- Page 1 User Manual Refrigerator-Freezer A3FE635C*J A3FE735C*J C3FE635C*J C3FE735C*J C3FE735C*JE *= Colour code: G, M, W, S or R...
- Page 2 Thank You Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions con- tain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
-
Page 3: Table Of Contents
Content 1- Safety information ........................4 2- Intended use ..........................8 3- Product description ........................9 4- Control panel ..........................11 5- Use ..............................12 6- Energy saving tips ........................18 7- Equipment ..........................19 8- Care and Cleaning........................23 9- Troubleshooting ........................26 10- Installation ..........................29 11- Technical Data .........................33 12- Customer Service ........................35... -
Page 4: 1- Safety Information
1- Safety information Before switching on the appliance for the first time read the follow- ing safety hints!: WARNING! Before first use ▶ Make sure there is no transport damage. ▶ Remove all packaging and keep out of children´s reach. ▶... - Page 5 1- Safety information WARNING! Daily use ▶ This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental ca- pabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 6 1- Safety information WARNING! Daily use ▶ Do not set unnecessarily low temperature in the refrigerator compartment. Minus temperatures may occur at high settings. Attention: Bottles can burst. ▶ Do not touch frozen goods with wet hands (wear gloves). Espe- cially do not eat ice lollies immediately after removal from the freezer compartment.
- Page 7 1- Safety information WARNING! Maintenance / cleaning ▶ Do not try to repair, disassemble or modify the appliance by your- self. In case of repair please contact our customer service. ▶ Eliminate the dust on the back of the unit at least once in the year to avoid hazard by fire, as well as increased energy consumption.
-
Page 8: 2- Intended Use
2- Intended use 2.1 Intended use This appliance is intended for cooling and freezing food. It has been designed exclusively for use in dry-interior house-holds. It is not intended for commercial or industrial use. Changes or modifications to the device are not allowed. Unintended use may cause haz- ards and loss of warranty claims. -
Page 9: 3- Product Description
3- Product description Notice: Differences Due to technical changes and different models, some of the illustrations in this manual may differ from your model. Pictures of appliances (Fig. 3.1-3.2) Model: C3FE635C*J Model A3FE635C*J C3FE735C*JE *= Colour code A: Refrigerator compartment B: Freezer compartment 1 Refrigerator LED lamp 12 Fan shield (model C3FE735C*JE) - Page 10 3- Product description Model C3FE735*J Model A3FE735*J *= Colour code: A: Refrigerator compartment B: Freezer compartment 13 Fan shield 1 Dynamic ABT 14 Upper Freeze Box 2 Air duct and sensor (behind panel) 15 Middle Freeze Box 3 Refrigerator LED lamp 16 Lower Freeze Box 4 Glass shelves 17 Adjustable feet...
-
Page 11: 4- Control Panel
4- Control panel Control panel (Fig. 4) Keys: A Fridge temperature setting B Freezer temperature setting and Super.Frz. function on/off C My Zone setting D Panel lock/unlock Chiller Indicators: a Temperature fridge compartment b1 Temperature freezer compartment b2 Super freeze function (“Super.Frz”) Super-Frz. -
Page 12: 5- Use
5- Use 5.1 Before first use ▶ Remove all packaging materials, keep them out of children`s reach and dispose them in an environmentally friendly manner. ▶ Clean the inside and outside of the appliance as well as the interior and accessories with water and a mild detergent and dry it well with soft cloth. - Page 13 5- Use 5.6 Door opening alarm When the refrigerator door is opened for more than 3 minutes, the door opening alarm will sound (Fig. 5.6). The alarm can be silenced by closing the door. If the door is left open for more than 7 minutes, the light in- side the refrigerator and control panel illumination will automatically switch off.
- Page 14 5- Use 5.8 Super-Freeze function Super-Frz. Fresh food should be frozen as quickly as possible to the core. This preserved the best nutritional value, ap- pearance and taste. The Super-Freeze function ac- Freezer celerates the freezing of fresh food and protects the 3 Sec.
- Page 15 5- Use 5.9.2 D-Frost (Defrost) This function allows to defrost frozen food without liquid residues on the food after de- frosting. It will leave the food partly frozen, convenient for cutting and cooking. The temperature in MyZone compartment is set to + 1 ° C. Notice: D-Frost Defrosting time may vary according to size and thickness of the food.
- Page 16 5- Use 5.10 Tips on storing fresh food 5.10.1 Storing into the refrigerator compartment ▶ Keep your fridge temperature below 5°C. ▶ Hot food must be cooled to room temperature before storing in the appliance. ▶ Foods stored in the refrigerator should be washed and dried before storing ▶...
- Page 17 5- Use 5.10.2 Storage into the freezer compartment ▶ Keep the freezer temperature at- 18°C. ▶ 24 hours before freezing switch on the Super-Freeze function; -for small quantities of food 4-6 hours are sufficient. ▶ Hot food must be cooled to room temperature before storing in the freezer com- partment.
