WASHING MACHINE
SERVICE MANUAL
CAUTION
READ THIS MANUAL CAREFULLY TO DIAGNOSE TROUBLE
CORRECTLY BEFORE OFFERING SERVICE.
MODEL : WD(M)-106(8)0F(H)D/WD(M)-106(8)5F(H)D
WD(M)-126(8)0F(H)D/WD(M)-126(8)5F(H)D
WD(M)-146(8)0F(H)D/WD(M)-146(8)5F(H)D
WD-1061FD/WD-1261FD/WD-1266FD
WD-1461FD/WD-1466FD
WD-1288FHD/WD-1488FHD
WD-1480(5)FDN/WD-1480(5)FDF
website : http://www.LGEservice.com
e-mail : http://LGEservice.com/techsup.html
100

Advertisement

Table of Contents
loading

Related Manuals for LG WDM-10680FHD

Summary of Contents for LG WDM-10680FHD

  • Page 1 website : http://www.LGEservice.com e-mail : http://LGEservice.com/techsup.html WASHING MACHINE SERVICE MANUAL CAUTION READ THIS MANUAL CAREFULLY TO DIAGNOSE TROUBLE CORRECTLY BEFORE OFFERING SERVICE. MODEL : WD(M)-106(8)0F(H)D/WD(M)-106(8)5F(H)D WD(M)-126(8)0F(H)D/WD(M)-126(8)5F(H)D WD(M)-146(8)0F(H)D/WD(M)-146(8)5F(H)D WD-1061FD/WD-1261FD/WD-1266FD WD-1461FD/WD-1466FD WD-1288FHD/WD-1488FHD WD-1480(5)FDN/WD-1480(5)FDF...

  • Page 2: Table Of Contents

    CONTENTS 1. SPECIFICATION..........................3 2. FEATURES & TECHNICAL EXPLANATION .................4 3. PARTS IDENTIFICATION ......................6 4. INSTALLATION ..........................7 5. OPERATION ..........................10 6. WIRING DIAGRAM / PROGRAM CHART ...................16 7. TROUBLESHOOTING.........................18 7-1.BEFORE PERFORMING SERVICE ..................18 7-2.QC TEST MODE........................18 7-3.HOW TO KNOW THE WATER LEVEL FREQUENCY............18 7-4.ERROR DISPLAY ........................19 8.

  • Page 3: Specification

    1. SPECIFICATION WD(M)-1080F(H)D/1085F(H)D/280F(H)D/1285F(H)D WD(M)-1060F(H)D/WD(M)-1065F(H)D/WD(M)-1260F(H)D/ WD(M)-480F(H)D/1485F(H)D/WD-1061FD/1261FD/1266FD ITEM WD(M)-1265F(H)D/WD(M)-1460F(H)D/WD(M)-1465F(H)D WD-1461FD/1466FD/1288FHD/1488FHD/1480(5)FDN/1480(5)FDF POWER SUPPLY 220-240V~, 50Hz PRODUCT WEIGHT 65kg WASHING 230W ELECTRICITY SPIN (1400rpm) 440W CONSUMPTION DRAIN MOTOR WASH HEATER 2000W WASH 45rpm 1400 rpm : No spin/400/800/1000/1400 rpm REVOLUTION SPEED SPIN 1200 rpm : No spin/400/800/1000/1200 rpm 1000 rpm : No spin/400/600/800/1000 rpm OPERATION WATER PRESSURE 0.3-10kgf/...

  • Page 4: Features & Technical Explanation

    2. FEATURES & TECHNICAL EXPLANATION 2-1.FEATURES Jumbo drum " ’s jumbo drum can wash about 40% more load than conventional washing machine. A bigger drum improves the wash performance. More economical by Intelligent Wash System Intelligent Wash System detects the amount of load and water temperature, and then determines the optimum water level and washing time to minimize energy and water consumption.
  • Page 5 2-2.DETERMINE WASHING TIME BY FUZZY LOGIC To get the best washing performance optimal time is determined by sensing of water temperature, selected washing temperature and laundry amount. water temperature washing time the best selected FUZZY washing washing rinsing time temperature LOGIC performance spin rhythm, time...

  • Page 6: Parts Identification

    3. PARTS IDENTIFICATION Power plug If the supply cord is damaged, it must be replaced by the manufacturer or it's service agents Drawer or a similarly qualified person in (For detergent and order to avoid a hazard. fabric softener) Control panel Drain hose Door Lower cover...

