Sony PSP-3003 Quick Reference

Hide thumbs Also See for PSP-3003:
Table of Contents

Advertisement

Quick Links

Quick Reference
PSP-3002
PSP-3003
4-115-362-21(1)

Advertisement

Table of Contents
loading

Related Manuals for Sony PSP-3003

Summary of Contents for Sony PSP-3003

  • Page 1 Quick Reference PSP-3002 PSP-3003 4-115-362-21(1)
  • Page 2 Introduction Using "XMB" (XrossMediaBar) GAME The PSP system includes a user interface called "XMB" ® (XrossMediaBar). The main screen for "XMB" is called the "home menu". Playing games VIDEO Playing video MUSIC Category Playing music PHOTO Displaying images NETWORK Home menu Connecting to the Internet SETTINGS Select a category using the left or right...
  • Page 3 This document describes basic operations of the PSP system. For detailed instructions, refer to the online user's guide ® page 5) : http://manuals.playstation.net/document/ Directional buttons: button: Used to select Cancels selected categories/items operations PS button: Returns to the Home Menu button: SELECT START...

  • Page 4: Checking The Package Contents

    ® every PSP format software manual. ® AC Adaptor AC Adaptor (PSP-3002 only) (PSP-3003 only) (PlayStation Portable) system ® ® AC Power Cord Printed Materials (PSP-3002 only) * The PSP-00 model comes with a combined AC Adaptor and AC Power Cord.
  • Page 5 Preparation Checking the package contents About the PSP system documentation ® The PSP system documentation includes the ® following: • Safety and Support Before using the product, carefully read this document first. It contains safety information related to the use of the PSP ®...

  • Page 6: Insert The Battery Pack

    Preparation Preparing the PSP system for use ® Charging the battery Insert the Battery Pack. Align the bottom surface of the battery pack with the Before using the PSP system for the first time after ® system to attach the battery. purchase, you must follow these steps to charge the battery.
  • Page 7 Preparation Preparing the PSP system for use ® Initial setup Attach the AC Adaptor* to charge the battery. Slide the POWER/HOLD switch up. POWER indicator SELECT START POWER/HOLD switch The POWER indicator lights up in green, and the initial setup screen is displayed. Follow the on-screen instructions to make the initial settings.

  • Page 8: Part Names And Functions

    Preparation Part names and functions System * The PS button on this PSP system performs the same ® WLAN switch (top) functions as the HOME button on PSP-1000 and PSP-000 series systems. LCD screen R button L button Right speaker Left speaker button, button...
  • Page 9 Preparation Part names and functions Using the sound button Connecting Headset You can connect the remote control (sold separately) Each time you press the button, the tone to the headset connector. You can also connect the Press and release changes among HEAVY POPS headset (sold separately) to the remote control.

  • Page 10: Basic Operations

    Basic operations Power and sleep mode functions Use the POWER/HOLD switch to turn the system on POWER/HOLD switch or off, or to put it into sleep or hold mode. Turning the system on / Slide up Putting into sleep mode Slide up and hold for more B Turning the system off than three seconds...
  • Page 11 Basic operations Power and sleep mode functions Sleep mode If the PSP system is switched to sleep mode, the ® software that is playing will be paused. When sleep mode is cleared, you can begin playback from the point where the system entered sleep mode. •...
  • Page 12 Basic operations Playing UMD content Place your finger in the indentation on Select the icon, and then press the the top of the system to open the disc button. cover. Insert a UMD and close the disc cover. Check that the disc cover is tightly closed. The icon is displayed in the Home Menu.

  • Page 13: Playing Memory Stick Duo™ Content

    Basic operations Playing Memory Stick Duo™ content Select the icon, and then press the Warning button. Keep Memory Stick Duo™ media out of the reach of small children, as the media could be swallowed by accident. Open the slot cover. Press the Memory Stick Duo™...

