About this manual
This manual is designed to assist you in setting up and using the LCD Monitor.
Information in this document has been carefully checked for accuracy; however,
no guarantee is given to the correctness of the contents. The information in this
document is subject to change without notice.
proprietary information protected by copyright. All rights are reserved. No part
of this manual may be reproduced by any mechanical, electronic or other means,
in any form, without prior written permission of the manufacturer.
Copyright
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
=
Reorient or relocate the receiving antenna.
=
Increase the separation between the equipment and the receiver.
=
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
=
Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the manufacturers may
void the user's authority to operate this equipment.
This document contains
Copyright 1999, All Rights Reserved
i
PREFACE

Advertisement

loading

Summary of Contents for Sceptre ST15

  • Page 1 About this manual This manual is designed to assist you in setting up and using the LCD Monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice.
  • Page 2 NOTE: A shielded-type power cord is required in order to meet the FCC emission limits and also to prevent interference to the radio and television reception. It is essential that only the supplied power cord be used. Use shielded cables only to connect I/O devices to this equipment. Canadian DOC Notice For Class B Computing Devices This Class B digital apparatus meets all requirements of the...
  • Page 3 Servicing of any nature should be performed only by an authorized technician. Safe storage of LCD Monitor is in a range of –20 ~ 60 C(or –4 ~ 140 F). Storing LCD Monitor outside this range could result in permanent damage.
  • Page 4: Table Of Contents

    Contents Of This Manual Chapter 1 : Quick Installation Chapter 2 : Installation 2.1 Unpacking 2.2 Positioning 2.3 Connecting the AC Power Adaptor 2.4 Setting Up the LCD Monitor 2.5 Power Management System Chapter 3 : Display Controls 3.1 User Controls and Indicator...
  • Page 5: Chapter 1 : Quick Installation

    3. Connect signal cable to the computer . 4. Connect the power cord into the jack of LCD Monitor and plug the other end of power cord into a wall socket. 5. Turn the computer on.
  • Page 6: Unpacking

    If you find that any of these items is missing or appears damaged, contact your dealer immediately. Do not throw away the packing material or shipping carton in case you need to ship or store LCD Monitor in the future.
  • Page 7: Positioning

    Even though LCD Monitor has been designed using components that don’t use much power, they still generate quite a bit of heat. Set up your LCD Monitor so that the screen doesn’t face a window where sunlight often comes in. The reflection of sunlight makes LCD Monitor screen difficult to read or view.
  • Page 8 Note, for added protection, we recommend you use a “Surge Protector” device plugged between the AC Adaptor and the electrical wall outlet to prevent the effects of sudden current variations from reaching the LCD Monitor. The sudden peaks of electricity are not good for the Moniotr.
  • Page 9: Power Management System

    1) Step 1: Connect the Power Cord into the AC Adaptor. 2) Step 2: Connect the Power Connector cable between the AC Adaptor and the LCD Monitor connector port located on the rear side of the LCD Monitor. 3) Step 3: Plug the Power Cord from the adaptor into an electrical wall outlet.
  • Page 10: User Controls And Indicator

    CHAPTER 3 Display Controls 3.1 User Controls and Indicator Operation of LCD Monitor is quite simple due to its intuitive, ergonomic design. A description for each of LCD Monitor function controls and indicator is provided below. Figure 3-1 shows the function controls as seen on the front panel of the Monitor.
  • Page 11 DC Power Switch Push the power switch to turn Monitor on. Push it again to turn Monitor off. Brightness Increment Press the control button to increase the brightness to the desired level. Brightness Decrement Press the control button to lower the brightness to the desired...