  • Page 7: Installation

    4. INSTALLATION Before servicing ask the customer what the trouble is. Check the adjustment (power supply is 220-240V~, remove the transit bolts..) Check the troubles referring to the troubleshooting. Decide service steps referring to disassembly instructions. Then, service and repair. After servicing, operate the appliance to see whether it works O K or NOT.
  • Page 8 HOW TO CONNECT INLET HOSE Check that the rubber washer is inside of the valve connector. Connect the inlet hose firmly to prevent leak. CONNECT DRAIN HOSE Make sure that the hose is not twisted. Avoid submerging the end of the hose. The drain hose should be placed under 100cm from the floor.
  • Page 9 TEST OPERATION Preparation for Press the power button. Press the Start/Pause washing. button. Start/Pause Connect the power plug to the outlet. In case of coloureds program. Connect the inlet hose. Check the water heating. Check automatic reverse Check the water supply. turn.

  • Page 10: Operation

    5. OPERATION [WD(M)-1060F(H)D / 1065F(H)D / 1260F(H)D / 1265F(H)D / 1460F(H)D / 1465F(H)D] Wash program selector LED display 7 program can be set depending on the type of the laundry. Display the estimated remaining time (Hour : Minute) to finish. If the power button is pressed, Coloureds program is In case of abnormal operation, error automatically set.
  • Page 11 Rinse hold Time Delay Press the button when delayed washing is needed. If you desire to leave fabrics in the When the button is pressed, is displayed, machine without spinning after rinse to maximum delay of hours can be set. prevent wrinkling, you may select Each press advances time delay by the hour.
  • Page 12 [WD(M)-1080F(H)D/1085F(H)D/1280F(H)D/1285F(H)D/1480F(H)D/1485F(H)D/1288FHD/1488FHD WD(M)-1480(5)FDN/1480(5)FDF] Time Save LED display • It is possible in Cotton-Eco, Cotton, Synthetic, Display the estimated remaining time Delicate, Wool and Hand Wash programs. (Hour : Minute) to finish. • By selecting the Time Save option, the wash In case of abnormal operation, error indications are time may be reduced, depending on the displayed.
  • Page 13 Rinse Hold Time Delay Press the button when delayed washing is needed. If you desire to leave fabrics in the machine without spinning after rinse to When the button is pressed, is displayed, prevent wrinkling, you may select maximum delay of hours can be set.
  • Page 14 [WD-1061FD/WD-1261FD/WD-1266FD/WD-1461FD/WD-1466FD] Time Save LED display • It is possible in Cotton-Eco, Cotton, Synthetic, Display the estimated remaining time Delicate, Wool and Hand Wash programs. (Hour : Minute) to finish. • By selecting the Time Save option, the wash In case of abnormal operation, error indications are time may be reduced, depending on the displayed.
  • Page 15 Rinse Hold Time Delay Press the button when delayed washing is needed. If you desire to leave fabrics in the machine without spinning after rinse to When the button is pressed, is displayed, prevent wrinkling, you may select maximum delay of hours can be set.

  • Page 16: Wiring Diagram / Program Chart

    6. WIRING DIAGRAM PROGRAM CHART [WD(M)-1060F(H)D / 1065F(H)D / 1260F(H)D / 1265F(H)D / 1460F(H)D / 1465F(H)D] * Water Supply : WáS * Intermittent Spin : IáS * Disentangle : DáT PROGRAM CHART Wash Rinse Spin Main Normal (Hold) Extra (Hold) Washing Staycooling Normal...
  • Page 17 [WD(M)-1080F(H)D/1085F(H)D/1280F(H)D/1285F(H)D/1480F(H)D/1485F(H)D WD-1061FD/1261FD/1266FD/1461FD/1466FD/1288FHD/1488FHD/1480(5)FDN/1480(5)FDF] ¡ ( ) : WD(M)-1080F(H)D / 1085F(H)D / 1280F(H)D / 1285F(H)D / WD-1061FD / WD-1261FD / 1266FD / 1288FHD * Water Supply : WáS * Intermittent Spin : IáS * Disentangle : DáT PROGRAM CHART Rinse Wash Spin Main Normal (Hold) Extra (Hold)

  • Page 18: Troubleshooting

    7. TROUBLESHOOTING 7-1.BEFORE PERFORMING SERVICE Be careful of electric shock or disconnecting the parts while troubleshooting. Voltage of each terminal in 220-240V~ and DC while applying an electric current. 7-2.QC TEST MODE. Pressing Rinse, and Spin button simultaneously. Power supply on with pressing upper two button.Then buzzer sound twice. Press the Start/Pause button as follows.

