APX™ 1000 Model 2 Digital Portable Radios Quick Reference Card
RF Energy Exposure and Product Safety Guide for Portable Two-Way Radios
This radio is restricted to Occupational use only. Before using the radio, read the RF Energy Exposure and Product Safety Guide for Portable
Two-Way Radios which contains important operating instructions for safe usage and RF energy awareness and control for Compliance with
applicable standards and Regulations.
Radio Controls
Single Knob Radio
Top Lightbar
Indicator
Microphone
Top Side (Select)
Button
__________
PTT Button
Side Button 1
__________
Side Button 2
__________
Home Button
Antenna
Microphone
Accessory
Connector
ATTENTION!
Two Knobs Radio
Top (Orange) Button
___________
LED
Microphone
Top Side (Select)
Button
Main
__________
Speaker
PTT Button
Main Display
Side Button 1
__________
Menu Select
Buttons
Side Button 2
Data Feature
__________
Button
Home Button
4-Way Navigation
Button
Multi Function Knob
Antenna
(MFK):
Primary Feature:
_________________
Secondary Feature:
_________________
Accessory
Connector
Battery
Top Lightbar
Top (Orange) Button
Indicator
___________
LED
Main
Speaker
Main Display
Menu Select
Buttons
Data Feature
Button
4-Way
Navigation
Button
On/Off/Volume
Control Knob
16-Position Select
Knob
Microphone
Battery
Radio On/Off
• On – Press and hold the MFK until the display
lights up.
• Off – Press and hold the MFK until you see Power
off?, then press Menu Select button below Yes.
Radio On/Off
• On – Rotate the On/Off/Volume Control Knob
clockwise until you hear a click.
• Off – Rotate the On/Off/ Volume Control Knob
counterclockwise until you hear a click.
Select Zone and Channel
1
Press the MFK to see
on the screen.
2
Turn the MFK to scroll to desired zone or channel.
3
Press MFK to select the desired zone or channel
and exit Mode Change.
Select Zone and Channel
1
Rotate the preprogrammed 16-Position Select
Knob to the desired channel.
Receiving and Transmitting
1
Select zone/channel.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the
Stylized M logo are trademarks or registered trademarks of
Motorola Trademark Holdings, LLC and are used under
license. All other trademarks are the property of their
respective owners.
© 2014 and 2015 by Motorola Solutions, Inc. All Rights
Reserved.
1303 East Algonquin Road, Schaumburg, Illinois 60196,
U.S.A.
*PMLN6812B*
06/15
PMLN6812B
English
