- Page 1 ITEM NO: M2019NBRV M2019MBKRV M2019BNRV M2019WHRV CEILING FAN CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS FAN RATING AC 120V. 60Hz UL LISTED MODEL : AC-552...
-
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screwdriver Blade screwdriver 11 mm wrench Step ladder Wire cutter 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Set of blades assembly (5) b. Hanger bracket c. -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, insure Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the 2. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the Outlet box building structure. appropriate fasteners and building materials. -
Page 5: Hanging The Fan
5. HANGING THE FAN REMEMBER to turn off the power. Follow CUL Listed electrical box the steps below to hang your fan properly. Hanger NOTE: This ceiling fan is supplied with two bracket types of hanging assemblies; the standard ceiling installation using the downrod with Mounting screws ball and socket mounting and the (supplied with... - Page 6 CLOSE-TO-CEILING INSTALLATION 1. Pass the 120-volt supply wires through Canopy the center hole in the ceiling hanger bracket as shown in Fig. 5. Decorative canopy cover Figure 8 2. Remove the decorative canopy cover from the canopy. (Fig. 8) 3. Secure the hanger bracket to the ceiling Screw and lockwasher (3 of 6 places) outlet box with the screws and washers...
-
Page 7: Make The Electric Connections
6. MAKE THE ELECTRIC CONNECTIONS POWER LINES 120V GREEN GROUND Remember to disconnect the power. Follow the steps below to connect the fan to your household wiring. Use the wire WIRING connecting nuts supplied with your fan. Secure the connectors with electrical tape. GROUND TO MOUNTING Make sure there are no loose strands or... -
Page 8: Finishing The Installation
7. FINISHING THE INSTALLATION Outlet box Screws STANDARD CEILING INSTALLATION Hanger bracket Slide canopy up to the ceiling as shown in Figure 14. Make sure you place the wires Canopy safely into the outlet box. Secure the canopy to the hanger bracket with the four screws with your fan. -
Page 9: Attaching The Fan Blades
8. ATTACHING THE FAN BLADES Caution: Remove 5 rubber packing mounts and discard before installation. Step 1. Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure 16. Start screw into bracket. Repeat for the two remaining screws. -
Page 10: Installing The Light Bulbs & Glass Shade
10. INSTALLING THE LIGHT BULBS & GLASS SHADE 1. Install 2 x 7W LED bulbs (provided). (Fig. 2. Remove the decorative nut, glass cap and metal nut from the light kit. Place glass shade over the light kit stem, secure with the metal nut (rubber side on the top)glass Light Kit Pull Chain... -
Page 11: Operating Your Fan
12. OPERATING YOUR FAN NOTE: Wait for fan to stop before changing the setting of the slide switch. Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1 pull- High, 2 pulls-Medium, 3 pulls- Low, and 4 pulls-Off. -
Page 12: Troubleshooting
13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds 1. Make sure all motor housing screws are snug. noisy.
