Page 1
The model number and serial number are on the back of your TV/DVD. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV/DVD. Model number: _________________ Serial number: _________________...
Precautions CAUTION: THIS UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED. THE FOLLOWING CAUTION LABEL IS LOCATED ON THE REAR PANEL OF THE UNIT. WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.
Precautions ... 2 Important safety information ... 5 Digital TV switchover ... 8 Location of controls ... 9 Remote control ... 10 I/O connections... 12 Using the Auto Brightness Sensor... 13 Auto setup ... 14 Quick guide for menu operation ... 16 Selecting the video input source ...
Page 4
Contents Status message ... 79 Troubleshooting table ... 80 Specifications ... 82 The GNU General Public License (GPL) ... 83 The Libpng License Notices ... 86 The zlib License ... 87...
This unit has been produced according to all current safety regulations. The following safety tips should safeguard users against careless use and the dangers related to such use. • Although this unit has been carefully manufactured and rigorously checked prior to leaving the factory as with all electrical appliances, it is possible for problems to develop.
Important safety information Where to install Locate the television away from direct sunlight and strong lights; soft and indirect lighting is recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight from falling on the screen. Always place the TV on a sturdy, level, stable surface that can support the weight of the TV.
Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited to the following: loss of profit, interruption of business, and/or loss of recorded data whether caused during normal operation or misuse of the product.
When does switchover happen? *Copeland switches on October 17, 2007 The exact date you switch depends on the transmitter you are served by. To check when you switch, go to Digital UK’s postcode checker on www.digitaluk.co.uk Television in the UK is going digital, bringing us all more choice and new services.
19DV713B/19DV714B/22DV713B/22DV714B Note: • The position of indicator labels on the keypad may be different depending on the model. 22DV713B, 22DV714B, and 32DV713B are used for illustration purposes. Description of indicators and controls POWER indicator: The Power indicator lights red in standby mode, orange in standby mode when the timer is activated, and green when TV is powered on.
Remote control Function Eject a disc from the disc slot Toggle between TV and DVD mode Toggle between analogue TV and digital TV Toggle between power on and standby mode - Select a channel - Select a teletext page - Enter the password Display source information Turn the sound on/off Toggle between TV, Radio, and Data modes...
Install the batteries Use R03/AAA/UM4 batteries. Note: • Weak batteries can leak and severely damage the remote control transmitter. Always remove batteries if they become weak or if the remote control is not to be used for an extended period of time. •...
I/O connections Note: Before you connect other appliances: • To avoid potentially damaging your TV, make sure all items are switched off and disconnected from the mains power when you make the connections. • Arrange the desired connection. • When you have finished making the connections, reconnect the mains power to the TV and switch it back on. Connect your aerial as shown below.
When the Auto Brightness Sensor feature is set to On, the TV will automatically optimise the backlighting levels to suit ambient light conditions. Press MENU SETUP display the Main Menu screen. Select Picture, and then press ENTER/CH LIST Press and then press your choice.
Auto setup Your TV has an automatic installation routine which makes installation easy. When you turn on the TV for the first time, the automatic installation routine is activated. This routine helps you select the on-screen language, country, energy saving mode, and automatically search for and store all available analogue and digital (DVB) channels.
Page 15
Press ENTER/CH LIST A message prompt will appear with option to connect aerial to TV. Press ENTER/CH LIST Your TV will now automatically detect all available channels in your area and store them in the TV’s memory. Analogue channels will be scanned first, and then digital channels.
Quick guide for menu operation Preparations: Quick guide for menu operation Launch the Main Menu screen. For example: Select Auto Tuning. • Turn on the TV with the button on its left Press INPUT side.The power indicator will light green. Press MENU SETUP To place the TV in standby mode, press...
Selecting the video input source Press INPUT DVD player. You can select each input source according to the devices you have connected to your TV. Press screen to select a video input source, and then press ENTER/CH LIST Note: • If no button is pressed after approximately 5 seconds, the Source Selection menu screen...
Automatic station presetting with the built-in tuner Automatic station presetting with the built-in tuner Perform this feature to search for and store new analogue and digital TV programmes after the Automatic Installation (see page 14). Preparation: Make sure your antenna is connected to the aerial input (see page 12). Select ATV or DTV (see page 16), and then press MENU SETUP Press ENTER/CH LIST...
Changing the order of stored channels Changing the order of stored channels The Automatic station presetting stores channels in a specific order. However, this order can be changed if you wish. Press MENU SETUP display the Main Menu screen. Select Channel, and then press ENTER/CH LIST Press Note: ENTER/CH LIST...
