image RGB Gray Treat- ment Settings Select whether graphic edges are empha- sized.
Page 119: Options Installed
Parameters Image RGB Intent Image RGB Source Options Installed Parameters Paper Source Unit Printer Memory Storage Specifying Printer Driver Settings Settings Specifies RGB intent for image as Vivid, Photographic, Relative Color, or Absolute Color. The default setting is Photographic. Specifies RGB source for image as None, sRGB, Adobe RGB (1998), Apple RGB, ColorMatch RGB, or Blue Adjust RGB.
Page 120: Simulation
Simulation Parameters CMYK Gray Treatment Match Paper Color Simulation Profile Text Options Parameters Text Edge Enhancement Text Halftone Text RGB Gray Treatment Text RGB Intent Text RGB Source Settings Specifies simulation gray treatment as Com- posite Black, Black and Gray, or Black Only.
Page 121: Banners
Banners Parameters Starting Banner Ending Banner Specifying Printer Driver Settings Settings Specifies the starting banner as none, clas- sified, confidential, secret, standard, topsecret, or unclassified. The default setting is none. Specifies the ending banner as none, classi- fied, confidential, secret, standard, topsecret, or unclassified.
Page 122: Printing A Document
The contents and available options that appear in the print dialog box may vary depending on the application being used. Example Using LPR Command With applications other than OpenOffice, the following print dialog box appears. Click Properties in the Print dialog box.
Page 123: Example Using Openoffice
The procedure for printing on Red Hat 9 with OpenOffice 1.0.2 is described below. The following procedure or some steps may be dif- ferent depending on the version of the operating system being used. First, use CX28PX.ppd to add the printer to the system. For details on adding a printer to the system, refer to “Installing PPD File From the Command Line”...
Page 124 Click Browse. In the Path, enter “/usr/ share/cups/model/”, then click Select. In the Selection of drivers list, select EPSON AL-CX28 OpenOffice PPD, then click Printing a Document...
Page 125 In the Please select a suit- able driver list, select EPSON AL-CX28 OpenOf- fice PPD, then click Next. Select the command to be displayed in the list, then click Next. Change the printer name. Click Finish. The Printer Administration dialog box appears again.
Page 126 Click Print in the File menu. Select the name of the printer specified in the Ope- nOffice printer settings. Click OK. The printer Print dialog box appears. Printing a Document...
Page 127: Checking Print Jobs
You can check the status of print jobs from a Web browser. Start up the Web browser. Enter the URL “http://local- host:631”. The CUPS Administration Web page appears. Click Manage Jobs. A list of the currently active print jobs appear. To check the status of completed print jobs, click Show Complete...
Page 128: Troubleshooting
Symptom The printer stops because of a paper size error or a paper type error. Printing does not continue with a custom paper size. Printing cannot be com- pleted correctly from OpenOffice or any other Office application (such as, Kword). When printing from Acrobat Reader, part of the image is printed in solid black or...
Page 129: Operation On Netware
Operation on NetWare...
Page 130: Printing With Netware
The printer controller supports the following environments. Network Printing in a NetWare Environment NetWare Version Protocol Used NetWare 4.x NetWare 5.x/6 For Remote Printer Mode With NetWare 4.x Bindery Emulation Before using bindery emulation, check that bindery emulation is com- patible with the NetWare server.
Page 131: For Print Server Mode With Netware 4.X Bindery Emulation
Printer Number: Specify the printer number (0-255). When 255 is specified, the set- ting is Auto. Restart the printer (turn the printer off, then on again). Use the NetWare server console to display the print server screen, and then check that the created printer is shown as Waiting for Job for the connected printer (0).
Page 132: For Netware 4.X Remote Printer Mode (Nds)
Use the NetWare server console to load MONITOR.NLM. Select the connection information and, in the active connection column, check that the created Pserver is connected. For NetWare 4.x Remote Printer Mode (NDS) Log on to NetWare as an administrator from a client computer. Start up NWadmin.
Page 133: For Netware 4.X/5.X/6 Print Server Mode (Nds)
To use the Print Server mode, the IPX protocol must be loaded on the NetWare server. Log on to NetWare as an administrator from a client computer. Start up NWadmin. Select either the organization or organizational unit container that offers the print service, and then click Print Services Quick Setup (non-NDPS) on the Tools menu.
Page 134: For Netware 5.X/6 Novell Distributed Print Service (Ndps)
(NDPS) Before specifying settings for NDPS, check that the NDPS broker and NDPS manager have been created and loaded. Also, before performing the following procedure, check that the TCP/ IP protocol has been set in the NetWare server, and check that the IP address has been set for this machine and that this machine is on.
Page 135: Setting Up A Client (Windows) Settings When Using The Netware Server
NetWare Server For Windows 2000, click the [Start] button, point to Settings, and then click Printers. For Windows Vista, click the [Start] button, select Control Panel, and then click Hardware and Sound to select Printers. For Windows XP/Server 2003, click the [Start] button, and then click Printers and Faxes.
Page 136 Printing With NetWare...
Page 137: Understanding The Network Setting Menu
Understanding the Network Setting Menu...
Page 138: Understanding The Network Setting Menu
Location within the Configuration Menu ADMIN. MANAGEMENT istrator. To display the settings for this menu, press UTILITY , and press select key to display and then select 6-digits administrator access code (default : 000000), and then press the Select key. ADMIN.
Page 139 NETWORK SETTING Menu BONJOUR DYNAMIC DNS RAW PORT DISABLE/ ENABLE BIDIRECTIONAL SNMP WSD PRINT IPSEC IP ADDR. FIL- ACCESS PER. ACCESS REFUSE...
Page 140 IPv6 NETWARE APPLETALK SPEED/DUPLEX IEEE802.1X E-MAIL SETTING SMTP SENDER NAME E-MAIL ADDRESS DEFAULT SUB- JECT NETWORK SETTING Menu DISABLE/ ENABLE AUTO SETTING LINK LOCAL GLOBAL ADDRESS GATEWAY ADDRESS...
Page 141 NETWORK SETTING Menu SMTP SERVER ADDR. SMTP PORT NO. SMTP TIMEOUT TEXT INSERT POP BEFORE DISABLE/ SMTP ENABLE POP3 SERVER ADDR. POP3 PORT NO. POP3 TIMEOUT POP3 ACCOUNT POP3 PASSWORD SMTP AUTH. DISABLE/ ENABLE SMTP USER NAME SMTP PASSWORD...
Page 142 LDAP SETTING DISABLE/ENABLE LDAP SERVER ADDR. LDAP PORT NO. SSL SETTING SEARCH BASE ATTRIBUTE SEARCH METHOD LDAP TIMEOUT MAX. SEARCH RESULTS AUTHENTICATION LDAP ACCOUNT LDAP PASSWORD DOMAIN NAME NETWORK SETTING Menu...
Page 143 CAMERA DIRECT USER SETTING SUPPLIES REPLACE NETWORK SETTING Menu...
Page 144: Accessing The Network Setting Menu
Use the following series of keystrokes at the printer to access the Network Setting menu options on your printer. This menu provides access to all of the configurable network items. Press this (until) the message window reads . . . key .
Page 145: Using The Network Setting Menu Options
If the printer is connected to a network, the following settings should be spec- ified. For details about each setting, contact your network administrator. To manually specify settings for the IP address, subnet mask and gateway, set When entering the IP address, do not enter a class D (between 224.0.0.0 and 239.255.255.255) or class E (between 240.0.0.0 and 255.255.255.255) IP address.
Page 146: Dns
Range Notes DNS AUTO SETTING Purpose Options Default SPECIFY Purpose Options Default Range (If IP ADDR. SETTING is set to SPECIFY) 0-255 for each xxx triplet Use the keypad to input each number; use the keys to move between triplets. A single digit number, such as “1”, cannot be input as “001”.
