- Page 1 CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: M2006XX FAN RATING AC 120V. 60Hz UL LISTED MODEL : AC-552...
-
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: a. Set of blades assembly (5) b. -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, insure 9. To avoid personal injury or damage to the electricity has been turned off at the fan and other items, be cautious when circuit breaker or fuse box before working around or cleaning the fan. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the Outlet box building structure. Use appropriate fasteners and building materials. -
Page 5: Hanging The Fan
5. HANGING THE FAN Hanger REMEMBER to turn off the power. Follow bracket the steps below to hang your fan properly: Ceiling canopy Step 1. Remove the decorative canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Step 2. -
Page 6: Make The Electric Connections
6. MAKE THE ELECTRIC CONNECTIONS POWER LINES 120V GREEN GROUND Remember to disconnect the power. Follow the steps below to connect the fan WIRING to your household wiring. Use the wire connecting nuts supplied with your fan. GROUND TO Secure the connectors with electrical tape. MOUNTING BRACKET Make sure there are no loose strands or... -
Page 7: Finishing The Installation
7. FINISHING THE INSTALLATION Step 1. Tuck connections neatly into Outlet box ceiling outlet box. Hanger Step 2. Slide the canopy up to hanger bracket bracket and place the key hole on the Screws canopy over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key holes. -
Page 8: Installing The Light Kit
9. INSTALLATING THE MOUNTING PLATE Step 1. Remove 1 of the 3 screws from the mounting ring and loosen the other 2 screws. (Do not remove) Step 2. Place the key holes on the mounting plate over the 2 screws previously loosened from the mounting Mounting ring ring, turn mounting plate until it locks in... - Page 9 11. INSTALLING THE LED LIGHT BULBS & LIGHT FRAME NOTE: Before starting installation, disco- nect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. Step 1.
-
Page 10: Operating Your Fan
13. OPERATING YOUR FAN Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1 pull- High, 2 pulls-Medium, 3 pulls- Low, and 4 pulls-Off. Light pull chain it controls the light in "ON" or "OFF". -
Page 11: Care Of Your Fan
14. CARE OF YOUR FAN Here are some suggestions to help you maintain your fan 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. -
Page 12: Troubleshooting
15. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds 1. Make sure all motor housing screws are snug. noisy.
