Summary of Contents for Boss Audio Systems MR1315WUA
-
Page 2: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS BAND MUTE MODE SCAN CLOCK AS/PS POWER Under the plastic cover 1. POWER BUTTON When the unit is powered off, it will switch on by pressing any button except the RELEASE button. 2&3&4. SEL BUTTON (Select) AND VOL CONTROL BUTTON a) Press the SEL button briefly, it is activated as selecting each mode of E. -
Page 3: Specifications
Specifications Supply voltage : 12V DC(11V-15V) Current consumption : Less than 10A Audio Signal Output : 2ch line out Characteristics : (1) Frequency Response: 20Hz-20KHz S/N Ratio: (Europe) Frequency Coverage: 87.5 to 108Mhz 10.7Mhz Sensitivity (S/N = 30dB) : 20dBu Frequency Coverage: 522 to 1620Khz Sensitivity (S/N = 20dB) : 45dBu... -
Page 4: Wiring Connection Diagram
7&8. TUNE, SEEK, TRACK, SKIP UP / DOWN BUTTONS a) During RADIO mode: Press the >>| or |<< button briefly to manual tune up/down for the desired radio station frequency step by step. Press and hold the >>| or |<< button for longer 0.5 seconds, to automatically tune up/down for the radio station frequency of strong signal. -
Page 5: Troubleshooting
TROUBLE SHOOTING Before using the check list please make all the connections first. If you still have questions after going through the checklist, please consult your local customer service representative. Common Symptoms Cause The car ignition is switched off. There is no power. The fuse has blown. -
Page 6: Installation Method
15-20. PRESET STATION MEMORY AND TOP/>||, INT, RPT, RDM BUTTONS a) During radio mode: When pressed briefly, these buttons select a preset station directly.If the six buttons are pressed for more than 2 seconds, the station currently being listened to is memorized into the selected preset button.
