- Page 1 P/No.: 3828ER3014P...
-
Page 2: Washing Machine
WD(M)-10160(5)F WD(M)-80160F WD(M)-65160F Thank you for buying a LG Fully Automatic Washing machine. Please read your owner’s manual carefully, it provides instructions on safe installation, use and maintenance. Retain it for future reference. Record the model and serial numbers of your washing machine. -
Page 3: Table Of Contents
Feature Jumbo drum LG’s jumbo drum can wash about 40% more load than conventional washing machines. A bigger drum improves the wash performance. More economical by Intelligent Wash System Intelligent Wash System detects the amount of load and water temperature, and then determines the optimum water level and washing time to minimize energy and water consumption. -
Page 4: Warnings
arnings READ ALL INSTRUCTIONS BEFORE USE For your safety, the information in this manual must be followed to minimize WARNING! the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following:... -
Page 5: Specification
pecification Power plug If the supply cord is damaged, it must be replaced by the manufacturer or its service agents Drawer or a similarly qualified person in (For detergent and order to avoid a hazard. fabric softener) Control panel Drum Door Lower cover Adjustable feet... -
Page 6: Installation
nstallation Install or store where it will not be exposed to temperatures below freezing or exposed to the weather. Properly ground washer to conform with all governing codes and ordinances. The base opening must not be obstructed by carpeting when the washing machine is installed on a carpeted floor. -
Page 7: Installation Place Requirement
nstallation Installation place requirement Level floor : Drain Hose Allowable slope under entire washer is 1˚ Washer Power outlet : Must be within 1.5 meters of either side of location of washer. Do not overload the outlet with more than one appliance. Laundry Additional Clearance : approx. -
Page 8: Electrical Connection
nstallation Electrical connection 1. Do not use an extension cord or double adapter. 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or similarly qualified person in order to avoid a hazard. 3. -
Page 9: Normal Tap Without Thread & Screw Type Inlet Hose
nstallation Normal Tap without thread & screw type inlet hose Unscrew the fixing screw to Push the connector up till the Push the water supply hose attach the tap. rubber packing is in tight contact vertically upwards so that the with the tap. - Page 10 nstallation This equipment is not designed for maritime use or for use mobile installations such as caravans, aircraft etc. Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday), especially if there is no floor drain(gully) in the immediate vicinity. When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside.
-
Page 11: Level Adjustment
nstallation Level adjustment 1. Adjusting the washing machine level properly prevents excessive noise and vibration. Install the appliance on a solid and level floor surface, preferably in a corner of the room. 2. If the floor is uneven, adjust the adjustable feet as required. -
Page 12: Care Before Washing
are before washing Caring before washing 1. Care Labels Look for a care label on your clothes. This will tell you about the fabric content of your garment and how it should be washed. 2. Sorting To get the best results, Sort clothes into loads that can be washed with the same wash cycle. Water temperature and spin speed and different fabrics need to be washed in different ways. -
Page 13: Adding Detergent
dding detergent Adding detergent and fabric softener 1. The Dispenser Drawer 3. Detergent dosage • The detergent should be used according to the instruction of the detergent manufacture. • If too much detergent is used more than the recommended amount, too many suds can occur and this will decrease the washing result or cause heavy load to the motor. -
Page 14: Function
unction Recommended courses according to the laundry type Fabric Proper Maximum Energy Time Program Option Type Temp. Load Minutes First check if laundry Pre Wash is machine 95˚C Time Save Rating 2.74 washable. Rinse+ (white cotton, linen Crease Care Cotton towel and sheets...) Color fast gaments Pre Wash... -
Page 15: How To Use Washer
ow to use washer Drain Drain 1. Cotton automatically 2. Manual Selecting selected upon power on. • Press the Power( ) button to start. • Press the Power( ) button to start. • Press the Start/Pause( ) button. • Select the conditions which you want to use, by pressing each button. -
Page 16: Pre Wash
ow to use washer Drain Drain (1) Button : Power (4) Button : Time Delay (7) Child Lock (2) Button : Program (5) Button : Option (8) Button : Temp. (3) Button : Start/Pause (6) Button : Option (9) Button : Spin Option 2. -
Page 17: Rinse Hold
ow to use washer Spin 2. No spin • If no spin is selected, the washer stops after draining water. The required lamp will light up for identification. 3. Rinse Hold [WD(M)-10160(5)F] [WD(M)-65160F] [WD(M)-80160F] • By pressing the Spin button, the spin speed •... -
Page 18: Child Lock
ow to use washer Water Temp. 1. Child Lock • Child Lock can be set by pressing and • By pressing the Temp. holding the the Option and the Temp. button, the water button simultaneously. temperature can be selected. - Cold - 30˚C / 40˚C / 60˚C / 95˚C •... -
Page 19: Time Delay
ow to use washer Program Time Delay Drain Drain 1. Time Delay Preparing washing before starting “Time Delay” - Turn on the water tap. (Program) - Load laundry and close the door. - Place the detergent and fabric softener in the drawer. - Page 20 Drain Drain ow to use washer Start/Pause Power 1. Power 1. Start • Press the Power button to turn power on • This Start/Pause( ) button is used to start and off wash cycle or pause the wash cycle. 2. Pause 2.
- Page 21 ow to use washer Display 4. Time left • During washing cycle, the remaining washing time is displayed. • Recommended program by manufacturer. 1. Special function display - Cotton 95˚C : around 2 hours and 43 minutes • When child lock is selected, the - Cotton 60˚C : around 2 hours and “...
-
Page 22: Maintenance
aintenance Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock to avoid electrical shock hazards. When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside. The water inlet filter - “... -
Page 23: Dispenser Drawer
aintenance Dispenser drawer After a while detergents and fabric softeners leave a deposit in the drawer. • It should be cleaned from time to time with a jet of running water. • If necessary it can be removed completely from the machine by pressing the catch downwards and by pulling it out. -
Page 24: Cleaning Your Washer
aintenance Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills. Wipe with damp cloth. Try not to hit surface with sharp objects. -
Page 25: Troubleshooting Guide
roubleshooting guide This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and react appropriately When the machine does not function properly or does not function at all, check the following points before you contact your service provider. - Page 26 roubleshooting guide Symptom Possible Cause Solution Washer does not start • Electrical power cord may not Make sure plug fits tightly in wall be plugged in or connection outlet. may be loose. • House fuse blown, circuit Reset circuit breaker or replace fuse. breaker tripped,or a power Do not increase fuse capacity.
- Page 27 roubleshooting guide Symptom Possible Cause Solution Check another tap in the house. • Water supply is not adequate in area Fully open tap. • Water supply taps are not completely open. Straighten hose(s). • Water inlet hose(s) are kinked. Check the filter of the inlet hose. •...
-
Page 28: Terms Of Warranty
erms of Warranty What Is Not Covered: • Service trips to your home to teach you how to use the product. • If the product is connected to any voltage other than that shown on the rating plate. • If the fault is caused by accident, neglect, misuse or Act of God. •...
