CONTROL SPRAY
OWNER'S MANUAL • MANUEL DE L'UTILISATEUR •
MANUAL DE USARIO
READ THIS MANUAL FOR COMPLETE INSTRUCTIONS •
LIRE CE MANUEL POUR OBTENIR DES DIRECTIVES COMPLÈTES •
LEA ESTE MANUAL PARA OBTENER LAS INSTRUCCIONES COMPLETAS
www.wagnerspraytech.com
QX5
™
ES
EN
F
EN
P. 2
F
P. 14
ES
P. 26
0421 • Form No. 2426875A

Advertisement

Table of Contents
loading

Related Manuals for WAGNER CONTROL SPRAY QX5

Summary of Contents for WAGNER CONTROL SPRAY QX5

  • Page 1 CONTROL SPRAY ™ OWNER‘S MANUAL • MANUEL DE L‘UTILISATEUR • MANUAL DE USARIO READ THIS MANUAL FOR COMPLETE INSTRUCTIONS • P. 2 LIRE CE MANUEL POUR OBTENIR DES DIRECTIVES COMPLÈTES • P. 14 LEA ESTE MANUAL PARA OBTENER LAS INSTRUCCIONES COMPLETAS P.

  • Page 2: Table Of Contents

    IMPORTANT SAFETY INFORMATION TABLE OF CONTENTS GROUNDING INSTRUCTIONS IMPORTANT SAFETY INFORMATION ..........2-3 This product must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by CONTROLS AND FUNCTIONS ............4-5 providing an escape wire for the electric current. This product SETUP ......................

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION SAFETY HAZARDS HAZARD: EXPLOSION OR FIRE HAZARD: ELECTRIC SHOCK Flammable vapors, such as solvent and paint This product can cause injury due to electric shock. vapors, in work area can ignite or explode. PREVENTION: • Power cord must be connected to a grounded circuit. •...

  • Page 4: Controls And Functions

    CONTROLS AND FUNCTIONS Cover release Turbine Filter housing ON/OFF switch Spray width ON/OFF lever switch Filter Air cap Lock N Go tab Material flow control Trigger Material container (1.5 quart) iSpray® Nozzle Seal Pickup tube...
  • Page 5 CONTROLS AND FUNCTIONS ON / OFF SWITCH The ON/ OFF switch turns the turbine ON (I) and OFF (0). No spray material will be delivered until trigger is pulled. MATERIAL FLOW CONTROL The material flow control knob determines the amount of material that is sprayed from the nozzle assembly.

  • Page 6: Setup

    SETUP For a video showing how to set up the Control Spray QX5, visit: www.wagnerspraytech.com/controlsprayQX5 MATERIAL PREPARATION Material to be sprayed may need to be strained to remove any impurities in the paint which may enter and clog the system. Impurities in the paint will give poor performance and a poor finish.
  • Page 7 SETUP For a video showing how to set up the Control Spray QX5, visit: www.wagnerspraytech.com/controlsprayQX5 ASSEMBLY NEVER point the spray gun at any part of the body. Make sure the power cord is unplugged. Stir the spraying material thoroughly. Fill the container. Use a strainer to remove any particles.

  • Page 8: Sprayer Controls

    SPRAYER CONTROLS For a video showing Control Spray QX5 spraying tips and best practices, visit: www.wagnerspraytech.com/controlsprayQX5 MATERIAL FLOW CONTROL The material flow control will be factory-set at its lowest setting out of the box. Adjust as needed. • Turn the knob out (counterclockwise) for less flow. Generally, low material flow is needed for spraying smaller surface areas, such as corners, lattice, or spindles.

  • Page 9: Spraying

    SPRAYING Frequently wipe the nozzle tip with a damp rag when spraying to remove dried material. HOW TO SPRAY PROPERLY Even coat throughout • Turn the ON/OFF switch to ON (I) to turn on the turbine. No Correct 6 to 8 inches material will spray until the trigger is activated.

  • Page 10: Cleanup

    CLEANUP For a video showing cleanup of the Control Spray QX5, visit: www.wagnerspraytech.com/controlsprayQX5 CLEANUP NOTES When cleaning, use the appropriate cleaning solution (warm, soapy water for water-based coatings, and mineral spirits for oil-based coatings. Special cleanup instructions for use with flammable solvents (must have a flashpoint above 100ºF (38ºC):...

  • Page 11: Maintenance

    MAINTENANCE CLEANING THE FILTER Before every use, you should inspect the air filter PRESS in the turbine to see if it is excessively dirty. If it is dirty, follow these steps to replace it. Attention Never operate your unit without the air filters. Dirt could be sucked in and interfere with the function of the unit.

  • Page 12: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION Problem A: Little or no material flow 1. Nozzle clogged. 1. Clean. 2. Suction tube clogged. 2. Clean. 3. Material flow setting too low. 3. Increase material flow setting. 4. Suction tube loose. 4. Remove and replace as tightly as possible. 5.

  • Page 13: Warranty

    This warranty does not cover any defects or damages caused by service or repair performed by anyone other than a Wagner Authorized Service Center. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED TO ONE YEAR FOLLOWING DATE OF PURCHASE.

  • Page 14: Parts List

    PARTS LIST • LISTE DE PIÈCES • LISTA DE PIEZAS Replacement parts available by calling customer service On peut obtenir des pièces de rechange en appelant le Service à la clientèle. Los repuestos están disponibles llamanado al servicio a clientes. 1-800-328-8251 Part No.
  • Page 15 PARTS LIST • LISTE DE PIÈCES • LISTA DE PIEZAS Part No. English Français Español Qty. Nº de piéce Description Description Descripción Qte. Pieza No. Cant. 0520006 Spray gun assembly (includes Ensemble de pistolet (inclut Ensamblaje de pistola (incluye items 1-7) des pièces 1 à...
  • Page 16 CONTROL SPRAY ™ www.wagnerspraytech.com...