Page 147: Dhcp
Notes When using network scanning and when specifying the SMTP server as a host name instead of as an IP address, be sure to set the IP address of the DNS server. DHCP Purpose Options Default BOOTP Purpose Options Default NETWORK SETTING Menu A single digit number, such as “1”, cannot be input as “001”.
Page 148: Arp/Ping
ARP/PING Purpose Options Default HTTP Purpose Options Default Purpose Options Default The FTP server function is to be used only when the printer is being serviced. If the IP address cannot be acquired due to the DHCP or BOOTP address and if a fixed IP address cannot be acquired, the destination IP address of the ICMP (Ping) packet previously received by the machine can be acquired as the IP address of the machine.
Page 149: Smb
Purpose Options Default BONJOUR Purpose Options Default DYNAMIC DNS Purpose Options Default NETWORK SETTING Menu Select whether or not to enable SMB. If ENABLE is selected, SMB is enabled. If DISABLE is selected, SMB is disabled. DISABLE/ENABLE ENABLE Select whether or not to enable Bonjour. If ENABLE is selected, Bonjour is enabled.
Page 150: Ipp
Purpose Options Default RAW PORT DISABLE/ENABLE Purpose Options Default BIDIRECTIONAL Purpose Options Default Purpose Options Default Select whether or not to enable IPP. If ENABLE is selected, IPP is enabled. If DISABLE is selected, IPP is disabled. DISABLE/ENABLE ENABLE Select whether or not to enable Raw port. If ENABLE is selected, Raw port is enabled.
Page 151: Snmp
SNMP Purpose Options Default WSD PRINT Purpose Options Default IPSEC Purpose Options Default IP ADDR. FILTER ACCESS PER. Purpose Options Default NETWORK SETTING Menu Select whether or not to enable SNMP. If ENABLE is selected, SNMP is enabled. If DISABLE is selected, SNMP is disabled. DISABLE/ENABLE ENABLE Select whether or not to enable WSD print.
Page 152: Ipv6
ACCESS REFUSE Purpose Options Default IPv6 DISABLE/ENABLE Purpose Options Default AUTO SETTING Purpose Options Default LINK LOCAL Purpose GLOBAL ADDRESS Purpose GATEWAY ADDRESS Purpose Select whether or not to enable Access Refuse transmis- sions. When ENABLE is selected, Access Refuse transmissions are enabled.
Page 153: Netware
NETWARE Purpose Options Default APPLETALK Purpose Options Default SPEED/DUPLEX Purpose Options Default IEEE802.1X Purpose Options Default NETWORK SETTING Menu Select whether or not to enable NetWare. If ENABLE is selected, NetWare is enabled. If DISABLE is selected, NetWare is disabled. DISABLE/ENABLE DISABLE Select whether or not to enable AppleTalk.
Page 154 NETWORK SETTING Menu...
Page 155: Network Printing
Network Printing...
Page 156: Network Connection
Theory To connect your printer in a TCP/IP network environment, you must make sure that the internal net- work addresses in the printer have been set. In many cases, you have to enter only a unique IP address. However, you may also have to enter a subnet mask and/or a gateway (router) address, depend-...
Page 157: Making The Connection
Ethernet Interface An RJ45 connector can be used as the Ethernet interface for this printer. When connecting your printer to an Ethernet network, the tasks you perform depend on how you plan to set the printer’s IP (Internet Protocol) address. IP Address—A unique identifier for each device on a TCP/IP network.
Page 158: Setting The Address Manually
Setting the Address Manually You may also manually change the printer’s IP address, subnet mask, and gateway by using the following instructions. When the IP address is changed, add a new port or reinstall the printer driver. CAUTION You should always notify your network’s administrator before changing the printer’s IP address.
Page 159 IP ADDRESS Use the keypad to input each number. A single digit number, such as “1”, cannot be input as “001”. Align the num- ber on the left and input “1” as “1 _ _”. Use the * and ) keys to move between triplets.
Page 160 Use the keypad to input each number. A single digit number, such as “1”, cannot be input as “001”. Align the num- ber on the left and input “1” as “1 _ _”. Use the * and ) keys to move between triplets.
Page 161: Network Printing
Network terms are described below: Apple Talk Bonjour BOOTP Dynamic DNS DHCP HTTP IEEE802.1X IPsec IPv6 IPX/SPX LDAP LPD/LPR POP Before SMTP Port 9100 SMTP SMTP Authentication SNMP TCP/IP WSD print This section contains descriptions of these network printing terms. AppleTalk A generic name for the protocol suite developed by Apple Computer for com- puter networking.
Page 162: Bonjour
Bonjour Macintosh network technology for automatically detecting devices connected to the network and for specifying settings. Previously called “Rendezvous”, the name was changed to “Bonjour” starting with Mac OS X v10.4. BOOTP BOOTP (Bootstrap Protocol) is an Internet protocol that enables a diskless workstation to discover (1) its own IP address, (2) the IP address of a BOOTP server on the network, and (3) a file that can be loaded into memory to boot the workstation.
Page 163: Ftp
Abbreviation for File Transfer Protocol. A protocol for transferring files over the Internet or an intranet on the TCP/IP network. HTTP HTTP (HyperText Transfer Protocol) is the underlying protocol used by the World Wide Web. It defines how messages are formatted and transmitted, and what actions web servers and browsers should take in response to vari- ous commands.
Page 164: Ipx/Spx
IPX/SPX IPX/SPX (Internetwork Packet Exchange/Sequenced Packet Exchange) is a networking protocol developed by Novell. It was used mainly in Netware envi- ronments as the general LAN protocol, where TCP/IP has become wide- spread. LDAP On a TCP/ IP network, such as the Internet or an intranet, LDAP (Lightweight Directory Access Protocol) is a protocol that is used to access a database for managing environment information and the e-mail addresses of network users.
Page 165: Slp
Traditionally, in order to locate services on the network, users had to supply the host name or network address of the machine providing the desired ser- vice. This has created many administrative problems. However, SLP (Service Location Protocol) simplifies the discovery and use of network resources such as printers by automating a number of network ser- vices.
Page 166: Smtp Authentication
SMTP Authentication Specification that adds user authentication functions to SMTP, which is used for sending E-mail. When sending E-mail, authentication of the user is performed by the SMTP server, and the E-mail message is permitted to be sent only if authentication was successful.
Page 167: Printing Via Ipp (Internet Printing Protocol)
You must have administrator privileges in order to install the printer driver. If the User Account Control window appears when installing on Windows Vista, click the Allow button or the Continue button. Adding an IPP Port using the software CD-ROM For IPP printing, specify the network setting.
Page 168 [Update List]: To update the printer information, click this button. Select Internet Printing as the printing method from the pull-down list, and then click Next. In the Confirm Installation Settings dialog box, click Install. [Installation Settings]: To change the settings, click this button. Network Printing...
Page 169: Adding An Ipp Port Using Add Printer Wizard - Windows Server 2003/Xp/2000
Click Finish. This completes the installation of the printer driver. Adding an IPP Port using Add Printer Wizard – Windows Server 2003/XP/2000 For Windows Server 2003/XP: Click Start, select Printers and Faxes, and then click Add Printer. For Windows 2000: Click Start, point to Settings, click Printers, and then click Add Printer.
Page 170 In the URL field in the next dialog box enter the printer’s network path- name in one of the following formats and then choose Next: http://ipaddress/ipp http://ipaddress:80/ipp http://ipaddress:631/ipp Windows Server 2003/XP If your system cannot connect to the printer, the following message appears: Windows Server 2003/XP—“Windows cannot connect to the printer.
Page 171: Adding An Ipp Port Using Add Printer Wizard - Windows Vista
Adding an IPP Port using Add Printer Wizard Vista Click Start, click Control Panel, and then click Printers. Click Add a printer. In the dialog box click Add a network, wireless or Bluetooth printer. In the dialog box, click The printer that I want isn’t listed. Network Printing Windows...
