Page 3 Welcome to your new vehicle This driver’s handbook contains the information necessary: – for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and the technical developments it incorporates. –...
Page 4 EXTERIOR Rear view mirrors ➥ 1.96 Electric windows ➥ 3.20 Wiper ➥ 1.107 and ➥ 1.112 Demisting ➥ 3.6 and ➥ 3.12 Key/Remote control ➥ 1.2 Map ➥ 1.6 Locking/unlocking the doors ➥ 1.14 Lights: operation ➥ 1.99 Bodywork maintenance ➥ 4.15 Lights: replacement ➥...
Page 5 PASSENGER COMPARTMENT Adjusting your driving po- Passenger compartment storage, fit- sition ➥ 1.23 tings ➥ 3.27 Rear bench seat ➥ 3.34 Rear headrests ➥ 3.33 Front seats ➥ 1.21 Front headrests ➥ 1.98 Luggage compartment stor- Child safety ➥ 1.37 age/fittings ➥...
Page 6 DRIVER’S POSITION Trip computer controls ➥ 1.77 Instrument panel ➥ 1.64 Exterior lighting ➥ 1.99 Multimedia screen ➥ 3.18 Cruise control ➥ 2.96 Adaptive cruise control Stop and Heated seat(s) ➥ 1.21 Go ➥ 2.101 Speed limiter ➥ 2.92 Heating/Air conditioning system ➥...
Page 7 DRIVING AIDS Speed limiter ➥ 2.92 ABS (anti-lock braking system) ESC (electronic stability control) Detection of road signs ➥ 2.88 Braking assistance Hill start assistance ➥ 2.44 Cruise control ➥ 2.96 Lane departure warning ➥ 2.49 Adaptive cruise control Stop and Go ➥...
Page 8 SAFETY ON BOARD Front Airbags ➥ 1.28 Inhibiting the front passen- Curtain Airbags ➥ 1.35 ger airbag ➥ 1.57 Side Airbags ➥ 1.35 Seat belts ➥ 1.23...
Page 9 IDENTIFYING A VEHICLE - LABELS Review of a vehicle identification number ➥ 6.2 Vehicle identification plate ➥ 6.2 Technical Information for the emergency services ➥ 6.3 Engine identification ➥ 6.4 Tyre pressure labels ➥ 2.38 ➥ 4.11...
Page 10 THE ENGINE COMPARTMENT (routine maintenance) Brake fluid ➥ 4.8 Coolant level ➥ 4.8 Engine oil filler cap ➥ 4.5 Battery ➥ 4.13 Engine oil dipstick ➥ 4.4 Windscreen washer fluid ➥ 4.8 Opening the bonnet ➥ 4.2...
Page 11 BREAKDOWN RECOVERY Replacing windscreen wiper Puncture: blade(s) ➥ 5.33 Tools ➥ 5.7 Emergency spare wheel ➥ 5.2 Changing wheel Replacing headlight ➥ 5.9 bulbs ➥ 5.14 Front towing point ➥ 5.35 Replacing rear screen wiper blade ➥ 5.33 Fuses ➥ 5.29 Replacing rear light bulbs ➥...
Page 12 0.10...
Page 13 Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........0.11...
Page 14 0.12...
Page 15: Table Of Contents
Section 1: Getting to know your Vehicle Key, radio frequency remote control: general information, use, deadlocking ....Card: general information, use, deadlocking ......... . . Locking, unlocking the opening elements .
Page 16 KEY, RADIO FREQUENCY REMOTE CONTROL: general information (1/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves or to others by starting the engine, 1 Locks all the opening elements.
Page 17 KEY, RADIO FREQUENCY REMOTE CONTROL: general information (2/2) Radio frequency remote control operating range This varies according to the surround- ings: take care not to lock or unlock the doors by inadvertently pressing the but- tons on the remote control. Note: if a door or the boot is open or not properly shut, locking is not carried out.
Page 18 RADIO FREQUENCY REMOTE CONTROL: use Unlocking the doors The remote control A can be used to lock or unlock the doors and boot. Pressing button 2 unlocks the doors It is powered by a battery which can be and tailgate. replaced.
Page 19 RADIO FREQUENCY REMOTE CONTROL UNIT: deadlocking To activate deadlocking Press button 1 twice in quick succes- sion. Locking is confirmed by two slow flashes and three quick flashes of the hazard warning lights and side indica- tor lights. Depending on the vehicle, the door mir- rors fold in automatically when the vehi- cle is locked ➥...
Page 20 CARD: general information (1/3) The card is used for: card operating range – locking/unlocking the doors and tail- This varies according to the environ- gate (doors, tailgate) and the fuel ment: take care not to accidentally lock filler flap (see the following pages); or unlock the vehicle by inadvertently –...
Page 21 CARD: general information (2/3) Advice Avoid leaving the card in hot, cold or humid areas. Do not keep the card in a place Driver’s responsibility where it could be bent or dam- when parking or stopping aged accidentally, such as in a back the vehicle pocket of a garment.
Page 22 CARD: general information (3/3) Fitting a strap 7 Insert the strap into the 8 component and pass the end of the strap through Slide the rear casing 5 downwards the buckle. while pressing on zone A. Position the strap at the 6 opening and close the cartridge.
Page 23 “HANDS-FREE” CARD: use (1/4) Deactivating/activating the “hands-free” mode Depending on the vehicle, you can de- Never leave your vehicle activate/activate: with the card inside. – unlocking when approaching and locking when moving away from the vehicle; – locking and unlocking by pressing on Driver’s responsibility the buttons on the door handle.
Page 24 “HANDS-FREE” CARD: use (2/4) Hands-free unlocking, when Hands-free locking when If the card has been within the detection area 3 for approximately 15 minutes, approaching the vehicle moving away from the remote locking is disabled. To lock the vehicle With the card in access zone 3, the ve- vehicle, press the 5 button or, depend- hicle will unlock.
Page 25 “HANDS-FREE” CARD: use (3/4) To indicate that the vehicle has been locked, the hazard warning lights flash twice and then light up for approxi- mately four seconds. Special features of the unlocking system Under certain circumstances, approach unlocking is deactivated: –...
Page 26 “HANDS-FREE” CARD: use (4/4) Locking using the card With the doors and boot closed, press button 5: the vehicle locks. To indicate that the vehicle has been locked, the hazard warning lights flash twice and then light up for approxi- mately four seconds.
Page 27 “HANDS-FREE” CARD: DEADLOCKING To activate deadlocking Press button 2 twice in quick succes- sion. Locking is confirmed by two slow flashes and three quick flashes of the hazard warning lights and side indica- tor lights. Depending on the vehicle, the door mir- rors fold in automatically when the vehi- cle is locked ➥...
Page 28 LOCKING, UNLOCKING THE DOORS (1/4) If the remote control or, depending on the vehicle, the card does not work In some cases, the radio frequency remote control or the card may not work: – card/radio frequency remote control battery worn or run flat, vehicle bat- tery flat etc.
Page 29 LOCKING, UNLOCKING THE DOORS (2/4) Using the key integrated in Vehicles with key/remote the card control – Insert the tip of the key 2 into the Using the key notch 3 at the bottom of the cover B – Insert the tip of the key 4 into the on the driver’s door;...
Page 30 LOCKING, UNLOCKING THE DOORS (3/4) Locking the doors manually Interior locking/unlocking door control Turn screw 5 with the door open (using the end of the key) and close the door. Switch 6 controls the doors, the boot and the fuel filler flap simultaneously. This means that the doors are then locked from the outside.
Page 31 LOCKING, UNLOCKING THE DOORS (4/4) Door and tailgate status Locking the opening indicator elements without the card or the key When the ignition is on, the 6 switch warning light indicates the locking For example, in the event of a dis- status of the opening elements: charged battery or the card or key tem- porarily not working etc.
Page 32: Opening And Closing The Doors
OPENING AND CLOSING THE DOORS (1/2) Opening the doors from the Opening from the inside Rear doors outside With the doors unlocked, pull handle 2. Pull handle 3. Front doors With the doors unlocked or the card on you, hold the 1 handle and pull towards you.
Page 33 OPENING AND CLOSING THE DOORS (2/2) Lights-on reminder buzzer If you have switched off the ignition and left the lights switched on, a re- minder buzzer will sound when a door is opened. Door/tailgate open buzzer Driver’s responsibility when parking or stopping When the vehicle is stationary, the the vehicle warning light appears on the instrument...
Page 34: Automatic Locking When Driving
AUTOMATIC LOCKING WHEN DRIVING Operating faults NB: if a door is opened or closed, it will automatically lock again when the If you experience an operating fault (no vehicle reaches a speed of 6 mph (10 automatic locking, the 1 switch warning km/h).
Page 35 FRONT SEATS (1/2) To tilt the seatback Lift the 2 or 4 handle and tilt the seat- back to the desired position. Release the handle at the desired position and make sure that it is locked. After making adjustments, make sure that the seat- backs are correctly locked in place.
Page 36 FRONT SEATS (2/2) Operating faults When an operating fault is detected, the warning lights of the 6 switch for the seat concerned go out after approxi- mately five seconds. Consult an approved dealer. Heated seats With the ignition on: – Pressing the switch 6 on the required seat for the first time activates the heating system on high.
Page 37: Seat Belts
SEAT BELTS (1/5) Adjusting your driving Always wear your seat belt when trav- elling in your vehicle. You must also position comply with the legislation of the par- – Sit well back in your seat (having ticular country you are in. first removed your coat or jacket).
Page 38 SEAT BELTS (2/5) Locking – move the shoulder strap 1 as close as possible to the base of the neck Unwind the belt slowly and smoothly without it actually resting against it and ensure that buckle 3 locks into (if necessary, adjust the height of the catch 5 (check that it is locked by pull- seat belt if available) and make sure ing on buckle 3).
Page 39 SEAT BELTS (3/5) ß Driver’s seat belt reminder It is accompanied by the 6 symbol which and, depending on the vehi- appears for approximately 60 seconds cle, front passenger seat belt re- each time one of the rear seat belts is minder fastened or unfastened.
Page 40 SEAT BELTS (4/5) Adjusting the height of the Rear seat belts 8 front seat belts The belts are locked, unlocked and adjusted in the same way as the front Use button 7 to adjust the seat belt belts. height so that the shoulder strap is worn as shown previously.
Page 41 SEAT BELTS (5/5) The following information applies to the vehicle’s front and rear seat belts. – No modification may be made to the component parts of the originally fitted restraint system: seat belts, seats and their mountings. For special operations (e.g. fitting child seats), contact an authorised dealer. –...
Page 42 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/6) Depending on the vehicle, they will con- – Have the entire restraint sist of: system checked following – seat belt inertia reel pretension- an accident. ers; – No operation whatso- –...
Page 43 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/6) Load limiter driver and passenger front Airbags Above a certain severity of impact, this mechanism is used to limit the force of Fitted to the driver and passenger the belt against the body so that it is at sides.
Page 44 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/6) Operating faults å This warning light comes on when the engine is started and then goes out after approximately three sec- onds. If it does not come on when the ignition is switched on or if it stays on, there is a fault in the system.
Page 45 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/6) The following cases trigger the pre- In a frontal impact with another vehi- In a side impact with another vehicle tensioners or airbags. cle of an equivalent or higher category, of an equivalent or higher category, at with an impact area equal to or greater an impact speed equal to or greater...
Page 46 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (5/6) In the following examples, the pre- In the following examples, there is a – side impact to the front or rear of the tensioners or the airbags could op- risk that pretensioners orairbags may vehicle;...
Page 47 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (6/6) All of the warnings below are given so that the airbag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when it inflates. Warnings concerning the driver’s airbag –...
Page 48 METHODS OF RESTRAINT IN ADDITION TO THE REAR SEAT BELTS Depending on the vehicle, they will con- – Have the entire restraint sist of: system checked following – side seat belt inertia reel preten- an accident. sioners; – No operation whatso- –...
Page 49 SIDE PROTECTION DEVICES Side Airbag This airbag may be fitted to each of the front seats and is activated at the sides of the seats (door side) to protect the occupants in the event of a severe side impact. Curtain Airbag This is an airbag fitted (depending on the vehicle) along the upper sides of the vehicle –...
Page 50: Additional Methods Of Restraint
ADDITIONAL METHODS OF RESTRAINT All of the warnings below are given so that the airbag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when it inflates. The airbag is designed to complement the action of the seat belt.
Page 51: Child Safety: General Information
CHILD SAFETY: General information (1/2) Carrying children Please ensure that you comply with the legislation of your country. Children, and adults, must be correctly seated and strapped in for all journeys. The children being carried in your vehi- cle are your responsibility. Driver’s responsibility A child is not a miniature adult.
Page 52 CHILD SAFETY: General information (2/2) Using a child seat Before fitting a child seat, read the manual and respect its instructions. If The level of protection offered by the you experience any difficulties during child seat depends on its ability to re- installation, contact the manufacturer strain your child and on its installation.
Page 53 CHILD SAFETY: choosing a child seat Rear-facing child seats Forward-facing child seats Booster cushions A baby’s head is, proportionally, heavier Up to 18 kg or 4 years, the child may From 15 kg or 4 years, the child can than that of an adult and its neck is very travel on a forward-facing seat.
Page 54: Choosing A Child Seat Mounting
CHILD SAFETY: choosing a child seat mounting (1/3) There are two ways of attaching child Attachment via the seat belt seats: via the seat belt or using the The seat belt must be adjusted to ISOFIX system. ensure that it is effective in the event of harsh braking or an impact.
Page 55 CHILD SAFETY: choosing a child seat mounting (2/3) Attachment using the ISOFIX Attach the child seat with the ISOFIX system locks, if these are provided. The ISOFIX system allows quick, easy, safe fitting. Approved child seats ISOFIX are stand- ardised in accordance with current reg- The ISOFIX system consists of 2 rings ulations if any of the four cases below and, in some cases, a third ring.
Page 56 CHILD SAFETY: choosing a child seat mounting (3/3) The ISOFIX anchorage points have been exclu- sively designed for child seats with the ISOFIX system. Never fit a different type of child seat, seat belt or other objects to these anchorage points. Check that nothing is obstructing the anchorage points.
Page 57: Fitting A Child Seat, General Information
CHILD SAFETY: fitting a child seat, general information (1/2) Some seats are not suitable for fitting The types of child seat indicated may After installing the child seat, when this child seats. The diagram on the follow- not be available. Before using a differ- is possible, you can move the vehi- ing page shows you how to attach a ent child seat, check with the manufac-...
