Sony XM-SD14X Service Manual page 15

Ref. No. Part No. Description
JR34 1-216-864-11 SHORT CHIP
< COIL >
L801 1-410-396-41 FERRITE
L901 1-411-756-11 INDUCTOR
< DIODE >
LED901 6-501-217-01 LED SEL1110W (PROTECTOR)
< TRANSISTOR >
Q101 8-729-202-38 TRANSISTOR 2SC3326N-A
Q102 8-729-232-66 TRANSISTOR 2SA1618Y
Q103 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q104 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q105 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q106 8-729-902-11 TRANSISTOR 2SC2021-Q
Q107 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q108 8-729-020-80 TRANSISTOR 2SC2235-O/Y(TPE6)
Q109 8-729-232-32 TRANSISTOR 2SA965
Q110 8-729-024-79 TRANSISTOR 2SC5100-P
Q111 8-729-024-76 TRANSISTOR 2SA1908-P
Q112 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q201 8-729-202-38 TRANSISTOR 2SC3326N-A
Q202 8-729-232-66 TRANSISTOR 2SA1618Y
Q203 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q204 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q205 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q206 8-729-902-11 TRANSISTOR 2SC2021-Q
Q207 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q208 8-729-020-80 TRANSISTOR 2SC2235-O/Y(TPE6)
Q209 8-729-232-32 TRANSISTOR 2SA965
Q210 8-729-024-79 TRANSISTOR 2SC5100-P
Q211 8-729-024-76 TRANSISTOR 2SA1908-P
Q212 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q301 8-729-202-38 TRANSISTOR 2SC3326N-A
Q302 8-729-232-66 TRANSISTOR 2SA1618Y
Q303 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q304 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q305 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q306 8-729-902-11 TRANSISTOR 2SC2021-Q
Q307 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q308 8-729-020-80 TRANSISTOR 2SC2235-O/Y(TPE6)
Q309 8-729-232-32 TRANSISTOR 2SA965
Q310 8-729-024-79 TRANSISTOR 2SC5100-P
Q311 8-729-024-76 TRANSISTOR 2SA1908-P
Q312 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q401 8-729-202-38 TRANSISTOR 2SC3326N-A
Q402 8-729-232-66 TRANSISTOR 2SA1618Y
Q403 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q404 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q405 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q406 8-729-902-11 TRANSISTOR 2SC2021-Q
Q407 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q408 8-729-020-80 TRANSISTOR 2SC2235-O/Y(TPE6)
Q409 8-729-232-32 TRANSISTOR 2SA965
Q410 8-729-024-79 TRANSISTOR 2SC5100-P
Q411 8-729-024-76 TRANSISTOR 2SA1908-P
Remark Ref. No.
0 Q412
Q801
Q802
Q803
0.45uH Q804
50uH
Q805
Q806
Q807
Q808
Q809
Q810
Q811
Q901
Q902
Q905
Q906
Q907
Q908
Q909
Q910
Q911
Q912
Q913
Q914
Q915
R101
R102
R103
R104
R105
R106
R107
R108
R109
R110
R111
R112
R113
R151
R152
R153
R154
R155
R156
R157
R158
R159
R160
R161
R162
R163
R164
R165
R166
R167
R168
Part No. Description
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-901-04 TRANSISTOR DTA114EK
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-209-15 TRANSISTOR 2SD2012
8-729-209-60 TRANSISTOR 2SB1375
8-729-901-04 TRANSISTOR DTA114EK
8-729-901-04 TRANSISTOR DTA114EK
8-729-901-04 TRANSISTOR DTA114EK
8-729-027-43 TRANSISTOR DTC114EKA-T146
8-729-027-38 TRANSISTOR DTA144EKA-T146
8-729-903-46 TRANSISTOR 2SB1132-P
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-027-43 TRANSISTOR DTC114EKA-T146
8-729-202-38 TRANSISTOR 2SC3326N-A
8-729-202-38 TRANSISTOR 2SC3326N-A
6-550-341-01 FET FKV550N
6-550-341-01 FET FKV550N
6-550-341-01 FET FKV550N
6-550-341-01 FET FKV550N
8-729-120-28 TRANSISTOR 2SC1623-L5L6
8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
< RESISTOR >
1-216-206-00 RES-CHIP 2.2K
1-216-081-00 RES-CHIP 22K
1-216-081-00 RES-CHIP 22K
1-216-849-11 METAL CHIP 220K
1-216-849-11 METAL CHIP 220K
1-216-077-11 RES-CHIP 15K
1-216-077-11 RES-CHIP 15K
1-216-077-11 RES-CHIP 15K
1-216-084-00 RES-CHIP 30K
1-216-073-00 RES-CHIP 10K
1-216-073-00 RES-CHIP 10K
1-216-045-00 RES-CHIP 680
1-216-069-00 RES-CHIP 6.8K
1-216-222-00 RES-CHIP 10K
1-216-065-11 RES-CHIP 4.7K
1-216-057-00 RES-CHIP 2.2K
1-216-222-00 RES-CHIP 10K
1-216-085-11 RES-CHIP 33K
1-216-085-11 RES-CHIP 33K
1-216-053-00 RES-CHIP 1.5K
1-216-053-00 RES-CHIP 1.5K
1-216-025-11 RES-CHIP 100
1-216-025-11 RES-CHIP 100
1-216-097-11 RES-CHIP 100K
1-216-097-11 RES-CHIP 100K
1-216-045-00 RES-CHIP 680
1-216-033-00 RES-CHIP 220
1-216-073-00 RES-CHIP 10K
1-216-182-00 RES-CHIP 220
1-216-134-00 RES-CHIP 2.2
1-216-134-00 RES-CHIP 2.2
XM-SD14X
MAIN
Remark
5% 1/8W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/8W
5% 1/10W
5% 1/10W
5% 1/8W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/10W
5% 1/8W
5% 1/8W
5% 1/8W
15
