Appendix-Wall Mounting Unit Specification

WALL MOUNTING UNIT SPECIFICATION

Unit Dimension(unit: mm)
400 x 200
Remark: The specification of screw is just used on the back cabinet.
NOTE: Wall mount bracket is not included with TV and mounting of wall mount bracket to wall may
vary depending on brand and size of bracket. Customer should consult bracket mounting
instructions that came with wall mount for specific information on how to mount bracket to wall.
Before reading the installing instruction, please notice:
A. The wall mount is not contained in the accessories sold with television. We only provide the installing
specifications but not the wall mount itself. If you need the mount, please consult with the local dealer
for the assorted fitting parts.
B. We strongly suggest to set the wall mount with equipments of specification we ordered. If not,
unappropriate installing may cause damage to both the device and yourself.
Screw Diameter
M4
Screw Length(unit: mm)
12
36
