Owner's Manual
Model No.
16005606510
EV651 Treadmill
- Assembly
- Operation
- Adjustments
- Parts
- Warranty
CAUTION:
You must read and
understand this
owner's manual
before operating
unit.
Keep this manual for
future reference.
Serial number
Write the serial
number in the space
above for reference.
Serial number can be
found at the front
bottom section of the
Treadmill.
Advertisement
Table of Contents
Related Manuals for Everlast EV651
Summary of Contents for Everlast EV651
- Page 1 Owner’s Manual Model No. 16005606510 EV651 Treadmill - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: You must read and understand this owner’s manual before operating unit. Keep this manual for future reference. Serial number Write the serial number in the space above for reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions Important Electrical Information Assembly Instructions Folding/Transport Instructions Treadmill Operation Programmable Features Parts List Parts Diagram General Maintenance Service Checklist - Diagnosis Guide Troubleshooting Training Guidelines Manufacturer's Limited Warranty Customer Service 1-888-707-1880 Dyaco Canada Inc. 2021 Email: customerservice@dyaco.ca... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY READ ALL INSTRUCTIONS BEFORE USING THIS TREADMILL CAUTION: Before starting any exercise program, it is recommended that you consult your physician. WARNING: Connect this unit to a properly grounded outlet only. DANGER: To reduce the risk of electric shock, always unplug the treadmill from the electrical outlet immediately after using and before cleaning. - Page 4 10. Read, understand, and test the emergency stop procedure before using the treadmill. Do not insert any objects into any openings. 11. Inspect and properly tighten all parts of the treadmill regularly. 12. Keep children and pets away from this equipment at all times while exercising. 13.
-
Page 5: Important Electrical Information
IMPORTANT ELECTRICAL INFORMATION WARNING! ●NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power cord away from any moving part of the treadmill, including the elevation mechanism and transport wheels. ●NEVER remove any cover without first disconnecting AC power. ●If voltage varies by ten percent (10%) or more, the performance of your treadmill may be affected. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS !!ATTENTION: IMPORTANT UNPACKING INSTRUCTIONS. PLEASE READ BEFORE UNPACKING YOUR FOLDING TREADMILL!! Serious injury could occur if this folding treadmill is not unpacked properly. The Velcro strap installed around the treadmill base prevents the treadmill from unfolding accidentally during shipping. - Page 7 BEFORE YOU BEGIN Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product we produce, occasional errors and/or omissions do occur. In any event, should you find this product to have either a defective or a missing part, please contact us for a replacement.
- Page 8 HARDWARE PACKING #80. #100. #99. Ø8 × 1.5T Ø8 × Ø18 ×1.5T 5/16" × UNC18 × 1/2" (4pcs) (8pcs) (8pcs) Split Washer Flat Washer Hex Head Bolt #125. 5/16" × UNC18 × 3/4" Button Head Socket Bolt (8pcs) #104. Lubricant (1pcs) #44.
- Page 9 ASSEMBLY INSTRUCTIONS Step 1. Take out the treadmill from the carton and lay it aside on the smooth ground. Step2. Connect Computer Cable (Middle) (54) with Computer Cable (Lower) (55) then insert Right and Left Uprights (4) and (5) into the Frame Base (2) and use 13m/m Wrench (90) to tighten 8 pcs of 5/16"...
- Page 10 Step 3 1. Connect the Computer Cable (Middle) (54) and Computer Cable (Upper) (53). 2. Connect the Speed Adjustment Switch W/Cable (Upper) (114) and Speed/Hand Pulse Complex (28). 3. Connect the Incline Adjustment Switch W/Cable (Upper) (115) and Incline/Hand Pulse Complex (29). 4.
- Page 11 MAINTENANCE INSTRUCTIONS 1. If the running belt slips while walking on it, users can adjust the tension of the running belt by turning screws on rear rollers of both sides with M6 L Allen Wrench(103), which is included in the hardware kit. During adjustment, while turning rear rollers' screws, be sure to keep running belt tension balanced on both sides;...
