Cooper Lighting Shaper 603 Specification Sheet

D E S C R I P T I O N
603 Luminous Wall Sconce features a clean geometric shape with
soft direct/forward and indirect illumination.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Painted or plated cold-rolled
steel, brass or copper base metal
with a 1/8" matte white acrylic
diffuser
F i n i s h
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Satin Nickel (SN),
Polished Nickel (PN), Lacquered
Satin Chrome (SCL), Lacquered
Satin Nickel (SNL) or Custom
Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral AC electronic HPF multi-
volt 120/277V (347V Canada)
thermally protected end-of-life
circuitry for 13W CFL lamps.
O R D E R I N G I N F O R M AT I O N
Sample Number: 603-CFL/4/13-277V-PCP
Series Lamp
603 Luminous = CFL/4/13
Vanity Wall
INC/2/75
Notes:
1
Available with CFL only.
2
Supplied by others. .
L a m p / S o cke t
Four (4) 13W (2GX7) 4-pin low
wattage CFL lamps or two (2)
75W A-19 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
mounting back for a standard 4"
J-box or plaster ring. One
mounting hole provided at the
ends to provide secure
attachment to the wall. Vertical or
horizontal mount.
O p t i o n s
Remote Emergency Battery -
Supplied by others (REM). Damp
Locations (DL): All Painted
finishes, Laquered Satin Chrome
(SCL), Laquered Satin Nickel
(SNL), finishes only. MRI
Applications (INC only) - Contact
Factory. Energy Star Rating -
Consult factory.
Voltage Finish
120V Standard
1
MW Matte White =
277V
1
347V
Premium
CC Custom Color =
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered Satin Chrome =
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
DL Damp Location =
REM Remote =
Emergency
2
Battery
shaperlighting.com
Type
Date
603 SERIES
I n t e r i o r W a l l L u m i n a i r e
L u m i n o u s Va n i t y W a l l
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Refer to the Icon Legend
Link on shaperlighting.com.