Page 172 In the URL field in the next dialog box enter the printer’s network path- name in one of the following formats and then choose Next: http://ipaddress/ipp http://ipaddress:80/ipp http://ipaddress:631/ipp If your system cannot connect to the machine, the following message appears: “Windows cannot connect to the printer. Make sure that you have typed the name correctly, and that the printer is connected to network.”...
Page 173: Printing Via Web Service Print Function
In Windows Vista, printers on the network that support Web Service print can be detected and installed. You must have administrator privileges in order to install the printer driver. Before proceeding with the installation, be sure to exit all running applications.
Page 174 Click Locate and install driver software (recommended). Click Browse my computer for driver software (advanced). Network Printing...
Page 175: Adding A Printer Using Add Printer Wizard
Click Browse, locate the directory on the CD where the printer driver files are located (for example : Windows\Printer Driver\color\ Drivers\Win_x86\PS\English), and then click OK. Click Next. Click Close. Adding a printer using Add Printer Wizard To use Web Service print, check that Network discovery is enabled in Network and Sharing Center on the computer.
Page 176 In the dialog box, click Add a local printer. Click Create a new port, and then select Standard TCP/IP port. Click Next. Network Printing...
Page 177 Select Web Services Device and type the IP address for the printer, and then click Next. The Found New Hardware Wizard dialog box appears. Click Locate and install driver software (recommended). Network Printing...
Page 178 Click Browse my computer for driver software (advanced). Click Browse, locate the directory on the CD where the printer driver files are located (for example : Windows\Printer Driver\color\ Drivers\Win_x86\PS\English), and then click OK. Click Next. Click Close. Network Printing...
Page 179 Click Next. Select whether the printer driver is to be shared, and then click Next. Network Printing...
Page 180 Click Finish. This completes the installation of the printer driver. Network Printing...
Page 181: Troubleshooting
Symptom Some client functions are not available with the Point and Print feature when the server is running Windows Vista/XP/Server 2003/2000 and the client computer is running Windows Vista/XP/ Server 2003/2000. Troubleshooting Action Install the printer driver directly on the client computer.
Page 182 Troubleshooting...
Page 183: Using Web-Based Epsonnet Config
Using Web-Based EpsonNet Config...
Page 184: About Web-Based Epsonnet Config
This chapter provides information on Web-based EpsonNet config, an HTTP (HyperText Transfer Pro- tocol)-based web page that resides in your printer and that you can access using your Web browser. This page gives you instant access to printer status and the most fre- quently used printer configuration options.
Page 185 You cannot access Web-based EpsonNet config using a local (USB) connection. About Web-Based EpsonNet Config...
Page 186: Setting Up The Printer Web
Setting up the printer web page to run on your network involves two basic steps: Determining the name or address of your printer Setting up the “no proxy” preferences in your browser software Determining the Printer Name The printer web page can be accessed in two ways: Through the assigned name of the printer—This name comes from the IP host table (the filename is hosts) on the computer system and is usually assigned by the system administrator (for example, AL-CX28).
Page 187: Internet Explorer (Version 6.0 For Windows)
Our examples represent the IP address of the printer with xxx.xxx.xxx.xxx. Always enter your printer’s IP address without lead- ing zeros. For example, 192.168.001.002 should be entered as 192.168.1.2. Internet Explorer (version 6.0 for Windows) Start Internet Explorer. From the Tools menu choose Internet Options.
Page 188: Netscape Navigator (Version 7.1)
Netscape Navigator (version 7.1) Start Netscape Navigator. From the Edit menu choose Preferences. Select the Advanced/Proxies directory from the left pane of the dialog box. Select the Manual Proxy Configuration radio button. In the No Proxy for: text box, type a comma after the last entry, and then type the printer name or the IP address of your printer.
Page 189: Understanding The Web-Based Epsonnet Config Window
Config Window The illustration below identifies the navigation and configuration areas of the windows that you see in Web-based EpsonNet config windows. Click to logout of current mode Links to subtopics Navigation Selecting the main topic and subtopic displays the configuration area for the printer options (parameters) associated with your selections.
Page 190: Current Status
The current status of the printer is displayed at the top of all Web-based EpsonNet config windows. The icon displays the type of status being dis- played. Icon Status Ready Warning Error Fatal Error The printer must be Understanding the Web-Based EpsonNet Config Description Examples The printer is online...
Page 191: Logging On To Web-Based Epsonnet Config
Login Page User authentication and language settings can be specified by using Web-based EpsonNet config. In order to perform authentication, you must log on in Administrator Mode. For details on authentication, refer to “Authentica- tion” on page 203 and “User Authentication” on page 295. A total of 100 users, including the administrator, can be logged on to Web-based EpsonNet config at the same time from client computers.
Page 192: Language Setting
If necessary, the display language used for EpsonNet Config can be changed. Public User Mode In Public User Mode, you can view configuration settings but not change them. Select Public User. Click the Log in button. Registered User Mode In Registered User Mode, you can view configuration settings but not change them.
Page 193: Administrator Mode
Click the Log in button. Administrator Mode In order to change any configuration settings through Web-based EpsonNet Config, you must first enter Administrator Mode. Select Administrator. Click the Log in button. Type the password in the Admin Password text box. Default password is set to “administrator”, however, once you have logged on in Administrator Mode, the password can be specified in the System - Admin Password window.
Page 194: Viewing Printer Status
System Page On this page you find printer status and current configuration settings, printer identification, and links to all other web pages. All of the information displayed on the System page is read only. Device Information Summary The System - Device Information - Summary window provides the follow- ing information.
Page 195 Paper Source The System - Device Information - Paper Source window provides the fol- lowing information. Item Paper Source Paper Size Paper Type Paper Detail button Paper Source (Detail) The System - Device Information - Paper Source - Detail window provides the following information.
Page 196 Storage The System - Device Information - Storage window provides the following information. Item Total Used Remaining Description Displays the total amount of space on the hard disk. If no optional storages are installed, “-” are dis- played. Displays the amount of space on the hard disk that is used.
Page 197 Interface Information The System - Device Information - Interface Information window provides the following information. Item Protocol TCP/IP Information IPv6 Bonjour FTP TX FTP Server LDAP Dynamic DNS Viewing Printer Status Description If Enable is displayed, TCP/IP is enabled. If Disable is selected, TCP/IP is disabled. If Enable is displayed, IPv6 is enabled.
Page 198 Item RAW Port SMTP SNMP WSD Print AppleTalk NetWare IEEE802.1x Description If Enable is displayed, RAW Port is enabled. If Disable is selected, RAW Port is disabled. If Enable is displayed, SLP is enabled. If Disable is selected, SLP is disabled. If Enable is displayed, SMTP is enabled.
Page 199 Item Network Type Information Ethernet Speed IP Address IPv6 Link Local Address IPv6 Global Address MAC Address Host Name Print Server Name (NetWare) Printer Name (AppleTalk) Current Zone Name (AppleTalk) Bonjour Name WSD Printer Name Viewing Printer Status Description Identifies the type of network interface installed on the printer (Ethernet 10Base-T/ 100Base-TX/1000Base-T).
Page 200: Counter
Consumables The System - Device Information - Consumables window provides the fol- lowing information. Item Consumables Status TYPE Counter The System - Counter window provides the following information. Item Description Total Print Indicates the total number of all printed pages. Normalized The number of printed pages is displayed calculated in terms Total Faces...
Page 201: Online Assistance
Displays the web site address for assistance. Information Product Help Displays the help web site address for machine assistance. Corporate Displays the Epson corporate web site address. Supplies and Displays the web site address where you can purchase Accessories machine supplies and accessories.
Page 202: User Authentication
User Authentication This page appears only when logged on to Registered User Mode. User Password Change The password for the user who is logged on can be changed from the Sys- tem - User Authentication - User Password Change page. Item User Name Current Password...
