- Page 1 Amaryllis Installation Manual Model: 51191 Noble Bronze 51192 Matte Silver Fan weight ±2 lbs: 24.9 lbs (11.3 kg) ©2020 Hunter Fan Co. PG3974 r122120...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 Here is what comes in your box: 1886 Hunter Pro Tip: We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Do not discard the hardware bags or mix parts from different bags.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Note: Fan style may vary. -
Page 7: Wiring The Fan
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualifi ed electrician. Hunter Pro Tip: Here is how to connect the wires: Push the bare metal ends of the wires together and slide a wire nut over them. -
Page 8: Installing The Canopy
Canopy Screw Lift the canopy into place so that the screw holes are aligned. Hunter Pro Tip: Let the tool do the work! A magnetic screwdriver will give you more visibility when securing the canopy. -
Page 9: Assembling The Light Kit
1886 Assembling the Light Kit 2 of 3 Light Kit Screw Align the keyhole slots in the top of the light kit Feed the 9-pin plug connector coming assembly with the partially installed assembly from the bottom of the motor housing screws. - Page 10 1886 Light Kit WARNING Lift the globe assembly and attach it to the upper switch housing using the four thumbscrews. Tighten all four GLASS FALL HAZARD screws securely by hand. To prevent SERIOUS INJURY or DEATH, make sure that glass is properly secured. 4 of 4 Thumb Screws...
-
Page 11: Preparing The Remote
1886 Preparing the Remote The remote control is Remote Function Guide already paired for use. For To access the battery Key Press Function your convenience, a remote compartment, remove the + Quick Press Light On/Off function card is packed in small Phillips head screw that secures the battery door to with your remote. -
Page 12: Troubleshooting
• Make sure the blades are properly installed. • Check to see if any of the blades are cracked. If so, replace all of the blades. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. -
Page 13: Limited Lifetime Warranty
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