Manual TV station presetting The Auto Tuning process stores all available stations in the reception area. However, some stations with weak or poor reception may not be detected. If this is the case and you still want to store these stations in your TV, press the ATV/DTV enter ATV or DTV mode, and then follow the steps below.
Channel selection Use the number buttons 0-9. For example: • CH 2: Press 0 and within 2 seconds, press 2. The TV will switch to CH 2. • CH 29: Press 2 and within 2 seconds, press 9. The TV will switch to CH 29. (1) Press CH channel to another.
Basic operation Information display In ATV mode: Press timer settings information on the screen. Current settings for the sound mode, picture size, and resolution (if in use) are also displayed. The information will appear for approx. 5 seconds. In DTV mode: When you switch channels, a channel banner is displayed for a few seconds.
A teletext service offers a range of text-based information, typically including news stories, sport articles, weather forecasts, and TV schedules. Information is sent page by page. The TV can store up to 256 pages, but they can only be accessed once they have been stored.
Stereo reception with the built-in analogue tuner The TV’s built-in tuner can detect and receive NICAM stereo broadcasts automatically. NICAM stereo sound reception Press MENU SETUP screen. Press ENTER/CH LIST Select NICAM, and then press Auto or Off. Select Off if you do not want to receive NICAM sound.
The broadcaster may transmit a widescreen signaling (WSS) signal which can determine the correct height/width of pictures and have it set automatically when the setting Auto is selected. If you want to change this setting, you can select from the formats listed below.
AV colour adjustment Use the AV Colour menu option to adjust the picture colour settings in AV mode. These settings do not apply when the TV is in any other mode. Press INPUT press ENTER/CH LIST Press MENU SETUP Press Note: Press •...
The TV Main Menu has several menu options you can configure to suit your viewing preferences. Main Selected items menu Picture Picture Setting Brightness Contrast Sharpness Colour Tint* Colour Temperature Adjust the level of white balance in the display. Available settings include: Backlight DynaLight Picture Preference...
Page 28
Customise the channels stored in the TV. See page 19. This is a new feature that uses CEC technology and allows you to control ® Toshiba REGZA-LINK compatible devices from the TV remote via HDMI connection. See pages 31-32. See pages 29-30.
This is a new feature that uses CEC technology and allows you to control Toshiba REGZA-LINK TV remote via HDMI connection (see page 76). When the Enable REGZA-LINK in the REGZA-LINK Setup menu (see page 32) is set to On,...
Using REGZA-LINK REGZA-LINK Press MENU SETUP Press ENTER/CH LIST Press then press ENTER/CH LIST Press REGZA-LINK Power Turn the selected device on and off. Root Menu Access the root menu of a disc or the selected device. Contents Menu Access the contents list when you press ENTER/CH LIST Player menu will appear.
Using REGZA-LINK ® REGZA-LINK input source selection ® If a REGZA-LINK device with HDMI switching capability (e.g. Audio Receiver) is connected to the HDMI input, you can select another REGZA-LINK HDMI device using INPUT on the remote control or INPUT/ENTER panel.
Using REGZA-LINK Other REGZA-LINK When the Enable REGZA-LINK and each item in the REGZA-LINK Setup menu are set to On, the following functions will be enabled. TV Auto Input Switch If a connected HDMI device starts playing video or audio, the TV will automatically switch to the appropriate HDMI input.
- Maximum viewable resolution: 8192 x 8192 pixels - Maximum photo size: 9MB - Supported file extension: .jpg You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. Using the Media Player IMPORTANT INFORMATION...
Page 34
Using the Media Player Basic operation Auto Start Press MENU SETUP Press ENTER/CH LIST Press press ENTER/CH LIST Press Note: • If Auto Start is set to Off, you can start the Media To set Auto Start Insert USB device into the USB terminal on the left side of the TV. A prompt will appear.
Using the Media Player Viewing JPEG files Single View mode Press MENU SETUP to display the Main Menu screen. to select Setup, then press Press select Media Player, and then press ENTER/CH LIST to select Photo, and then press Press ENTER/CH LIST When the thumbnail view appears, press Note:...
Using the Media Player Using the photo Quick Menu You can select your preferred photo viewing settings from the photo Quick Menu. From the photo Single View, Slide Show or thumbnail mode, press MENU SETUP enter the Quick Menu. Note: •...
Page 37
Using the Media Player Setting background music for photo mode You can select music from the music list stored in the USB device to be played back in photo mode. From the photo Single View or Slide Show mode, press MENU SETUP to enter the Quick Menu.