-
Page 18: 6- Energy Saving Tips
6- Energy saving tips Energy saving tips ▶ Make sure the appliance is properly ventilated (see INSTALLATION). ▶ Do not install the appliance in direct sunlight or in the near of heat sources(e.g. stoves, heaters). ▶ Avoid unnecessarily low temperature in the appliance. The energy consumption in- creases the lower the temperature in the appliance is set. -
Page 19: 7- Equipment
7- Equipment Notice: Differences depending on model Due to different models, your product may not have all of the following features. Please refer to chapter PRODUCT DESCRIPTION. 7.1 Multi-air-flow The refrigerator is equipped with a multi-air-flow sys- tem, with which cool air flows are located on every shelf level (Fig. - Page 20 7- Equipment 7.5 Moist Zone box In this compartment (Fig. 7.5) the humidity level is around 90%. It is controlled automatically by the sys- tem and is suitable to store fruits,vegetables, salads etc. 7.6 OK-temperature indicator The OK-temperature (Fig. 7.6) indicator can be used to determine temperatures below +4°C.
- Page 21 7- Equipment 7.9 Pre-freezing rack Each freezer drawer is equipped with a pre-freezing rack (Fig. 7.9). Fresh frozen food can be separated from already frozen, so that a smooth freezing process can take place and freezing food will not defrosted. After rearrangement of frozen food these compartments can be used for easy storage of small parts such as herbals, ice cream or for the ice cube tray.
- Page 22 7- Equipment 7.12 The Light The LED interior light comes on when the door is opened. The performance of the lights is not affected by any of the appliances other settings. 7.13 Special features Some models are equipped with following additional special features: 7.13.1 Dynamic ABT This feature sterilizes the refrigerator compartment with a rate of 99.9%;...
-
Page 23: 8- Care And Cleaning
8- Care and Cleaning WARNING! Disconnect the appliance from the power supply before cleaning. 8.1 General Clean the appliance when only little or no food is stored. The appliance should be cleaned every four weeks for good maintenance and to prevent bad stored food odours. - Page 24 8- Care and Cleaning 8.3 Replacing the LED-lamps WARNING! Do not replace the LED lamp yourself, it must only be replaced by either the manufac- turer or the authorised service agent. The lamp adopts LED as its light source, featuring low energy consumption and long ser- vice life.
- Page 25 8- Care and Cleaning 8.5 Non-use for a longer period If the appliance is not used for an extended period of time: ▶ Take out the food. ▶ Unplug the power cord. ▶ Clean the appliance as described above. ▶ Keep the door and freezer drawers/door open to prevent the creation of bad odours inside. Notice: Switch off Turn the appliance off only if strictly necessary.
-
Page 26: 9- Troubleshooting
9- Troubleshooting Many occuring problems could be solved by yourself without specific expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! ▶ Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket. - Page 27 9- Troubleshooting Problem Possible Cause Possible Solution It is not cold enough • The temperature is set too high. • Reset the temperature. inside the appli- • Too warm goods has been stored. • Always cool down goods before ance. storing them.
- Page 28 9- Troubleshooting Problem Possible Cause Possible Solution A slight sound is • This is normal. • - to be heard simi- lar to that of flow- ing water. You will hear an • The fridge storage compartment • Close the door or silence the alarm beep.
-
Page 29: 10- Installation
10- Installation 10.1 Unpacking WARNING! ▶ The appliance is heavy. Always handle with at least two persons. ▶ Keep all packaging materials out of children´s reach and dispose them in an environ- mentally friendly manner. ▶ Take the appliance out of the packaging. ▶... - Page 30 10- Installation 10.6 10.6 Aligning the appliance The appliance should be placed on a flat and solid sur- face. 1. Tilt the appliance slightly backwards (Fig. 10.6). 2. Set the feet to the desired level. 3. The stability can be checked by alternately bump- max 45°...
- Page 31 10- Installation 10.9 Door Reversibility Before connecting the appliance to the power supply you should check, whether the door swing must changed from right (as delivered) to left, if this is required by the installation location and the usability. WARNING! ▶...
- Page 32 10- Installation Next steps (a-h) are only necessary for models with two doors: a Remove lower door b This step needs two persons; one who holds the appliance in place and one who carries out the as- sembly steps! Tilt the appliance slightly backwards and remove the lower hinge with the feet (1).
-
Page 33: 11- Technical Data
11- Technical data regulation EU No. 1060/2010 11.1 Product fiche according to Trade mark Haier A3FE C3FE Model identifier 635C*J 735C*J 635C*J 735C*J 735C*JE Refrigerator-freezer Category of the model Energy efficiency class Annual energy consumption (kWh/year) Storage volume cooling (L) - Page 34 11- Technical data 11.2 Additional technical data A3FE C3FE Model identifier 635C*J 735C*J 635C*J 735C*J 735C*JE Voltage / Frequency 220-240V ~/ 50Hz Input current (A) Main fuse (A) Coolant R600a Total volume (L) Net volume (L) Dimensions (in mm) Depth Width Height 1905...
-
Page 35: 12- Customer Service
If you cannot find a solution there, please contact ▶ your local dealer or ▶ the Service & Support area at www.haier.com where you can find telephone numbers and FAQs and where you can activate the service claim. To contact our Service, ensure that you have the following data available.
