Summary of Contents for Boss Audio Systems MR400UAB
-
Page 2: Table Of Contents
CONTENTS Precautions..............................1 Take Precaution ............................1 Installation ............................... 2-3 Installation Procedures .......................... Installation Opening ..........................Wiring Connections ..........................3 Remove of the Main Unit ........................3 Control Panel Button Locations ........................4 Operation ..............................4-5 Power / SRC ............................4 ........................ -
Page 3: Precautions
PRECAUTIONS Take Precaution • • Some MP3/WMA files may not be playable. • • • • Be sure to lower the volume before switching off the unit or the ignition key. -
Page 4: Installation
INSTALLATION Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening This unit can be installed in any dashboard Having an opening as shown below. 2.05 inch 7.20 inch Insert mounting collar into the dashboard and bend the mounting tabs out with a screwdriver. Make sure that lock lever is flush with the mounting collar( not projecting outward). -
Page 5: Wiring Connections
INSTALLATION(CONT.) - Only use speakers with 4 ohms impedance. - The maximum current of the auto antenna is 200mA. Wiring Connections WIRING DIAGRAM Radio Antenna White:Front Left PRE-AMP Output Red: Front Right PRE-AMP Output Red: Rear Right PRE-AMP Output White: Rear Left PRE-AMP Output Purple + Green + CAUTION... -
Page 6: Control Panel Button Locations
CONTROL PANEL BUTTON LOCATIONS OPERATION 1.POWER/SRC to turn off the unit. RADIO, USB, BT, AUX IN,modes (if there are USB inside the unit). radio , BT and Aux. When the user insert a USB flash memory device, their respective logos will illuminate on the display. During USB mode, press the ‘1/ ’... -
Page 7: Insert Usb
OPERATION 9. USB Port Rotate the volume knob to increase or decrese the volume level of the sound output. Press the SEL button repeatedly to cycle through the following adjustable audio functions: ILL MID/HI/LOW, BASS, TREBLE, BALANCE, FADER, EQ OFF, CLASS/ROCK/POP/ FLAT, LOUD ON/OFF, DX/LOC, STEREO/MONO, CLOCK 12/24, AREA US/EU. -
Page 8: Reset System (Reset)
To begin pairing, enable BT mode on your mobile phone. 2. When the phone the car audio system, the BOSS MR400UAB will be displayed. 3. Choose the BOSS MR400UAB from the device list to pair and connect with the car audio system. Upon the BT logo will stop 4. -
Page 9: Troubleshooting
TROUBLESHOOTING If you suspect something is wrong, immediately switch power off. Do not use the unit in abnormal condition, for example without sound, or with smoke or foul smell, can cause fire or electric shock. Immediately stop using it and call the store where you purchased it. Never try to repair the unit by yourself because it is dangerous to do so. - Page 10 SPECIFICATIONS General Power supply Requirement : DC 12V Maximum power output : 50W X 4CH Speaker impedance : 4 - 8 Ohm Unit Dimensions(WxHxD) : 7.0 X 2.0 X 3.8 inch Weight : 1.54 Lb (0.7 kg) Fuse : 15 A RADIO Frequency Range USA / EUROPE: 87.5 MHz - 107.9 MHz / 87.5 MHz - 108.0MHz...