Page 203: Job Page
Item Output Permission Information Job Page This page allows you to view the status of current print jobs. Active Job List The Job - Active Job List window provides the following information for up to 45 print jobs: Item Job Number User Name File Name Job Status...
Page 204: Done Job List (Detail)
Item Detail button Done Job List (Detail) The Job - Done Job List - Detail window provides the following information for the selected job: Item Job Number User Name File Name Delivery Type Create Time End Time Result Back button Description Displays a screen containing details.
Page 205: Print Page
This page allows you to check the settings for printing when there is no PDL printer driver. Default Settings General Settings The Print - Default Settings - General Settings window provides the follow- ing information. Item Paper Source Duplex Output Tray Copies Paper Size Width...
Page 206 Paper Source Settings The Print - Default Settings - Paper Source Settings window provides the following information. Item Tray1 Tray2 Tray3 This item appears only if an optional lower feeder unit is installed. Description Paper Size Indicates the setting for the size of paper loaded into Tray 1.
Page 207 Item Any Tray Tray1 Setting Tray2 Tray3 This item appears only if an optional lower feeder unit is installed. Tray Chaining Viewing Printer Status Description Paper Size Indicates whether Any Paper Size setting for Tray1 is enabled or disabled. Paper Type Indicates whether Any Media Type setting for Tray1 is enabled or disabled.
Page 208 Tray Mapping Settings The Print - Default Settings - Tray Mapping Settings window provides the following information. Item Tray Mapping Mode Logical Tray 0-9 PCL Settings The Print - Default Settings - PCL Settings window provides the following information. Item Font Number Symbol Set Lines Per Page...
Page 209 Print Quality Settings The Print - Default Settings - Print Quality Settings window provides the following information. Item Print Color Mode Quality Set- tings Color Separation Brightness Halftone (Image/Text/ Graphics Printing) Edge Enhancement (Image/Text/ Graphics Printing) Edge Strength Economy Print Mode Shows the setting for whether or not Contrast Settings Image/Text/Graphics...
Page 210 Item PS Settings Image/Text/Graphics Printing (RGB Source) Image/Text/Graphics Printing (RGB Intent) Image/Text/Graphics Printing (RGB Gray Treatment) Image/Text/Graphics Printing (Destination Profile) Simulation (Profile) Simulation (Intent) Simulation (CMYK Gray Treatment) Calibration Tone Calibration Settings Cyan/Magenta/ Yellow/ Black Density (Highlight) Cyan/Magenta/ Yellow/ Black Density (Middle) Cyan/Magenta/ Yellow/ Black Density...
Page 211 Camera Direct Settings The Print - Default Settings - Camera Direct Settings window provides the following information. Item Camera Direct Print Image Quality Tray1 Paper Size Tray1 Media Type Tray2 Paper Size N-up Layout Viewing Printer Status Description If Enable is indicated, camera direct printing is enabled. If Disable is indicated, camera direct printing is disabled.
Page 212: Font/Form
Font/Form PCL Font The Print - Font/Form - PCL Font page allows you to check the list of PCL fonts that the printer manages. Item Number Font Name Source PS Font The Print - Font/Form - PS Font page allows you to check the list of Post- Script fonts that the printer manages.
Page 213: Report Types
Form Overlay The Print - Font/Form - Form Overlay page allows you to check the list of form overlays that the printer manages. Item Number File Name Source Color Profile The Print - Font/Form - Color Profile page allows you to check the list of color profiles that the printer manages.
Page 214: Direct Print
Direct Print The Print - Direct Print page allows you to print a file directly from the printer without starting up the application. This page appears only if an optional hard disk drive is installed This page appears when both Public Access (in the Network - Authentication - User Authentication page) and Print (in the Sys- tem - Authentication - Default Permission Settings) are set to Allow.
Page 215: Scan Page
This page allows you to view the currently specified dial settings. Favorite The Scan - Favorite window provides the following information. Item Description Displays the number in the Favorite list. Name Displays the destination name of the selected address num- ber.
Page 216: Configuring The Printer
Configuring the Printer In order to make any configuration changes through Web-based EpsonNet Config, you must first enter Administrator Mode. See “Administrator Mode” on page 171 for instructions on logging into Administrator Mode. System Page This page allows you to configure several user- and printer-specific items. Configuring the Printer...
Page 217: Device Information
Device Information Summary The System - Device Information - Summary window provides the follow- ing information. Item Copier RAM Printer RAM Duplex Paper Source Output Tray Network Paper Source The System - Device Information - Paper Source window provides the fol- lowing information.
Page 218 Paper Source (Detail) The System - Device Information - Paper Source - Detail window provides the following information. Item Paper Source Paper Size Paper Type Capacity Paper Back button Output Tray The System - Device Information - Output Tray window provides the fol- lowing information.
Page 219 Interface Information The System - Device Information - Interface Information window provides the following information. Item Protocol TCP/IP Information IPv6 Bonjour FTP TX FTP Server LDAP Dynamic DNS Configuring the Printer Description If Enable is displayed, TCP/IP is enabled. If Disable is selected, TCP/IP is disabled. If Enable is displayed, IPv6 is enabled.
Page 220 Item RAW Port SMTP SNMP WSD Print AppleTalk NetWare IEEE802.1x Description If Enable is displayed, RAW Port is enabled. If Disable is selected, RAW Port is disabled. If Enable is displayed, SLP is enabled. If Disable is selected, SLP is disabled. If Enable is displayed, SMTP is enabled.
Page 221 Item Network Type Information Ethernet Speed IP Address IPv6 Link Local Address IPv6 Global Address MAC Address Host Name Print Server Name (NetWare) Printer Name (AppleTalk) Current Zone Name (AppleTalk) Bonjour Name WSD Printer Name Consumables The System - Device Information - Consumables window provides the fol- lowing information.
Page 222: Counter
Item TYPE Counter The System - Counter window provides the following information. Item Total Print Normalized Total Faces Counter Scan Counter Tray Counter Paper Size Counter Paper Type Counter Application Counter Description Identifies the type of Toner Cartridge. Starter, Standard, High Description Indicates the total number of all printed pages.
Page 223: Online Assistance
Sets the help web site address for printer assis- tance. Range: Up to 127 characters Default: http://www.epson.com Sets the Epson corporate web site address. Range: Up to 127 characters Default: http://www.epson.com Sets the web address where you can purchase printer supplies and accessories.
Page 224: Import/Export
Import/Export This page appears only if an optional hard disk drive is installed. Job Log This page appears when Job Log (in the System - Machine Settings page) is set to Enable. The System - Import/Export - Job Log window allows you to configure the following items.
Page 225: Authentication
User Information This page appears when User Authentication (in the Network - Authentication - User Authentication page) is set to On. The System - Import/Export - User Information window allows you to con- figure the following items. Item Import Text Box Browse button Import button Export button...
Page 226 User Registration This page appears only if User Authentication (in the Network - Authentication - User Authentication page) is set to On. The System - Authentication - User Registration window allows you to configure the following items. Item Search for Number User Name Edit icon Delete icon...
Page 227 User Registration (New Registration) The System - Authentication - User Registration - New Registration win- dow allows you to configure the following items. Item User Registration User Name Specify the name of the new user. User Password Retype User Password Function Print Permission...
Page 228: Date/Time
Item Cancel button Date/Time Manual Settings The System - Date/Time - Manual Settings window allows you to configure the following items: Item Year Month Hour Description Click to cancel the entered data and return to the System - Authentication - User Registration page.
Page 229 Item Minute Time Zone Apply button Clear button Configuring the Printer Description Specifies the minute for the printer’s internal clock. Range: 0-59 Default: 0 Configuration Menu Equivalent: UTILITY - ADMIN. MANAGEMENT - USER SETTING - DATE&TIME Specifies the time zone for sending e-mail notifications.