Page 58 CHILD SAFETY: fitting a child seat, general information (2/2) In the rear side seat Always remove the headrest from the Rear centre seat rear seat on which the child seat is A carrycot can be installed across the Check that the belt is suitable for secu- positioned.
Page 59 CHILD SEATS: attachment by seat belt (1/6) Visual installation of the five-door version ³ Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. ² Seat not suitable for fitting child seats. Child seat attached using the belt ¬...
Page 60 CHILD SEATS: attachment by seat belt (2/6) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Five-seater version Front passenger seat Rear side Rear centre Type of child seat Weight of the child Without airbag...
Page 61 CHILD SEATS: attachment by seat belt (3/6) X = Seat not suitable for fitting child seats of this type. U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted. B2 = Booster seats in groups 2 and 3 (15 to 25 kg and 22 to 36 kg).
Page 62 CHILD SEATS: attachment by seat belt (4/6) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Utility version Front passenger seat Type of child seat Weight of the child Without airbag or with airbag...
Page 63 CHILD SEATS: attachment by seat belt (5/6) X = Seat not suitable for fitting child seats of this type. U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted. B2 = Booster seats in groups 2 and 3 (15 to 25 kg and 22 to 36 kg).
Page 64 CHILD SEATS: attachment by seat belt (6/6) Visual installation of the utility version ³ Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. ² Seat not suitable for fitting child seats. Child seat attached using the belt ¬...
Page 65 CHILD SEATS: fitted using the ISOFIX SYSTEM (1/6) Visual installation of the five-door version Child seat fitted using the ISOFIX mounting  Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a forward-facing ISOFIX child seat with universal approval to be attached.
Page 66 CHILD SEATS: fitted using the ISOFIX SYSTEM (2/6) The table below summarises the information already shown on the diagram on the previous pages, to ensure the regula- tions in force are respected. Front passenger seat Weight of Seat size Rear side Rear centre Type of child seat Without airbag...
Page 67 CHILD SEATS: fitted using the ISOFIX SYSTEM (3/6) X = Seat not suitable for fitting child seats of this type. IUF/IL = On equipped vehicles, seat which allows an approved “Universal/semi-universal” or “vehicle specific” child seat to be at- tached using the ISOFIX system; check that it can be fitted. i-U = Suitable for “universal”...
Page 68 CHILD SEATS: fitted using the ISOFIX SYSTEM (4/6) The table below summarises the information already shown in the diagram on the following pages, to ensure the appli- cable regulations are respected. Utility version Front passenger seat Type of child seat Weight of the child Seat size ISOFIX Without airbag or with...
Page 69 CHILD SEATS: fitted using the ISOFIX SYSTEM (5/6) X = Seat not suitable for fitting child seats of this type. IUF/IL = On equipped vehicles, seat which allows an approved “Universal/semi-universal” or “vehicle specific” child seat to be at- tached using the ISOFIX system; check that it can be fitted. i-U = Suitable for “universal”...
Page 70 CHILD SEATS: fitted using the ISOFIX SYSTEM (6/6) Visual installation of the utility version Child seat fitted using the ISOFIX mounting  Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a forward-facing ISOFIX child seat with universal approval to be attached.
Page 71 CHILD SAFETY: deactivating, activating AIRBAG front passenger (1/3) The passenger airbag may only be activated or deacti- vated when the vehicle is stationary, with the igni- tion off. If it is interfered with when the ve- hicle is being driven, indicator lights å...
Page 72 CHILD SAFETY: deactivating, activating AIRBAG front passenger (2/3) The markings on the dashboard and labels A on each side of the passen- ger sun visor 3 (example: label shown above) remind you of these instruc- tions. DANGER Since operation of the front passenger airbag is not compatible with the position of a rear-facing child seat, NEVER...
Page 73 CHILD SAFETY: deactivating, activating AIRBAG front passenger (3/3) Operating faults It is forbidden to fit a rear-facing child seat to the front passenger seat if the airbag activation/deactivation system is faulty. Allowing any other passenger to sit in that seat is not recommended. Contact your approved dealer as soon as possible.
Page 74: Driving Position
DRIVING POSITION: LEFT-HAND DRIVE (1/2) 1.60...
Page 75: Instrument Panel
DRIVING POSITION: LEFT-HAND DRIVE (2/2) The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY. 1 Side air vents. 9 Controls for: 16 Handbrake. 2 Stalk for: – front seat heating; 17 “Hands-free” card holder. – direction indicator lights; –...
Page 76 DRIVING POSITION: RIGHT-HAND DRIVE (1/2) 1.62...
Page 77 DRIVING POSITION: RIGHT-HAND DRIVE (2/2) The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY. 14 LPG control. 1 Side air vents. 8 Main switch and controls for the 2 Passenger airbag location. Cruise control/speed limiter, adap- 15 Control for adjusting steering 3 Heating or air conditioning con- tive cruise control and “Lane wheel height and reach.
Page 78 WARNING LIGHTS (1/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Instrument panel A, B or C: it illumi- In some cases, the appearance of a nates when the ignition is switched on. warning light is accompanied by a mes- Press or lift the 1 switch as many times sage on the instrument panel.
Page 79 WARNING LIGHTS (2/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. š å Side light warning light Indicator light airbag Brake circuit fault warning light It lights up when the ignition or á Main beam headlight tell- the engine is switched on and goes off It lights up when the ignition or the tale...
Page 80 WARNING LIGHTS (3/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. À Oil pressure warning light Warning light Handbrake “on” and elec- © It lights up when the ignition or tronic parking brake warn- This lights up when the igni- the engine is switched on and goes off ing light ➥...
Page 81 WARNING LIGHTS (4/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. É Anti-lock braking warning Preheating warning light Low fuel level warning light light (Diesel version) It lights up orange when the ig- It lights up when the ignition or the This should come on when the igni- nition or the engine is switched on and engine is switched on and goes off after...
Page 82 WARNING LIGHTS (5/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Ô Ð  Coolant temperature warn- Speed limiter warning light Assisted parking brake fault ing light ➥ 2.92 light ➥ 2.141 Ï  This lights up blue when you switch on Cruise control warning light Overspeed warning light the ignition or start the engine.
Page 83 WARNING LIGHTS (6/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. ß Front and rear seat belt re- minder warning light (de- pending on the vehicle) ➥ 1.23 On display D  Passenger Airbag ON ➥...
Page 84: Displays And Indicators
DISPLAYS AND INDICATORS (1/7) Instrument panel in miles (option to switch to km/h) Vehicles not fitted with a multimedia screen – With the ignition off, press the 2 switch as many times as required to reach the vehicle tab 5; –...
Page 85 DISPLAYS AND INDICATORS (2/7) Instrument panel A Rev counter 7 Total mileage recorder 9 ➥ 1.81 (graduations x 1000) It lights up when the ignition is switched Trip computer 10 ➥ 1.77 This is displayed differently according on. In some cases, the appearance of a to how the instrument panel is custom- warning light is accompanied by a mes- Estimated mileage with remaining...
Page 86 DISPLAYS AND INDICATORS (3/7) Coolant temperature indicator 14 Fuel gauge 15 In normal use, indicator 14 should be If the level is at the minimum, warn- before area 13. Under “intensive” op- ing light integrated in the indica- erating conditions, the needle may ap- tor comes on orange, accompanied by proach this zone.
Page 87 DISPLAYS AND INDICATORS (4/7) Instrument panel B Coolant temperature indicator 16 Overspeed buzzer In normal use, indicator 16 should be Depending on the vehicle and country, It lights up when the ignition is switched  before area 17. Under “intensive” op- on.
Page 88 DISPLAYS AND INDICATORS (5/7) Multimedia information 21 Fuel gauge 25 Depending on the vehicle, you can dis- If the level is at the minimum, warn- play information from the multimedia screen (the compass, telephone, navi- ing light integrated in the indica- gation, etc.).
Page 89: Trip Computer 29
DISPLAYS AND INDICATORS (6/7) Instrument panel C Rev counter 26 Trip computer 29 (graduations x 1000) ➥ 1.77 It lights up when the ignition is switched on. In some cases, the appearance of a Coolant temperature indicator 28 Estimated mileage with remaining warning light is accompanied by a mes- fuel 30 In normal use, the indicator 28 should...
Page 90 DISPLAYS AND INDICATORS (7/7) Fuel gauge 34 If the level is at the minimum, warn- ing light integrated in the indica- tor comes on orange, accompanied by a beep. Fill up as soon as possible. Speedometer 33 Driving style indicator 32 ➥ 2.28 Overspeed buzzer Depending on the vehicle and country, ...
Page 91 TRIP COMPUTER: general information (1/4) Trip computer A, B or C Depending on the vehicle, this includes the following functions: – distance travelled; – journey settings; – information messages; – operating fault messages (con- © nected to the warning light); –...
Page 92 TRIP COMPUTER: general information (2/4) Vehicle fitted with trip computer A The functions will be distributed in zones 5, 6 and 7. The location of the zones differs depending on the style selected. The 7 area is dedicated to driving aids and cannot be customised.
Page 93 TRIP COMPUTER: general information (3/4) Vehicle fitted with trip computer B Vehicle fitted with trip computer C The functions will be distributed in Press the 1 switch as many times as re- zones 5, 6 and 7. quired to reach the “Vehicle” tab. Press the 1 switch to browse between Repeatedly press the 2 or 3 switches.
Page 94 TRIP COMPUTER: general information (4/4) Interpreting some of the Selections values displayed after (the display depends on the vehicle resetting equipment and country) a) Trip log, operating faults and infor- The values showing average fuel con- mation message readout; sumption, range and average speed will become more stable and reliable b) Journey settings: the further you travel after pressing the...
Page 95 TRIP COMPUTER: journey parameters (1/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected a) Trip log. Successive display: Vehicle Systems OK – information messages (passenger airbag OFF etc.); –...
Page 96 TRIP COMPUTER: journey parameters (2/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Average LPG d) Average LPG fuel consumption –-.- L/100 Range LPG Estimated range with remaining LPG fuel. –-- km Distance LPG Distance travelled on LPG fuel since the last reset.
Page 97 TRIP COMPUTER: journey parameters (3/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Tyre pressure init. f) Reset the tyre pressure. long press ➥ 2.38 g) Setting the time. 16:30 ➥...
Page 98 TRIP COMPUTER: journey parameters (4/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with mileage- before-service message f) Mileage before service or oil change. Mileage before service Service in With the ignition on and engine not running, access the “Mileage 30 000 km / 12 months...
Page 99 TRIP COMPUTER: journey parameters (5/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with distance before next service message (cntd.) f) Mileage before service or oil change. Mileage before service Oil change in With the ignition on and the engine not running, access the mileage...
Page 100 TRIP COMPUTER AND WARNING SYSTEM: information messages These can help in the vehicle starting phase, or give information about a selection or a driving status. Examples of information messages are given in the following pages. Examples of messages Interpreting the display selected “Parking Brake ON”...
Page 101 TRIP COMPUTER AND WARNING SYSTEM: operating fault messages © These appear with the warning light and mean that you should drive very carefully to an authorised dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.
Page 102 TRIP COMPUTER AND WARNING SYSTEM: warning message ® These appear with the warning light and require you to stop immediately, for your own safety, as soon as traffic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer. Some examples of warning messages are given below.
Page 103: Vehicle Settings Customisation Menu
VEHICLE SETTINGS CUSTOMISATION MENU (1/3) Adjusting the settings d) “Welcome”: – External welcome; Select a menu then the function to be – Automatic fold-out of mirrors; modified (the display depends on the – Interior welcome; vehicle equipment and country): – Courtesy light auto mode. a) “Driving”: Depending on the function, select: –...
Page 104 VEHICLE SETTINGS CUSTOMISATION MENU (2/3) Adjusting the settings d) “DRIVING ASSIST”: – Lane departure warning sound Navigate using the 4 or 5 control to volume; select the function to be modified and – Lane departure warning sensitiv- press 6 “OK” to confirm (display may ity;...
Page 105 VEHICLE SETTINGS CUSTOMISATION MENU (3/3) To exit the menu, press 4 or 5 to access “BACK” and confirm by pressing 6 “OK”. It may be necessary to carry out this operation more than once. Once a line has been selected, press 6 “OK"...
Page 106 CLOCK AND EXTERIOR TEMPERATURE (1/2) Vehicles fitted with a multimedia Vehicles not fitted with a multimedia Set the hour using the 3 or 4 control, screen screen then wait for three seconds: the min- utes will flash. The time and exterior temperature are Press the switch 2 as many times as re- displayed on the multimedia screen 1.
Page 107 CLOCK AND EXTERIOR TEMPERATURE (2/2) External temperature indicator Depending on the vehicle, If the Special note: electrical supply is cut (battery dis- connected, broken supply wire, When the external temperature is be- etc.), the clock will automatically tween -3°C and +3°C, the °C symbols go back to the right time after a few flash (indicates risk of ice).
Page 108 STEERING WHEEL POWER-ASSISTED (1/2) Activating the function With the ignition on, press the 3 switch: the switch warning light illuminates. Deactivating the function - Automatic: The function switches off automatically after the regulation phase of approxi- mately 30 minutes. The 3 switch warn- ing light remains on.
Page 109: Steering Wheel, Power-Assisted Steering
STEERING WHEEL POWER-ASSISTED (2/2) Power-assisted steering Note: the power-assisted steering de- pends on the driving mode selected in Never drive with an inadequately the “MULTI-SENSE” menu (➥ 3.2). charged battery. Variable power-assisted steering The variable power assisted steering system is equipped with an electronic control system which alters the level of assistance to suit the vehicle speed.
Page 110: Rear View Mirrors
REAR VIEW MIRRORS (1/2) Electrical folding mirrors Special case When the rear view mirror has been The door mirrors will fold-out automati- manually deployed or folded back, it is cally when the vehicle is unlocked. The possible to reset it to a usage position. door mirrors fold in when the vehicle is locked.
Page 111 REAR VIEW MIRRORS (2/2) Interior rear view mirror Its position can be adjusted. For safety reasons, carry Rear view mirror with lever 4 out any adjustments when When driving at night, to avoid being the vehicle is not being dazzled by the headlights of the vehicle driven.
Page 112 FRONT HEADRESTS To raise the headrest Raise it to its highest position (tilt the seatback backwards if necessary). Press button 2 and lift the headrest to release it. To refit the headrest Check that the headrest rods are clean 3. Insert the headrest rods into the holes 1 (tilt the seatback backwards if neces- sary).
Page 113: Exterior Lighting And Signals
EXTERIOR LIGHTING AND SIGNALS (1/6) Depending on the vehicle, the dipped beam headlights come on automati- cally after several sweeps of the wind- screen wiper blades. Side lights Dipped beam š headlights Turn ring 2 until the symbol is opposite mark 3. Manual operation This indicator light on the instrument Turn ring 2 until the symbol is opposite...
