MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
Page 5
SETUP Unpacking and setting up the vehicle – Remove straps and box. S00791-10 – Remove the adhesive tape in the upper area of the motorcycle. S00792-10 – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have finished work on the vehicle.
Page 6
SETUP – Position the handlebar. – Position the handlebar clamps. Mount and evenly tighten the four screws. Guideline Screw, handlebar clamp 20 Nm (14.8 lbf ft) The marking of the handlebar scale are located centrally between the han- dlebar clamps. ...
SETUP – Recharge the battery. ( p. 7) – Plug in connector on the starter relay. S00801-10 – Remove the rear fairing. ( p. 11) – 4 markings are found on the underside of the rear fairing. At these location, drill holes to the specified diameter in three stages.
Page 8
SETUP – Print out the current PDI form found on the KTM Dealer.net and perform the pre- delivery inspection. – Set kilometers or miles. ( p. 13)
– Do not dispose of batteries with the household waste. Dispose of a defective battery in an environmentally friendly manner. Give the battery to your authorized KTM dealer or dispose of it at a collection point for used batteries. Warning Environmental hazard Hazardous substances cause environmental damage.
Page 10
WORK Preparatory work – Switch off all power consumers and switch off the engine. – Remove the seat. ( p. 7) – Remove the battery. ( p. 8) Main work – Connect the battery charger to the battery. Switch on the battery charger. Battery charger (58429074000) You can also use the battery charger to test rest potential and start potential of the battery, and to test the alternator.
Page 11
WORK – Disconnect negative cable of the battery. – Take off the positive pole cover S00622-10 – Disconnect the ABS connection cable and positive cable from the battery. S00620-10 – Remove screws – Pull retaining bracket of the battery forward and remove it.
WORK – Position the engine electronics control unit – Mount battery cover S00624-10 Finishing work – Mount the seat. ( p. 7) – Set the clock. ( p. 13) Opening the filler cap Danger Fire hazard Fuel is highly flammable. –...
Page 13
WORK Removing rear fairing Preparatory work – Remove the seat. ( p. 7) Main work – Remove screws S00805-10 – Remove screws – Open the filler cap. ( p. 10) – Take off the rear fairing. – Close the filler cap. ( p.
Page 14
WORK 3.11 Mounting the rubber strap for the side stand – Drill a hole of the specified size at marking Guideline Hole diameter for rubber strap 8.0 mm (0.315 in) Info 0 0 1 A marking is found on the inside of the left heel protector. –...
WORK – Switch off the engine. – Open the filler cap. ( p. 10) – Fill the fuel tank with fuel up to measurement Guideline 20 mm (0.79 in) Measurement Total fuel tank 12 l (3.2 US gal) Super unleaded (ROZ 95/RON 95/PON capacity, approx.
Page 18
SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
