Daikin VRV IV+ RYYQ12U7Y1B Series Installer And User Manual page 41

[2‑8]
T target temperature during cooling operation.
e
[2‑8]
0 (default)
2
3
4
5
6
7
For more information and advice about the impact of these settings,
see "7.3 Energy saving and optimum operation" on
[2‑9]
T target temperature during heating operation.
c
[2‑9]
0 (default)
1
3
6
For more information and advice about the impact of these settings,
see "7.3 Energy saving and optimum operation" on
[2‑12]
Enable the low noise function and/or power consumption limitation
via external control adaptor (DTA104A61/62).
If the system needs to be running under low noise operation or
under power consumption limitation conditions when an external
signal is sent to the unit, this setting should be changed. This setting
will only be effective when the optional external control adaptor
(DTA104A61/62) is installed.
[2‑12]
0 (default) Deactivated.
1 Activated.
[2‑14]
Input additional refrigerant amount that was charged.
In case you want to use the automatic leak detection functionality, it
is required to input the total additional refrigerant charge amount.
[2‑14] Additional amount charged (kg)
0 (default)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
RYYQ+RYMQ+RXYQ8~20U7Y1B
VRV IV+ heat pump
4P546228-1 – 2018.09
T target (°C)
e
Auto
6
7
8
9
10
11
page 43.
T target (°C)
c
Auto
41
43
46
page 43.
Description
No input
0<x<5
5<x<10
10<x<15
15<x<20
20<x<25
25<x<30
30<x<35
35<x<40
40<x<45
45<x<50
50<x<55
55<x<60
60<x<65
65<x<70
70<x<75
75<x<80
[2‑14] Additional amount charged (kg)
17
18
19 Setting cannot be used. Total refrigerant
charge has to be <100 kg.
20
21
▪ For details concerning the charging procedure, see
charging refrigerant" on page 27.
▪ For details concerning the calculation of additional refrigerant
charge amount, see "6.7.3 To determine the additional refrigerant
amount" on page 27.
▪ For guidance concerning the input of the additional refrigerant
charge amount and leak detection function see
detection function" on page 46.
[2‑18]
Fan high static pressure setting.
In order to increase the static pressure the outdoor unit fan is
delivering, this setting should be activated. For details about this
setting, see technical specifications.
[2‑18]
0 (default) Deactivated.
1 Activated.
[2‑20]
Manual additional refrigerant charge.
In order to add the additional refrigerant charge amount in a manual
way (without automatic refrigerant charging functionality), following
setting should be applied. Further instructions regarding the different
ways to charge additional refrigerant into your system can be found
in chapter "6.7.2 About charging refrigerant" on
[2‑20]
0 (default) Deactivated.
1 Activated.
To stop the manual additional refrigerant
charge operation (when the required additional
refrigerant amount is charged), push BS3. If
this function was not aborted by pushing BS3,
the unit will stop its operation after 30 minutes.
If 30 minutes was not sufficient to add the
needed refrigerant amount, the function can be
reactivated by changing the field setting again.
[2‑21]
Refrigerant recovery/vacuuming mode.
In order to achieve a free pathway to reclaim refrigerant out of the
system or to remove residual substances or to vacuum the system it
is necessary to apply a setting which will open required valves in the
refrigerant circuit so the reclaim of refrigerant or vacuuming process
can be done properly.
[2‑21]
0 (default) Deactivated.
1 Activated.
To stop the refrigerant recovery/vacuuming
mode, push BS3. If BS3 is not pushed, the
system will remain in refrigerant recovery/
vacuuming mode.
[2‑22]
Automatic low noise setting and level during night time.
7 Configuration
80<x<85
85<x<90
"6.7.2 About
"7.4 Using the leak
Description
page 27.
Description
Description
Installer and user reference guide
