To install a new DisplayPort expansion card, hold the card just above the DisplayPort expansion

socket on the system board then move the card toward the rear of the chassis (1) so that the

bracket on the card is aligned with the open slot on the rear of the chassis. Press the card

straight down into the expansion socket on the system board (2).

NOTE:

for it.

Figure 2-22

NOTE:

connector seats properly in the expansion card slot.

11.

Rotate the slot cover retention latch back in place to secure the expansion card.

Figure 2-23

12.

Replace the computer access panel.

13.

If the computer was on a stand, replace the stand.

Chapter 2 Hardware Upgrades

You must install the DisplayPort expansion card into the socket specifically designated

Installing a DisplayPort Expansion Card

When installing an expansion card, press firmly on the card so that the whole

Closing the Expansion Card Retention Latch