Using the Media Player Listening to MP3 files Besides viewing JPEG files, you can also listen to the music files stored in the USB device. From Media Player menu, press When the list appears, press Press ENTER/CH LIST folder. Press RETURN folder.
Page 39
Using the music Quick Menu You can select your preferred music playback settings from the music Quick Menu. From the music list or music playback mode, press MENU SETUP Menu. Note: • The Quick Menu items of music list and music playback modes are different. Press Note: Press...
Display setup/Timer setting (DTV mode only) Display Setup Press MENU SETUP Press Press press ENTER/CH LIST The Display Setup menu appears. Press After all the changes are made, press EXIT/CANCEL Timer Setting If the time displayed on the Channel banner differs from the actual time, it can be corrected. Press MENU SETUP Press Press...
Password setup (Parental lock) (DTV mode only) Password Setup (Parental lock) This feature allows you to have parental control of services based on your viewing preferences. Once a service is protected with a password, it cannot be viewed unless the correct password is provided.
Version Version You can check the software version information. Press MENU SETUP Press Press then press ENTER/CH LIST Note: • Version check also applies to ATV mode. The software version will be displayed. Note: • The software version printed here in the manual Press EXIT/CANCEL or DIGITAL MENU to select the Setup menu, and then press ENTER/CH LIST...
Software Upgrade Software Upgrade allows you to download the latest software available for the channel. Press MENU SETUP Press Press then press ENTER/CH LIST check if the TV has the Over Air Download service. Note: • Do not disconnect the AC cord when the software upgrade is in progress, as this may cause the...
Common interface Common Interface You can access the Common Interface module information from this menu option. Preparations: Insert CAM into the DVB Common Interface (C.I.) slot on the side of the TV (see page 9). Press MENU SETUP Press Press then press ENTER/CH LIST The conditional access module (CAM) name is displayed.
Multi audio (DTV mode only) Multi audio The Multi audio menu enables you to choose your preferred audio mode and DVB (Digital Video Broadcasting) subtitle languages available for the current broadcasting programmes. Press AUDIO SELECT to display the Multi audio menu. The Audio mode and Language Code will be displayed, if available.
DVB-Subtitle/Using the Digital Service (DTV mode only) DVB-Subtitle DVB-Subtitle is a feature supported by DVB (Digital Video Broadcasting) applications. It provides on-screen text display in parallel with the corresponding audio services, and can be enabled or disabled at any time. Press SUBTITLE menu.
EPG (Electronic Program Guide) (DTV mode only) The Guide menu shows a list of available programmes for the next eight days only, including today. However, it will show “No Event Name” for programmes which are more than eight days ahead, or for programmes within the eight days when no programme information is available.
EPG Timer (DTV mode only) You can choose whether or not to switch on your TV screen when a timer event begins (see page 28: Rec Screen Status (LCD Power on/off)). This is so that if you are using the timer to make a recording from your VCR or other device, the TV screen will not turn on unless you want it to.
DVD discs must be Region 2 or Region ALL type to play on this TV/DVD. If region numbers, which stand for their playable area, are printed on your DVD and you do not find will display a message on-screen). Some DVDs that have no region code label may still be subject to area restrictions and therefore not playable.
Basic playback This section shows you how to play a disc. Basic playback (DVD/VCD/Audio CD) Press The power indicator on the front of the TV will change to green. Press TV/DVD mode. The DVD startup screen will appear on-screen. Hold the disc by its edges and load it in the disc slot with the label side facing forward. (If the disc has a label.) Note: •...
To start playback in stop mode Press PLAY To pause playback (still mode) Press PAUSE during playback. To continue playback from still mode Press PLAY To stop playback Press STOP To remove a disc Press EJECT on the TV control panel or on the remote control. Wait for the disc drive to eject the disc, and then remove the disc from the slot.
Advanced playback The TV supports several playback modes that allow you to play discs at various speeds. Playing in fast reverse or fast forward direction (DVD/VCD/Audio CD) Press REV • REV • FF Each time you press REV To resume normal playback, press PLAY Note: •...
Zoom function/Scene navigation Using the Zoom function (DVD/VCD) You can change the viewing scale of a picture by using the Zoom function. Once the image has been rescaled, use the arrow buttons Press CH RTN ZOOM during playback. The view will zoom into the centre of the image. Each press of the button will increase the scale value: 1(x 1.3), 2 (x 1.5), and...
Scene bookmark Bookmarking a scene (DVD/VCD/Audio CD) Scene bookmarks refer to specific points in the playback range that have been marked for later access. You can create up to three markers per disc. Note: • The saved scene bookmarks are only accessible during the current session. Once you eject the disc or turn off the TV, all bookmarks will be cleared.