Page 114 EXTERIOR LIGHTING AND SIGNALS (2/6) During deactivation of the main beam The main beam headlights come on au- headlights, the dipped beam headlights tomatically if: return to their original position. – exterior light is weak; – no other vehicles or lighting are de- tected;...
Page 115 EXTERIOR LIGHTING AND SIGNALS (3/6) Operating faults When the message “Check Automatic Lighting” appears on the instrument panel, the system is deactivated. Consult an approved dealer. Using the portable naviga- tion system at night in the windscreen area below the ...
Page 116 EXTERIOR LIGHTING AND SIGNALS (4/6) Lights-on reminder buzzer Welcome and goodbye function If the lights are on after the engine is (depending on the vehicle) switched off, a warning beep sounds when the driver’s door is opened to Once the function is activated, the day- warn you that the lights are still on (to time running lights and the rear side avoid battery discharge or other prob-...
Page 117 EXTERIOR LIGHTING AND SIGNALS (5/6) With the engine lights switched off, the 2 ring in AUTO, pull the lever 1 to- wards you: the side lights and dipped beam headlights will switch on for ap- proximately 30 seconds along with the š...
Page 118 EXTERIOR LIGHTING AND SIGNALS (6/6) Rear fog lights Cornering lights  (depending on vehicle) Turn centre ring 4 on the stalk until the symbol faces mark 3, then re- When driving in forward gear, with lease it. the vehicle speed below approxi- mately 25 mph (40 km/h), whenever Operation of the fog lights depends on the dipped beam headlights are on:...
Page 119: Audible And Visual Signals
AUDIBLE AND VISUAL SIGNALS Direction indicators Move the stalk 1 in the same direc- tion as you want to move the steering wheel. One-touch mode Briefly shift the stalk 1 upwards or downwards, not exceeding the point of resistance, then release it: the stalk will return to its original position and the direction indicator light concerned will flash three times.
Page 120: Headlight Beam Adjustment
HEADLIGHT BEAM ADJUSTMENT Examples of positions for adjusting control A according to the load Driver alone or with front passenger All seats occupied Switch A is used to adjust the height of Driver with passengers and luggage the headlight beams according to the (or load) reaching the maximum load.
Page 121 WINDSCREEN WASH, WIPE (1/5) Vehicle fitted with intermittent Special note windscreen wipers When driving the vehicle, the wiping speed slows down whenever the ve- A single sweep hicle stops. For example, fast wiping A short push will trigger one sweep speed will slow to normal wiping speed.
Page 122 WINDSCREEN WASH, WIPE (2/5) When activating automatic wiping or when increasing sensitivity, one sweep of the blades is performed. Note: – the rain sensor is only intended as a driving aid. In the event of reduced visibility, the driver should manually activate the wipers.
Page 123 WINDSCREEN WASH, WIPE (3/5) Operating faults Special note When driving the vehicle, the wiping In the event of a malfunction of the au- tomatic wiping, the wiper is set to inter- speed slows down whenever the vehi- mittent wiping. Contact an authorised cle stops.
Page 124 WINDSCREEN WASH, WIPE (4/5) Specific front wiper position (service position) This position enables the blades to be lifted to remove them from the winds- creen. It may be useful to: – to clean the blades; – to release the blades from the winds- creen in winter;...
Page 125 WINDSCREEN WASH, WIPE (5/5) Note: In temperatures below zero, the washer liquid risks freezing to the windscreen, thereby reducing visibility. Heat the windscreen using the demister control before cleaning. Efficiency of a wiper blade Check the condition of the wiper blades.
Page 126 REAR SCREEN WASHER, WIPER (1/2) To stop the operation, pivot ring 3 again. Note When washing using a roller type car wash, return the ring 3 on the stalk 1 to the stop position to deactivate auto- matic wiping. Efficiency of a wiper blade Follow usage recommendations.
Page 127 REAR SCREEN WASHER, WIPER (2/2) Activation/deactivation of the rear In the event of obstacles present on the screen wiper rear window (dirt, snow, etc.), the wiper will try to sweep away all the obstacles. Engaging reverse gear triggers inter- If an obstacle prevents the blade from mittent wiping (if the front wipers are in moving, it can be stopped.
Page 128: Fuel Tank (Filling With Fuel)
FUEL TANK (1/5) Fuel grade Use a high-grade fuel that complies with the legislation in force in each country and which must comply with the specifications given on the label on the cover 1. ➥ 6.6. Fuel types that conform to European standards with which the engines of vehicles sold in Europe are compat- ible: refer to the table ➥...
Page 129 FUEL TANK (2/5) Filling with fuel If it is not possible to add at least 1.10 gallons (5 litres) of fuel due to the With the ignition off, insert the nozzle fuel level in the tank, drive the vehicle and insert it fully before turning it on to until the tank has capacity.
Page 130 FUEL TANK (3/5) Vehicles with card No modifications what- With the card in the passenger com- soever are permitted on partment, press the start button 4 with- any part of the fuel supply out pressing any of the pedals. Wait a system (electronic units, few minutes before starting.
Page 131 FUEL TANK (4/5) Useable capacity of the LPG tank: ap- proximately 7.04 gallons (32 litres). Filling up with LPG Apply the parking brake, stop the engine, switch off the ignition and switch off the lights. Always respect the safety instructions given at filling stations.
Page 132 FUEL TANK (5/5) Depending on the type of station, it may be necessary to perform press and hold the station button before filling will start. When the pump stops supplying LPG, or when the pump flow reduces sig- nificantly, the maximum tank level has been reached.
Page 133: Reagent Tank
REAGENT TANK (1/4) Please ensure that you comply with the legislation of your country. It is impor- tant to remember that failure to respect regulations in force could lead to legal action being taken against the vehicle To fill up with reagent, the engine owner.
Page 134 REAGENT TANK (2/4) Filling (continued) If the reagent overflows, or contami- nates any paintwork, clean the affected The tank can be filled at the pump. With area quickly with plenty of cold water the ignition off, insert the nozzle fully and a soft cloth.
Page 135 REAGENT TANK (3/4) Maintenance/Range The information displayed on the instrument panel may be accompanied by a beep. Indicator Message What to do? lights When the message is displayed when the ignition is switched on, you have less than 1,488 miles (2,400 km) range. –...
Page 136 REAGENT TANK (4/4) System faults When the indicator lights light up, this may be accompanied by a beep. Indicator lights Message Readings “Check Anti- Pollution System” Indicates a fault in the system. Contact your approved  “AdBlue quality to check” ©...
Page 137 Section 2: Driving Running in ..............Ignition switch .
Page 138: Running In
RUNNING IN Petrol version Diesel version For the first 600 miles (1,000 km), do For the first 930 miles (1,500 km), do not exceed 78 mph (130 km/h) in the not exceed 80 mph (130 km/h) in the highest gear, or 3,000 to 3,500 rpm. highest gear, or 2,500 rpm.
Page 139: Ignition Switch
IGNITION SWITCH: vehicle with key “Ignition” position ON 2 The ignition is switched on: Any acces- sories (radio etc.) can be used. “Start” position START 3 If the engine fails to start at the first attempt, the key must be turned back before the starter can be activated again.
Page 140: Starting, Stopping The Engine
STARTING, STOPPING THE ENGINE: vehicle with key (1/2) Petrol versions Note: on vehicles equipped with a – Activate the starter without acceler- manual gearbox, in the event of engine ating; stalling the message “Press Clutch” will – release the key as soon as the be displayed on the instrument panel.
Page 141 STARTING, STOPPING THE ENGINE: vehicle with key (2/2) LPG versions The engine is always started using petrol. Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone in your vehicle, even for a short time.
Page 142 STARTING, STOPPING THE ENGINE: vehicle with card (1/4) Note: on vehicles equipped with a manual gearbox, in the event of engine stalling the message “Press Clutch” will be displayed on the instrument panel. Fully press the clutch pedal to restart the engine.
Page 143 STARTING, STOPPING THE ENGINE: vehicle with card (2/4) LPG versions The engine is always started using petrol. Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone in your vehicle, even for a short time.
Page 144 STARTING, STOPPING THE ENGINE: vehicle with card (3/4) “Hands-free” starting with Operating faults The message “Place card on zone + START” appears on the instrument the tailgate open In certain cases, the hands-free card panel. may not work: In this case, the card should not be lo- Press the brake or clutch pedal, then cated in the luggage compartment, to –...
Page 145 STARTING, STOPPING THE ENGINE: vehicle with card (4/4) If the card is no longer in the passen- When you leave your vehi- ger compartment or if the card’s bat- cle, especially if you have tery is flat, when the vehicle is station- your card with you, check ary and you try to switch the engine off, that the engine is com-...
Page 146: Stop And Start Function
STOP AND START FUNCTION (1/4) This system enables a reduced fuel The vehicle equipment remain opera- consumption and lower greenhouse – when the vehicle speed is zero tional while the engine is stopped. gas emissions. The system is acti- during approximately one second or, When the engine switches to standby, vated automatically when the vehicle depending on the vehicle, as soon...
Page 147 STOP AND START FUNCTION (2/4) Preventing the engine from Conditions for coming out of standing by engine standby In certain situations, such as negotiat- For vehicles equipped with auto- ing a crossroads for instance, it is pos- matic gearboxes: sible (with the system activated) to keep –...
Page 148 STOP AND START FUNCTION (3/4) Conditions preventing the For vehicles equipped with manual – the gradient is too steep for vehicles gearboxes: fitted with an automatic gearbox; standby of the engine – when opening the driver’s door, with- – the “Clear view” function is activated Certain conditions prevent the system out any gear engaged and the clutch ➥...
Page 149 STOP AND START FUNCTION (4/4) Deactivating, activating the Special feature of the automatic engine re-start function Under certain conditions, the engine Press 1 to deactivate the function. The can restart on its own in order to guar- message “Stop & Start deactivated” antee your safety and comfort.
Page 150 SPECIAL FEATURES OF PETROL VERSIONS, PARTICLE FILTER (1/2) The following operating conditions If you notice any of the above operat- should be avoided: ing faults, have the necessary repairs carried out as soon as possible by an – driving for long periods when the low approved dealer.
Page 151 SPECIAL FEATURES OF PETROL VERSIONS, PARTICLE FILTER (2/2) Particle filter Note: the indicator light may go out If the filter becomes saturated, the © after 20 minutes if the driving condi- warning light and, depending The particle filter is used in the treat- ...
Page 152 SPECIAL FEATURE OF DIESEL VERSIONS, PARTICLE FILTER (1/2) Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with an injec- tion pump which prevents the engine To avoid any faults in icy weather: speed being exceeded irrespective of –...
Page 153 SPECIAL FEATURES OF DIESEL VERSIONS: PARTICLE FILTER (2/2) Particle filter Note: the warning light may reappear If the filter becomes saturated, the © if the driving conditions are not fully warning light and, depending The particle filter is used in the treat- ...
Page 154: Special Features Of Lpg Versions
SPECIAL FEATURES OF LPG VERSIONS (1/4) Yellow warning light B A constant warning light indicates that petrol mode is active. Fuel gauge warning light A The warning lights A (four green lights and one red light) indicate the level in the LPG tank.
Page 155 SPECIAL FEATURES OF LPG VERSIONS (2/4) Starting the engine The engine is always started using petrol. – For vehicles with a key ➥ 2.4. While the fuel tank is empty, the – For vehicles with a card ➥ 2.6. vehicle cannot start or drive in Note: if LPG mode is active when the LPG mode only.
Page 156 SPECIAL FEATURES OF LPG VERSIONS (3/4) Changing fuel mode during Operating faults driving (continued) In the event of a fault which may affect the correct operation of the engine, the Automatically switching from LPG system automatically switches from mode to petrol mode LPG to petrol mode.
Page 157 SPECIAL FEATURES OF LPG VERSIONS (4/4) If driving under severe conditions cold weather (temperatures below 10°C) and depending on the quality of the gas used, the system may automatically manage the conditions for switching between LPG mode and petrol mode. Note: for vehicles that are equipped, it is recommended that you use the ECO mode in these conditions (particularly...
Page 158: Gear Lever, Handbrake
GEAR LEVER, HANDBRAKE Handbrake To release: Pull the lever 3 up slightly, press button 2 and then lower the lever to the floor. When stationary and de- The warning light on the instru- pending on the slope and/or ment panel will go out. vehicle load, it may be nec- The red warning light on the instrument essary to pull up the hand-...
Page 159: Electronic Parking Brake
ELECTRONIC PARKING BRAKE (1/4) In all other instances, for example the engine has stalled or is in standby due to the Stop and Start ➥ 2.10, the assisted parking brake is not applied automatically. Manual mode must be used. For certain country-specific model ver- sions, the assisted brake application function is not activated.
Page 160 ELECTRONIC PARKING BRAKE (2/4) Assisted operation (continued) Note: in some situations (electronic parking brake failure, manual release of the parking brake, etc.), a beep sounds and the message “WARNING: Apply Parking Brake” appears on the instru- ment panel to warn you that the elec- tronic parking brake has been released: –...
Page 161 ELECTRONIC PARKING BRAKE (3/4) – manually release the electronic park- ing brake (please see the informa- tion on “Manually releasing the elec- tronic parking brake” on the previous page); – depending on the vehicle, the elec- tronic parking brake is applied auto- matically.
Page 162 ELECTRONIC PARKING BRAKE (4/4) Versions with an automatic Operating faults gearbox © – If there is a fault, the warning light illuminates on the instrument For safety reasons, automatic release panel accompanied by the “Check is deactivated when the driver’s door Parking Brake”...
Page 163: Autohold" Function
“AUTOHOLD" FUNCTION Vehicle stopped (e.g. at a red light, an Conditions for interrupting the intersection, a traffic jam, etc.), the func- braking force tion ensures braking force even when The following conditions must be met: the driver releases the brake pedal. –...
Page 164: Eco-Driving
DRIVING ADVICE, ECO DRIVING (1/8) Fuel consumption is accredited in ac- Depending on the vehicle, you will have cordance with a standard regulatory various functions which enable you to method. lower your fuel consumption: Identical for all manufacturers, this ena- –...
Page 165 DRIVING ADVICE, ECO DRIVING (2/8) On the instrument panel A, B Gear change indicator 1 or C Depending on the vehicle, to obtain op- timum consumption levels, a warning Depending on the vehicle, the informa- light on the instrument panel lets you tion display can be organised and cus- know the best time to move up or down tomised based on the instrument panel...