Page 230 Time Adjustment Settings The System - Date/Time - Time Adjustment Settings window allows you to configure the following items: Item Time Adjustment NTP Server Address Port Number Time Zone Adjustment Time Apply button Clear button Description Select whether or not the time is automatically adjusted with NTP.
Page 231: Admin Password
Admin Password The System - Admin Password window allows you to configure the follow- ing items: Item Current Password New Password Retype New Password Verifies the new password typed in the New Pass- Apply button Clear button If you forget the new passward you’ve assigned, contact Technical Support.
Page 232: Save Settings
Save Settings From the System - Save Settings window, the machine settings can be saved as a file on the computer being used. In addition, the saved settings file can be read by the machine. The following settings are not saved in the file: - ADDRESS books Item Save...
Page 233: Machine Settings
Machine Settings The System - Machine Settings window allows you to configure the follow- ing items: Item Administrator Name Device Name Device Location Device Information Do Startup Page Auto Continue Configuring the Printer Description Specifies the name of the administrator for the printer.
Page 234 Item Hold Job Timeout Energy Saver Time Grayscale Page Description Specifies the length of time until print jobs saved on the hard disk are deleted. If Disable is selected, print jobs are not deleted at a specific time. Choices: Disabled, One Hour, Four Hours, One Day, One Week Default: Disabled Configuration Menu Equivalent:...
Page 235 Item Job Log Apply button Clear button Configuring the Printer Description Select whether or not the Job Log function is used. Choices: Enable, Disable Default: Disable This menu item appears only if an optional hard disk drive is installed. Applies the configuration settings for this window. Resets all configuration settings to previous values.
Page 236: Rom Version
ROM Version The System - ROM Version window provides the following information. Item Engine ROM Version Controller ROM Ver- sion PS/PCL Controller ROM Version Boot ROM Version PS/PCL Boot ROM Version Maintenance Clear Settings The System - Maintenance - Clear Settings page allows you to reset the printer settings to its factory defaults.
Page 237: Status Notification Settings
Status Notification Settings The System - Status Notification Settings window allows you to configure the following items: Item IP Address IPX Address Configuring the Printer Description Notification Specify the IP address of the SNMP trap Address receiver. An IPv4 or IPv6 address or a host name can be specified.
Page 238 Item Email Address Alert Description Email Notice Specifies whether or not a notification is sent by e-mail when a warning occurs in the printer. Choices: Enable, Disable Default: Enable Notification Specifies the e-mail address where the Address notification is sent. Range: Up to 320 characters Default: [Blank] Paper Empty...
Page 239 Item Apply button Clear button Configuring the Printer Description Operator Call Specifies whether or not a notification is sent when the operator must be called. Choices: Enable, Disable Default: Enable Service Call Specifies whether or not a notification is sent to the service representative when a condition occurs that requires servicing.
Page 240: Job Page
This page allows you to view the status of current print jobs. Active Job List The Job - Active Job List window provides the following information for up to 45 print jobs. Item Job Number User Name File Name Job Status Create Time Delete button Done Job List...
Page 241: Done Job List (Detail)
Done Job List (Detail) The Job - Done Job List - Detail window provides the following information for the selected job. Item Job Number User Name File Name Delivery Type Create Time End Time Result Back button Configuring the Printer Description Displays the print job identification number.
Page 242: Print Page
This page allows more detailed printer settings to be specified. Local Interface The Print - Local Interface window allows you to configure the following items: Item I/O Timeout Apply button Clear button Description Specifies the reception timeout (in seconds). Range: 5-300 Default: 15 Applies the configuration settings for this window.
Page 243: Default Settings
Default Settings General Settings The Print - Default Settings - General Settings window allows you to con- figure the following items: Item Paper Source Duplex Output Tray Copies Configuring the Printer Description Selects default language to be selected. Choices: Auto, PCL, PS Default: Auto Configuration Menu Equivalent: PS/PCL PRINT - SYS DEFAULT MENU...
Page 244 Item Paper Size Width Length Description Specifies the default setting for the size of paper. Choices: Letter, Legal, Executive, A4, A5, A6, B5 (JIS), B6, Government Letter, State- ment, Folio, SP Folio, UK Quarto, Foolscap, Government Legal, 16K, Photo 4x6, Kai 16, Kai 32, Envelope C6, Enve- lope DL, Envelope Monarch, Envelope Chou #3, Envelope Chou #4, B5 (ISO), Envelope Com10, Japanese Postcard,...
Page 245 Item Paper Type Collate Apply button Clear button Configuring the Printer Description Specifies the default setting for the type of paper. Choices: Plain Paper, Recycled, Thick 1, Thick 2, Label, Transparency, Envelope, Postcard, Letterhead, Glossy 1, Glossy 2 Default: Plain Paper Configuration Menu Equivalent: PS/PCL PRINT - SYS DEFAULT MENU - PAPER - DEFAULT PAPER - PAPER...
Page 246 Paper Source Settings The Print - Default Settings - Paper Source Settings window allows you to configure the following items: Item Tray1 Description Paper Size Specifies the setting for the size of the paper loaded into Tray 1. Choices: Letter, Legal, Executive, A4, A5, A6, B5 (JIS), B6, Government Letter, Statement, Folio, SP Folio, UK Quarto, Foolscap,...
Page 247 Item Tray2 Configuring the Printer Description Length Specifies the paper length when Paper Size is set to Custom Size. Range: 5.83 - 14.00 (inch) / 148 - 356 (mm) Default: 11.69 inch/297 mm Configuration Menu Equivalent: UTILITY - PAPER SETUP - TRAY1 PAPER Paper Type Specifies the setting for the type of the...
Page 248 Item Tray3 This item appears only if an optional lower feeder unit is installed. Description Width Specifies the paper width when Paper Size is set to Custom Size. Range: 3.63 - 8.50 (inch) / 92 - 216 (mm) Default: 8.27 inch/210 mm Configuration Menu Equivalent: UTILITY - PAPER SETUP - TRAY2 PAPER...
Page 249 Item Any Tray Tray1 Setting Tray2 Configuring the Printer Description Paper Size Select whether or not the Any Paper Size setting is selected for Tray 1. Choices: Off, Any Default: Off Configuration Menu Equivalent: PS/PCL PRINT - PAPER MENU - ANY TRAY SETTING - TRAY1 PAPER - TRAY1 ANY SIZE Paper Type...
Page 250 Item Tray 3 This item appears only if an optional lower feeder unit is installed. Tray Chaining Apply button Clear button Tray Mapping Settings The Print - Default Settings - Tray Mapping Settings window provides the following information. Item Tray Mapping Mode Description Paper Type Select whether or not the Any Media Type...
Page 251 Item Logical Tray 0-9 Apply button Clear button PCL Settings The Print - Default Settings - PCL Settings window allows you to configure the following items: Item Font Number Symbol Set Configuring the Printer Description Select the tray that is used for printing when a print job is received from another manufacturer’s printer driver.
Page 252: Point Size
Item Lines Per Page Font Point Size Font Pitch Size CR/LF Mapping Apply button Clear button Description Selects how many lines are in a page in PCL lan- guage. Range: 5 - 128 Default: 60 Configuration Menu Equivalent: PS/PCL PRINT - SYS DEFAULT MENU - EMULATION - PCL - LINES PER PAGE Sets the font size in the PCL language.
Page 253 PS Settings The Print - Default Settings - PS Settings window allows you to configure the following items: Item Wait Timeout PS Protocol Print to PS Error Apply button Clear button Configuring the Printer Description Sets Postscript timeout. “0” means that no time-out control is effective.
Page 254 Print Quality Settings The Print - Default Settings - Print Quality Settings window allows you to configure the following items: Item Print Color Mode Quality Settings Color Separation If On is selected, color separation is per- Brightness Description If Color is selected, the pages are printed in full color.
