1. Product Summary

1.1. Features

SI Unit
The SI (Serial Interface) Unit represents a PROFINET IO-device for SMC pneumatic valves. It is
designed for digital data control by connecting compatible the EX245 digital Input/Output modules
and IO-Link modules and for use within rugged industrial environments, especially automotive plants.
The SI Unit has the following properties:
・
IP65 protection
・
Two connectors for supply voltages and two connectors for PROFINET IO connection,
EX245-SPN1A: 2 x Push Pull connectors (24 Volt) and 2 x Push Pull connectors (SCRJ)
EX245-SPN2A: 2 x Push Pull connectors (24 Volt) and 2 x Push Pull connectors (RJ45)
EX245-SPN3A: 2 x 7/8 inch 5 pins connectors and 2 x M12 4 pins socket D-coded connectors
・
Up to 32 solenoid valves
・
Up to 128 digital inputs
・
Up to 64 digital outputs independent of solenoid valves
・
Up to 32 IO-Link devices can be connected
・
Up to 8 modules (limited by the total current consumption)
・
FSU (Fast Start Up) supported
・
Conformance Class C (Only for IRT switch function) supported
・
MRP (Media Redundancy Protocol) and MRPD (Media Redundancy for Planned Duplication)
function supported
・
System redundancy S2 supported
・
Shared device function supported
・
PROFIenergy function supported
・ Net Load Class Ⅲ of Security Level 1 supported
・
Built-in Web server function
・
A firmware update function
・
Maintenance alarm supported for the Fibre-optic cables for the EX245-SPN1A
・
Integrated diagnostic and protection function
・
Maximum loop through current between power connectors
is 16A (EX245-SPN1A/EX245-SPN2A), or is 6A (EX245-SPN3A)
・
Galvanically isolated power supplies
・
Free module configuration
Corresponding solenoid valve manifolds
・
JSY series JSY3000, JSY5000
・
SY series SY3000, SY5000
・
VQC series VQC2000, VQC4000
Compatible EX245 modules
・
Digital Input Module
・
Digital Output Module
・
IO-Link Module
: EX245-DX1 (16 digital inputs)
: EX245-DY1 (8 digital outputs)
: EX245-LA1 (4 IO-Link ports, Class A)
EX245-LB1 (4 IO-Link ports, Class B)