Page 166 DRIVING ADVICE, ECO DRIVING (3/8) Driving style indicator 2 Informs you about the driving style adopted in real time. This is shown by indicator light 2. The more petals displayed on 2, the more your driving is flexible and eco- nomical.
Page 167 DRIVING ADVICE, ECO DRIVING (4/8) Acceleration indicator Eco 3 This informs you in real time whether you are accelerating moderately or strongly. This is shown by the 3 warning light: – green: acceleration is moderate and correct; – white: acceleration is too high; –...
Page 168 DRIVING ADVICE, ECO DRIVING (5/8) An overall rating from 0 to 100 is dis- played to let you assess your eco driv- ing performance. The higher the rating, the lower the fuel consumption. Eco advice is given to help improve your performance.
Page 169 DRIVING ADVICE, ECO DRIVING (6/8) ECO mode Free-wheel function ECO mode is a function which opti- Depending on the vehicle, for vehicles mises fuel consumption. fitted with an automatic gearbox, in the deceleration phases (with the foot fully It affects certain driving operations (ac- off the accelerator pedal), switching to celeration, shifting gears, cruise con- freewheeling (automatic neutral) de-...
Page 170 DRIVING ADVICE, ECO DRIVING (7/8) – High speeds significantly affect the – Do not try to maintain the same vehicle’s fuel consumption. speed up a hill, accelerate no more than you would on flat ground. Keep Examples (at a steady speed): your foot in the same position on the –...
Page 171 DRIVING ADVICE, ECO DRIVING (8/8) – On vehicles equipped with non-au- tomatic air conditioning, switch off the air conditioning when it is not re- quired. Advice for reducing consumption and therefore helping to preserve the environment: If the vehicle has been parked in the sun, open the doors for a few mo- ments to let the hot air escape before starting the engine.
Page 172: Maintenance And Antipollution Advice
MAINTENANCE AND ANTIPOLLUTION ADVICE Your vehicle complies with criteria for In addition, replacing engine, fuel – Air filter, fuel filter: a choked ele- recycling and recovering vehicles at the supply system and exhaust compo- ment will reduce efficiency. It must end of their service life, which entered nents with parts other than those origi- be replaced.
Page 173: Environment
ENVIRONMENT Emissions Your vehicle has been designed with – At the end of the vehicle’s service respect for the environment in mind for life, it should be sent to approved Your vehicle has been designed to emit its entire service life: during production, centres to ensure that it is recycled.
Page 174: Tyre Pressure Loss Warning
TYRE PRESSURE LOSS WARNING (1/6) Operating principle When fitted to the vehicle, this system notifies the driver if one or more tyres This system detects a loss of pressure lose pressure. in one of the tyres by measuring the The system can be identified by the 1 wheel speed while driving.
Page 175 TYRE PRESSURE LOSS WARNING (2/6) Operating conditions Resetting the standard level – significant change in load or distribu- tion of load on one side of the vehi- for the tyre pressures The system must be reinitialised with cle; tyre pressure equal to that shown on This should be done: –...
Page 176 TYRE PRESSURE LOSS WARNING (3/6) Tyre pressure init. long press Resetting procedure – briefly press the 3 or 4 switch to reach the “Tyre pressure init. long Ignition on, vehicle stopped: press” page; – for vehicles fitted with a type A or C –...
Page 177 TYRE PRESSURE LOSS WARNING (4/6) The table below shows the possible messages related to the tyre resetting procedure. Steps Messages Readings – Tyre pressure init. at stop The message is displayed during driving. If you want to reset the pressure of the four tyres, stop the vehicle.
Page 178 TYRE PRESSURE LOSS WARNING (5/6) Readjustment of tyre After each change of wheel/tyre, read- just the tyre pressure and launch the pressures reset of the tyre pressure reference The pressure of the four tyres must value. be set when cold (refer to the label lo- cated on the edge of the driver’s door).
Page 179 TYRE PRESSURE LOSS WARNING (6/6) The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). Indicator Messages Readings lights This indicates that tyre under-inflation or puncture has been detected.  Inflate tyres and init. Check and adjust the pressure of the four tyres when cold and reset the system.
Page 180 DRIVING CORRECTION DEVICES AND AIDS (1/5) Anti-lock braking system Depending on the vehicle, this is com- posed of: (ABS) – anti-lock braking system (ABS); Under heavy braking, the ABS prevents the wheels from locking, allowing the – electronic stability program (ESC) stopping distance to be managed and with understeer control and trac- keeping control of the vehicle.
Page 181 DRIVING CORRECTION DEVICES AND AIDS (2/5) Operating faults: © – lit up on the in- strument panel accompanied by the messages “Check ABS”, “WARNING: Check Braking System” and “Check ESC”: this indicates that the ABS, the ESC and the emer- gency brake assist are disabled.
Page 182 DRIVING CORRECTION DEVICES AND AIDS (3/5) Electronic stability program Understeer control In some situations (driving on very wet ground: snow, mud, etc. or driving with (ESC) with understeer control This system optimises the action of the snow chains fitted), the system may and traction control ESC in the case of pronounced unders- reduce the engine output to limit wheel-...
Page 183 DRIVING CORRECTION DEVICES AND AIDS (4/5) Emergency brake assist Braking anticipation Depending on the vehicle, when you This system supplements the ABS rapidly release the accelerator, the and helps reduce vehicle stopping dis- system anticipates the braking ma- tances. noeuvre in order to reduce stopping Operating principle distances.
Page 184 DRIVING CORRECTION DEVICES AND AIDS (5/5) Hill start assistance The hill start assistance Depending on the gradient of the in- system cannot completely cline, this system assists the driver prevent the vehicle from when starting on a hill. It prevents the rolling backwards in all sit- vehicle from rolling backwards by au- uations (extremely steep gradients...
Page 185: Lane Departure Warning
LANE DEPARTURE WARNING (1/5) Location of the camera 1 Make sure the windscreen is not ob- scured (dirt, mud, snow, condensation etc.). Using information from the 1 camera, the function warns the driver when a continuous or broken line is crossed or when approaching the roadside (di- vider, barrier, pavement, embankment, etc.) without the direction indicator...
Page 186 LANE DEPARTURE WARNING (2/5) To disable the function, press the 2 switch as many times as required to select “Lane departure warning off” (or, depending on the vehicle “Lane Keeping deactivated”) on the instru-  ment panel. Warning light goes out on the instrument panel.
Page 187 LANE DEPARTURE WARNING (3/5) Temporarily not available Conditions for non-activation of the system – Very fast lane departure; The system cannot be activated when: – driving continuously on a line; – reverse gear is engaged; – four seconds approximately after changing lanes;...
Page 188 LANE DEPARTURE WARNING (4/5) Operating faults – press the 6 or 7 control repeatedly to reach the “DRIVING ASSIST” menu. In the event of a malfunction, the left Press the switch 8 OK; and right line indicators (and, depend-  –...
Page 189 LANE DEPARTURE WARNING (5/5) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 190: Lane Keeping Assist
LANE KEEPING ASSIST (1/6) Location of the camera 1 Make sure the windscreen is not ob- scured (dirt, mud, snow, condensation etc.). Using information from the 1 camera, the function triggers corrective action on the vehicle steering system when a continuous or broken line is crossed or when approaching the roadside (di- vider, barrier, pavement, embankment, etc.) without the direction indicator...
Page 191 LANE KEEPING ASSIST (2/6) To disable the function, press the 2 switch as many times as required to select “Lane Keeping deactivated” on the instrument panel.  Warning light goes out on the in- strument panel. Note: deactivating the “Lane Keeping Assist”...
Page 192 LANE KEEPING ASSIST (3/6) In these cases: Special cases – the function triggers an action on the When using the function: vehicle’s steering system to correct – If the system can no longer detect the vehicle trajectory; any action by the driver on the steer- ...
Page 193 LANE KEEPING ASSIST (4/6) Temporarily not available Conditions for non-activation of the system – Very fast lane departure; – driving continuously on a line; The system cannot be activated when: – four seconds approximately after – reverse gear is engaged; changing lanes;...
Page 194 LANE KEEPING ASSIST (5/6) Operating faults – press the 6 or 7 control repeatedly to reach the “DRIVING ASSIST” menu. When the system detects an operating Press the switch 8 OK; © fault, the warning light appears – press the 6 or 7 control repeatedly on the instrument panel along with the to reach the “Lane Keeping sensitiv- message “Front camera to check”.
Page 195 LANE KEEPING ASSIST (6/6) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 196: Blind Spot Warning
BLIND SPOT WARNING (1/7) Special feature Using information from the sensors in- stalled on each side of the rear bumper Make sure that the radar area C is not (area C), the function warns the driver: obscured (by stickers, mud, snow etc.). –...
Page 197 BLIND SPOT WARNING (2/7) – press the switch 5 OK again to acti- vate or deactivate the function: function activated < function deactivated Activation/deactivation – press the 3 or 4 control repeatedly to reach the “Settings” menu. Press the Vehicles fitted with a multimedia switch 5 OK;...
Page 198 BLIND SPOT WARNING (3/7) Indicator 6 Operation An indicator light 6 is located on each The function warns you when the speed rear view mirror 7. of your vehicle is over approximately 9 mph (15 km/h) and: Note: clean the rear view mirrors 7 reg- –...
Page 199 BLIND SPOT WARNING (4/7) Display E Conditions for non-function Direction indicator activated, the 6 – When driving on a road with tight warning light flashes when the func- bends; tion detects a vehicle in the blind spot – in reverse. warning area and/or a vehicle is rapidly If the vehicle is equipped with a towbar approaching from the rear on the side...
Page 200 BLIND SPOT WARNING (5/7) Operating faults If the system detects a fault, the mes- sage “Side radars to check” is displayed on the instrument panel. Consult an ap- proved dealer. – The system’s detection range operates according to a standard lane width. If you are driving in wide traf- fic lanes, the system might not be able to detect a vehicle in the...
Page 201 BLIND SPOT WARNING (6/7) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
Page 202 BLIND SPOT WARNING (7/7) Limitation of the system operation – The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the system. – Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system. –...
Page 203: Safe Distance Alert
SAFE DISTANCE ALERT (1/4) The function is activated when the vehi- cle speed is between about 19 and 124 mph (30 and 200 km/h). Location of the camera 1 Make sure the windscreen is not ob- scured (by dirt, mud, snow, condensa- tion etc.).
Page 204 SAFE DISTANCE ALERT (2/4) – press the 5 or 6 control repeatedly to reach the “Distance warning” menu. Press the switch 7 OK; – Press the switch 7 OK again to acti- vate or deactivate the function: function activated < function deactivated Activating/deactivating the Vehicles not fitted with a multimedia...
Page 205 SAFE DISTANCE ALERT (3/4) – C (orange): the time interval falls be- tween around 1 and 2 seconds (in- sufficient distance between the two vehicles); – D (red): the time interval is less than or equal to around one second (very insufficient distance between the two The measurement is dis- vehicles).
Page 206 SAFE DISTANCE ALERT (4/4) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 207: 360° Camera
360° CAMERA (1/9) Operation Using information from cameras 1, 2, – front side view (depending on the ve- and 3 located in the front bumper, door hicle): using camera 2 (passenger The cameras transmit four separate mirrors and on the tailgate, as well as side).
Page 208 360° CAMERA (2/9) Front view 1 Rear view 3 The view of the front camera is dis- The view of the rear camera is dis- played on the multimedia screen 5. played on the multimedia screen 5. In front view or rear view: when manoeuvring on a slope, objects shown on the multimedia screen may...
Page 209 360° CAMERA (3/9) The front, rear and side view guide- lines are a representation projected onto flat ground; this information must not be taken into account when superimposed on a vertical object or an object on the ground. Objects displayed on the edge of the multimedia screen may appear distorted.
Page 210 360° CAMERA (4/9) Bird’s eye view Front side view on passenger side 2 The bird’s eye view is a combined rep- (depending on the vehicle) resentation from cameras 1, 2 and 3. The camera, fitted in the door mirror, It displays a view of the top of the vehi- transmits a side view to the multimedia cle and its surroundings.
Page 211 360° CAMERA (5/9) In addition to the sound alert, these in- dicator lines show the proximity of ob- stacles via different colours: – Green: obstacle between approxi- mately 50 and 70 cm; – Yellow: obstacle between approxi- mately 30 and 50 cm; –...
Page 212 360° CAMERA (6/9) Automatic mode is disabled: – when the gear lever is in neutral (manual gearbox) or in position N or P (automatic gearbox) for approxi- mately three seconds; – when the vehicle speed moving for- ward exceeds 6 mph (10 km/h). Manual mode To activate manual mode, with the ve- hicle stopped and the engine running,...
Page 213 360° CAMERA (7/9) Difference between the Driving or reversing towards a steep Driving or reversing towards a downhill slope protruding object estimated distance and actual distance The fixed guidelines 15 show the dis- Position H seems further than posi- tances as further than they actually are. tion J on the screen.
Page 214 360° CAMERA (8/9) Adjusting the display Limitations of system operation The system is unable to display objects With the ignition on, press the 14 switch located in certain areas. or move the selection lever to posi- tion R (on an automatic gearbox) or to In the front or rear view mode, the reverse gear (on a manual gearbox) in system cannot be used to view an...
Page 215 360° CAMERA (9/9) Adjusting the camera If the gear lever is in position R (on an When shifting from reverse gear to po- automatic gearbox) or in reverse (on a sition D (on an automatic gearbox) or settings manual gearbox), the following views into a gear (on a manual gearbox), the The following settings can be modified: are available:...
Page 216: Active Emergency Braking
ACTIVE EMERGENCY BRAKING (1/8) Depending on the reactivity of the driver, the system can assist with brak- ing in order to limit damage or prevent a collision. Note: ensure that the windscreen and front bumper are not obstructed (by dirt, mud, snow, condensation, number plate, etc.).
Page 217 ACTIVE EMERGENCY BRAKING (2/8) Operation Special features of warnings Depending on the speed, the warning Detection of vehicles and braking may be activated simulta- When driving, in the event of a risk of neously. collision with the vehicle in front the system will: Special features of stationary vehicles...
Page 218 ACTIVE EMERGENCY BRAKING (3/8) Detection of pedestrians and Special features of warnings cyclists Depending on the speed, the warning (depending on the vehicle) and braking may be activated simulta- When driving at a speed between ap- neously. proximately 4 mph (7 km/h) and 50 mph (80 km/h), if there is a risk of col- lision with a cyclist or a pedestrian, the system:...
