- Page 1 Operating manual Washer extractors W465H – W4300H, W475M – W4330M W475N – W4330N, W475S – W4330S W4280X, W4350X Type W3..., EXSM.X. Compass Control 438 9213-01/EN Operating manual in original language 2011.06.07...
-
Page 3: Table Of Contents
Contents Contents Safety precautions ..................5 General .......................7 Control panel ..................7 Control knob ..................7 Display ....................8 Preset buttons ..................8 Wash program ....................9 Start menu ....................10 Start .....................10 Options ....................10 Program time ..................13 Delayed start ..................13 Info ......................13 Exit ......................13 Washing functions ..................14 Start .....................14 Rapid advance ..................14 Pause ....................14... -
Page 5: Safety Precautions
Safety Precautions Safety Precautions The machine is only intended for water-wash use. Do not allow minors to use the machine. Do not hose down the machine with water. The machine's door lock must under no circumstances be bypassed. If the machine develops a fault, this must be reported to the person in charge as soon as possible. -
Page 7: General
General General Control panel The control panel is used to choose the wash program with options and to start and stop the machine. The panel houses a control knob and a display. Some machines also have two preset buttons. Preset buttons Display Control knob 6611... -
Page 8: Display
General Display The display presents the wash programs, options and additional functions. The up and down arrows on the right-hand side of the display 60° indicate that there are more options available in the current menu. Turn the knob for next NORMAL 60 program. -
Page 9: Wash Program
General Wash program The machine is programmed with a number of programs adapted to the range of uses to which the machine is intended. NORMAL The following wash programs can be available: 6277 Wash program Normal. Cotton. Full load. Different temperatures can be selected. Wash program Synthetics. -
Page 10: Start Menu
General Start menu A start menu will appear on the display once a NORMAL 60 60° wash program has been selected. Here, you can complement the selected wash program with up OPtiON 1 to two options (on certain machines), select how StARt the machine is to start and obtain information on the selected wash program. - Page 11 General ”NO PREWASH” Prewash will be excluded from the selected SeLect OPtiON wash program. NO PReWASh ”LIGHT SOILED” The temperature is lowered 5 °C at all 6204 temperatures and the main wash shortened by 4 minutes. SeLect OPtiON ”QUICk WASH” Light SOiLeD The machine excludes the selected wash program’s prewash and shortens spin drying...
- Page 12 General ”GENTLE EXTRACTION” Extraction in the selected wash program is ex- SeLect OPtiON cluded between rinses and the final extraction is shorter. geNtLe ”SHORT EXTRACTION” 6204 Final spin dry in selected wash program is shortened by 4 minutes. SeLect OPtiON ”EXTRA EXTRACTION”...
-
Page 13: Program Time
General Program time Shows approximate wash time for selected NORMAL 60 60° program. Delayed start PROgR.tiMe, MiN In this menu, you can set a delay of up to 99 6204 hours and 59 minutes before the machine starts the selected wash program. The arrow in the menu indicates the column NORMAL 60 60°... -
Page 14: Washing Functions
General Washing functions NORMAL 60 Activated 60° START option OPtiON 1 Turn the control knob to the START row. Press StARt the knob to start the selected program. On machines equipped with preset buttons, the preset wash program can be started with the 6204 respective button. -
Page 15: Detergent Supply
General Detergent supply Prewash, powder or liquid detergent, if option "Prewash" has been selected. Main wash. Two compartments, one for powder detergent and one for liquid. Alt. Fabric softener, liquid 5343... -
Page 16: Remaining Time
General Remaining time During the wash, the remaining time for the selected wash program will be shown at the NORMAL 60 60° bottom of the display. The time is given in minutes. MAiNWASh To calculate the remaining time, the machine uses tiMe Left 20 a model calculation based on earlier used wash programs. -
Page 17: Handling
