Unpacking

Thank you for buying the MSI
to make sure your motherboard box contains the following items. If something is
missing, contact your dealer as soon as possible.
Motherboard
Quick Guide
I/O Shield
Case Badge
V-Check Cable x6
X99A XPOWER GAMING TITANIUM
®
Drivers & Utilities
Disc
SATA Cable Labels
RGB LED Extension Cable 40cm x1
RGB LED Extension Cable 80cm x1
Door Hanger
motherboard. Check
Motherboard User
Guide
SATA Cable x10
Antenna x2
SLI Bridge 102mm Cable (short) x2
SLI Bridge 140mm Cable (long) x2