  • Page 19: 7-4.Error Display

    7-4.ERROR DISPLAY. If you press the Start/Pause button when an error in displayed, any error except will disappear and the machine will change into pause status. In case of if the error is not resolved within 20 sec. In the case of other errors, if the error is not resolved within 4 min., power will be turned off automatically and the error only will be blinked.
  • Page 20 ERROR SYMPTOM CAUSE • MAIN PWB ASSEMBLY is out of order Replace the MAIN PWB ASSEMBLY CURRENT • Winding in the STATOR ASSEMBLY is short-circuited. ERROR Replace the STATOR ASSEMBLY • The connector (3-pin, male, white) in the LEAD WIRE ASSEMBLY is not connected to the connector (3-pin, female, white) of LOCK STATOR ASSEMBLY.

  • Page 21: Error Diagnosis And Check List

    8. ERROR DIAGNOSIS AND CHECK LIST 8-1.DIAGNOSIS AND ANSWER FOR ABNORMAL OPERATION SYMPTOM GUIDE FOR SERVICE CALL NO POWER Is the power plug connected firmly to 220-240V~ outlet? Power failure? or Breaker opened? Is the outlet controlled by a switch Visit to check WATER INLET TROUBLE displayed?
  • Page 22 SYMPTOM GUIDE FOR SERVICE CALL DOOR OPEN ERROR Did you press the Start/Pause button when Close the door the door is open? Visit to check Check if the door switch is O.K displayed? DRAIN TROUBLE Is the debris filter clogged with foreign Clean up the filter.
  • Page 23 SYMPTOM GUIDE FOR SERVICE CALL Suds overflow from the Is low-sudsing detergent for the drum appliance. washing machine used? (In this condition, wash and spin do not operate LOW-SUDSING normally) Is the proper amount of detergent used DETERGENT as recommended? Recommend to reduce the amount of detergent.

  • Page 24: Fault Diagnosis And Troubleshooting

    8-2.FAULT DIAGNOSIS AND TROUBLESHOOTING CAUTION 1. Be careful of electric shock or disconnecting the parts while troubleshooting. 2. First of all, check the connection of each part terminal with wiring diagram. 3. If you replace the MAIN PWB ASSEMBLY, put in the connectors correctly. NO POWER When measuring the voltage of the outlet, Check the fuse?
  • Page 25 NO WATER SUPPLY Is water supply shut-off? Is the tap opened? Open the tap. Check the AIR CHAMBER When you press both Rinse button and Spin button and the tube clogged simultaneously, is the water level frequency below 240? with impurity. Is the inlet valve filter clogged with impurity? Clean the filter.
  • Page 26 SOFTENER DOES NOT FLOW IN Option (Hot) Refer to Is water supplied? NO WATER SUPPLY Check the wiring on the Are receptacles correctly connected to the terminals dispenser. of the INLET VALVE ASSEMBLY? Wiring diagram Is softener put in the correct compartment of the Put it in the correct compartment.
  • Page 27 HEATING WITHOUT WATER When pressing Rinse and Spin at the same time after draining, is the water level frequency 252 or more? Replace the When pressing Rinse, Spin buttons at the same time S.PRESSURE SWITCH while wash, is the water level frequency between ASSEMBLY Rinse Spin...
  • Page 28 WASH HEATER TROUBLE MAIN PWB ASSEMBLY When checking the voltage between Replace the MAIN PWB connectors ( ) during ASSEMBLY whites washing, Is the voltage 220 - 240V 220 - 240V~ YELLOW After power off,is the resistance of wire (RED-YELLOW) connectors between Normal Replace the After power off and the heater terminal is...
  • Page 29 SPIN TROUBLE Check the S.PRESSURE SWITCH ASSEMBLY or HOSE (Pressure). Check on the spinning, is the frequency of the If the problem is on the water level 248 or more. The frequency can be S.PRESSURE SWITCH checked by pressing the Rinse and Spin buttons at Rinse Spin ASSEMBLY or the HOSE,...