Page 255 Item Halftone (Image/ Text/Graphics Printing) Edge Enhance- ment (Image/Text/ Graphics Printing) Configuring the Printer Description Specifies how halftones are reproduced. If Line Art is selected, halftones are repro- duced with high precision. If Detail is selected, halftones are repro- duced with detail. If Smooth is selected, halftones are repro- duced with smoothness.
Page 256 Item Edge Strength Economy Print Mode Description Select the desired amount that edges are emphasized. If Off is selected, the edges are not empha- sized. If Low is selected, the edges are slightly emphasized. If Middle is selected, the edges are empha- sized by an average amount.
Page 257 Item Contrast Settings Image/Text/ Graphics Printing (Source) Image/Text/ Graphics Printing (Intent) Image/Text/ Graphics Printing (Gray Treatment) Configuring the Printer Description Specifies the contrast of the image. Choices: +15%, +10%, +5%, 0, -5%, -10%, -15% Default: 0 Configuration Menu Equivalent: PS/PCL PRINT - QUALITY MENU - PCL SETTING - CONTRAST Specifies the color space for RGB data.
Page 258 Item Image/Text/ Settings Graphics Printing (RGB Source) Image/Text/ Graphics Printing (RGB Intent) Image/Text/ Graphics Printing (RGB Gray Treat- ment) Description Specifies the color space for RGB data. Choices: Device Color, sRGB, AppleRGB, AdobeRGB1998, ColorMatchRGB, BlueAdjustRGB, Custom Profile Default: sRGB Configuration Menu Equivalent: PS/PCL PRINT - QUALITY MENU - PS SETTING - IMAGE/ TEXT/GRFX.
Page 259 Item Image/Text/ Graphics Printing (Destination Pro- file) Simulation (Pro- file) Simulation (Intent) Simulation (CMYK Gray Treatment) Configuring the Printer Description Specifies the ICC destination profile to be used for printed output. Choices: Auto, Custom Profile Default: Auto Configuration Menu Equivalent: PS/PCL PRINT - QUALITY MENU - PS SETTING - IMAGE/ TEXT/GRFX.
Page 260 Item Calibration Tone Calibration Settings Cyan/Magenta/ Yellow/Black Den- sity (Highlight) Cyan/Magenta/ Yellow/Black Den- sity (Middle) Cyan/Magenta/ Yellow/Black Den- sity (Shadow) Apply button Clear button Description If On is indicated, image adjustments are applied. If Off is indicated, image adjustments are not applied.
Page 261 Camera Direct Settings The Print - Default Settings - Camera Direct Settings allows you to config- ure the following items: Item Camera Direct Print Image Quality Tray1 Paper Size Configuring the Printer Description If Enable is selected, camera direct printing is enabled. If Disable is selected, camera direct printing is disabled.
Page 262: Download Font/Form
Item Tray1 Media Type Tray2 Paper Size N-up Layout Apply button Clear button Download Font/Form This page appears only if an optional hard disk drive is installed. Description Select the media type when using Tray 1 with camera direct printing. Choices: Plain Paper, Label, Thick 1, Thick 2, Glossy 1, Glossy 2, Postcard Default: Plain Paper...
Page 263 PS Font The printer must have an optional hard disk drive to use the PS Font parameters described below. The Print - Download Font/Form - PS Font window allows you to configure the following items: Item Download PS Font Delete PS Font Delete button Form Overlay The Print - Download Font/Form - Form Overlay window allows you to...
Page 264 Item Delete Form Overlay Delete button Color Profile The Print - Download Font/Form - Color Profile window allows you to con- figure the following items: Item Download Color Profile Delete Color Profile Description Check box Select the check box of the form overlay file to be deleted, and then click Delete button to delete the selected form overlay from the printer.
Page 265: Scan Page
Item Delete button Scan Page On the Scan page, settings for the destination information to be registered in the machine and the scan transmission settings can be specified. Favorite The Scan - Favorite page, settings for address and group can be specified. Item Name Address...
Page 266: Address Setting
Item Apply button Clear button Cancel button From Group The Scan - Favorite - Group List window allows you to configure the follow- ing items: Item Radio button Name Address Apply button Clear button Cancel button Address Setting The Scan - Address Setting window, settings for address can be specified. Item Address List Description...
Page 267 Item Name Address Delete button Configuring the Printer Description Displays the number in the address list. Click an address number where no destination is registered to add a des- tination from the Address Registration page. If a destination is already registered with the address number that is clicked, the registered information can be edited.
Page 268 Address Registration The Scan - Address Setting - Address Registration window, select the type of Address destination to be added. Item Speed Registration From the drop-down list, select the type of address des- Apply button Clear button E-mail Destination The Scan - Address Setting - E-mail Destination window allows you to configure the following items: Item Destination Name Specify the name of the destination.
Page 269 LDAP Search The Scan - Address Setting - LDAP Search window allows you to configure the following items: Item LDAP Search LDAP Search String Apply button Clear button When an LDAP server is used, the correct search results may not be retrieved when the search is performed from a server using anony- mous access.
Page 270 For FTP Server The Scan - Address Setting of address registration (for FTP server) window allows you to configure the following items: The Network - FTP - Client screen, set to “Enable” from Send when sending to FTP server. Also, when sending via proxy server, specify the proxy server setting.
Page 271 Item Basic Color Setting Setting Resolution Mode Attachment file format Coding method Scan area Configuring the Printer Description Select the color tone to be used. Choices: BW Only, Color or Gray Default: Color or Gray Select the resolution of the scanner. Choices: 150 x 150, 300 x 300, 600 x Default:...
Page 272 Item E-mail Enable Notification Notification Notification Address Register the destination e-mail address of Account Anonymous/Private Information Site User Name Password Confirm Apply button Clear button Description Select whether or not e-mail notifications are to be sent after a transmission to an FTP server is completed.
Page 273 For SMB server The Scan - Address Setting of address registration (for SMB server) window allows you to configure the following items: The Network - SMB screen, set to “Enable” from Send when sending to SMB server. For details, refer to “SMB” on page 288. Item File Destination Name...
Page 274 Item Attachment file format Coding method Scan area E-mail Noti- Enable Notification fication Notification Address Register the destination e-mail address of Description Select the desired file format. Choices: TIFF, PDF, JPEG Default: If “Color Setting” is set to “BW Only”, “JPEG” cannot be selected. Select the coding method.
Page 275 Item Account Anonymous/Private Information Site User Name Password Confirm Apply button Clear button Configuring the Printer Description Select the type of account used for log- ging into the FTP server. If “Anonymous” is selected, log in with “Anonymous” as the account name and “guest”...
Page 276: Group Setting
Group Setting On the Scan - Group Setting page, settings for group can be specified. Item Name Address Delete button Group Registration (Destination type) In the Scan - Group Setting - Group Registration window, select the type of group destination to be added. Item Group Registration From the drop-down list, select the type of group desti- Apply button...
Page 277 Group Registration (Add Destinations) The Scan - Group Setting - Group Registration window allows you to con- figure the following items: Item Group Name Address Index Address 001-020 Address 021-040 Address 041-060 Address 061-080 Address 081-100 Address 101-120 Address 121-140 Address 141-160 Address 161-180 Address 181-200...
Page 278: User Setting
User Setting In the Scan - User Setting window allows you to configure the following items: Item Country Setting Preset Zoom Apply button Clear button Description Displays the country where this machine is installed. Configuration Menu Equivalent: UTILITY - ADMIN. MANAGEMENT - USER SETTING - Country SETTING Select whether the zoom method is aligned on inch paper sizes or metric sizes.
Page 279: Downloading/Uploading Destination List
Downloading/Uploading Destination List In the Scan - Downloading/Uploading Destination List window, the desti- nation information can be downloaded or uploaded. Item Download Upload When making changes to an exported CSV file, use a text editor. If the file is not saved using a text editor, an error will occur when the file is imported.
