  • Page 4 - Upgrading your Computer Upgrading your Computer In this section, you will find: • Instructions on how to replace a hardware component...
  • Page 5: Upgrading Your Computer

    Upgrading your Computer - 1. UPGRADING YOUR COMPUTER Installation precautions Before you install any computer component, we recommend that you read the following sections. These sections contain important ESD precautions along with pre-installation and post-installation instructions. ESD precautions Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components.
  • Page 6: Pre-Installation Instructions

    - Upgrading your Computer Pre-installation instructions Always observe the following before you install any component: 1. Make sure that the ODD and card reader slot is empty. 2. Turn off the power to the computer and all peripherals. 3. Unplug the power cord from the computer. 4.
  • Page 7: System Upgrade

    Upgrading your Computer - System Upgrade Removing the left side system cover 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 6. 2. Remove the two screws that secure the system cover to the computer.
  • Page 8: Installing The Left Side System Cover

    - Upgrading your Computer Installing the left side system cover 1. Align the cover to the sides of the computer and slide the cover toward the front of the computer. 2. Secure the cover with two screws. 3. Observe the Post-installation instructions on page 6.
  • Page 9: Removing The Right Side System Cover

    Upgrading your Computer - Removing the right side system cover 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 6. 2. Remove the two screws that secure the system cover to the computer.
  • Page 10: Installing The Right Side System Cover

    - Upgrading your Computer Installing the right side system cover 1. Align the cover to the sides of the computer and slide the cover toward the front of the computer. 2. Secure the cover with two screws. 3. Observe the Post-installation instructions on page 6.
  • Page 11: System Layout

    Upgrading your Computer - 11 System Layout Control box M2_2 M2_3 Wifi M2_1...
  • Page 12: Hard Drives

    - Upgrading your Computer Hard drives The computer supports installation of one 3.5-inch SATA hard drives in the internal HDD cage. Removing the 3.5-inch hard drives 1. Perform Pre-installation instructions on page 6. 2. Remove the two screws that the Mask cover. 3.
  • Page 13 Upgrading your Computer - 13 4. Remove the four screws that the Power Cover. 5. Take off the Power Cover.
  • Page 14 - Upgrading your Computer 6. Disconnect the power and data cables from the hard drives. 7. Pull black rack out from HDD cage and take it off.
  • Page 15 Upgrading your Computer - 15 8. Remove HDD from black rack.
  • Page 16: Installing The 3.5-Inch Hard Drives

    - Upgrading your Computer Installing the 3.5-inch hard drives 1. Remove the new hard drive from their packaging. 2. Insert the new hard drive into the black rack. 3. Insert black rack into HDD cage.
  • Page 17 Upgrading your Computer - 17 4. Connect the power and data cables to the hard drive. 5. Insert the Power Cover and fix it.
  • Page 18 - Upgrading your Computer 6. Insert the Mask Cover and fix it. 7. Observe the Post-installation instructions on page 6...
  • Page 19: Memory

    DIMM4 DIMM2 DIMM3 DIMM1  To ensure data integrity, use only Acer-approved DDR4 2666 MHz or DDR4 3200 MHz type memory modules.  Memory modules must be installed starting with DIMM1 slot.  Always handle memory modules by its edges.
  • Page 20: Removing A Memory Module

    - Upgrading your Computer Removing a memory module 1. Perform Pre-installation instructions on page 6. 2. Disconnect the thermal fan cable from the mainboard. 3. Press outward the holding clips on both sides of the DIMM slot outward to release the memory module (1). 4.
  • Page 21: Installing A Memory Module

    Upgrading your Computer - 21 Installing a memory module Note DIMM slots on the mainboard must be installed only in certain configurations. Numbers next to DIMM slots correspond to installation sequence. Be sure to install the memory module in DIMM1 slot followed by DIMM2 slot. 1.
  • Page 22: Graphic Board

    - Upgrading your Computer Graphic board The computer contains one or two Graphic boards installed in the PCIe x16 slots. The detail configuration will be differed by different models. Removing the Graphic board 1. Perform Pre-installation instructions on page 6. 2.
  • Page 23 Upgrading your Computer - 23 4. Release the latch that secures the graphic board to the mainboard. 5. Detach the Graphic board from the PCIe x16 slot. 6. Remove the screw that secure the Graphic boards to the VGA Holder Bracket.
  • Page 24: Installing The Graphic Board