-
Page 12: Folding/Transport Instructions
FOLDING INSTRUCTIONS Do not attempt to move the unit unless it is in the folded and locked position. Be sure the power cord is secured to avoid possible damage. Use both handrails to maneuver the unit to the desired position. ■... -
Page 13: Treadmill Operation
TREADMILL OPERATION Your treadmill features a walking belt coated with a lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or walking board. Such substances will deteriorate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD. GROUNDING INSTRUCTIONS. - Page 14 OPERATION OF YOUR TREADMILL GETTING STARTED: Before operating the console, read the following precautions: CAUTION: Do not stand on the walking belt when turning on the treadmill. Always wear the safety key. Pulling the safety key will stop tread-belt movement. Adjust the speed in small increments to avoid sudden jumps in speed To reduce the possibility of electric shock, keep the console dry.
- Page 15 TO OPERATE TREADMILL CAUTION: To avoid injury, hold onto the handrails while mounting and dismounting the treadmill. Hold onto the handrails and place feet on side rails before starting. Step onto the walking belt only at the slowest speed. Always hold on to a handrail or hand bar while making control changes (incline, speed, etc.).
- Page 16 BUTTON FUNCTION: A > SPEED ▲ (FAST)： Pressing this button increases the speed by 0.1(mph/km). Press and hold this button for 3 seconds to increase speed rapidly. Press this button during setting the program to adjust the value (to increase). B >...
-
Page 17: Programmable Features
PROGRAMMABLE FEATURES Once you install the safety key after turning on the power, the treadmill enters the ready mode. Press the START button to start the treadmill or press the PROGRAM button to select the training mode, normal or manual mode, preset programs (P1~P24) or heart rate control mode. - Page 18 METRIC TABLE Customer Service 1-888-707-1880 Dyaco Canada Inc. 2021 Email: customerservice@dyaco.ca...
- Page 19 ENGLISH TABLE Customer Service 1-888-707-1880 Dyaco Canada Inc. 2021 Email: customerservice@dyaco.ca...
- Page 20 HEART RATE PROGRAMS The old motto, "no pain, no gain," is a myth that has been overpowered by the benefits of exercising comfortably. A great deal of this success has been promoted by the use of heart rate monitors. With the proper use of a heart rate monitor, many people find that their usual choice of exercise intensity was either too high or too low, and exercise is much more enjoyable by maintaining their heart rate in the desired benefit range.
- Page 21 RATE OF PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate all contribute to the intensity at which you should workout.
-
Page 22: Parts List
PARTS LIST KEY NO. PART NO. DESCRIPTION Q'TY 6065101 Main Frame 6065102 Frame Base 6065103 Incline Bracket 6065104 Right Upright 6065105 Left Upright 6065106 Console Support 6065107 Outer Slide 6065108 Inner Slide-□21.4×21.4×1.5T×395L 6065109 Handrail Support 6065110 Incline Motor-JS15-A,30128L,AT90-110V 6065111 Drive Belt-8J240 6065112 Motor Bracket-170×100×30×3T,R50,15H 6065113... - Page 23 KEY NO. PART NO. DESCRIPTION Q'TY 6065162 3/8" × UNC16 × 3/4"_Hex Head Bolt 6065163 M8 × P1.25 × 60L_Hex Head Bolt 6065164 M8 × P1.25 × 12L_Hex Head Bolt 6065165 5/16" × UNC18 × 3"_Button Head Socket Bolt 6065166 3/8"...
-
Page 24: Parts Diagram
PARTS DIAGRAM Customer Service 1-888-707-1880 Dyaco Canada Inc. 2021 Email: customerservice@dyaco.ca... -
Page 25: General Maintenance
GENERAL MAINTENANCE BELT ADJUSTMENTS: Tread-belt Tension Adjustment - Belt tension is not critical for most users. It is very important for joggers and runners in order to provide a smooth, steady running surface. Adjustments must be made from the right side of the rear roller in order to adjust tension with the 6 mm Allen wrench provided in the parts package. - Page 26 BELT / DECK LUBRICATION: Do not lubricate with anything other than DYACO CANADA INC approved Lubricant. Your treadmill comes with one tube of Lubricant, and extra tubes can be ordered directly from DYACO CANADA INC. There are commercially available lube kits, but the only one currently approved by DYACO CANADA INC is Lube-N-Walk.