Page 280: Tcp/Ip
TCP/IP TCP/IP The Network - TCP/IP - TCP/IP window allows you to configure the following items. For more information on these TCP/IP, see chapter 5, “Network Print- ing.” Item TCP/IP Speed Apply button Clear button Description Select whether or not to make a connection via TCP/IP. Choices: Enable, Disable Default: Enable Configuration Menu Equivalent:...
Page 281 IPv4 Settings The Network - TCP/IP - IPv4 Settings window allows you to configure the following items. For more information on these TCP/IP, see chapter 5, “Net- work Printing.” Item Auto IP IP Address* Subnet Mask* Configuring the Printer Description Specifies the automatic assigning method for the printer IP address.
Page 282 Item Default Gateway* If a router is used on the network, sets the router’s Apply button Clear button * Always enter these addresses without leading zeros. For example, 131.011.010.001 should be entered as 131.11.10.1. IPv6 Settings The Network - TCP/IP - IPv6 Settings window allows you to configure the following items.
Page 283 Item IPv6 Link Local Address IPv6 Global Address IPv6 Gateway Address Apply button Clear button RAW Port Settings The Network - TCP/IP - RAW Port Settings window allows you to configure the following items. Item RAW Port Configuring the Printer Description Displays IPv6 Link Local Address.
Page 284 Item RAW Port Number RAW Port Bidirectional Apply button Clear button Description Specify the number of the printer’s RAW port. Choices: 1 to 65535 Default: 9100 The currently used port number and numbers 80, 161, 427, 443, 515, 631 and 4567cannot be specified.
Page 285 DNS Settings The Network - TCP/IP - DNS Settings window allows you to configure the following items. Item Host Name Domain Name Domain Name Automatic Acquisition DNS Server DNS Server Automatic Acquisition Dynamic DNS Apply button Clear button Configuring the Printer Description Specifies the host name.
Page 286 IP Address Filtering The Network - TCP/IP - IP Address Filtering page allows you to specify the IP address and limitations for accessing the printer. The settings described below are not applied to the DNS server and DHCP server. If the range of permitted IP addresses in Access Permission Address overlaps the range of refused IP address in Access Refuse Address, the refuse setting of Access Refuse Address is given pri- ority.
Page 287 Item Access Refuse Address Range of IP address refused access* Apply button Clear button * Always enter these addresses without leading zeros. For example, 131.011.010.001 should be entered as 131.11.10.1. Configuring the Printer Description If Enable is selected, the range of IP addresses refused access to the printer can be specified.
Page 288 IPsec The Network - TCP/IP - IPsec window allows you to configure the following items. Item Generic IPsec Settings IKE Life Time IKE Diffie-Hell- man Group IPsec SA Life Time Edit icon IKE Settings /IPsec SA Set- tings /IPsec Peer Settings IKE Settings /IPsec SA Set- tings /IPsec Peer Settings (Edit icon)
Page 289 Item IKE Diffie-Hell- man Group IPsec SA Life Time Apply button Clear button Cancel button IPsec (IKE Settings) The Network - IPsec - IKE Settings window allows you to configure the fol- lowing items. Item Encryption Algo- rithm Authentication Algorithm Apply button Clear button Cancel button...
Page 290 IPsec (IPsec SA Settings) The Network - IPsec - IPsec SA Settings window allows you to configure the following items. Item Security Protocol Select the security protocol. Encryption Algo- rithm for ESP Authentication Algorithm for Authentication Algorithm for AH Apply button Clear button Cancel button IPsec (IPsec Peer Settings)
Page 291: Bonjour
Item Peer’s Address Pre-Shared Key Specify the Pre-Shared Key text shared with the peer. Encapsulation Mode Apply button Clear button Cancel button Bonjour The Network - Bonjour page allows you to configure the following items. Item Bonjour Bonjour Name Priority Protocol Apply button Configuring the Printer Description...
Page 292: Ldap
Item Clear button LDAP In the Network - LDAP window, settings can be specified for the following parameters. Item LDAP Server Address Port Number Enable SSL Port Number (SSL) Description Resets all configuration settings to previous values. Description Select whether or not the LDAP server is used. Choices: Enable, Disable Default:...
Page 293 Item Search Base Attribute Search Method Timeout Maximum Search Result Configuring the Printer Description Specify the search starting point in a hierarchical structure arranged on the LDAP server. Range: Up to 64 characters Default: [Blank] Configuration Menu Equivalent: UTILITY - ADMIN. MANAGEMENT - LDAP SETTING - SEARCH BASE Specify the attribute that acquires.
Page 294 Item Authentication Method LDAP Account Password Domain Name Apply button Description Select the authentication method used for logging on to the LDAP server. If “Anonymous” is selected, a user name and password are not necessary. If “Simple” is selected, a user name and password are necessary.
Page 295: Wsd
Item Clear button Check Connec- tion When an LDAP server is used, the correct search results may not be retrieved when the search is performed from a server using anony- mous access. The Network - WSD window allows you to configure the following items: Item WSD Print Secure Mode...
Page 296: Netware
Item Device Informa- tion Apply button Clear button NetWare NetWare The Network - NetWare - NetWare window allows you to configure the fol- lowing items Item NetWare Description Displays the Device information. Default: [Blank] Specify the settings from the System - Machine Settings page.
Page 297 Item PServer Configuring the Printer Description Print Server Sets the Print Server Name for the printer. Name Range: Up to 63 characters Default: AL-CX28-xxxxxx xxxxxx displays six last digits of the MAC address in hexadecimals. Print Server Sets the Print Server password. Password Range: Up to 31 characters Default: [Blank]...
Page 298: Ipp
Item NPrinter/ RPrinter Apply button Clear button NetWare Status The Network - NetWare - NetWare Status window allows you to configure the following items: Item File Server Queue Name Queue Status The Network - IPP window allows you to configure the following items. For details on IPP, refer to chapter 5, “Network Printing.”...
Page 299 Item Accept IPP Job Printer Name Printer Location Printer Information Printer URI Configuring the Printer Description Selects whether or not to accept IPP Job. Choices: Enable, Disable Default: Enable Displays the printer’s name. Range: Up to 127 characters Default: AL-CX28-xxxxxx Specify the settings from the System - Machine Settings page.
Page 300 Item Operational Support IPP Authentication User Name Password Realm Description Print Job If this check box is selected, Print Job is enabled. Default: Checked Validate Job If this check box is selected, Validate Job is enabled. Default: Checked Cancel Job If this check box is selected, Cancel Job is enabled.
Page 301: Ftp
Item Apply button Clear button Server The Network - FTP - Server window allows you to configure the following items: Item FTP Server Apply button Clear button Client In the Network - FTP - Client window, settings can be specified for the fol- lowing parameters.
Page 302: Snmp
Item Connection Time- Apply button Clear button SNMP The Network - SNMP window allows you to configure the following items: Item SNMP SNMP SNMP v1/ v2c(IP) SNMP v3(IP) SNMP v1(IPX) UDP Port Description Select the amount of time (in seconds) until the connec- tion with the FTP server times out.
Page 303 Item SNMP v1/ Read v2c/(IP) Commu- nity Name Write Write Commu- nity Name SNMP v3 Context Name Discovery If Enable is selected, Discovery is enabled. Discovery User Name Read User Name Read Security Level Read Auth-pass- word Configuring the Printer Description Specifies the community name to be used for scan- ning.
Page 304 Item Read Priv-pass- word Write User Name Write Security Level Write Auth-pass- word Write Priv-pass- word Trap Set- Allow Set- tings ting Trap Set- ting When Authenti- cation Fails Apply button Clear button Description Specifies the read only user privacy password to be used for privacy (encryption).