Page 219 ACTIVE EMERGENCY BRAKING (4/8) – press the 6 or 7 control repeatedly to reach the “Active braking” menu and press the 8 OK switch. Press the switch 8 OK again to activate or deactivate the function: function activated < function deactivated Upon deactivation of the system, the ...
Page 220 ACTIVE EMERGENCY BRAKING (5/8) Temporarily not available Operating faults If the system detects a temporary When the function detects an operat-   © fault the warning light illumi- ing fault, the warn-  nates, or depending on the vehicle the ...
Page 221 ACTIVE EMERGENCY BRAKING (6/8) Active emergency braking This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steer- ing wheel, pedals etc.).
Page 222 ACTIVE EMERGENCY BRAKING (7/8) System disturbance Some conditions can disturb or damage the operation of the system, such as: – a complex environment (metal bridge, tunnel etc.); – poor weather conditions (snow, hail, black ice etc.); – poor visibility (night, fog etc.); –...
Page 223 ACTIVE EMERGENCY BRAKING (8/8) Deactivating the function You must disable the function if: – the brake lights are not functioning; – the area of the camera has been damaged (e.g. on the inside or outside of the windscreen); – the front of the vehicle was damaged (impact, scratch on the radar, etc.); –...
Page 224: Detection Of Road Signs
DETECTION OF ROAD SIGNS (1/4) Note: make sure the windscreen is not For vehicles equipped with a navigation obscured (dirt, mud, snow, condensa- system and if the vehicle is travelling in tion etc.). a country where the speed units differ from those of the vehicle, the system For vehicles which are equipped with it, displays the speed limit sign in the unit...
Page 225 DETECTION OF ROAD SIGNS (2/4) – press the 4 or 5 control repeatedly to reach the “Settings” menu and press 6 OK; – press the 4 or 5 control repeatedly to reach the “DRIVING ASSIST” menu and press 6 OK; –...
Page 226 DETECTION OF ROAD SIGNS (3/4) If the speed limit is exceeded, the circle around the panel flashes (7 warning light) along with a sound signal to warn the driver. Operation Varying the limit speed If the speed limit notification differs from Warning lights the detected speed value, press and The function displays the following...
Page 227 DETECTION OF ROAD SIGNS (4/4) Operating faults The system cannot detect the speed limit if: – the windscreen is not clean; – the camera is blinded by the sun; – there is insufficient visibility (night, fog etc.); – the signs are not legible (snow, etc.) or are hidden (by another vehicle or by trees);...
Page 228: Speed Limiter
SPEED LIMITER (1/4) Controls 1 Speed limiter On/Off switch. 2 Cruise control On/Off switch. 3 Speed limiter activation and speed reduction (SET/-). 4 Speed limiter activation and speed increase or recall of memorised limit speed (RES/+). 5 Speed limiter function standby (with limited speed memory) (O).
Page 229 SPEED LIMITER (2/4) Driving Switching on To store the current speed, press the 4 switch (RES/+) or the 3 switch (SET/- ) : When a limit speed has been set but Press switch 1. The 7 warning light ap- the limit speed replaces the dashes not yet reached, driving is similar to pears in grey.
Page 230 SPEED LIMITER (3/4) Exceeding the limit speed Limited speed cannot be maintained When driving down a steep gradient, It is possible to exceed the limit speed the system may not maintain the limit at any moment. To do this, press firmly speed: the limit speed flashes in red and fully the accelerator pedal (beyond on the instrument panel and an audi-...
Page 231 SPEED LIMITER (4/4) Putting the function on Switching off the function standby The speed limiter function is inter- rupted: The speed limiter function is suspended when you press switch 5 (O). The limit – when you press the 1 switch. In this speed is stored and displayed in grey case, the speed is no longer stored;...
Page 232: Cruise Control
CRUISE CONTROL (1/5) Controls 1 Cruise control On/Off switch. 2 Switch to activate and decrease cruising speed (SET/-). 3 Switch to activate and increase cruising speed or to recall the mem- orised cruising speed (RES/+). 4 Switch the function to standby (with cruising speed saved) (O).
Page 233 CRUISE CONTROL (2/5) Switching on Activating cruise control Driving Press switch 1. While the vehicle is moving a steady Once a cruising speed is registered speed above approximately 19 mph and the cruise control function is active, The 6 warning light appears in grey. (30 km/h), press the 2 (SET/-) switch you may lift your foot off the accelera- The “Cruise control ON”...
Page 234 CRUISE CONTROL (3/5) Exceeding the cruising speed The cruising speed may be exceeded at any time by depressing the accelera- tor pedal. While it is being exceeded, the cruising speed flashes in red on the instrument panel. Then, release the accelerator pedal: after a few seconds, the vehicle will automatically return to its set cruising speed.
Page 235 CRUISE CONTROL (4/5) Putting the function on Returning to the cruising speed NB: if the speed previously stored is much higher than the current speed, standby If a speed is stored, it can be recalled, the vehicle will accelerate more rapidly once you are sure that the road condi- The function is set to standby if you: to reach this threshold.
Page 236 CRUISE CONTROL (5/5) Switching off the function The warning light 6 disappears from the instrument panel to confirm that the The cruise control function is inter- function is no longer active. rupted: – when you press the 1 switch. In this case, the speed is no longer stored;...
Page 237 ADAPTIVE CRUISE CONTROL (1/14) Based on information from a radar According to conditions on the road or camera, the adaptive cruise con- (traffic, weather etc.), the adaptive trol function (or Stop and Go adap- cruise control function can be activated: tive cruise control function on vehicles –...
Page 238 ADAPTIVE CRUISE CONTROL (2/14) Location of the camera 1 Controls Make sure the windscreen is not ob- 3 Safe distance settings scured (by dirt, mud, snow, condensa- 4 Switch the function to standby (with tion etc.). cruising speed saved) (0). 5 Adaptive cruise control main stop/ Location of the radar 2 ...
Page 239 ADAPTIVE CRUISE CONTROL (3/14) Switching on The cruising speed 11 replaces the dashes and cruise control is confirmed Press switch 5. by the appearance of the cruising speed   Warning light appears in grey, in green and warning light and the message “Adaptive Cruise Ctl If you try to activate the function when ON”...
Page 240 ADAPTIVE CRUISE CONTROL (4/14) Safe distance control activation As soon as cruise control is activated, the default safe distance 10 is displayed in green on the instrument panel. The default safe distance corresponds to approximately two seconds (see follow- ing pages). If the system detects a vehicle in your lane, an outline of a vehicle 9 appears above the distance gauge 10 on the in-...
Page 241 ADAPTIVE CRUISE CONTROL (5/14) Adjusting the safe distance (cont.) – distance gauge B: intermediate dis- tance 2 (corresponding to approxi- mately 2 seconds); – distance gauge C: intermediate dis- tance 1 (corresponding to approxi- mately 1.6 seconds); – distance gauge D: short distance (corresponding to approximately 1.2 seconds).
Page 242 ADAPTIVE CRUISE CONTROL (6/14) Stop and start Putting the function on On vehicles fitted with an automatic standby gearbox, if the vehicle in front slows You can set the function to standby down, the system adapts its speed to a when: complete stop if necessary (in the event of a traffic jam, etc.).
Page 243 ADAPTIVE CRUISE CONTROL (7/14) Exit from standby Depending on the situation, the system sounds a beep associated with: Based on the stored cruising speed – the orange alert E if the situation re- If a speed is stored, it can be recalled, quires the driver’s attention;...
Page 244 ADAPTIVE CRUISE CONTROL (8/14) Operating faults If the radar detection area is obstructed or the radar signal is disrupted, the If an “Adaptive cruise control” function message “Front radar no visibility” is operating fault is detected, the mes- displayed on the instrument panel and sage “Check Adaptive Cruise control”...
Page 245 ADAPTIVE CRUISE CONTROL (9/14) Limitations of system The system cannot detect: Detection during cornering operation – vehicles arriving at intersections: slip When entering a corner or bend, the road (e.g. H) etc; radar and/or camera may temporarily Vehicle detection not be able to detect the vehicle in front –...
Page 246 ADAPTIVE CRUISE CONTROL (10/14) Detection of vehicles in adjacent Vehicles hidden due to variations in – vehicles transporting long objects lanes ground relief which exceed the line; The system may detect vehicles driving The system will not detect vehicles – the actual length of tall vehicles on an adjacent lane when: hidden due to variations in ground relief (e.g.
Page 247 ADAPTIVE CRUISE CONTROL (11/14) Stationary and slow moving – vehicles in front 12 that change lane, vehicles discovering a stationary vehicle 13 (e.g. P); When your speed is over approximately 31 mph (50 km/h), the system does – when the vehicle is stationary 14, not detect: when you change lane (e.g.
Page 248 ADAPTIVE CRUISE CONTROL (12/14) Non-detection of fixed obstacles Detection of vehicles moving into and objects of a small size lane at high speed The system cannot detect: If your vehicle is overtaken by another vehicle driving at high speed 15 (motor- –...
Page 249 ADAPTIVE CRUISE CONTROL (13/14) This function is an additional driving aid. It can under no circumstances replace the driver’s responsibility to respect speed limits and safe distances and to be vigilant. The driver must always be in control of the vehicle. The driver must always adapt their speed to the surroundings and driving conditions, regardless of system indications.
Page 250 ADAPTIVE CRUISE CONTROL (14/14) In the event of system disturbance Some conditions can disturb or damage the operation of the system, such as: – the windscreen or radar area is obscured (by dirt, ice, snow, condensation, number plate etc.); – a complex environment (tunnel etc.); –...
Page 251 MOTORWAY AND TRAFFIC ASSISTANT (1/16) The “Stop and Go adaptive The Motorway and Traffic Assistant is a Note: driving aid system designed for use on cruise control” function – the driver must observe the maxi- long motorway journeys, where traffic is mum speed limit and safe distances Based on information from a radar or flowing or in jams.
Page 252 MOTORWAY AND TRAFFIC ASSISTANT (2/16) The “Lane centring” function Additional information Using information from a camera, the Depending on the vehicle, the “Lane Centring” function manipulates “Motorway and Traffic Assistant” func- the steering system to direct the vehi- tion may be used with other driving aid cle to the middle of the lane.
Page 253 MOTORWAY AND TRAFFIC ASSISTANT (3/16) 2.117...
Page 254 MOTORWAY AND TRAFFIC ASSISTANT (4/16) Computer 1 Power-assisted steering 4 Active vehicle control 7 Receives information from the radar Operates the front wheels to assist the This system provides information on and camera to determine the vehi- trajectory of your vehicle according to vehicle dynamics to the computer 1 cle trajectory and speed (acceleration details transmitted by the 1 computer.
Page 255 MOTORWAY AND TRAFFIC ASSISTANT (5/16) 2.119...
Page 256: Stop And Go Adaptive Cruise Control
MOTORWAY AND TRAFFIC ASSISTANT (6/16) Controls Displays on the instrument Steering wheel 21 panel Safe distance settings The driver must always keep their hands on the steering wheel. If too “Stop and Go adaptive cruise con- Set active functions to standby ...
Page 257 MOTORWAY AND TRAFFIC ASSISTANT (7/16) Note: if you press button 11 when the Stop and Go adaptive cruise control is not activated, the message: “First acti- vate Adapt. cruise ct” appears on the instrument panel. Activating the “Lane Note: you must keep your hands on the driving wheel when using the “Lane Centring”...
Page 258 MOTORWAY AND TRAFFIC ASSISTANT (8/16) “Lane Centring” function on Certain actions carried out by the driver also suspend the “Lane Centring” func- standby tion: The “Lane Centring” function is put on – activating the indicators; standby automatically when: – too much force is used when han- –...
Page 259 MOTORWAY AND TRAFFIC ASSISTANT (9/16) Note: in some situations, the “Lane Centring” function may no longer detect your hands on the steering wheel and may sound a signal: – the vehicle is moving along a long straight lane and the driver’s hands are immobile on the steering wheel;...
Page 260 MOTORWAY AND TRAFFIC ASSISTANT (10/16) If the vehicle crosses a line com- pletely and moves out of lane, the “Lane Centring” function is put on standby. Standby of the function is  confirmed by the 15 warning light and the left-hand and right-hand line indicators 17 appearing in grey on the instrument panel.
Page 261 MOTORWAY AND TRAFFIC ASSISTANT (11/16) Image en attente – the Stop and Go adaptive cruise control is deactivated ➥ 2.101;  Note: pressing the 10 button once deactivates both the “Stop and Go adaptive cruise control” function and the “Lane Centring” function. –...
Page 262 MOTORWAY AND TRAFFIC ASSISTANT (12/16) Temporary unavailability Conditions in certain geographical If a “Stop and Go adaptive cruise con- areas may hinder the function, for ex- trol” function operating fault is detected, The radar is able to detect vehicles ample: the “Check Adaptive Cruise control”...
Page 263 MOTORWAY AND TRAFFIC ASSISTANT (13/16) The “Motorway and Traffic Assistant” function is an additional driving aid. It can under no circumstances replace the driver’s responsibility to respect speed limits and safe distances and to be vigilant. The driver must always be in control of the vehicle. The driver must always adapt their trajectory and speed according to the surroundings and traffic conditions.
Page 264 MOTORWAY AND TRAFFIC ASSISTANT (14/16) The “Motorway and Traffic Assistant” function is an additional driving aid. it can under no circumstances replace the driver's responsibility to respect speed limits and safe distances and to be vigilant. The driver must always be in control of the vehicle. The driver must always adapt their trajectory and speed according to the surroundings and driving conditions, regardless of system indications.
Page 265 MOTORWAY AND TRAFFIC ASSISTANT (15/16) Deactivating the system You must deactivate the system if: – the vehicle is travelling on a windy road; – the vehicle is being towed (breakdowns); – the vehicle is being driven with an emergency spare wheel; –...
Page 266 MOTORWAY AND TRAFFIC ASSISTANT (16/16) Some conditions can disrupt or damage the operation of the system, for example: – obstruction of the windscreen or the radar area (by dirt, ice, snow, condensation etc.) Frequently check the cleanli- ness and condition of the windscreen, front wiper blades and front bumper; –...
Page 267: Parking Distance Control
PARKING DISTANCE CONTROL (1/7) Location of the ultrasonic Depending on the vehicle, the system detects obstacles to the front, the rear sensors 1 and the sides of the vehicle. Ensure that the ultrasonic sensors indi- The parking distance control system cated by the arrows 1 are not obscured is only activated when the vehicle is (by dirt, mud, snow, a badly fitted/at-...
Page 268 PARKING DISTANCE CONTROL (2/7) Note: for vehicles fitted with the “360° camera” function ➥ 2.71, analysis of the vehicle surroundings (areas A and B) is not displayed in “Bird’s eye view” or “Side view” mode. Operation Most objects located less near the front, rear and sides of the vehicle are detected.
