Cooper Lighting Shaper 609 Specification Sheet

D E S C R I P T I O N
609 Luminous Vanity Wall Sconce with a MR-16 Downlight. Indirect
and direct illumination. Downlight can be switched separately.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Solid aluminum with a matte
white formed acrylic panel.
Semi-open top. One (1) Halo 3"
adjustable reflector with a cast
aluminum white trim ring and
specular clear reflector. Trim
includes a soft focus cover glass
lense. 35° vertical adjustment
and 360° rotation.
F i n i s h
Standard: Natural Aluminum
(NA). Premium: Matte White
(MW), Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Oxidized Brass (OBRS),
Lacquered Satin Aluminum
(SAL), Satin Copper (SCP),
Polished Copper (PCP), Satin
Nickel (SN), Polished Nickel (PN),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL) or
Custom Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
O R D E R I N G I N F O R M AT I O N
Sample Number: 609-CFL/2/18-120V-OBRS-FP
Series Lamp
609 Luminous = CFL/2/18/26/32W
Vanity Sconce
Notes:
1
Interior applications only
2
Available with CFL only
3 Supplied by others.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
L a m p / S o cke t
Contact factory for INC uplight.
Two (2) 18W (G24q-2), 26W or
32W (G24q-3) 4-pin triple CFL
lamps and one (1) 50W MR-16
12V incandescent lamp.
Fluorescent socket injection
molded plastic. Lamps furnished
by others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring with
additional mounting holes. Refer
to the specification sheet for
additional drawings.
O p t i o n s
Hand Painted Faux Alabaster
Acrylic Panel (FP), Hand Painted
Faux Linen Panel (LNP),
Dimming Ballast - Contact
factory for ballast options (DM),
Voltage Finish
Standard
120V
MW Matte White =
277V
347V Premium
CC Custom Color =
GNM=Gun Metal
OBRS Oxidized Brass =
NA=Natural Aluminum
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered Satin =
Aluminum
SCL Lacquered Satin Chrome =
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Damp Location (DL): All painted
finishes, Lacquered Satin
Chrome (SCL) and Lacquered
Satin Nickel (SNL) finishes only.
Energy Star Rating - Contact
factory.
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
1
DL Damp Location =
2
DM CFL Dimming Ballast =
REM Remote Emergency =
3
Battery
FP Hand Painted Faux =
Alabaster Panel
LNP= Hand Painted
Faux Linen Panel
shaperlighting.com
Type
Date
609 SERIES
I n t e r i o r W a l l L u m i n a i r e
L u m i n o u s Va n i t y
S c o n c e w i t h D o w n l i g h t
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Refer to the Icon Legend
Link on shaperlighting.com.
