CLIMATE 5000 VRF
Bosch VRF Intelligent Manager (Network Controller)
BVIM
Installation-user manual
Before using your air conditioning system, please read this manual carefully and keep it for future reference.

Advertisement

loading

Related Manuals for Bosch CLIMATE 5000 VRF BVIM

Summary of Contents for Bosch CLIMATE 5000 VRF BVIM

  • Page 1 CLIMATE 5000 VRF Bosch VRF Intelligent Manager (Network Controller) BVIM Installation-user manual Before using your air conditioning system, please read this manual carefully and keep it for future reference.

  • Page 2: Table Of Contents

    2 | Contents Contents SAFETY INFORMATION ................................3 ACCESSORIES .................................... 3 BVIM GATEWAY CONTROLLER INSTRUCTIONS ..........................4 SYSTEM INTRODUCTION ................................8 SETTINGS ....................................12 OPERATION INSTRUCTIONS ............................... 14 TROUBLESHOOTING ................................. 20 6 720 862 466 (2017/05) CLIMATE 5000 VRF...

  • Page 3: Safety Information

    SAFETY INFORMATION | 3 SAFETY INFORMATION The following contents are stated on the product and the operation manual, including usage, precautions against injury and property damage, and the methods of using the product correctly and safely.After fully understanding the following contents (identifiers and icons), read the text body and observe the following rules. ■...

  • Page 4: Bvim Gateway Controller Instructions

    4 | BVIM GATEWAY CONTROLLER INSTRUCTIONS ■ Do not install where naked flames are present; ■ Ensure you don’t over tighten or press terminals when tightening. This may break the BVIM or cause over heating of the module. Before carefully read this manual, do not connect the control system power, and do not do any installation work, until the preparation work has been done. BVIM GATEWAY CONTROLLER INSTRUCTIONS CAUTION ■...
  • Page 5 BVIM GATEWAY CONTROLLER INSTRUCTIONS | 5 3) Detailed drawing of installation holes (Unit: mm) Installation precautions: ■ Must be installed indoors, guarantee the gateway controller installation must be higher than the ground 50 cm; ■ Install at a place where should not be affected by electromagnetic wave or dust; ■...
  • Page 6 6 | BVIM GATEWAY CONTROLLER INSTRUCTIONS NOTE ■ Install the gateway at a side of B-net communicating bus, do not install it in the middle of the bus. ■ Use 3-core shielding wire with 0.7mm ~1.0mm for wiring, details please refers to professionals. 2) Terminal figure LAN terminal I/O terminal...
  • Page 7 BVIM GATEWAY CONTROLLER INSTRUCTIONS | 7 5) Definitions for code switch as follow Table.3-3 Gateway controller Off (Factory state) SW1-1 No power consumption function power consumption function SW1-2 Dial code setting IP WEB setting IP SW1-3 Manual topology Auto topology SW1-4 Reserve Note: Dial Code requires setting before powering on.

  • Page 8: System Introduction

    8 | SYSTEM INTRODUCTION SYSTEM INTRODUCTION BVIM is a Central Air-conditioning multi-connected devices’ gateway which based on WEB, is an important part of Intelligent Manager system. Connect to Central Air-conditioning devices through the B-net terminal. Allows you to connect multiple systems through the B net connector (B-net connector is XYE communication terminals and K1K2E communication terminals);...
  • Page 9 SYSTEM INTRODUCTION | 9 Fig.4-2 After configuration, click the “OK” button. 2) Configure several IP Before configuring several IP’s it needs to configure a statistic IP address, configuring steps as follow: ■ Check the local IP Open the property dialogue box, as Fig.4-2 display, if the option “Use the following IP addresses(S)” has been selected, and the interface displayed IP address, that means the local IP is static IP address.Otherwise it is a dynamic IP address, then it needs to configure a static IP address.
  • Page 10 10 | SYSTEM INTRODUCTION Fig.4-4 Click the “ADD” button under IP address column, and add a IP address with the same network segment of “192.168.100.40”, such as IP: 192.168.100.101, sub network cover code: 255.255.255.0, and click “OK” button. 4.4.2. Local LAN access If there is a computer or other similar device of same subnet area as BVIM in LAN, then type the link address of BVIM gateway (e.g.: http://192.168.100.40) on the browser address bar can visit the BVIM WEB interface to operate the air-conditioning device.
  • Page 11 SYSTEM INTRODUCTION | 11 ■ Computer establishing way Establish VPN tunnel by computer is a little difficult for general users. Use VPN client-side software and VPN Server to establish VPN tunnel in the user’s computer, then user can visit WEB interface through VPN tunnel. VPN client-side software and VPN Server can be achieved by commercial ways. Its topology structure as follow display: Fig.4-7 4.6.