Handling Starting with control knob • Select the desired wash program with the control knob and confirm by pressing the 60° knob. • Add any options to the selected wash pro- gram. Select from the list with the control 6182 6179/6180 knob and confirm by pressing the knob. Note! Max two options can be chosen for each NORMAL 60 60°... -
Page 18: Starting With Preset Button
Handling Starting with preset button • Empty any pockets. • Close the door. • Add the correct amount of detergent and softener. Note! Refer to the dosages on the detergent packaging. Do not overdose. • Press the preset button for the desired pro- gram. • If the machine has a coin meter, insert the correct amount of coins/tokens. 5343 Note! Pushing one of these buttons will activate the corresponding wash program directly and the machine will start automatically. -
Page 19: Starting Machine With Coin-Meter
Handling Starting machine with coin-meter • Select the desired wash program with the WARM 60 60° control knob and confirm by pressing the knob. 2.00 • Price for the wash program is now shown in the display. 6204 • Add the correct amount of detergent and softener. Note! Refer to the dosages on the detergent packaging. Do not overdose. • Start the machine by inserting correct amount of coins / tokens. -
Page 21: Timer
Timer Timer (only on certain models) The timer is located under the door, to the right of the control panel. Open the door to change timer settings. 1 Setting the day 2 Setting the time 3 Manual operation 4 Ok button 5 Programming 4691A Day OK... -
Page 22: Setting The Timer
Timer Setting the timer Set the time for the start of the udder cloth program's final rinse: 1. Press "Prog" to select a "program" from 1 to 20 (each "program" corresponds to a start signal). Press "Ok". 2. Press repeatedly on "Day" until the required day(s) (1-7) is/are indicated. The selected day(s) is/are indicated by arrows. -
Page 23: Setting The Time
Timer Setting the time Set the time in the time display menu in the right-hand corner of the display: 1. Press and hold the button with the clock symbol until the desired hour is shown. 2. Press the button with the clock symbol repeatedly, until the desired minute is shown. -
Page 24: Setting The Date (Year, Month And Day)
Timer Setting the date (year, month and day) Set the date in the time display menu in the right-hand corner of the display: 1. Press and hold the clock symbol and hand symbol simultaneously, until "PrY" is shown in the display. Press repeatedly on both buttons simultan- eously until the desired year is shown. -
Page 25: Error Messages
Error messages Error messages A fault in the program or in the machine is indi- cated by an error message comprising an error code and a descriptive text. eRROR Resetting of error code and restart of washing program can be done by a quick press on the No water knob. -
Page 27: Maintenance
Maintenance Maintenance Daily • Clean the door seal from detergent residue. • Make sure the door is not leaking. • Clean the detergent supply box and wipe off the machine with a damp rag. • Make sure the drain valve is not leaking. • Start the machine and make sure the door is locked during the program. Rapid advance the program to stop and make sure the door cannot be opened until after the program is complete. Every month • Check that valves, hoses and connections are not leaking. • Remove any lint from the drain connection, joints in the drain pipe, etc. Every third month When chemicals have collected on the edges of the panels: • Turn off power to machine. -
Page 28: Cleaning The Mop Elements
Maintenance Every month (only for mop machines) Cleaning the mop elements • Depending on the size of the machine, you will find one or two core covers in the machine’s inner drum so that the elements can be cleaned if so required. The front cover is located directly above the drain, while the other is in front of the element retainer. - Page 31 Skrotning av maskin När maskinen inte längre skall användas måste den lämnas till en återvinningsstation för destruktion. Många detaljer i maskinen går att återanvända, men den innehåller även annat material som måste tas om hand på ett korrekt sätt. Lämna därför aldrig maskinen eller delar av maskinen i hushållsavfallet, eftersom det kan leda till hälsorisker eller skador på...
- Page 32 Electrolux Laundry Systems Sweden AB 341 80 Ljungby, Sweden www.electrolux.com/laundrysystems Share more of our thinking at www.electrolux.com...
