User's
Information Manual
If the information in this manual is not followed exactly, a fi re or explosion may result,
causing property damage, personal injury or loss of life.
Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any telephone in your building.
• Immediately call your gas supplier from a neighbor's telephone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fi re department.
Installation & service must be performed by a qualifi ed installer, service technician or the gas supplier.
— WHAT TO DO IF YOU SMELL GAS —
CONDENSING GAS BOILER
110/155
Part number 550-100-191/0917
Part number 550-100-212/1220
Advertisement
Table of Contents
Related Manuals for Weil-McLain EVERGREEN PRO 1 EVG-110
Summary of Contents for Weil-McLain EVERGREEN PRO 1 EVG-110
- Page 1 User’s CONDENSING GAS BOILER Information Manual 110/155 If the information in this manual is not followed exactly, a fi re or explosion may result, causing property damage, personal injury or loss of life. Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance. —...
- Page 2 — 110/155 User’s information Manual CONDENSING GAS BOILER Please read this page fi rst Evergreen Boiler components ® To . . . Read and use . . . Page Learn Pressure/temperature Pressure/temperature See Hazard Defi nitions, below precautions gauge gauge Locate boiler See illustration at right components...
- Page 3 Thoroughly clean and fl ush any replacement boiler system fi ed service technician. that has used glycol before installing the new boiler. Use only the products listed by Weil-McLain for use with this boiler. Combustion air — See boiler manual for details.
-
Page 4: Prevent Combustion Air Contamination
— 110/155 User’s information Manual CONDENSING GAS BOILER Prevent combustion air contamination Air contamination Combustion air contamination: Ensure that the combustion air will not contain any of Common household and hobby products often contain the contaminants in Figure 1 fl uorine or chlorine compounds. When these chemicals Combustion air supply openings or intake terminations pass through the boiler, they can form strong acids in must NOT be near a swimming pool, for example. -
Page 5: Annual Startup And General Maintenance
— 110/155 User’s information Manual CONDENSING GAS BOILER Annual startup and general maintenance Figure 2 Service and maintenance schedules OWNER MAINTENANCE (see the following pages for instructions) Contact your boiler service technician to inspect, service and start up your boiler. You must have an annual start-up performed by BEGINNING OF SEASON a qualifi... -
Page 6: User Maintenance Procedures
— 110/155 User’s information Manual CONDENSING GAS BOILER User maintenance procedures The boiler should be inspected and started annually, at the beginning of the heating Boiler must season, only by a qualifi ed service technician. In addition, the maintenance and care of the boiler designated on page 5 and explained on the following pages must be be serviced performed to assure maximum boiler effi... - Page 7 2. Remove the cap from any automatic air vent in the system and check operation by 1. Observe the date and time shown below the depressing valve “B” slightly with the tip Weil-McLain logo on the control display on of a screwdriver. page 11 . Scald hazard —...
- Page 8 — 110/155 User’s information Manual CONDENSING GAS BOILER User maintenance procedures (continued) Check boiler piping EVERY 3. Lift the relief valve top lever slightly, allow- 1. Check all gas lines and smell for gas odors. ing water to relieve through the valve and Perform gas leak inspection per steps 1 6 MONTHS discharge piping.
- Page 9 — 110/155 User’s information Manual CONDENSING GAS BOILER OPERATING INSTRUCTIONS Figure 5 Operating instructions (see page 2 for location of manual gas valve) Part number 550-100-212/1220...
-
Page 10: Control Display
— 110/155 User’s information Manual CONDENSING GAS BOILER The Evergreen control display ® Figure 6 Evergreen boiler control display states ® Part number 550-100-212/1220... - Page 11 — 110/155 User’s information Manual CONDENSING GAS BOILER The Evergreen control display ® (continued) Figure 7 boiler control display USER Menu — (set date and time, reset faults). Evergreen ® Date and time 1. Set month, date, year, hour and minutes. 2.
- Page 12 — 110/155 User’s information Manual CONDENSING GAS BOILER...
