Haier AFD630IX Instructions For Use Manual

Combined fridge-freezer
Hide thumbs Also See for AFD630IX:

Advertisement

Table of Contents

See also: Operating Manual , User Manual
Combined fridge-freezer
Instruction for use
MODELS:
AFD630IX (61116)
AFL628CX (61115)
CFL629CW (61114)
HBMF348AX
HBMF348AW
HBMTD349AS
HBMTD349AW

Advertisement

Table of Contents
loading

Related Manuals for Haier AFD630IX

Summary of Contents for Haier AFD630IX

  • Page 1 Combined fridge-freezer Instruction for use MODELS: AFD630IX (61116) AFL628CX (61115) CFL629CW (61114) HBMF348AX HBMF348AW HBMTD349AS HBMTD349AW...

  • Page 2: Table Of Contents

    This user manual covers a number of different appliances. Some slight differences may therefore apply to some models. TABLE OF CONTENTS KEY FEATURES ......................3 DESCRIPTION MODELS: AFD630IX / AFL628CX / HBMTD349AS / HBMTD349AW ...4 DESCRIPTION MODELS: CFL629CW / HBMF348AX / HBMF348AW ......5 SAFETY PRECAUTIONS ....................6 PLACING AND ENVIRONMENT ..................9 PREPARATION PRIOR TO USE ...................10...

  • Page 3: Key Features

    KEY FEATURES  Removable automatic icemaker (only on some models).  The freezer door is replaced by drawers. This facilitates food access, ensuring energy saving and convenience (only on some models).  One slide in half shelf, a full length shelf that slides to half length to allow storage of taller items below.

  • Page 4: Description Models: Afd630Ix / Afl628Cx / Hbmtd349As / Hbmtd349Aw

    DESCRIPTION MODELS: AFD630IX / AFL628CX / HBMTD349AS / HBMTD349AW FRIDGE STORAGE COMPARTMENT FREEZER STORAGE COMPARTMENT...

  • Page 5: Description Models: Cfl629Cw / Hbmf348Ax / Hbmf348Aw

    DESCRIPTION MODELS: CFL629CW / HBMF348AX / HBMF348AW...

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS...

  • Page 9: Placing And Environment

    PLACING AND ENVIRONMENT Levelling of the cabinet: Never place the refrigerator in a damp area The refrigerator should be placed on a flat or a location where it may be splashed with and solid surface. If the refrigerator is water. Clean and dry any water splashes placed on a pedestal, flat, strong and fire- and stains with a soft cloth.

  • Page 10: Preparation Prior To Use

    PREPARATION PRIOR TO USE Remove all packaging Please also remove the foam base and the adhesive tape fixing accessories. Check accompanying accessories and documents. Check the items inside the box against the packing list. Install the handles: (HBMTD349AS / HBMTD349AW) Take out the two handles from the accessory box and insert them in the handle seats respectively as shown in the figure.
  • Page 11 CONNECTION TO POWER SUPPLY When the refrigerator is connected to power supply, the fridge temperature and freezer temperature are automatically set to 5 C and -18 C respectively. OPERATION MODES OF THE REFRIGERATOR Manual adjustment mode: set temperature by pressing the temperature setup key (see “Function description”...

  • Page 12: Function

    FUNCTION Models: AFL628CX / CFL629CW / HBMF348AX / HBMF348AW / HBMTD349AS / HBMTD349AW A1 Switch on/off the fridge storage A2 Holiday function compartment A3 Super cool A4 Fridge temperature up A5 Fridge temperature down A6 Freezer temperature up A7 Freezer temperature down A8 Super freeze A9 Over-temperature/door open alarm A10 Power ON/OFF...
  • Page 13 SUPER COOLING Select this function after you have put in a large amount of fresh food in the fridge storage compartment. Press key A3, and this function is activated and the corresponding indicator illuminates. This function will automatically deactivate when the temperature decreases to the required level.
  • Page 14 FAULT INDICATION When E or F is displayed due to a fault, the refrigerator can still refrigerate. Please contact an Authorized Service Centre as soon as possible. Models: AFD630IX CONTROL PANEL A1 Turns on/off the fridge storage Fridge compartment indicating icon...
  • Page 15 FRIDGE STORAGE TEMPERATURE SETUP Press key A2 until icon D flashes. Then, press key A3 or A4 to set the temperature. The refrigerating storage temperature cycles from 2 to 8. After you have set it to the desired value, press key A5 to confirm. Note: Flashing of icon D is accompanied by flashing of icon E.
  • Page 16 DISPLAY CONTROL The display screen will dim 1 minute after an operation is finished. It will recover to normal brightness when you open the door or press any key. (Alarm does not light up the display screen). DOOR OPEN ALARM When the fridge storage compartment door is open for more than 3 minutes, icon G will flash and the buzzer will give out 3 beeps every 30 seconds.

