BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your partic-
ular installation. This will aid you in avoiding the unneces-
sary expense associated with improper installation. In
addition to proper installation, read all operating and safe-
ty instructions.
NOTES
S
Seat post holes on 5-1/2" centers.
S
Water depth from rim is 6-11/16".
S
1-3/4" passageway.
S
Ensure that the new toilet has the correct
roughing-in dimension. The K-3414-PB has a 14"
roughing-in dimension. See Fig. #1.
S
Be very careful while working with vitreous china
products. Vitreous china can break and chip if
you overtighten bolts and nuts or carelessly
handle the product.
S
Carefully inspect new fixture for any sign of
damage.
S
Observe all local plumbing and building codes.
S
Shut off hot and cold water supplies.
S
For new construction, refer to the dimensions in
Fig. #1 and Fig. #4 for locating the shut-off valve.
S
Fixture dimensions are nominal and conform to
tolerances by ANSI Standards (A112.19.2).
WARNING: Do not flush toilet with float valve cap
removed. Pressurized water will spray upward and
may cause water damage or injury.
AA
111784-2- (9412)
R
WELLWORTH LITE VITREOUS CHINA
1 1
REVERSE TRAP TOILET
All information in these instructions is based on the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time with-
out notice.
These instructions contain important care, cleaning, and
warranty information - please leave instructions for the
consumer.
ORDERING INFORMATION
Bowl K-4237-PT
Tank K-4597-A with:
Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tank cover . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bolt cap accessory pack
Tank accessory pack
Float valve (assembly w/hosed elbow)
Flush valve (for insulated tank)
Flush valve (for unlined tank)
Trip lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When specified:
Tank w/cover locks (pr.)
Tank with insuliner and trim
3/8" supply . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor bolts (pr.) . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended round front seat
K-3414-PB
K-4512
K-4598
. . . . . . . . . . . . . . . . . 52048
. . . . . . . . . . . . . . . . . . . . 52153
. . . . . 81093
. . . . . . . . . . . . 81094
. . . . . . . . . . . . . 81095
30324
. . . . . . . . . . . . . . K-4597-AT
. . . . . . . . . . . K-4597-AU
K-7638
21401
. . . . . . . . . . K-4662
Copyright E1994 Kohler Co.