  • Page 12: Settings

    12 | SETTINGS SETTINGS Do the following settings before using the BVIM gateway. Only the administrator can make the following operation. 5.1. BVIM setting BVIM gateway setting as the following display,the setting of baud rate and the energy-requiring compatibility please refer to BVIM Technical Manual. Fig.5-1 5.2.
  • Page 13 SETTINGS | 13 5.3. IP setting If adding the BVIM into local network, then it needs to reset the BVIM IP address, and click “OK ” button after setting. If there are multiple BVIMs in the same network area, then the IP address should be different on each BVIM. Fig.5-3 5.4.

  • Page 14: Operation Instructions

    14 | OPERATION INSTRUCTIONS OPERATION INSTRUCTIONS 6.1. User login Type the link address of BVIM gateway on the browser address (take windows 7 system, IE for example), then can visit the BVIM WEB login interface. Fig.6-1 Enter the login page, user operates as follow to enter into system: 1) Select user name, type in password;...
  • Page 15 OPERATION INSTRUCTIONS | 15 6.3. Devices monitoring Displays the operating status of indoor and outdoor units, and control the indoor unit. Find out the error in system through checking the operating status of indoor and outdoor units. Provides a detailed display and the page will refresh every 10 seconds. 6.3.1.
  • Page 16 16 | OPERATION INSTRUCTIONS Select the 5-8 terminals, the page will display the corresponding outdoor unit, and then click the picture of an outdoor unit, and it will display its operating status include ON/OFF state, operating mode, fan state, indoor unit quantity, error protection, ammeter readings etc. 4) Control the operating status of outdoor unit Priority selecting content of mode include: 5 modes of heating priority,cooling priority, multi-opening priority, heating only and cooling only,this setting is only valid for water source multi-connected model.
  • Page 17 OPERATION INSTRUCTIONS | 17 2) Control the operating status of indoor unit Fig.6-8 Click the “ ” button in the page, then you can control the indoor unit operating status page. Select one or more air-conditioners, set the controlling parameters, include “ON/OFF setting”, “Mode setting”, “Swing setting”, “Temp setting”...
  • Page 18 18 | OPERATION INSTRUCTIONS 6.4. System mapping Display the entire refrigerant system, to reflect the mapping relationship between the indoor and outdoor units. Fig.6-9 Select a single refrigerant system, the page display all the indoor unit pictures of this refrigerant system, and the bottom of the page displays the indoor unit quantity, outdoor unit quantity and ammeter quantity.
  • Page 19 OPERATION INSTRUCTIONS | 19 6.5.2. Refrigerant system mapping Output the topology document, the auto topology structure as follow display: Fig.6-11 6.5.3. Gateway controller status Display the status information of gateway controller. Fig.6-12 6.6. Device information Check the indoor/outdoor device information in the refrigerant system. 6.6.1.

  • Page 20: Troubleshooting

    20 | TROUBLESHOOTING 6.6.2. Outdoor unit information Select the refrigerant system, click the “Outdoor Info”, and the display will show all outdoor unit information. Fig.6-14 The display contents include: serial port, address, physics location and sales model. 6.7. Help This function offers error code table for analysing to help user to check the error of air-conditioner. This error code may differ from the display contents in the display board, please consult the local technical support specialist.
  • Page 21 TROUBLESHOOTING | 21 2) Wrong password When the password was wrong, it would display as follow: Fig.7-2 Type the correct password again. 7.3. No device displayed If login successfully, and no data display in the home page, then contact the dealer or technicians to check whether the wiring of B-net communication terminal was correct, and whether the air-conditioner system has been installed correctly to the BVIM gateway.
