TCSNAC01-- A, TCSNHP01-- A
Non-- Programmable Thermostat
NOTE: Read the entire instruction manual before starting the
installation.
SAFETY CONSIDERATIONS
Read and follow manufacturer instructions carefully. Follow all
local electrical codes during installation. All wiring must conform
to local and national electrical codes. Improper wiring or
installation may damage thermostat.
Recognize safety information. This is the safety- -alert symbol
When you see this symbol on the equipment and in the instruction
manual, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety- -alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies a hazard
which could result in personal injury or death. CAUTION is used
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
Power
Note that all thermostats are dual powered where batteries can be
installed or in the presence of R and C (24VAC) are not required.
Two AA batteries are furnished with the product.
Installation Instructions
Models
There are 2 different models. The 5th and 6th letters of the part
number indicate the model. These 2 letters also appear on the
package and on the circuit board. Be sure to have the proper
thermostat for the intended application. Models are:
AC - - 1- -stage cool, 1- -stage heat for AC systems only.
HP - - 1- -stage cool, 2- -stage heat for either HP, or AC with 2- -stage
heat.
Use each only for its intended purpose. See Table 1.
Thermostat Location
Thermostat should be mounted:
S Approximately 5 ft. (1.5m) from floor.
S Close to or in a frequently used room, preferably on an inside
partitioning wall.
A08147
S On a section of wall without pipes or duct work.
Thermostat should NOT be mounted:
S Close to a window, on an outside wall, or next to a door leading
to the outside.
S Exposed to direct light and heat from a lamp, sun, fireplace, or
other temperature- -radiating object which may cause a false
reading.
S Close to or in direct airflow from supply registers and return- -air
.
grilles.
S In areas with poor air circulation, such as behind a door or in an
alcove.
Select Model
AC Model
(1- -stage cool, 1- -stage heat) is to be used for single stage heating
and/or cooling applications only.
HP Model
(1- -stage cool, 2- -stage heat) can be used with a single- -speed heat
pump (HP), or an air conditioner (AC) with a 2- -stage furnace or
fan coil. Software Option 5 selects HP/AC operation. This
thermostat comes configured from the factory as a heat pump
thermostat. Select AC in software Option 5 for AC operation.
INSTALLATION

Advertisement

Table of Contents
loading

Summary of Contents for Carrier TCSNAC01-A

  • Page 1 TCSNAC01-- A, TCSNHP01-- A Non-- Programmable Thermostat Installation Instructions Models There are 2 different models. The 5th and 6th letters of the part number indicate the model. These 2 letters also appear on the package and on the circuit board. Be sure to have the proper thermostat for the intended application.
  • Page 2 Table 3 – Model Selection and Wiring Diagram Chart AIR CONDITIONER HEAT PUMP INDOOR UNIT 1 Speed 1 Speed 1--- Stage Furnace TCSNAC See Fig. 1 2--- Stage Furnace TCSNAC01--- A See Fig. 2 TCSNHP01--- A See Fig. 2 Typical Fan Coil TCSNAC01--- A See Fig.
  • Page 3 To enter the configuration mode: OPTION 03 - - FAHRENHEIT/CELSIUS SELECTION This option selects Fahrenheit or Celsius operation. To enter Configuration Mode, hold the FAN button down for approximately 15 seconds. After the 15 second period, Option To Select: “01” will appear in the display and the SERVICE icon will be 1.
  • Page 4 3. Press MODE button once. The SET icon will come on. The 3. Press MODE button once. The SET icon will come on. The display now shows Option 07 setting. display now shows Option 15 setting. 4. Use up and down buttons to move between available 4.
  • Page 5 To Select: 2. Pressing the FAN button while the heating or cooling equipment is not running will turn on the FAN relay and 1. Enter configuration mode (if not already there). display the FAN icon. 2. Use up and down buttons to display Option 21. The SET 3.
  • Page 6: Wiring Diagram Notes

    Thermostat Fan Coil Heat Pump Thermostat Fan Coil Air Conditioner Heat Heat Cool Cool 24VAC 24VAC Common Common A08163 A08164 *Common connection not required if batteries are used. *Common connection not required if batteries are used. Fig. 3 - - HP Thermostat with Fan Coil Fig.
  • Page 7: Operational Information

    OPERATIONAL INFORMATION Five- - minute Compressor Timeguard The cycle timer limits the number of times the heating or cooling equipment can be energized in one hour. If option 1 is set to a value of 1 or 2, the equipment will be allowed to energize up to six times per hour. If option 1 is set to 3 or greater, the equipment will be allowed to energize up to four times per hour.
  • Page 8 Catalog No: TCSNACA ---01SI Copyright 2014 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Edition Date: 08/14 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations. Replaces: NEW...
  • Page 9: Non-- Programmable Thermostat

    Take a few minutes to review the features and functions listed at 1. Press the FAN button to switch between ON and AUTO fan the right. Carrier gives you control over your comfort with simple se ttings. instructions, responsive push buttons and an easy- -to- -read backlit FAN on indicator will be displayed on LCD.
  • Page 10: Auto Changeover

    Catalog No: TCSNACA ---01SI Copyright 2014 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Edition Date: 08/14 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
