Package Contents

Thank you for purchasing the FortiGate 60C-LENC. The FortiGate 60C-LENC
multi-threat security appliance offers you unmatched performance, flexibility, and
security for your remote, branch, or small office network.
Your box contains the following:
FortiGate 60C-LENC
QuickStart Guide
USB Cable
Ethernet cable
Power Cable
Power Adapter
Wall mount template
Power Cable
Ethernet Cable
Power Adapter
USB Cable
Wall-mount
Template
Wall-Mount Template
FortiGate 60 Series Devices
The unit should be placed farther than 75mm on each side from a heat source. If you
Drill hole are mounting more than one unit, place them in a vertical row to provide better ventila- Drill hole
tion.
Required Materials:
Drill bit: Size is determined by the screw size.
Anchors: Two for mounting on dry-wall, plasterboard, or gyprock.
Screws: Two appropriate for anchors. Maximum diamter of 3.5mm.
Instructions:
1. Tape this template to the wall in the desired location.
2. Mark the position of the drill holes on the wall.
3. Drill two holes.
4. Insert anchors into drilled holes.
5. Insert the screws into the anchors. Screws should protrude 5mm out of wall.
6. Place FortiGate key holes over the screws and slide the unit down into position. The
FortiGate can be placed in either position shown below.