- Page 27 GENERAL MAINTENANCE WARNING: Always unplug your treadmill prior to cleaning in order to avoid electrical hazard or shock. BELT AND DECK Your treadmill uses a very high-efficient low-friction deck. Performance is maximized when the deck is kept as clean as possible. Use a soft, damp cloth or paper towel to wipe the edge of the belt and the area between the belt edge and frame.
- Page 28 RESET SWITCH RESETTING If your treadmill loses power or will not start, check the reset switch located on the front of the motor cover. If the white tab of the reset switch is not showing, then the reset switch has not been tripped. If the white tab of the reset switch is showing, the reset switch has tripped.
-
Page 29: Service Checklist-Diagnosis Guide
SERVICE CHECKLIST-DIAGNOSIS GUIDE Before contacting your dealer for aid, please review the following information. It may save you both time and expense. This list includes common problems that may not be covered under the treadmill's warranty. PROBLEM SOLUTION/CAUSE 1. Tether cord not in position. Display does not light. -
Page 30: Troubleshooting
TROUBLESHOOTING I. ENGINEERING MODE Remove the safety key and reinsert it after pressing the ENTER button to enter the engineer mode. Press the ENTER button once to select roller diameter (60), km or miles, speed (0.5mph to 10mph) and incline (12). Press FAST button and SLOW button to change the value. -
Page 31: Training Guidelines
TRAINING GUIDELINES EXERCISE Exercise is one of the most important factors in the overall health of an individual. Listed among its benefits are: Increased capacity for physical work (strength endurance) Increased cardiovascular (heart and arteries/veins) and respiratory efficiency ... - Page 32 Overload is where you exercise at a level above that which can be carried out comfortably. The intensity, duration and frequency of exercise should be above the training threshold and should be gradually increased as the body adapts to the increasing demands. As your fitness level improves, so the training threshold should be raised.
- Page 33 PULSE COUNT The pulse count (on your wrist or carotid artery in the neck, taken with two index fingers) is done for ten seconds, taken a few seconds after you stop exercising. This is for two reasons: (a) 10 seconds is long enough for accuracy, (b) the pulse count is to approximate your BPM rate at the time you are exercising.
- Page 34 WHAT TO WEAR Wear clothing that will not restrict your movement in any way while exercising. Clothes should be light enough to allow the body to cool. Excessive clothing that causes you to perspire more than you normally would while exercising gives you no advantage. The extra weight you lose is body fluid and will be replaced with the next glass of water you drink.
- Page 35 STRETCHING Stretching should be included in both your warm-up and cool-down and should be performed after 3-5 minutes of low-intensity aerobic activity or callisthenic type exercise. Movements should be performed slowly and smoothly, with no bouncing or jerking. Move into the stretch until slight tension, but no pain is felt in the muscle and hold for 20-30 seconds.
- Page 36 INNER THIGH STRETCH TOUCHES Sit with the soles of your feet together with your Slowly bend forward from your waist, letting knees pointing outward. Pull your feet as close your back and shoulders relax as you stretch Into your groin as possible. Gently push your toward your toes.
-
Page 37: Manufacturer's Limited Warranty
REPAIR PARTS AND SERVICE All of the parts for the Everlast treadmill, shown in the parts list, can be ordered from Dyaco Canada Inc. 5955 Don Murie Street, Niagara Falls, ON, L2G 0A9. When ordering parts, the parts will be sent and billed at the current prices. - Page 38 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. spiritfitness.ca solefitness.ca xterrafitness.ca dyaco.ca/products/everlast.html dyaco.ca/UFC/UFC-home.html spiritfitness.ca/johnnyg.html trainorsports.ca For more information, please contact Dyaco Canada Inc. T: 1-888-707-1880 ⏐ 5955 Don Murie St., Niagara Falls, Ontario L2G 0A9 ⏐ sales@dyaco.ca Customer Service 1-888-707-1880 Dyaco Canada Inc.