  • Page 30: Disassembly Instructions

    9. DISASSEMBLY INSTRUCTIONS Be sure to unplug the machine out of the outlet before disassembling and repairing the parts. CONTROL PANEL ASSEMBLY Unscrew 2 screws on the back of the top plate. TOP PLATE ASSEMBLY Pull the top plate backward and upward as shown. Disconnect the ASSEMBLY connector.
  • Page 31 DISPENSER ASSEMBLY Disassemble the TOP PLATE ASSEMBLY. Pull out the drawer slightly upward. Unscrew 2 screws. PUSH DRAWER Disassemble hose clamps and hoses. Option Disassemble the ventilation bellows and the water inlet bellows from the tub. DISPENSER ASSEMBLY...
  • Page 32 INLET VALVE ASSEMBLY Disconnect the wiring connector. 3 Option Unscrew 2 screws from the back. When reconnecting the connector Cold only model VALVE#1 (MAIN) Whited/Black-Black VALVE#2 (PRE) Gray/ White - Black Cold and Hot model VALVE #1 (MAIN) Whited/Black-Black VALVE #2 (PRE) Gray/ White - Black VALVE #3 (HOT) Blue/Red - Black...
  • Page 33 DOOR ASSEMBLY Open the door completely. Remove the two screws from the hinge. When removing the DOOR ASSEMBLY, it is necessary to hold the BRACKET that is inner of the CABINET COVER. GASKET Take apart the CLAMP ASSEMBLY (cabinet). Unscrew 2 screws from the CABINET COVER. Open the lower cover cap and unscrew 1 screw inside Take apart the LOWER COVER.
  • Page 34 ROTOR ASSEMBLY, STATOR ASSEMBLY, FRICTION DAMPER ASSEMBLY Remove the BACK COVER. Unscrew the bolt to pull out the ROTOR ASSEMBLY. Rotor Bolt (ROTOR ASSEMBLY) Disconnect the wiring connector. Unscrew 6 bolts from the STATOR. Remove the BODY FRAME. (Only 1400 rpm models) Note : Hook of connector (1) is on the backside (STATOR ASSEMBLY) Pull out the HINGE, pressing its snap.
  • Page 35 DRAIN PUMP ASSEMBLY Remove PUMP HOSE. PUMP HOSE Remove BELLOWS.. Remove CAP (Remaining Hose.) Disconnect the wiring. Screw Unscrew 3 screws Remove the DRAIN PUMP ASSEMBLY. (Remaining Hose) BELLOWS HEATER ASSEMBLY Loosen the M6 heater nuts to pull out the HEATER ASSEMBLY.
  • Page 36 SWITCH ASSEMBLY, DOOR LOCK Take apart the CLAMP ASSEMBLY (cabinet) and release the GASKET. Unscrew 2 screws holding the DOOR SWITCH ASSEMBLY. Disconnect the door lock from the wiring connector. WHEN FOREIGN MATERIAL IS STUCK BETWEEN DRUM AND TUB Remove the HEATER ASSEMBLY. Remove the foreign material (wire, coin and others) by inserting a long bar through the hole.

  • Page 37: Exploded View And Parts List

    10. EXPLODED VIEW AND PART LIST 10-1.THE PART LIST OF CABINET ASSEMBLY : Service Part A110 : Non-Service Part A150 A120 A102 A101 A104 A141 A103 A131 A100 A130 A430 A440 A151 A450 A133 A410 A200 A303 A310 A300 A201 A220 A277 HOT (ORANGE)

  • Page 38: The Exploded View Of Control Panel And Dispenser Assembly

    10-2 THE EXPLODED VIEW OF CONTROL PANEL & DISPENSER ASSEMBLY F430...

  • Page 39: The Exploded View Of Drum And Tub Assembly

    10-3 THE EXPLODED VIEW OF DRUM & TUB ASSEMBLY : Service Part K124 K350 K126 K360 : Non-Service Part K143 F140 K211 K121 K122 K411 K125 K420 K320 K110 K100 K141 K310 K140 K143 K105 K410 K610 K510 K611 K341 K130 K530 K131...

  • Page 40: Appendix (Replacement Parts List)

    Printed date : OCT. 2001 P/No.:3828ER3008D...