Repeat playback/A-B repeat playback Enabling repeat playback (DVD/VCD) You can choose to repeat DVD playback by title or chapter. For VCDs, you can repeat a single track or the entire disc. Press PLAY MODE during playback or stop mode. Press ENTER/CH LIST repeatedly to select a repeat mode.
Scene angle/Title selection/DVD menu Changing the scene angle (DVD) When playing back a DVD recorded with multi-angle scenes, you can select the scene angle that you prefer. Press ANGLE The current angle will appear. Press ANGLE Note: • Depending on the DVD, you may not be able to change the scene angle even if multi-angle data are recorded on the disc.
Soundtrack language/Audio channel/Subtitle Selecting a soundtrack language (DVD) You can select the soundtrack language when you play a multilingual DVD. During playback, press AUDIO SELECT until the preferred language is selected. Selecting the audio channel (VCD) During playback, press AUDIO SELECT heard.
Playback information/VCD playback control (PBC) Viewing the playback information (DVD/VCD) You can view the playback status and other disc information. Press To close the display panel, press VCD mode DVD mode Press On Video CDs This TV/DVD supports Video CDs equipped with the Playback Control (PBC) function, version 2.0.
• MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. ® and Audio CD operation ®...
About the file browser/Audio file playback About the file browser File icons Music file (MP3 or audio CD track) Picture file (JPEG) Movie file (DivX If a CD contains a mixture of MP3, JPEG, and DivX selecting a file, playback starts automatically from the first file in the list. Setting the file type listing You can choose the type of files listed in the file browser.
Load an MP3 or audio CD in the disc slot. The file browser appears on-screen. The first audio file in the list plays automatically (applicable only to audio CD). Press to select another audio file for playback. Press ENTER/CH LIST or PLAY To stop playback: Press STOP...
JPEG file operation Viewing a JPEG file Load a disc containing JPEG files in the disc slot. The file browser appears on-screen. Press A preview of the selected file is displayed in the Preview panel. To display a thumbnail list: Press DVD MENU select an image file.
® DivX Load a disc containing DivX The file browser appears. Press When PLAY starts automatically from the first file in the list. Press ENTER/CH LIST playback. Note: • Depending on the recording conditions of ® DivX file, you may not be able to use the Fast Reverse, Fast Forward playback, and Jump...
MP3/JPEG/DivX Enabling repeat playback (Audio CD/MP3/JPEG/DivX You can choose to repeat CD playback by track or the entire disc. During stop mode, in the Option panel of the file browser, press Press ENTER/CH LIST mode: Track or All. Note: • These playback modes Press PLAY are only applicable during the current session.
Page 65
MP3/JPEG/DivX Programming the playback sequence (Audio CD/MP3/JPEG/DivX You can customise the file playback sequence. In the Option panel of the file browser, press select Edit Mode, and then press ENTER/CH LIST Press select a file, and then press ENTER/CH LIST Note: mark it for inclusion in the programmed playlist.
Programme playback/Random playback The TV enables you to arrange the playback order of tracks and files on the disc, and it can also select tracks and files at random and playback them. These features can be applied for Video CD. For Audio CD and MP3/JPEG/DivX “Enabling random playback (Audio CD/MP3/JPEG/DivX ®...
Customising disc playback You can customise the disc playback settings to suit your preferences. Configuring the disc playback settings (DVD/VCD/CD) In DVD mode, press MENU SETUP mode. Press to select a setup tab, and then press The first option will be highlighted. Press to select the setup option you want to customise.
Page 68
Customising disc playback Settings details Section Note: These setup settings are retained in the TV’s memory. It remains active even if the power is turned off. (continued) Option Details Menu Select the language for the DVD menu display. Subtitle Select the subtitle language for disc playback. DivX Subtitle Select the subtitle encoding format for DivX Audio...
Customising disc playback Menu / OSD Select the language for the DVD and Setup menu display. Options include: English, French, Spanish, German, and Italian. Subtitle / Audio Select the language for the subtitle display and audio track output during disc Menu :English playback.
Customising disc playback Night Mode :Off Parental Menu E.B.L. : Off : Off : English Digital Out :Bitstream Subtitle TV Screen Set Password : 4:3 : English Display Output Audio : On : English : Interlace Picture Mode DivX(R) VOD : Auto JPEG Interval : 5 Seconds...
