IEEE1394 Connector: J1394_1 (optional)
This connector allows you to connect the IEEE1394 device via an optional IEEE1394
bracket.
2
1
J1394_1
S/PDIF-Out Connector: JSP1
This connector is used to connect S/PDIF (Sony & Philips Digital Interconnect Format)
interface for digital audio transmission.
PIN
1
10
9
3
5
7
9
JSP1
VCC
SPDIF
S/PDIF Bracket (optional)
Hardware Setup
Pin Definition
SIGNAL PIN
TPA+ 2
Ground 4
TPB+ 6
Cable power 8
Key (no pin) 10
IEEE1394 Bracket (optional)
GND
SIGNAL
TPA-
Ground
TPB-
Cable power
Ground
