Cooper Lighting 1250 Series Specifications

D E S C R I P T I O N
The 1250 Direct/Indirect High Performance Luminous Pendant is
available in three diameters with multiple mounting options.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l / M o u n t i n g
Painted and plated cold rolled
steel or natural aluminum with a
matte white acrylic bowl.
Single Stem (Standard): 5/8"
stem with a standard hang
height of 28" (OA) for the 26"
dia., 32" (OA) for the 36" dia. and
42" ( OA) for the 44" dia.
Minimum overall hang height is
18" (OA). Maximum overall hang
height for one piece stem
assembly is 8'(OA). 9' to 30' (OA)
stems are supplied in multiple
sections and require field
assembly. Supplied with a swivel
canopy which will accommodate
up to 45° adjustment.
F i n i s h
Standard: Matte White (MW).
Premium: Natural Aluminum
(NA) [Sustainable Design], Satin
Chrome (SC), Polished Chrome
(PC), Satin Brass (SB), Polished
Brass - only (PB), Oxidized Brass
(OBRS), Lacquered Satin
Aluminum (SAL), Satin Copper
(SCP), Polished Copper - only
(PCP), Satin Nickel (SN), Polished
Nickel (PN), Oxidized Copper
(OCP), Gun Metal (GNM),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL) or
Custom Color (CC).
Custom Decorative Metals:
(Specify a Color and Pattern)
Colors - Clear (CLR), Cabernet
(CBT), Sapphire (SPE), Sage
(SGE), Brass (BRS), Copper
(CPR), Black Pearl (BPL), Slate
Green (SGN), Champagne (CMP),
Chocolate (CLE), Indigo (IDO),
Royal Blue (RBE), or Pewter
(PWR). Patterns - Coral (COL),
Seashell (SHL) or Smooth (SMT).
Note: Select a standard or
premium finish for the stem(s),
canopy and solid or floating rod
trims. Example: CLR (Clear color)
- COL (Coral pattern) - SC (Satin
chrome) stems, canopy and trim.
Minimum quantity is 5 for one
color/pattern. Contact the factory
for lead-time.
O p t i c s
Dedicated CFL lamp optics with a
"kick reflector" formed out of
94% reflective specular anodized
aluminum. Three or four
individual T6 metal halide or
halogen dedicated optic systems.
The main reflector is formed with
94% reflective specular anodized
aluminum and the upper
reflector is formed out of 94%
reflective semi-specular anodized
aluminum. Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral CFL electronic HPF ,
multi-volt 120/277V (347V
Canada), thermally protected
with end-of-life circuitry to
accommodate the specified lamp
wattage. Metal Halide ballast is
electronic HPF , multi-volt
(120V/277V) for the specified
lamp wattage. 347V MH ballast -
contact factory.
L a m p / S o cke t
26" - Three (3) or six (6) 27W
(2G11) high lumen CFL lamps,
three (3) 32W (GX24q-3) or 42W
(GX24q-4) 4-pin triple CFL lamps,
or three (3) 39W or 70W T6 CDM
metal halide lamps, or three (3)
T4 (DC Bay) clear linear halogen
lamps.
One (1) 22W (2GX13) T5 circular
lamp (bowl illumination).
Downlight: (Optional) One (1)
20W MHMR-16 (Twist lock, GX10)
metal halide, 39W MHMR-16
(Twist lock, GX10) metal halide
(Contact factory for availability)
or 50W HMR-16 (BI-PIN, GX5.3)
halogen lamp (Contact factory
for other halogen MR-16 base
options).
36" - Three (3) or six (6) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps, three (3)
32W (GX24q-3), 42W (GX24q-4)
4-pin triple CFL lamps, 57W
(GX24q-5) or 70W (GX24q-6) 4-
pin triple HO CFL lamps, three (3)
39W, 70W or 150W T6 CDM metal
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
halide lamps, or three (3) 150W
T4 (DC Bay) clear linear halogen
lamps.
One (1) 40W (2GX13) T5 circular
lamp (bowl lumination).
Downlight: (Optional) One (1)
20W MHMR-16 (Twist lock, GX10)
metal halide, 39W MHMR-16
(Twist lock, GX10) metal halide
(Contact factory for availability)
or 50W HMR-16 (BI-PIN, GX5.3)
halogen lamp. (Contact factory
for other halogen MR-16 base
options).
44" - Four (4) or eight (8) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps, four
(4)57W (GX24q-5) or 70W
(GX24q-6) 4-pin triple HO CFL
lamps, four (4) 70W or 150W T6
CDM metal halide lamps or four
(4) 150W T4 (DC Bay) clear linear
halogen lamps.
One (1) 40W (2GX13) T5 circular
lamp (bowl illumination).
Downlight: (Optional) One (1)
20W MHPAR-20 (MED BAS)
metal halide or 39W MHPAR-20
(MED BAS) metal halide. CFL
sockets injection molded plastic.
Metal halide socket ceramic
pulse-rated, 4KV. Lamps
furnished by others.
I n s t a l l a t i o n
Installation requires 1/4-20 UNC-
2A All Thread rod. All Thread
(supplied by others) through a
standard J-box to an integral
support canopy support system.
The 1/4-20 UNC-2A All Thread
rod must be attached to the
building structure to support the
fixture's weight.
O p t i o n s
Dimming Ballast - Except 27W
and DM bowl illumination as a
MOD with T5 55W only, contact
factory for ballast options (DM),
Sloped Ceiling Adaptor - Specify
up to 45° (SCA), Triple Stem (3S),
Single Stem with Aircraft Cable
(1SAC), Aircraft Cable with White
SJ Cord (SJWAC), Aircraft Cable
with Clear SJ Cord (SJCAC),
shaperlighting.com
Type
Date
1250 SERIES
H i g h P e r f o r m a n c e
P e n d a n t L u m i n a i r e
I n d i r e c t / D i r e c t
L u m i n o u s S h a l l o w B o w l
W i t h F o u r Tr i m O p t i o n s
New Custom
Decorative Metals Finish
HIGH PERFORMANCE
OPTICS
Shaper offers a line of products that
offer optically-engineered, high
performance optics for compact
fluorescent, metal halide and halogen
sources.
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Refer to the Icon Legend
Link on shaperlighting.com.