Page 269 PARKING DISTANCE CONTROL (3/7) If a side obstacle is detected: – the beeps become faster and then sound continuously as the obstacle gets nearer. Green, orange and red zones will be displayed on the dis- play D; – if there is no risk of collision, no beep will sound when approaching the ob- stacle.
Page 270 PARKING DISTANCE CONTROL (4/7) Vehicles not fitted with a multimedia screen With the vehicle stopped, press the 6 switch to deactivate parking distance control. The switch warning light illu- minates. Press again on the 6 switch to activate the function. The switch 5 warning light goes out.
Page 271 PARKING DISTANCE CONTROL (5/7) – select “BIP VOLUME” to adjust the – when an operating fault is detected. Park Assist volume using the 8 or 9 Note: if the vehicle is fitted with a control. towbar recognised by the system, only the rear Park Assist function is deacti- vated.
Page 272 PARKING DISTANCE CONTROL (6/7) System servicing/repairs – In the event of an impact, the alignment of the sensors may be altered and their operation may consequently be affected. Deactivate the function and consult an authorised dealer. – Any work in the area where the sensors are located (repairs, replacements, etc.) must be carried out by a qualified profes- sional.
Page 273 PARKING DISTANCE CONTROL (7/7) Limitation of the system operation – The area around the sensors must be kept clean and free of any modifications in order to ensure the proper operation of the system. – Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system. –...
Page 274: Reversing Camera
REVERSING CAMERA (1/3) Operation Fixed clearance gauge 3 4 moving guide line: The fixed clearance gauge comprises This is shown in blue on the multimedia When the vehicle is reversing, the coloured markers A, B and C indicating screen 2. camera 1 on the luggage compart- the distance behind the vehicle: ment lid transmits a view of the area...
Page 275 REVERSING CAMERA (2/3) Operating faults When reverse gear is engaged, if the system detects an operating fault, a black screen is displayed temporarily The screen shows a reverse mirror on the multimedia screen 2. image. This may be caused by a fault affecting The frames are a representation the camera or screen (clearness, fixed projected on a flat surface.
Page 276 REVERSING CAMERA (3/3) H J K Difference between the Reversing towards a steep downhill Reversing towards a protruding slope object estimated distance and actual distance The fixed guidelines 3 show the dis- Position H seems further than posi- tances as further than they actually are. tion J on the screen.
Page 277: Assisted Parking
ASSISTED PARKING (1/5) Switching on Special features Using ultrasonic detectors as indicated by the 3 arrows installed in the vehicle With the vehicle stationary or driving Ensure that the ultrasonic sensors indi- bumpers, this function helps to find ac- at less than approximately 19 mph cated by the 3 arrows are not obscured cessible parking spaces and assists in (30 km/h):...
Page 278 ASSISTED PARKING (2/5) Operation Note: when starting the vehicle, or after having successfully completed parallel Parking parking using the system, the default manoeuvre proposed by the system is As long as the vehicle speed is less assistance in exiting a parallel parking than 19 mph (30 km/h), the system space.
Page 279 ASSISTED PARKING (3/5) The space is then indicated on the mul- – Release the steering wheel; timedia screen by a capital letter “P”. – carry out manoeuvres at the front – Stop the vehicle; and rear by following the instructions shown on the multimedia screen 1 –...
Page 280 ASSISTED PARKING (4/5) Cancelling the manoeuvre The warning light on the 2 switch turns  The manoeuvre is cancelled in the fol- off, the warning light disappears lowing cases: from the instrument panel and a sound signal confirms that the manoeuvre has –...
Page 281 ASSISTED PARKING (5/5) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. Make sure that the manoeuvre complies with the applicable traffic regulations in your location.
Page 282 AUTOMATIC TRANSMISSION (1/4) Selector lever 1 Operation Gear changing paddles 5 and 6 P: park With gear lever 1 in position P, start the R: reverse engine. Depending on the vehicle, you can use N: Neutral paddles 5 and 6 to change gear when To move out of position P, you must de- D: automatic mode the lever is in position D.
Page 283 AUTOMATIC TRANSMISSION (2/4) Driving in automatic mode Driving in manual mode Put lever 1 into position D. When driving in position D you can switch to manual driving mode using In most road conditions you will en- paddles 5 and 6 on the steering wheel. counter, you will not need to touch your Depending on the vehicle, two manual lever again: the gears will change au-...
Page 284: Automatic Gearbox
AUTOMATIC TRANSMISSION (3/4) Special cases Special circumstances Note: in “Low” mode, the variations in engine speed are continuous and In certain driving conditions (result- If the road type or weather condi- the accelerations are more linear. tions ing in, for example, engine protection, (steep uphill slopes, sudden To avoid the engine stalling in very operation of the Electronic Stability...
Page 285 AUTOMATIC TRANSMISSION (4/4) Parking the vehicle Maintenance period Refer to the maintenance document When the vehicle is stopped, move the for your vehicle or consult an Approved lever to position P while keeping your Dealer to check whether the automatic foot on the brake pedal: the gearbox is gearbox requires scheduled mainte- in neutral and the drive wheels are me-...
Page 286: Emergency Call
EMERGENCY CALL (1/3) If the vehicle is equipped, the emer- gency call function can be used to call the emergency services (without charge) automatically or manually in the event of an accident or illness, re- ducing the time it takes for the emer- gency services to arrive.
Page 287 EMERGENCY CALL (2/3) Automatic mode In the event of unintended operation, it is possible to cancel the call by press- If the automatic mode 2 warning light ing the 3 button for around two sec- appears in green this confirms that the onds, before the call is connected to automatic system is activated.
Page 288 EMERGENCY CALL (3/3) The system operates with a dedi- cated battery. The battery serv- ice life is approximately four years (the 1 warning light lights up in red to warn you when approaching Without the emergency call feature, expiry). the system is not trackable and will Consult an approved dealer not be under constant surveillance.
Page 289 Section 3: Your Comfort MULTI-SENSE ..............Air Vents .
Page 290: Multi-Sense
MULTI-SENSE (1/2) “Eco” mode The “MULTI-SENSE” system enables a choice between three driving modes “Eco” mode focuses on energy saving. MULTI-SENSE that can be used to control driving, The steering is smooth, engine and ambient lighting, comfort and engine gearbox management enable fuel con- sound (depending on the vehicle): sumption to be reduced ➥...
Page 291 MULTI-SENSE (2/2) “Sport” mode This mode enables an increased re- sponsiveness from the engine and the gearbox. The steering is firmer. “My Sense” mode Using standard default vehicle settings, this mode can be used to manually con- figure driving, ambient lighting, comfort and engine sound (depending on the vehicle).
Page 292: Air Vents
AIR VENTS, air outlets (1/2) 6 Right-hand air vent 1 Left-hand air vent 7 Passenger footwell heater outlets 2 Left-hand side window demisting 8 Control panel vent 9 Footwell heater outlets for rear 3 Windscreen demisting vents passengers (depending on the 4 Centre air vents vehicle) 5 Right-hand side window demister...
Page 293 AIR VENTS, air outlets (2/2) Centre 4 and side vents 1 Rear seats and 6 (depending on vehicle) Passenger footwell heater outlets 9. Air flow To close: move the cursor 10 towards the outside of the vehicle beyond the resistance point. To open: move the cursor 10 towards the inside of the vehicle.
Page 294: Manual Air Conditioning, Heating System
MANUAL AIR CONDITIONING, HEATING SYSTEM (1/6) Distribution of air in the passenger compartment There are five air distribution options. Turn control 1 to choose the distribution option. The air flow is directed to the windscreen and the front side window demisting vents. ...
Page 295 MANUAL AIR CONDITIONING, HEATING SYSTEM (2/6) Switching air conditioning on or off Activation is not possible if the 3 control is set to “0” (control A) or “OFF” (con- trol B). Press the 6 button to deactivate the air conditioning. The button’s warning light will go out.
Page 296 MANUAL AIR CONDITIONING, HEATING SYSTEM (3/6) Air recirculation (isolation of Switching air conditioning on Stopping the system the passenger compartment) or off Turn the 3 control to “OFF” or “0” to switch off the system or press the 4 Air recirculation is for: In automatic mode, the system switches button.
Page 297 MANUAL AIR CONDITIONING, HEATING SYSTEM (4/6) Switching the air recirculation on Press button 4: the button’s warning light comes on. Under these conditions, air is taken from the passenger com- partment and is recirculated, with no air being taken from outside the vehicle. If the air conditioning is not acti- Air recirculation is for: vated (“A/C”...
Page 298 MANUAL AIR CONDITIONING, HEATING SYSTEM (5/6) Adjusting the air temperature Turn control 5 to obtain the desired temperature. The further towards the red the slide is, the higher the tempera- ture will be. When the air conditioning system is used for long periods, it may begin to feel cold.
Page 299 MANUAL AIR CONDITIONING, HEATING SYSTEM (6/6) Rear screen de-icing/ Rapid demisting demisting Turn controls 1, 3 and 5 to: With the engine running, press – demisting button 2. The operating tell-tale comes – the fan speed in position 3 or 4; This function permits rapid demisting/ –...
Page 300: Automatic Climate Control
AUTOMATIC CLIMATE CONTROL (1/4) Adjusting the ventilation speed. In automatic mode, the system uses the most suitable amount of air to reach and maintain the desired comfort level. You can still adjust the ventilation speed by turning control 1 to increase or reduce the ventilation speed.
Page 301 AUTOMATIC CLIMATE CONTROL (2/4) Clear View function Press the 2 button: the integrated indi- cator light comes on. This function quickly demists and de- ices the windscreen, the rear screen, the front side windows, and the door mirrors (depending on the vehicle). It automatically activates the air condi- tioning and rear screen de-icing func- tions.
Page 302 AUTOMATIC CLIMATE CONTROL (3/4) Rear screen de-icing/ Switching air conditioning on demisting or off Press the 8 button: the integrated in- In automatic mode, the system switches dicator light comes on. This function the air conditioning system on or off, enables rapid demisting or de-icing of depending on the climate conditions.
Page 303 AUTOMATIC CLIMATE CONTROL (4/4) Stopping the system Turn the control 1 to “OFF” to stop the system. To start it, turn the control 1 again, then adjust the fan speed or press the button 4. Air recirculation (isolation of Manual use the passenger compartment) Press the 7 button: the integrated indi- cator light comes on.
Page 304 AIR CONDITIONING: information and operating instructions (1/2) Advice on use Fuel consumption Operating faults In some situations (air conditioning off, You will normally notice an increase in As a general rule, contact your ap- air recirculation activated, ventilation fuel consumption (especially in town) proved dealer in the event of an oper- speed at zero or low etc.), you may when the air conditioning is operating.
Page 305 AIR CONDITIONING: information and operating instructions (2/2) Ñ Type of refrigerant fluid  Type of oil in the air condi- tioning circuit  Inflammable product  Consult the driver’s hand- book  Maintenance Quantity of refrigerant fluid present in the ve- x.xxx kg hicle.
Page 306: Multimedia Equipment
MULTIMEDIA EQUIPMENT (1/2) Multimedia systems A, B or Multimedia sockets 2 The sockets USB can also be used to recharge accessories with a maximum radio C You can use the USB sockets to access power rating of 12 Watts (5 Volts) per the multimedia content of your acces- The location and operation of equip- socket, which have been approved by...
Page 307 MULTIMEDIA EQUIPMENT (2/2) Steering column controls 4 Microphone 8 Wireless charger 9 You can use the hands-free telephone 6 ➥ 3.27 and voice recognition 7 controls on ve- hicles fitted with these. Using the telephone We remind you of the need to conform to the legislation in force concerning the use of such equipment.
Page 308: Electric Windows
ELECTRIC WINDOWS (1/3) These systems operate with the igni- tion on or off, until one of the front doors is opened (limited to about 3 minutes). Driver’s responsibility Never leave your vehicle with the card or key inside, with a child, adult who is not self-sufficient or a pet in the vehicle, even for a short while.
Page 309 ELECTRIC WINDOWS (2/3) Remote control window Impossible to operate the one-touch electric window closing The one-touch electric window is When the doors are locked from the equipped with heat protection: if you outside, if you double press the lock- press the switch for the window more ing button on the driver’s door in than sixteen consecutive times it goes hands-free mode, on the card or, de-...
Page 310 ELECTRIC WINDOWS (3/3) Operating faults In case of a fault when closing a window, the system reverts to normal mode: pull the switch concerned up as often as necessary to fully close the window (the window will close gradu- ally), hold the switch (still on the clos- ing side) for one second then lower and raise the window fully to reinitialise the system.
Page 311: Sun Visor
SUN VISOR Front sun visor Lower sun visor 1. Courtesy mirrors (depending on the vehicle) Lift the cover 2. The light 3 switches on automatically. When driving, ensure the courtesy mirror cover is closed. Risk of injury. 3.23...
Page 312: Interior Lighting
INTERIOR LIGHTING (1/3) Courtesy light A Courtesy light B Press switch 1 for: Press the 2 switch for the driver and press 3 for the front passenger to – permanent lighting; enable: – lighting controlled by the unlocking of – permanent lighting; the vehicle or by opening one of the doors.
Page 313 INTERIOR LIGHTING (2/3) Map reading light Note: on vehicles fitted with a multime- dia screen, you can use the multime- (depending on the vehicle) dia screen to deactivate/activate the Press the 4, 5 or 6 switch to enable: reading lights which switch on when –...
Page 314 INTERIOR LIGHTING (3/3) Glove box light Luggage compartment light Depending on the vehicle, the 7 light Light 8 comes on when the luggage switches on when the cover is opened. compartment is opened. Unlocking and opening the doors or tailgate switches on the timed cour- tesy lights and lights.
Page 315: Passenger Compartment Storage, Fittings
PASSENGER COMPARTMENT STORAGE, FITTINGS (1/5) Front door storage pockets 1 Open storage compartment 2 Dashboard storage compartment 3 It can hold a 1.5 litre bottle. Open and move the flap to access the storage compartment Nothing should be placed Ensure that no hard, heavy on the floor area in front of or pointed objects are the driver as such objects...
Page 316 PASSENGER COMPARTMENT STORAGE, FITTINGS (2/5) Sun blind storage Centre console storage compartment 4 compartment/induction charging zone 5 This can be used for storing motorway tickets, cards, etc. For more information on the induction charging zone, please refer to the mul- timedia instructions.
Page 317 PASSENGER COMPARTMENT STORAGE, FITTINGS (3/5) Centre armrest storage compartment 7 Lift the central armrest cover 6. 3.29...
