LED Status
Blinking
Off
(Activity)
Orange
(DSL)
Green
On
Off
Blinking
On (Green)
Blinking (Green)
(Wireless LAN
On/Off/WPS)
Blinking (Orange)
Off
On (Green)
Blinking (Green)
(Wireless LAN
On/Off/WPS)
Blinking (Orange)
On
Blinking
~
Off
(LAN1/2/3/4)
On
(USB)
Blinking
5 V a c
5 V a c
Explanation
The router is powered on and running normally.
The router is powered off.
On The DSL link up, waiting for the Internet connection.
Slowly - The DSL connection is ready for training.
Blinking
Quickly - The DSL connection is synchronizing.
The router is ready to access to the Internet through
On
DSL link.
Blinking The data is transmitting.
The phone connected to this port is off-hook.
The phone connected to this port is on-hook.
A phone call comes.
The wireless access point is ready.
The data is transmitting via wireless connection based
on the rate of 2.4GHz.
Blinks with one second cycle for two minutes. The WPS
function is active.
The wireless access point is turned off.
The wireless access point is ready.
The data is transmitting via wireless connection based
on the rate of 5GHz.
Blinks with one second cycle for two minutes. The WPS
function is active.
The LAN port is connected.
The data is transmitting.
The LAN port is disconnected.
A USB device is connected and active.
The data is transmitting.