  • Page 14: Checking The Battery Charge Level

    Basic operations Checking the battery charge level Battery charge level Methods of charging the battery You can use either of the following methods to charge the battery. • Using the AC adaptor When you connect the AC adaptor to the PSP system ®...
  • Page 15 Basic operations Copying music/videos/images Copy music/video/image files to Memory Stick Duo™ media and play or view files on the PSP system. ® Copy methods vary depending on the device and software in use as well as file type. The following instructions are based on the most common copying methods.
  • Page 16 Basic operations Copying music/videos/images Copying music files Copying video files Example: Importing music tracks from an audio CD Example: Downloading legally available video files from the Internet 1. Import 1. Download Use compatible software to import music tracks from an audio CD to a PC.
  • Page 17 Basic operations Copying music/videos/images Copying image files Conversion software Example: Importing images from a digital still camera Media Manager* for PSP (PlayStation Portable) can ® ® be used to convert music, video and image files to 1. Import the required format. When copying files to Memory Import images to a PC.
  • Page 18 Basic operations Outputting video to a TV You can output PSP system video to a TV using a video output cable (sold separately). ® Selecting a video output cable Select a video output cable suited for the TV in use. Notice The PSP system outputs in the NTSC video format.
  • Page 19 Basic operations Outputting video to a TV Outputting to a TV Turn on the PSP system ( page 10), ® and then press and hold the display Connect the PSP system to the TV using ® button on the system front for at least 5 a video out cable (sold separately).

  • Page 20: Adjusting Network Settings

    Network Adjusting network settings Required items Warning Turn off the WLAN switch when in crowded places, such as The following items are generally required to set up in a crowded train. If a person nearby is using a the system to connect to a network. pacemaker, it is possible that the radio waves could affect the pacemaker.
  • Page 21 Network Adjusting network settings Creating a new network connection Select "Scan", and then press the right button. You can adjust network settings to connect to an access point and save the network connection data on the system. Network settings may vary depending on the equipment in use and the network environment.
  • Page 22 Network Adjusting network settings Select the access point that you want to Select the security settings as use, and then press the button. necessary, and then press the right button. An SSID is a code or a name that is assigned to the access point.
  • Page 23 Network Adjusting network settings Select "Easy" or "Custom" and adjust Check the setting list. settings as necessary. The setting values you entered are displayed. Follow the on-screen instructions to complete your network settings. • If the connection test fails, follow the on-screen instructions to check the settings.

  • Page 24: Connecting To The Internet

    Network Connecting to the Internet Using the Internet browser Using the on-screen keyboard ( page 26), enter the address for the Web page. Check that you have access to a wireless After you have entered the address, the PSP system will network.
  • Page 25 Network Connecting to the Internet Basic operations of the Internet browser Viewing the online user's guide You can use the Internet browser to view the online button + Scroll in any direction user's guide for the PSP (PlayStation Portable) analog stick ®...

  • Page 26: Using The Onscreen Keyboard

    Keyboard Using the on-screen keyboard Control panel item list Cursor Text entry field Keyboard keys Function (displays characters Function keys Enters a space as they are entered) When entering text in the Internet browser address field, previously entered addresses are displayed. Addresses are displayed only when input mode is set to Web address shortcuts.
  • Page 27 Keyboard Using the on-screen keyboard Switching input mode Entering characters The number of input modes available varies This section will demonstrate how to enter text using depending on the language selected. Each time you the word "FUN" as an example. press the SELECT button, the input mode changes Select "DEF3", and then press the among the options in the diagram below:...
  • Page 28 system updates ® Updating the system software Software updates may include security patches, new or revised settings and features, and other items, • For the latest information on updates, visit www.playstation.com which will change your current operating system. It is •...
  • Page 29 system updates ® Updating the system software Without an Internet connection Update methods You can perform an update in any of the following Update using a UMD ways. You can update using a UMD that contains update data. With an Internet connection Connect the AC Adaptor to the PSP ®...

  • Page 30: Setting The Parental Control Level

    Security settings Setting the parental control level The PSP system includes a parental control feature. For further information about Parental Control Levels ® You can use this feature to set a password and limit and corresponding age groups, visit the playback of content restricted by a parental control http://manuals.playstation.net/document/ or refer to level (games, videos and other content).
  • Page 31 Entertainment Inc. "XMB" and "xross media bar" are trademarks of Sony Corporation and Sony Computer Entertainment Inc. "SONY" and " " are registered trademarks of Sony Corporation. Also "Memory Stick" , "Memory Stick Duo" , " " , "MagicGate" and "ATRAC"...
  • Page 32 Information about system functionality and images published in this document may vary from those for your PSP system, depending on the ® system software version in use. © 2008 Sony Computer Entertainment Inc. All rights reserved. Printed in China...
