- Page 1 Gilmour Installation Manual Model: 51844 Flat Matte Black 51845 Matte Silver 51846 Matte Fresh White Fan weight ±2 lbs: 17.7 lbs (8.1 kg) ©2022 Hunter Fan Co. PG4064 r041822...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Note: Fan style may vary. -
Page 7: Wiring The Fan
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a quali ed electrician. Hunter Pro Tip: Here is how to connect the wires: Push the bare metal ends of the wires together and slide a wire nut over them. -
Page 8: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades Blade Screw Put the blade washers found in the hardware bag onto the blade screws found in the hardware bag. -
Page 9: Assembling The Light Kit
1886 Assembling the Light Kit 2 of 6 1 of 6 Light Kit Screw Light Kit Screw Partially install two light kit assembly screws, found in the hardware bag, halfway into Feed the wire plug through the center hole the motor housing as shown. of the upper switch housing, then wrap It does not matter which two Insert the third screw, found in the... -
Page 10: Preparing The Remote
1886 Preparing the Remote For your convenience, a remote function card The remote transmitter is already is packed in with your remote. paired to the receiver and ready to use. Dimming mode is on by default. Note: If you need to pair your remote, To access the battery compartment, turn fan power off and back on at the remove the the battery door to the... -
Page 11: Troubleshooting
“How do I properly install multiple remote-controlled fans?” for information on how to correct this issue. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. Cleaning products may damage the finishes. -
Page 12: Limited Lifetime Warranty
Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. cosmetic blemishes; refurbished fans; and fans that are damaged due to any of the...