  • Page 17: Fridge Storage Compartment

    FRIDGE STORAGE COMPARTMENT SHORT TERM STORAGE Please put food to be stored for a short period or for daily consumption in the fridge storage compartment: Although the average temperature in most areas in the fridge storage compartment can be regulated between C and 10 C, an extended period of food storage is not recommended.
  • Page 18 USE OF THE SLIDING SHELF Fig. (1) shows the extended state of the sliding shelf used to store small food containers. Fig. (2) shows the retracted state of the sliding shelf which allows for taller food containers below. To slide the shelf from state (1) to state (2), simply push structure “a”...

  • Page 19: Fridge Storage Precautions

    FRIDGE STORAGE PRECAUTIONS...

  • Page 20: Tips On Food Storage In The Fridge

    TIPS ON FOOD STORAGE IN THE FRIDGE...

  • Page 21: Freezer Storage Precautions

    FREEZER STORAGE PRECAUTIONS...

  • Page 22: Icemaker Use Instructions (Only On Models With An Icemaker)

    ICEMAKER USE INSTRUCTIONS (ONLY ON MODELS WITH AN ICEMAKER) PREPARATIONS BEFORE USING THE ICEMAKER  Cut the water pipe to desired length while ensuring it is free from excessive bends. Generally its total length should not be more than 5m. A longer pipe may reduce water pressure and, as a result, the water output flow-rate and ice-making capacity.
  • Page 23 IF YOU DO NOT USE ICE CUBES FREQUENTLY Cubed ice stored for an extended period may become opaque or emit an odour. Please empty the cubed ice storage box regularly and clean it with warm water. Before putting the box back, make sure to cool it down and to dry it. Otherwise ice cubes may stick to the box.

  • Page 24: Defrosting And Cleaning

    DEFROSTING AND CLEANING DEFROSTING THE FREEZER The freezer defrosts automatically. No manual operation is needed. CLEANING The refrigerator should be cleaned regularly to prevent bad food odours.  For safety, unplug the power cord before cleaning the refrigerator.  Clean the refrigerator with a soft cloth or sponge and warm water (a mild detergent can be added).

  • Page 25: Stopping Use

    STOPPING USE POWER INTERRUPTION Even in summer, food may be stored in the refrigerator for a few hours after a power interruption. If a power interruption occurs, please call the power company to ask about the interruption duration.  Do not put additional food into the refrigerator during a power interruption and try to open the door as few times as possible.
  • Page 26 MOVING THE REFRIGERATOR Unplug the refrigerator. Remove all food. Secure the shelves and crisper in the fridge storage compartment as well as the shelves and other movable parts in the freezer with adhesive tape. Close the door and secure with adhesive tape. Do not tilt the refrigerator more than 45 degrees (angle to vertical) to avoid damaging the refrigerating system.

  • Page 27: Troubleshooting

    TROUBLESHOOTING Before calling for service, please read the following troubleshooting table first. This can save both time and money. The table contains common problems and solutions. PROBLEMS CAUSES SOLUTIONS Refrigerator operation The compressor  The refrigerator is in the  This is normal for an automatic does not work.
  • Page 28 PROBLEMS CAUSES SOLUTIONS The temperature in  The fridge temperature  Set the fridge temperature lower. It the fridge storage is set too high. takes 24 hours for the temperature of compartment is too the refrigerator to become stable. high while the temperature in the freezer is OK Water / moisture / frost in the refrigerator...
  • Page 29 PROBLEMS CAUSES SOLUTIONS Bad odours in the refrigerator The inside of the  The inside of the  Clean the inside of the refrigerator. refrigerator is dirty refrigerator needs  Wrap the food tightly. cleaning  Food of strong odour is stored in the refrigerator If you hear…...