Page 71
Customising disc playback Parental A DVD is usually encoded with a rating level to indicate the recommended audience age. You have the option to select the content rating level allowed for playback in your TV. You will be prompted to key in the system password to access this setting option. For initial access to this menu: (1) Press Parental...
Customising disc playback (continued) Password Select this option to change the access password for the parental control setting. to select Password, and then press ENTER/CH LIST (1) Press The Enter Current Password screen will appear. (2) Use the number buttons (0–9) to input the current password, and then press ENTER/CH LIST If the password has not been set yet, key in “0000”.
Temporary cancel the rating level by DVD disc Load a DVD disc. If the DVD disc has been designed to temporarily cancel the rating level, the screen which follows the Reading screen will change, depending on which disc is played. If you select Yes and press ENTER/CH LIST Use the number buttons (0–9) to input the password, and then press ENTER/CH LIST...
PC connection As PCs are sometimes supplied with a “conventional” CRT monitor, you may need to adjust the display settings of your PC’s graphic card; otherwise the pictures may not appear correctly. Switch on your PC (still with your original monitor), select “1360 x 768”...
Connecting an HDMI or DVI device to the HDMI input The HDMI input on your TV receives digital audio and uncompressed video from an HDMI-equipped device, or uncompressed digital video from a DVI-equipped (Digital Visual Interface) device. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of...
® • The REGZA-LINK feature uses the CEC technology as regulated by the HDMI standard. • This feature is limited to models incorporating Toshiba’s REGZA-LINK Refer to the individual instruction manuals for compatibility information. Note: • This feature may not work properly depending on the devices that are connected.
Connecting aerials and other devices to your TV Connect the TV’s coaxial cable directly to the aerial input jack at the back of the TV. Antenna Satellite antenna Decoder Satellite receiver Caution: Before connecting: • Make sure to disconnect the appliance from the power supply in order to avoid any potential damage from occurring. •...
Page 78
Connecting TV to other equipment Connecting a DVD player DVD player can be connected to the TV either by a SCART cable or a standard audio cable along with a component video cable (see 5 on this page). In this case, a SCART cable is required for the connection.
Information/Status message Invalid entry No radio services No TV services No data services No services No Teletext signal Duplicate Timer No video No audio Audio stream not available Descrambling not possible CI card initialised CAM module has been removed No CAM Found Database empty No signal Locked service...
Troubleshooting table Refer to the following checklist to troubleshoot simple problems that may occur during TV operation. If the problem still exists after you try out the possible solutions, consult your local dealer or service outlet for assistance. Check that all connections are properly made when using the TV with another equipment.
Page 81
• DivX , DivX Certified and associated logos are registered trademarks of DivX, Inc. and are used under license. Troubleshooting table ® feature is available for Toshiba REGZA-LINK ® device does not work correctly after you ® feature may not operate...
Specifications Model 19DV713B / 19DV714B Television LCD panel (approximate 19.0 inch screen size, diagonal) System Analogue PAL UK, IR, CCIR, French System, B/G, D/K, I/I, L/L’ Digital DVB-T (OFDM 2k/8k 16QAM/64QAM) Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60 Preset channels Analogue channels (99) + Digital channels (Carrier 200/Service1000) Frequency Analogue...
The GNU General Public License (GPL) Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The licenses for most software are designed to take away your freedom to share and change it.
Page 84
In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License. (3) You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: Accompany it with the complete corresponding machine-readable source code, which must be distributed under the...
Page 85
NO WARRANTY (1) BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
The Libpng License Notices This copy of the libpng notices is provided for your convenience. In case of any discrepancy between this copy and the notices in the file png.h that is included in the libpng distribution, the latter shall prevail. COPYRIGHT NOTICE, DISCLAIMER, and LICENSE: If you modify libpng you may insert additional notices immediately following this sentence.
Libpng is OSI Certified Open Source Software. OSI Certified Open Source is a certification mark of the Open Source Initiative. Glenn Randers-Pehrson glennrp at users.sourceforge.net December 3, 2009 The zlib License zlib.h -- interface of the “zlib” general purpose compression library Version 1.2.3, July 18th, 2005 Copyright (C) 1995-2005 Jean-loup Gailly and Mark Adler This software is provided “as-is”, without any express or implied warranty.
Page 88
“This product is marked with “CE” and complies therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC and the EMC Directive 2004/108/EC.” Responsible for CE-marking is TOSHIBA INFORMATION SYSTEMS (U.K.) LTD, Toshiba Court, Weybridge Business Park, Addlestone Road, Weybridge,...
Page 89
Printed in China 52G0101A P69-Back.indd 76 1/5/09 3:08:45 PM...
