Mitel MiVoice 6930/6930w IP Phone - Quick Reference Guide
QUICK REFERENCE GUIDE
Getting started
Softkeys
5 state-sensitive softkeys
Contacts
Displays
a list of your
contacts.
Call History
Displays a list of
missed, outgoing
and received
calls as well as
My Mobile and
Missed calls
Voicemail
Provides
access to
your voicemail
service.
Settings
Provides
services and
options that
allow you to
customize
your phone.
Navigation/Select
Volume
Multi-directional navigation
Adjusts the
keys are used to navigate
volume of
through phone menu. Press
the ringer,
the center button to select
handset,
menu options and perform
speaker,
various actions
and headset.
On the Home screen,
the left and right navigation
keys can be used to access
the additional pages of
programmable keys
© Copyright 2022, Mitel Networks Corporation. All Rights Reserved.
The trademarks, service marks, logos and graphics (collectively "Trademarks") appearing on Mitel's Internet sites or in its publications are registered and unregistered trademarks of Mitel Networks Corporation (MNC) or its subsidiaries (collectively "Mitel") or others.
Use of the Trademarks is prohibited without the express consent from Mitel. Please contact our legal department at legal@mitel.com for additional information. For a list of the worldwide Mitel Networks Corporation registered trademarks, please refer to the website:
http://www.mitel.com/trademarks.
Mitel's Power Over Ethernet (PoE) Powered Device (PD) products are covered by one or more of the U.S. patents (and any foreign patent counterparts thereto) identified at Mitel's website: www.mitel.com/patents. For more information on the PD patents that are licensed,
please refer to www.cmspatents.com.
Programmable Keys
Up to 72 programmable keys,
Goodbye
a maximum of 12 programmable keys
Ends active calls
per page
and used for
existing menus
Redial
Displays Call
History with a list
of outgoing calls
Hold
Places an active
call on hold or
resumes a call
from hold
Mute
Mutes/unmutes
all outgoing audio
on headset,
handset or
speaker
Speaker/Headset
Toggles the phone's audio between speaker
and headset. If you are using a DHSG/EHS
headset, ensure that the headset jack adapter is
removed from the headset port. See the Mitel Mivoice
6930 IP Phone Installation Guide for more details.
Warning!
The headset port is for headset use only.
Plugging any other devices into this port
may cause damage to the phone and will
void your warranty.
Information Regarding Model Variants
The 6930L and 6939Lt variant has the Bluetooth circuitry removed and so all associated
features and capability relating to Bluetooth are not available. Any information within this
guide that relates to Bluetooth wireless capabilities do not apply to the 6930L or 6930Lt
variants.
A new variant of the 6930 IP Phone is available called the 6930w IP Phone. The 6930w
IP Phone is physically identical to the 6930 IP Phone. There are new features supported
by the 6930w IP Phone relative to the 6930 IP Phone, namely embedded Wi-Fi,
Bluetooth 5.0, IEEE 802.3az standard (Energy Efficient Ethernet) capability. The 6930w
IP Phone also supports the same accessories as the current 6930 IP Phone.
Basic call handling
Making a call
1. Lift the handset or press the
and dial the number.
2. Press the Line programmable key and dial
the number.
Ending a call
Place the handset back in its cradle, press the End Call softkey, or press the
key.
Answering a call
Lift the handset or press the
Redialing
Press the Redial softkey once or the
displayed on the Home screen.
or
Press the key once to access the Call History application with a list of recently
dialed numbers. Use the up and down navigation keys to scroll through the entries and
either press the Select button or Dial softkey to redial the selected number.
Muting or unmuting a call
Press the key while on an active call to mute the microphone for your handset,
headset, or speaker. Press the
key,
key for handsfree operation.
key twice to call the last dialed number as
key again to unmute the audio.
58016699 REV00