    - Upgrading your Computer Installing the Graphic board 1. Remove the new graphic board from its packaging. 2. Fix Graphic boards on VGA Holder Bracket with three screw 3. Insert the Graphic boards into the PCIe x16 slot and press it down until it latches into place. [Note] For replace/upgrade graphic board, please check the specification of graphic board &...
  • Page 25 Upgrading your Computer - 25 4. Secure the Graphic board with screws. 5. Connect the power cables to the Graphic boards. 6. Observe the Post-installation instructions on page 6...
  • Page 26: M.2 Ssd Module

    - Upgrading your Computer M.2 SSD module The computer contains one M.2 SSD module installed in the M.2 PCIe slot. Removing the M.2 SSD module for M2_2 1. Perform Pre-installation instructions on page 6. 2. Remove the Graphic board. See Removing the Graphic board.
  • Page 27: Installing The M.2 Ssd Module For M2_2

    Upgrading your Computer - 27 Installing the M.2 SSD module for M2_2 1. Remove the new M.2 SSD module from its packaging. 2. Insert the M.2 SSD module into its slot in the mainboard. 3. Secure the M.2 SSD module and mainboard with screws. 4.
  • Page 28: Removing The M.2 Ssd Module For M2_3

    - Upgrading your Computer Removing the M.2 SSD module for M2_3 1. Perform Pre-installation instructions on page 6. 2. Remove the Graphic board. See Removing the Graphic board. 3. Remove the screws that secures the M.2 SSD module from the mainboard. 4.
  • Page 29: Installing The M.2 Ssd Module For M2_3

    Upgrading your Computer - 29 Installing the M.2 SSD module for M2_3 1. Remove the new M.2 SSD module from its packaging. 2. Insert the M.2 SSD module into its slot in the mainboard. 3. Secure the M.2 SSD module and mainboard with screws. 4.
  • Page 30: Odd Drives

    - Upgrading your Computer ODD drives The computer supports installation of one ODD drives. Open ODD door. 1. Perform Pre-installation instructions on page 6. 2. Push triangle icon for opening. 3. Press ODD eject-Button.
  • Page 31: Easy Swap Hdd

    Upgrading your Computer - 31 Easy swap HDD The computer supports installation of one 2.5-inch SATA hard drives in the easy swap HDD cage. 1. Perform Pre-installation instructions on page 6. 2. Push triangle icon for opening. 3. Release the latch and take it off.
  • Page 32 - Upgrading your Computer 4. Insert the new 2.5-inch SATA hard drive into the easy swap cage. 5. Insert easy swap into HDD cage.
  • Page 33: Glass Side Cover

    Upgrading your Computer - 33 Glass Side cover 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre-installation instructions on page 6. 2. Remove the two screws that secure the system cover and take it off.
  • Page 34 - Upgrading your Computer 4. Secure the glass cover with screws. 5. Observe the Post-installation instructions on page 6...
  • Page 35: Dust Filter

    Upgrading your Computer - 35 Dust filter 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 6. 2. Pull latch from Dust filter and take it off.
  • Page 36 - Upgrading your Computer...
  • Page 37: Me Features

    Upgrading your Computer - 37 ME Features Handle Headphone hook...
  • Page 38 - PredatorSense PredatorSense In this section, you will find: • Introduction to the PredatorSense utility • How to use PredatorSense...
  • Page 39: Predatorsense

    PredatorSense - 39 2 PREDATORSENSE PredatorSense (DT) is an Acer proprietary utility to enhance the user experience of Gaming products on Microsoft Windows 10. The central idea of this utility is to provide a user interface to easily control fan speed , OverClocking and also display system information.
  • Page 40 - PredatorSense Alternatively, you can double-click the PredatorSense desktop shortcut to run the application. • Lighting Water Cooler Air Cooler...
  • Page 41 PredatorSense - 41 Category Description Provide overview of all features with quick adjustment  CPU/GPU/System health information Home  Fan speed control (Auto, Gaming and Custom) Provide control and adjustment for the LEDs on Front Face, Left Side Face and Motherboard. ...
  • Page 42 - PredatorSense Provide 3 tabs for CPU/System and GPU.  Temperature in C  Loading in %  Frequency in MHz Monitoring  Voltage in V  Download/Upload in bytes/s of WIFI/Ethernet  Usage in GB of RAM...