Page 318 PASSENGER COMPARTMENT STORAGE, FITTINGS (4/5) Cup holders 9 Cup holders 10 Passenger storage compartment Slide 8 to access the cup holder. This can be used to store a mobile ash- tray, drink cans, etc. Pull handle 11 to open it. The cup holder is equipped with retain- ing hooks to keep the cup in place.
Page 319 PASSENGER COMPARTMENT STORAGE, FITTINGS (5/5) Rear door storage Rear seat storage pockets 13 Grab handle 14 compartment 12 This offers support and can be held when the vehicle is moving. Do not use it for getting into or out of the vehicle.
Page 320: Accessories Socket
ACCESSORIES SOCKET Accessories socket 1 You can use the 1 socket. It is pro- vided for the purpose of connecting ac- cessories approved by our Technical Department. Connect accessories with a maximum power of 120 watts (12 V) only. When several accessory sockets are used at the same time, the total power of the connected accessories must not exceed...
Page 321: Rear Headrests
REAR HEAD RESTS Position for use To refit the headrest When the headrest is set at the lowest position, this is for storage Lift the headrest fully until it locks. Enter the rods in their housing and only. It should not be in this position push down the headrest until it locks to Check that the bonnet is correctly when a seat is occupied.
Page 322: Rear Bench Seat: Functions
REAR BENCH SEAT: functions To replace the seatback, proceed in the reverse order to removal. Refit the seatback and click it back into place. When refitting the seat- back, make sure it is cor- rectly locked in place. If seat covers are fitted, make sure these do not prevent the seatback latch from locking in.
Page 323: Luggage Compartment
BOOT To open Opening the doors manually from the inside Press the 1 button to open the luggage compartment lid a few centimetres. If it is impossible to unlock the tailgate, it can be done manually from inside: Lift the luggage compartment lid. –...
Page 324: Rear Parcel Shelf
REAR PARCEL SHELF Removal Utility version – Lift the clips 1 using movement A to Unclip mountings 3 on either side of the detach the cords from the luggage parcel shelf, then remove it via the boot. compartment lid; To refit it, proceed in the reverse order –...
Page 325 BOOT ARRANGEMENTS Mobile floor 1 Intermediate position Storage position In the blocked position, it allows you to This allows for more space to store Flat position access the tools stored under the boot things in the boot. Enables you to flatten the floor by fold- carpet.
Page 326: Transporting Objects In The Luggage Compartment
TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT Always position the objects transported so that the largest surface is against: – the rear bench seatback, for normal loading (example A); – the front seatbacks with the rear seat- backs folded down, as is the case for maximum loads (example B).
Page 327: Transporting Objects Towbar
TRANSPORTING OBJECTS towbar Permissible nose weight, maxi- - mum permissible towing weight braked and unbraked: ➥ 6.9. Choice and fitting of towing equipment Maximum weight of towing equip- ment: – 10 kg on a vehicle with towing pre-equipment; Maximum dimension A: 762 mm. –...
Page 328: Roof Bars, Spoiler
ROOF BARS, SPOILER Precautions during use Handling the tailgate Before handling the tailgate, check the objects and/or accessories (bike rack, roof box, etc.) fitted to the roof bars: these must be correctly positioned and secured, so as not to hinder the opera- tion of the tailgate.
Page 329 Section 4: Maintenance Bonnet ............... . Engine oil level: general information .
Page 330: Bonnet
BONNET (1/2) Unlocking the bonnet catch Opening the bonnet To open the bonnet, open a door and pull the 1 handle, located on the left- To unlock, push tab 2 at the same time Lift the bonnet and release stay 5 from hand side of the dashboard.
Page 331 BONNET (2/2) Ensure that the bonnet is properly locked. Check that nothing is pre- venting the catch from lock- ing (gravel, cloth, etc.). Closing the bonnet After any procedure in the Before closing the bonnet, make sure engine compartment, make that nothing has been left in the engine sure that you do not forget compartment.
Page 332: Engine Oil Level: General Information
ENGINE OIL LEVEL: general information It is normal for an engine to use oil for Adding engine oil lubrication and cooling of moving parts and it is normal to top up the level be- Use a funnel or protect the tween oil changes.
Page 333: Engine Oil Level: Topping Up, Filling
ENGINE OIL LEVEL: topping up, filling, draining (1/3) Topping up/filling – Unscrew cap 1; – top up the level (capacity between The vehicle must be parked on level “mini” and “maxi” of the gauge 2 and ground and the engine should be cold between 0.9 to 2 litres according to (for instance, before the engine is the engine);...
Page 334: Oil Change
ENGINE OIL LEVEL: topping up, filling, draining (2/3) Oil change Service interval: refer to the mainte- nance document for your vehicle. Oil change capacity Exceeding the maximum Please refer to the maintenance doc- engine oil level ument for your vehicle, or contact an Under no circumstances authorised dealer.
Page 335: Levels
ENGINE OIL LEVEL: topping up, filling, draining (3/3) Consult your approved dealer at once if you notice an abnormal or repeated drop in any of the fluid levels. When working in the engine compartment, ensure that the windscreen wiper stalk is in the park position.
Page 336 LEVELS, FILTERS (1/3) Frequency of checking coolant level Replacement interval Check the coolant level regularly Refer to the Maintenance Document for (very severe damage is likely to be your vehicle. caused to the engine if it runs out of coolant). If the level needs to be topped up, only use products approved by our Technical Department which ensure:...
Page 337: Brake Fluid
LEVELS, FILTERS (2/3) Level 2 It is normal for the level to drop as the brake shoes become worn, but it must never drop lower than the “MINI" warn- ing line. If you wish to check the disc and drum wear yourself, you should obtain the document explaining the checking pro- cedure from the manufacturer’s net-...
Page 338: Windscreen Washer Reservoir
LEVELS, FILTERS (3/3) Filters Liquid Windscreen washer fluid. In winter, use The replacement of filter components anti-freeze product. Use products rec- (air filter, cabin filter, diesel filter, etc.) ommended by an authorised dealer. is scheduled in the maintenance opera- tions for your vehicle. Note: do not use pure water (risk of damage to the priming pump, limescale Replacement intervals for filter el-...
Page 339: Tyre Pressure
TYRE PRESSURE (1/2) Vehicle fitted with a tyre pressure loss warning system In the event of under-inflation (punc-  tures, under-inflation etc.), the warning light appears on the instrument panel. ➥ 2.38. Label A B: dimension of the tyres fitted to the vehicle.
Page 340 TYRE PRESSURE (2/2) Tyre safety and chain fitting: for infor- Vehicles used fully laden mation on servicing conditions and, de- (Maximum Permissible pending on the vehicle version, the use All-up Weight) and towing of chains. ➥ 5.11. a trailer The maximum speed must be lim- For your safety, please re- ited to 62 mph (100 km/h) and the spect the speed limit.
Page 341: Battery
BATTERY (1/2) Depending on the vehicle, a system continuously checks the battery charge status. If this decreases, the “Battery Now In Standby Mode” message ap- pears on the instrument panel followed by “Battery Low Start Engine”. In this case, start the engine and the message on the instrument panel will disappear.
Page 342 BATTERY (2/2) For your own safety and for The battery is a specific the proper operation of the type, please ensure it is vehicle's electrical equip- replaced with the same ment (lights, windscreen type. Consult an approved wipers, ABS, etc.), any intervention dealer.
Page 343: Bodywork Maintenance
BODYWORK MAINTENANCE (1/3) You should A well-maintained vehicle will last Respect local regulations about wash- longer. ing vehicles (e.g. do not wash your ve- Wash your car frequently, with the hicle on a public highway). It is therefore recommended to main- engine off, with cleaning products rec- tain the exterior of the vehicle regularly.
Page 344 BODYWORK MAINTENANCE (2/3) What you should not do Vehicles with a matte paint Degrease or clean using finish Wash the vehicle in bright sunlight or high-pressure cleaning freezing temperatures. This type of paint requires certain pre- equipment or by spray- cautions.
Page 345 BODYWORK MAINTENANCE (3/3) Using a roller type car wash Cleaning the headlights, Cleaning stickers, decorative sensors and cameras films, etc. Return the wiper stalk to the park posi- tion ➥ 1.107. Use a soft cloth or cotton wool. You should do the following Check the mounting of external ac- If this does not clean them properly, Use a soft cloth or cotton wool.
Page 346: Interior Trim Maintenance
INTERIOR TRIM MAINTENANCE (1/2) Glass instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g. instrument panel, clock, exterior Vacuum-clean the textiles regularly. maintain the interior of the vehicle regu- temperature display etc.) larly.
Page 347 INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable You should not: equipment originally fitted in Position objects such as deodorants, the vehicle scents etc. near air vents as this could damage your dashboard trim. If you need to remove equipment in order to clean the passenger com- partment (for example, mats), always ensure that they are correctly refitted and are the right way around (the driv-...
Page 348 4.20...
Page 349 Section 5: Practical Advice Puncture, emergency spare wheel ..........Tyre inflation kit .
Page 350: Puncture, Emergency Spare Wheel
PUNCTURE, EMERGENCY SPARE WHEEL (1/2) In case of puncture If the emergency spare wheel has been stored for several years, have it Depending on the vehicle, a tyre infla- checked by your Dealer to ensure that it is safe to use. tion kit or emergency spare wheel is Vehicle fitted with an emergency spare wheel that differs from the provided (refer to the following pages).
Page 351 PUNCTURE, EMERGENCY SPARE WHEEL (2/2) Emergency spare wheel – remove the tool kit 4; To get to it: – remove the emergency spare wheel (A or B, depending on the vehicle). – open the boot; – depending on the vehicle, lift up the movable floor and the luggage com- partment mat 1;...
Page 352 TYRE PRESSURE KIT (1/3) Do not attempt to use the The kit is only approved for inflation kit if the tyre has inflating the tyres of the ve- been damaged as a result hicle originally equipped of driving with a puncture. with the kit.
Page 353 TYRE PRESSURE KIT (2/3) With the engine running and the If a minimum pressure of 1.8 bar is parking brake applied, not reached after 15 minutes, repair is not possible; do not drive the ve- – Disconnect any accessories previ- ously connected to the vehicle’s ac- hicle but contact an approved dealer.
Page 354 TYRE PRESSURE KIT (3/3) – Start immediately and drive at a speed between 12 to 37 mph (20 to 60 km/h) in order to distribute the product evenly in the tyre; after driv- ing a distance of 2 miles (3 km), stop and check the pressure.
Page 355: Tools
TOOLS Jack 2 Fold it correctly before refitting it in its housing (ensure that the wheelbrace is correctly positioned). Hubcap tool 3 This tool is used to remove the wheel trims. Wheel bolt guide 4 To finish loosening or starting to tighten the wheel bolts.
Page 356: Wheel Trim, Wheel
WHEEL TRIM, WHEEL Remove the wheel trim using hubcap tool 1 (located in the tool kit) by en- gaging the hook in the opening near valve 2. To refit it, align it with valve 2. Push the retaining hooks in fully, starting with side A near the valve, followed by B and C, finishing at D opposite the valve.
Page 357: Changing A Wheel
CHANGING A WHEEL (1/2) Vehicles equipped with a jack Start cranking the jack by hand, posi- tioning the 4 jack support plate in the and wheelbrace slightly indented groove underneath If necessary, remove the wheel trim. the vehicle, located between the two notches 5 and in the direction of the Use the wheelbrace 1 to slacken off the arrow 3.
Page 358 CHANGING A WHEEL (2/2) Undo the bolts and take off the wheel. Vehicle fitted with a tyre pressure loss warning system Fit the emergency spare wheel on the central hub and turn it to locate the In the event of under-inflation (punc- ...
Page 359: Tyres (Tyre And Wheel Safety, Use In Winter)
TYRES (1/3) Tyre and wheel safety When the tyre tread has been worn to the level of the warning strips, they The tyres are the only contact between become visible 2: it is then neces- the vehicle and the road, so it is essen- sary to replace your tyres because the tial to keep them in good condition.
Page 360 TYRES (2/3) Tyre pressures Pressures should be checked when the Vehicle fitted with a tyre pressure tyres are cold; ignore higher pressures loss warning system Adhere to the tyre pressures (including which may be reached in hot weather In the event of under-inflation (punc- the emergency spare wheel).
Page 361 TYRES (3/3) Fitting new tyres Use in winter Snow or Winter tyres We would recommend that these be Chains fitted to all four wheels to ensure that For safety reasons, fitting snow your vehicle retains maximum adhe- chains to the rear axle is strictly for- sion.
Page 362: Headlights (Changing Bulbs)
FRONT HEADLIGHTS: replacing the bulbs LED front fog lights/ cornering lights 3 (depending on the vehicle) Consult an authorised dealer. Additional lights If you wish to fit fog lights to your ve- hicle, please see an authorised dealer. Direction indicators/dipped beam headlights/LED main beam headlights 1 Please see an authorised dealer.
Page 363: Rear Lights And Side Lights (Replacing Bulbs)
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/3) LED side light/brake light 1 – release the light assembly from out- Refitting side the vehicle by pulling towards To refit, proceed in the reverse order, Consult an approved dealer the rear; taking care not to damage the wiring.
Page 364 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (2/3) Fog lights and reversing High level brake light 7 Number plate lights 8 lights 6 Consult an approved dealer. – Unclip the light by pressing tab 9; Consult an approved dealer –...
Page 365 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (3/3) LED number plate lights 10 LED side repeaters11 (depending on vehicle) (depending on vehicle) Consult an approved Dealer. Consult an approved dealer. The bulbs are under pres- sure and can break when replaced.
Page 366: Interior Lighting: Changing Bulbs
INTERIOR LIGHTING: changing bulbs (1/2) Courtesy light Map reading lights 2 Consult an authorised dealer. Courtesy light fitted with diffusers 1 Unclip the lens (using a flat-blade screwdriver or similar). Remove the bulb concerned. Bulb type: W5W. The bulbs are under pres- sure and can break when replaced.
Page 367 INTERIOR LIGHTING: changing bulbs (2/2) Luggage compartment light Glovebox light Courtesy mirror lights 5 Unclip the light 3 by pressing the tab on Unclip the light 4 by pressing the tab on Please consult an authorised dealer. its left side (using a flat-bladed screw- its left side (using a flat-bladed screw- driver or similar).
Page 368: Remote Control Key: Battery
REMOTE CONTROL KEY: BATTERY: battery (1/2) Replacing the battery Note: It is not advisable to touch the electronic circuit in the key cover when Open the case at slot 1 using a flat- replacing the battery. blade screwdriver or similar, and re- When refitting, ensure that the cover is place the battery 2, observing the type correctly clipped on and the screw tight-...