Page 305: Appletalk
AppleTalk The Network - AppleTalk window allows you to configure the following items: Item AppleTalk Printer Name Zone Name Current Zone Name Apply button Clear button Email Send Email The Network - Email - Send Email window allows you to configure the fol- lowing items: Item E-mail...
Page 306 Specify the subject of the E-mail message when using network scanning. Range: Up to 20 chacacters Default: from EPSON AL-CX28 Configuration Menu Equivalent: UTILITY - ADMIN. MANAGEMENT - E-MAIL SETTING - DEFAULT SUBJECT Specify the IP address or host name for the SMTP server.
Page 307 Item Port Num- Connec- tion Time- Text Insert Select whether or not text is inserted into the body Authenti- cation before SMTP before SMTP Time Configuring the Printer Description Specify the port number communicating with the SMTP server. Range: 1-65535 Default: Configuration Menu Equivalent: UTILITY - ADMIN.
Page 308 Item POP3 Server Address Account Name Password Type in the password used for POP3 server. Port Num- POP3 Tim- eout Description Type in the host name or IP address for the POP3 server used for authentication with POP before SMTP. Range: Up to 64 characters Default:...
Page 309 Item SMTP Authenti- cation User Name Password Type in the password used for authentication with Realm Apply button Clear button Use alphanumeric characters (including some symbols) for the Sender Name and Default Subject. Using other characters will corrupt the characters for the E-mail destination. For details on characters that can be entered, refer to the User’s Guide on the software CD-ROM.
Page 310: Smb
In the Network - SMB window, settings can be specified for the following parameters. Item Send NTLM Setting User Authentica- tion Apply button Clear button SSL/TLS SSL/TLS Information The Network - SSL/TLS - SSL/TLS Information page allows you to specify SSL/TLS settings.
Page 311: Ssl/Tls Setting (When A Certificate Is Installed)
Item Request a Certificate Install a Certificate Next button Cancel button SSL/TLS Setting (When a certificate is installed) The Network - SSL/TLS - SSL/TLS Setting page allows you to select the fol- lowing SSL/ TLS settings that appear. Item Request a Certificate Set a Encryption Strength Remove a Certificate...
Page 312 Item Organization Organization Unit Locality State/Province Country Email Address Validity Start Date Validity Period Encryption Strength Description Specify the name of the group or organization. Range: Up to 63 characters Default: [Blank] Specify the name of the post. Range: Up to 63 characters Default: [Blank] Specify the name of the municipality.
Page 313: Request A Certificate
Item Create button Back button Cancel button Request a certificate The Network - SSL/TLS - Request a Certificate page allows you to config- ure the following items: Item Common Name Organization Organization Unit Locality State/Province Country Configuring the Printer Description Creates the self-signed certificate.
Page 314: Certificate Request
Item Email Address Next button Back button Cancel button Certificate Request The Network - SSL/TLS - Certificate Request page displays the data that will be submitted to the certificate authority to request that a certificate be issued. Item Certificate Request Save button OK button Description...
Page 315: Install A Certificate
Install a Certificate The Network - SSL/TLS - Install a Certificate page allows you to install the certificate issued by the certificate authority. Item Install a Certificate Next button Back button Cancel button Encryption Strength Setting This menu item appears if a certificate is installed. The Network - SSL/TLS - Encryption Strength Setting page allows you to specify the encryption level.
Page 316: Remove A Certificate
Remove a Certificate This menu item appears if a certificate is installed. The Network - SSL/TLS - Remove a Certificate page allows you to delete the installed certificate. Item OK button Back button Cancel button Mode Using SSL/TLS This menu item appears if a certificate is installed. The Network - SSL/TLS - Mode Using SSL/TLS page allows the SSL trans- mission mode to be specified.
Page 317: Authentication
Authentication User Authentication The Network - Authentication - User Authentication page allows you to specify user authentication settings. This page appears only if an optional hard disk drive is installed. When User Authentication is set to On and Public Access is set to Restrict on this page, printing is not possible except from a host where authentication settings can be specified (Windows printer driver).
Page 318 Auto Logout Network - Authentication - Auto Logout window allows you to configure the following items. Item Admin. Mode Logout Time User Mode Logout Time Apply button Clear button IEEE802.1x The Network - Authentication - IEEE802.1x window allows you to configure the following items: Item IEEE802.1x...
Page 319 Item Password TTLS Anonymous Name TTLS Authentication Type Server Certificate Check Send Client Certificate Select whether or not the client certificate is sent Client Certificate Configuring the Printer Description Specifies the password, when EAP Type is set to EAP-MD5, EAP-TLS, EAP-TTLS, PEAP, LEAP or Server Specification.
Page 320 Item CA Certificate Server ID Encryption Strength Limit Time of Network Stop Apply button Clear button Description Shows whether or not a CA certificate has been specified for CA reliability verification of server cer- tificates. Specify the settings from the Network - Authentication - CA Certificate page.
Page 321 CA Certificate CA Certificate Information The Network - Authentication - CA Certificate - CA Certificate Informa- tion window allows you to specify CA Certificate settings. As a default, CA Certificate is not installed. Click Setting to create a certificate and specify the CA Certificate settings. Item Setting button CA Certificate Setting (When a certificate is installed)
Page 322 Item Next button Back button Cancel button Remove a Certificate The Network - Authentication - CA Certificate - Remove a Certificate page allows you to delete the installed certificate. Item OK button Back button Cancel button Description Click to display the Network - Authentication - CA Certificate - Install a Certificate page.
Page 323 Index Account Mode 169 Active job list, Web-Based EpsonNet Config Print job status 181 Address Setting, Web-Based EpsonNet Config 244 Administrator Mode 169 Apple Talk 25, 139 AppleTalk, Web-Based EpsonNet Config 283 ARP/PING 126 Authentication, Web-Based EpsonNet Config 295 Bonjour 9, 140 Bonjour, Web-Based EpsonNet Config 269 Index...
Page 324 Config 258 Address registration 246 Address registration (server) 247 Address Setting 244 AppleTalk 283 Camera Direct settings 189, 239 Certificate request 292 Downloading/Uploading Destination List 257 Email 283 E-mail destination 246 Encryption strength setting 293 FTP 279 Group list 244 Group registration 255 Group Setting 254 Install a certificate 293...
Page 325 Config 254 Host table 164 HTTP 141 IEEE802.1x 141 IEEE802.1x, Web-Based EpsonNet Config 296 IKE Settings, Web-Based EpsonNet Config 267 Install a certificate, Web-Based EpsonNet Config 293, 299 Installing Certificate 293, 299 PPD file 89 Printer driver 3, 89 Scanner driver 72 IP address 123, 135 Manual setting 136 IP address filtering, Web-Based...
Page 326 Overview 116 Using options 123 Network printing 139 Network setting 116 Network, Web-Based EpsonNet Config DNS settings 263 IP address filtering 264 IPsec 266 IPv4 settings 259 IPv6 settings 260 RAW port settings 261 Page setup settings 36 Custom paper size options 38 Page attributes options 37 Paper source settings, Web-Based EpsonNet Config 184, 224...
Page 327 Scan, Web-Based EpsonNet Config Address registration 246 Address registration (server) 247 E-mail destination 246 Group list 244 Group registration 255 LDAP search 247 Self-signed certificate setting, Web- Based EpsonNet Config 289 SLP 143 SMB, Web-Based EpsonNet Config SMTP 143 SMTPAuthentication 144 SNMP 144 SNMP, Web-Based EpsonNet Config SSL/TLS information, Web-Based...
Page 328 FTP 279 General settings 183, 221 Group Setting 254 IEEE802.1x 296 IKE settings 267 Import/Export 195 Install a certificate 293, 299 Interface information 172, 195 IP address filtering 264 IPP 276 IPsec 266 IPsec Peer settings 268 IPsec SA settings 268 IPv4 settings 259 IPv6 settings 260 Job log 195...
