Rotel RX-1052 Command List

Table: RX 1052 Waveform format expected:
•
For units BEFORE serial # 090-6441001 (Black) or 990-6441001 (Silver):
Baud Rate Parity
19200
•
For units AFTER serial # 090-6441001 (Black) or 990-6441001 (Silver):
Baud Rate Parity
38400
Table: RX 1052 expected format of a request by RS 232 controller:
Start Count Device ID
0xFE 0x03 0x61
Table 1: Type 10 Primary Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RX 1052 HEX
FE 03 61 10 00 74
FE 03 61 10 01 75
FE 03 61 10 02 76
FE 03 61 10 03 77
FE 03 61 10 04 78
FE 03 61 10 05 79
FE 03 61 10 06 7A
FE 03 61 10 07 7B
FE 03 61 10 08 7C
FE 03 61 10 0A 7E
FE 03 61 10 0B 7F
FE 03 61 10 0C 80
FE 03 61 10 0D 81
FE 03 61 10 0E 82
FE 03 61 10 0F 83
FE 03 61 10 10 84
FE 03 61 10 17 8B
FE 03 61 10 18 8C
FE 03 61 10 19 8D
FE 03 61 10 1A 8E
FE 03 61 10 1B 8F
FE 03 61 10 1E 92
FE 03 61 10 20 94
FE 03 61 10 21 95
FE 03 61 10 23 97
RX 1052
RS232 Controller Command List
Valid Data Bits
N 8
Valid Data Bits
N 8
Type Key
0x10 0xXX
Command
RMC Vol+
RMC Vol-
CD
Tuner
Tape
Video 1
Video 2
Video 3
Video 4
Power
Vol+
Vol-
Treble+
Treble-
Bass+
Bass-
Rec
Menu
Enter
Right (+)
Left (-)
Mute
Tune / Preset
Preset Scan
Zone 2 / Main
Stop Bit Value Handshaking
1
Stop Bit Value Handshaking
1
Checksum
0xXX
Command Description
Remote Volume Up
Remote Volume Down
Source CD
Source Tuner
Source Tape
Source Video 1
Source Video 2
Source Video 3
Source Video 4
Power Toggle
Volume Up
Volume Down
Treble Up
Treble Down
Bass Up
Bass Down
Record
Display Label
Enter
Right
Left
Mute
Tune / Preset Toggle
Preset Scan
Zone
Data Type
None String
Data Type
None String