Page 369 REMOTE CONTROL KEY: BATTERY: battery (2/2) Operating faults If the battery is too weak to ensure cor- rect operation, you will still be able to start and lock/unlock the vehicle ➥ 1.14. Precautions relating to Do not throw away your used bat- batteries: teries;...
Page 370: Card: Battery
CARD: battery (1/2) The batteries are available from ap- proved Dealers, and their service life approximately two years. Check that there is no dye on the battery: risk of an incorrect electrical con- tact. When they need to be re- Replacing the battery When refitting, proceed in the reverse placed, be sure to use...
Page 371 CARD: battery (2/2) Operating faults If the battery is too weak to ensure cor- rect operation, you will still be able to start and lock/unlock the vehicle ➥ 1.14. Precautions relating to batteries: – keep (new or used) bat- teries out of reach of chil- dren;...
Page 372 BATTERY: troubleshooting (1/3) To avoid all risk of sparks: Connecting a battery charger – Ensure that any power consumers The battery charger must be com- (courtesy lights, etc.) are switched patible with a battery with nominal off before disconnecting or recon- voltage of 12 volts.
Page 373 BATTERY: troubleshooting (2/3) Starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.
Page 374 BATTERY: troubleshooting (3/3) Start the engine of the vehicle supply- ing the current and run it at an interme- diate engine speed. If your vehicle’s engine does not start immediately, switch off the ignition and wait a few seconds before repeating the operation.
Page 375: Fitting A Radio
FITTING A RADIO – In all cases, it is very important to follow the manufacturer’s instruc- tions carefully. – The specifications of the brack- Radio location 1 Front door speakers 2 ets and wires (available from our network) vary depending on the Unclip the blanking cover.
Page 376: Accessories
ACCESSORIES Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po- sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer. Before connecting an accessory to a socket, please ensure that you do not exceed the maximum power authorised for the socket.
Page 377: Fuses
FUSES (1/4) Fuse boxes Passenger compartment fuses B Fuses located in the passenger compartment behind a flap in the C Unclip the access flap 2. If any electrical component does not glovebox work, check the condition of the fuses. Open and tilt the 2 flap completely then Unclip the access flap 3.
Page 378 FUSES (2/4) To comply with current legislation, or as a precaution, you can obtain an Tweezers 4 emergency kit from your approved Remove the fuse using the tweezers 4 dealer containing a set of spare on the back of the flap. bulbs and fuses.
Page 379 FUSES (3/4) Allocation of fuses (the presence of certain fuse depends on the vehicle equipment level) Symbol Allocation Windscreen washer Multimedia accessories socket, multimedia î screen Æ Front and rear second row accessories socket Ì Horn Ý Towbar socket  Heated rear view mirrors Use the fuse allocation label in the ×...
Page 380 FUSES (4/4) LPG fuse in the front Fuses in engine compartment D Please note when work- compartment ing close to the engine that Some functions are protected by fuses it may be hot. In addition, located in the engine compartment 5 fuse: LPG circuit shut-off.
Page 381: Wiper Blades: Replacement
WIPER BLADES: replacement (1/2) Replacing the windscreen To refit wiper blades 2 To refit the wiper blade 2, insert it in its To replace the wipers, first put them in housing in the arm 3, then clip it until the service positionB. you hear a click.
Page 382 WIPER BLADES: replacement (2/2) To refit To refit the wiper blade, proceed in re- verse order to removal. Make sure that the blade is correctly locked in position. – In frosty weather, make sure that the wiper blades are not stuck by ice (to avoid the risk of the motor overheating).
Page 383 TOWING: breakdown recovery (1/2) Before carrying out any towing, posi- The speed specified by current legis- tion the gearbox in neutral position (po- lation for towing must always be ob- sition N on vehicles equipped with an served. If you are driving the towing automatic gearbox), unlock the steering vehicle, do not exceed the permissible column then release the parking brake.
Page 384 TOWING: breakdown recovery (2/2) Tighten the towing hitch 5 fully: first by hand until it stops, then finish by locking it with the wheel brace or, de- pending on the vehicle, the lever. Only use the towing hitch 5 and the wheelbrace or lever provided with the tools.
Page 385: Operating Faults
OPERATING FAULTS (1/7) Using the card POSSIBLE CAUSES WHAT TO DO The card does not lock or unlock the Card battery is flat. Replace the battery. You will still be able to doors. lock/unlock and start your vehicle. ➥ 1.14 and ➥...
Page 386 OPERATING FAULTS (2/7) The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved dealer as soon as possible. Using the remote control POSSIBLE CAUSES ACTION REQUIRED The remote control does not lock or The remote control battery is flat.
Page 387 OPERATING FAULTS (3/7) The starter is activated POSSIBLE CAUSES ACTION REQUIRED The instrument panel indicator lights are Battery terminals not tight, bat- Retighten or reconnect the terminals, or clean them if weak or fail to light up and the starter tery terminals disconnected or they are oxidised.
Page 388 OPERATING FAULTS (4/7) On the road POSSIBLE CAUSES WHAT TO DO Vibrations. Tyres not inflated to correct pres- Check the tyre pressures: if this is not the sures, incorrectly balanced or dam- problem, have them checked by an ap- aged. proved Dealer.
Page 389 OPERATING FAULTS (5/7) On the road POSSIBLE CAUSES WHAT TO DO Steering becomes heavy. Assistance overheating. Drive carefully at reduced speed, be aware of the level of force in the steering wheel needed to turn the wheels. Fault with the electric assistance Consult an authorised dealer.
Page 390 OPERATING FAULTS (6/7) Electrical equipment POSSIBLE CAUSES WHAT TO DO The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved dealer. Fuse damaged. Replace the fuse or have it replaced ➥...
Page 391 OPERATING FAULTS (7/7) Electrical equipment POSSIBLE CAUSES WHAT TO DO Traces of condensation in the head- Traces of condensation may be a nat- lights or rear lights. ural phenomenon caused by varia- tions in temperature and humidity. In this case, the traces will disappear slowly once the lights are switched The front seat belt reminder light An object is stuck between the floor...
Page 392 5.44...
Page 393 Section 6: Technical Specifications Vehicle identification plate ............Technical information for the emergency services.
Page 394: Vehicle Identification Plate
VEHICLE IDENTIFICATION PLATES The information shown on the ve- 4 MMAC (Maximum permissible hicle identification plate should be all-up weight). quoted on all correspondence or 5 MTR (Gross train weight: vehicle orders. fully loaded, with trailer). 6 MMTA (Maximum Permissible The presence and location of the in- Weight) front axle.
Page 395: Technical Information For The Emergency Services
TECHNICAL INFORMATION FOR THE EMERGENCY SERVICES The QR Code on the A label allows emergency workers using a tablet or smartphone to immediately access the technical information useful for working on the vehicle in the event of an acci- dent. Ensure that the A label is always visible and present on the windscreen as well as the rear screen.
Page 396: Engine Identification
ENGINE IDENTIFICATION Please quote the engine identifica- tion information in area A in all cor- respondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine serial number.
Page 397: Dimensions
DIMENSIONS (in metres) 0,831 2,583 0,633 1 ,518 4,047 1,440* 1,506 1,728** Unladen ** 1,988 with rear view mirrors open 1,798 with rear view mirrors folded away...
Page 398: Engine Specifications
ENGINE SPECIFICATIONS (1/3) Versions 1.0 SCe 1.0 TCe 1.3 TCe 1.5 dCi Engine type H4D Turbo H5H Turbo K9K Turbo (see engine plate) Cubic capacity (cc) 1 333 1461 Type of fuel Petrol Diesel Octane rating You must use unleaded petrol with the octane The label located in the fuel filler flap indicates rating stated on the label inside the fuel filler the authorised fuels.
Page 399 ENGINE SPECIFICATIONS (2/3) Versions 1.0 SCe 1.0 TCe 1.3 TCe 1.5 dCi Engine type H4D Turbo H5H Turbo K9K Turbo (see engine plate) Cubic capacity (cc) 1 333 1461 Fuel types that meet European standards and are Unleaded petrol compliant with Diesel fuel compliant with stand- compatible with the engines standard EN 228 contains up...
Page 400 ENGINE SPECIFICATIONS (3/3) Versions 1.0 SCe 1.0 TCe 1.3 TCe 1.5 dCi Engine type H4D Turbo H5H Turbo K9K Turbo (see engine plate) Cubic capacity (cc) 1 333 1461 Spark plugs Only use the spark plugs specified for your vehicle’s engine.
Page 401: Weights
WEIGHTS (in kg) The weights indicated for a basic vehicle without options: they vary depending on your vehicle’s equipment. Consult your approved Dealer. Maximum Authorised Mass (MMAC) Maximum Permissible Weight (MMTA) Weights indicated on the vehicle identification plate ➥ 6.2 Gross Train Weight (MTR) Braked Trailer Weight* found by calculating: MTR - MMAC...
Page 402: Replacement Parts And Repairs
REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the repair order.
Page 403: Service Sheets
SERVICE SHEETS (1/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km):...
Page 404 SERVICE SHEETS (2/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km):...
Page 405 SERVICE SHEETS (3/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km):...
Page 406 SERVICE SHEETS (4/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km):...
Page 407 SERVICE SHEETS (5/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km):...
Page 408 SERVICE SHEETS (6/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km):...
Page 409: Anticorrosion Check
ANTICORROSION CHECK (1/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.17...
Page 410 ANTICORROSION CHECK (2/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.18...
Page 411 ANTICORROSION CHECK (3/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.19...
Page 412 ANTICORROSION CHECK (4/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.20...
Page 413 ANTICORROSION CHECK (5/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.21...
Page 414 6.22...
Page 415 ALPHABETICAL INDEX (1/8) ashtray ................3.32 ABS ..............1.67, 2.44 → 2.48 assisted parking........1.68, 2.131 → 2.145 access audible and visual signals..........1.105 vehicle ........0.2, 1.4 → 1.12, 1.14 → 1.19 AUTO mode ............1.99 → 1.101 accessories ............2.8, 5.28 Autohold ................2.27 accessories - installation ........... 5.28 automatic gearbox (use) ....2.22, 2.26, 2.146 → 2.149 accessories socket ........3.18 – 3.19, 3.32 automatic gearbox selector lever.......2.146 → 2.149 adaptive cruise control........2.101 → 2.114 automatic locking of the doors while driving ......
Page 416 ALPHABETICAL INDEX (2/8) child safety ..... 0.3, 1.7, 1.9, 1.19, 1.33, 1.37 – 1.38, windscreen ..........3.9, 3.12 → 3.15 1.40 → 1.50, 1.52 → 1.59, 3.20 → 3.22 dimensions ................6.5 child seats....1.37 – 1.38, 1.40 → 1.50, 1.52 → 1.56 dipstick................. 4.4 children ....0.3, 1.37 – 1.38, 1.43 → 1.50, 1.52 → 1.59, display ......1.64 → 1.69, 1.71, 1.73 → 1.76, 3.18 3.20 → 3.22 doors.......... 1.18 – 1.19, 1.66, 1.89 – 1.90 children (safety) ..............
Page 417 ALPHABETICAL INDEX (3/8) energy front seats «ECO» mode ............... 1.67 adjustment ..........1.21 → 1.23, 1.98 engine fuel technical specifications ........6.6 → 6.8 advice on fuel ...........2.28 → 2.35 engine coolant ........1.67, 1.74 – 1.75, 4.8 consumption ..............2.28 engine identification ............0.7, 6.4 filling ............. 1.114 → 1.118 engine oil ..............4.4 → 4.7 quality ............
Page 418 ALPHABETICAL INDEX (4/8) horn: lane departure warning .........1.68, 2.49 → 2.59 flash ................1.105 Lane Keeping Assist ..........2.54 → 2.59 hubcap tool ..............5.7 – 5.8 lane keeping: assistance ........2.54 → 2.59 level information engine oil ............1.66, 1.70 ignition switch ..........2.3, 2.23 → 2.26 levels ..............0.8, 4.8 → 4.10 indicator lights..............5.17 levels: indicators ...........1.105, 2.62, 5.14 → 5.17 brake fluid ..............
Page 419 ALPHABETICAL INDEX (5/8) side lights ........1.99, 1.103, 5.14 – 5.15 Multi-Sense............1.95, 3.2 – 3.3 lights-on warning buzzer......... 1.19, 1.102 multi-view camera..........2.71 → 2.79 Liquefied Petroleum Gas: LPG ..... 1.80, 1.82, 1.117, 2.18 load permitted on the roof............ 6.9 navigation ............... 3.18 – 3.19 locking ..............1.24 → 1.27 navigation system ...........
Page 420 ALPHABETICAL INDEX (6/8) precautions during use ........1.107 → 1.111 replacement parts .............. 6.10 pretensioners ............1.28 → 1.33 reverse gear puncture........0.9, 1.88, 5.2 → 5.7, 5.9 – 5.10 selecting ............... 2.22 reversing sensor ..........2.131 → 2.137 roof bars ................3.40 QR Code ..............0.7, 6.3 roof rack roof bars ............... 3.40 running in ................2.2 radio................
Page 421 ALPHABETICAL INDEX (7/8) signals and lights ..........1.99 → 1.106 towing speakers breakdown ............5.35 – 5.36 location ................ 5.27 towing equipment ............3.39 special features of diesel versions......2.16 – 2.17 towing .................. 0.9 special features of LPG versions ......2.18 → 2.21 towing a caravan ............3.39, 6.9 special features of petrol vehicles ......
Page 422 ALPHABETICAL INDEX (8/8) vehicle range ..............1.121 ventilation ventilation .............. 3.4 – 3.5 ventilation ..............3.4 → 3.15 warning lights..... 1.64 → 1.69, 1.65 → 1.69, 1.73 → 1.88 washing ..............4.15 → 4.17 weights ................6.9 welcome aboard your vehicle general introduction ............0.1 welcome aboard your vehicle ..........0.1 wheelbrace ..............5.7, 5.9 wheels (safety) ............5.11 → 5.13 windows ................
Page 424 à999105682Sï î ï ä 3E RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 122-122 BIS, AVENUE DU GENERAL LECLERC 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / renaultgroup.com...

Renault Clio User Manual

Section 1: Getting to Know Your Vehicle

Section 2: Driving

Section 3: Your Comfort

Section 4: Maintenance

Section 5: Practical Advice

Quick Links

Chapters

Related Manuals for Renault Clio

Summary of Contents for Renault Clio

Table of Contents
